Mi-T-M CAW Aluminum Series User manual

Mi-T-M Corporation •50 Mi-T-M Drive, Peosta, IA 52068 •[phone] •www.mitm.com
Mi1924-100319
Pump
- Direct drive triplex piston General pump with ceramic pistons
- Stainless-steel and brass trapping unloader
- Forged brass manifold
- Thermal relief valve
- External quick connect low pressure detergent injector
- Pump accepts incoming water up to 165°F
(175°F on CAW-4004-0ME1)
Motor
- Industrial-duty totally enclosed fan-cooled electric motor
with manual thermal overload protection
- Low speed 1750 RPM
- 4-foot power cord
Frame
- Aluminum base plate and frame
- Aluminum wall mounting brackets
- Aluminum hose and gun/wand holder
CAW Aluminum Series
COLD WATER PRESSURE WASHERS
Designed to attach directly to a wall, this series offers a secure system for use in a wide range of
locations. Featuring non-corrosive aluminum construction, it is perfect for high volume cleaning
and sanitizing jobs and is especially versatile in factories, wash bays and food processing plants.
Electric | Direct Drive | Wall Mount
Components
- Time delay shutdown
- Remote mounted electrical box included, must be mounted
within 3
1⁄2
-feet of unit
Unit Includes:
- Quick connect nozzles - 0°, 15°, 25° and 40°
- 50-foot x
3
⁄ 8 -inch non-marking high pressure hose with quick connects
- Professional-grade insulated trigger gun with safety lock-off
- Adjustable pressure insulated dual lance
Limited Warranties:
- 1 year electric motor
- 7 year General pump
CAW-2004-0ME1
Made in
with Globally Sourced
Components
USA
Decal Part No. : 34-3553 (revised material/adhesive 2-15-17)
Date: 02-10-17
Customer: Mi-T-M
Units: All Mi-T-M labeled products manufactured in the US
Designer: Teresa Gottschalk 563.556.7484 x.231
Artwork at 100%: Yes
Decal size: 2.0625” wide x 1” high
Over laminate: .001 clear laminate
Material/Adhesive: 3.5 mil white vinyl flexible white perm
L344 1 mil 50# liner
Must adhere to polyester and epoxy powder coatings, epoxy paint,
polypropylene, polyethylene and stainless steel
Print on a roll
Colors:
PMS 485 Red
PMS 293 Blue
Black
Colors that do not print: Magenta outline does not print
Art disk file No.: DE6061
Actual size decal proof required
34-3553

Accessories & Options:
Part Number Description Fits Models
851-0338 50-ft. x
3⁄8
-in. non-marking hose - For when you need extra hose for added mobility All models
CX-0078 Remote box - Adds control box, may be mounted away from unit to control on/off All models
CX-0109 Additional remotes (up to 3) - Additional remotes that may be added to the unit after the first remote is installed; requires remote box option CX-0076 All models
CX-0110 460V on 6.0 HP, 3Ø model - When 460V of power is available CAW-2004-0ME3
CX-0111 460V on 8.0 HP, 3Ø model - When 460V of power is available CAW-3004-0ME3
CX-0112 Auto start/stop - When trigger gun is released timer will turn unit off, when trigger gun is pulled, unit will restart All models
Model Number PSI GPM Horsepower/Motor Pump Unloader Plug Type Lance Dimensions (LxWxH)*Ship Wt. Net Wt.
CAW-2004-0ME1 2000 3.9 6.0 HP, 230V, 1Ø, 24.1A General Factory preset NEMA 6-30P Adjustable, dual, 36in. 31x17.25x18in. 248 lb. 188 lb.
CAW-2004-0ME3 2000 3.9 6.0 HP, 230V, 3Ø, 16.4A General Factory preset NEMA L15-20P Adjustable, dual, 36in. 31x17.25x18in. 223 lb. 163 lb.
CAW-3004-0ME1 3000 3.9 8.0 HP, 230V, 1Ø, 34.5A General Factory preset NEMA 6-50P Adjustable, dual, 36in. 31x17.25x18in. 268 lb. 208 lb.
CAW-3004-0ME3 3000 3.9 8.0 HP, 230V, 3Ø, 22.8A General Factory preset NEMA L15-30P Adjustable, dual, 36in. 31x17.25x18in. 253 lb. 193 lb.
CAW-4004-0ME1 4000 4.0 10.0 HP, 230V, 1Ø, 40.8A General Factory preset NEMA 6-50P Adjustable, dual, 48in. 34x18x19in. 368 lb. 293 lb.
Mi-T-M Corporation •50 Mi-T-M Drive, Peosta, IA 52068 •[phone] •www.mitm.com
Mi1924-100319
*Dimensions do not include the mounting brackets.
NEMA L15-20P,
20-amp plug NEMA L15-30P,
30-amp plug
NEMA 6-30P,
30-amp plug
WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov.
CAW Aluminum Series
COLD WATER PRESSURE WASHERS
Electric | Direct Drive | Wall Mount
NEMA 6-50P,
50-amp plug
