Micromax MWMSA6510VRS1 User manual

Understand Your Device
WASHING
COVER
WATER SUPPLY
SELECTOR
OVER FLOW
FILTER
WATER LEVEL
SELECTOR
CONTROL
SPIN DRYER
COVER
SPIN MID
COVER
SPIN DRYER
BASKET
ROTATION
FILTER-C
CABINET
PULSATOR
POWER CORD

Button Functionalities
WaterInlet
Buzzer
35
Off Normal
5
10
Wash Rinse
Gentle Strong Drain
15
Off
Buzzer
Water Inlet Water Inlet
Water Supply Inlet
Connect here with the inlet hose from the water tap to
feed water to the tub.
Water Selector
Select "WASH" to supply water for washing and rinsing and
"SPIN" for spin shower rinse or connect the inlet pipe to supply
water in "WASH" and "SPIN" individually.
Wash Timer
Select the desired time for soaking, washing or rinsing.
Normal
Gentle
Strong
Off
5
35
10
15
5
1
4
2
3
Off
5
1
4
2
3

Wash Selector
Settheprogramto"Gentle","Normal",and"Strong"accordingto
thekindsandquantity ofthelaundry.
*"Gentle"modeisnotavailableinMWMSA651OVRS1model.
Drain Selector
Select"Wash-Rinse"forwashingandrinsingand"Drain"todrain
thewateroutofthetub.
*"Drain"modeisavailableinWashSelectorin
MWMSA651OVRS1model.
SpinTimer
Selectthedesiredtimeforspinning.Themaximumlimitis5mins.
Don'trotatethe knobmorethantheprescribedlimit.
Note:Graphicsmaydifferfromtheactualmachine.
AccessoriesInside:
1.SpinDryerSafetyCover–1No.
2.WaterInletPipe–1No.
3.DrainPipe(Somemodelsalreadyfit)–1No.
4.UserManualwithWarrantyCard–1No.

Machine Care
•Install the washing machine on a horizontal surface,
otherwise it may cause vibration and noise.
•Be sure to disconnect the power cord from the electric outlet
before starting care and maintenance. It may cause electric
shock.
•Be sure to earth the motors to prevent electric shock. To
reduce the risk of electric shock, do not install the machine
in humid spaces.
•Do not use volatile materials such as Benzene,
Gasoline, and bug killer on/near the washing machine.
•Do not leave strong alkaline substance such as bleach
inside the tub. Damage on plastic surface and rubber parts
may occur.
Power Cord Care
•If the power supply cord is damaged, it must only be replaced
by the agent or a similarly manufacturer, service qualified
person in order to avoid a hazard.
•Do not treat the power supply cord with wet hands. It may
cause electric shock.
•Avoid connecting several electric devices to a single outlet.
It may cause fire.

Preparation before Wash
1. Check the washing instruction labels on the clothing
to be washed.
2. Remove all objects from the pockets of the clothing.
Objects like keys, toothpicks, coins, screws, pins, sand, etc.
may damage clothing or break the washing machine
(Could cause the drain hose to clog).
3. Separate oiled and dyed clothing before washing.
4. Set the Drain Hose for drainage.
5. Plug the power supply plug into a three-pin power outlet
with reliable grounded wire. Do not attempt to change the
three-pin plug to a two-pin plug as the machine needs to
be grounded.
6. Insert the Water Inlet Hose into the 'Wash' Water Inlet at the
Control panel.
7. Add clothes one by one. Remove hooks, pins and pull up all
zips. If the hooks cannot be removed tie all of them up in one
garment.
Washing Procedure
Washing
1. Place the water level in the desired position.
2. Add in water and dissolved detergent.
3. Allow the water to reach the expected level.
4. Operate the machine to stir the detergent evenly by turning
the Wash Knob.
5. Put in laundry.
6. Select wash duration according to the laundry weight.
7. Select wash type (Gentle*/Normal/Strong) according to the
laundry weight.
8. After each wash, set the Program Selector to Drain.
*("Gentle" mode is not available in MWMSA651OVRS1 model.)

Intermediate - Spin (To Rinse/Dry)
1. Remove the laundry from the Wash Tub and put into the
Spin Tub to remove dissolved detergent.
2. Arrange laundry uniformly in the Spin Tub without stacking
lopsidedly. An unbalanced Spin Tub may cause abnormal
vibration and noise.
3. Press the laundry down firmly and place the Safety Cover
over them.
4. To rinse, close the Spin Tub outer cover and allow to spin
for 1 minute.
Soak-Rinse
1. Place the laundry into the Wash Tub and select suitable
wash type.
2. Select the water level (Choose the water level according to
the laundry quantity).
3. Rinse: Set the timer between 0-5 minutes to rinse.
Dry-Spin
1. Arrange laundry uniformly in the Spin Tub without stacking
lopsidedly.
2. Press the laundry down firmly and place the Safety Cover
over them.
3. Select suitable spin duration according to the laundry
quantity. (Example: 1 minute, 3 minutes or 5 minutes)
Notes: An unbalanced Spin Tub may cause abnormal vibration
or noise. If such an incident both the Spin occurs, open Tub
Inner and Outer Covers and rearrange the laundry. Then,
continue the spin operation again.

Spin Guide
Spin Time (min)
Type of Fabric
2–3
Synthetics, silk, woolen,
knits, cotton, linen
3–5
Very Soiled, Cotton and linen
*Amount of laundry is based on dry laundry.
*Detergent amount is based on a general synthetic detergent.
CAUTION: Fill in the wash tub to a height of 20mm above the
level you desire.
When washing starts water level will automatically come to the
level you desire.

Specifications
Model No.
MWMSA6510VRS1
MWMSA725TVRS1
MWMSA755TVRS1
MWMSA825TVRS1
MWMSA855TVRS1
Maximum Rated
6.5
7.2
7.5
8.2
8.5
Input Main Power
230V~50Hz
230V~50Hz
230V~50Hz
230V~50Hz
230V~50Hz
Washer Power
360W
380W
380W
420W
420W
Spinner Power
160W
160W
160W
160W
160W
Unit Size
780×420×870 (ex.
Drain Hose)
805×475×935
805×475×960
805×475×995
805×475×1040
Packed Size
820×450×930
845×535×1000
845×535×1030
820×520×1070
820×520×1100
Net Weight
20Kg
22Kg
22.5Kg
23Kg
24Kg
Gross Weight
23Kg
26Kg
26.5Kg
27Kg
29Kg
Water Capacity
42L
43L
43L
43L
43L
Water Capacity
63L
66L (Over Flow 70L)
66L (Over Flow 70L)
66L(Over Flow 70L)
66L (Over Flow 70 L)
Probability
Castor Wheels
Castor Wheels
Castor Wheels
Castor Wheels
Castor Wheels
Alarm/Buzzer
Buzzer
Buzzer
Buzzer
Buzzer
Buzzer
Wash Timer
35min
35 min
35 min
35 min
35 min
Soak time
20min
20 min
20 min
20 min
20 min
Spin time
5 min
5 min
5 min
5 min
5 min
Power cord &
Plug Top
3 core 3 Pin 5A
250V AC, IS STD
3 core 3 PIN 5S
250 VAC, IS STD
3 core 3 PIN 5A,
250VAC, IS STD
3 core 3 PIN 5A
250 VAC, IS STD
3 core 3 PIN 5A
250VAC, IS STD
Pulsate type
Static Bumps
Dynamic Bumps
Dynamic Bumps
Dynamic Bumps
Dynamic Bumps

Troubleshooting*
Before you call for a technician or send the machine for repair,
please check from mentioned possible causes:
Phenomena
Possible Causes
The machine does not work
•Has there been a power
cut?
•Is the power supply cord
connected to a power outlet?
•Is the Pulsator tangled
With something?
Unable to drain
•Has the Drain Hose
been lowered?
•Is the Drain Hose kinked?
•Is the Drain Hose blocked
•Are there any clothes
dangling on the Spin
Tub?
Abnormal sound during wash
Are there any loose
articles in the Wash Tub?
Reduced water in the Wash Tub
Are the Overflow Filter
Bellows correctly Installed?
There is abnormal sound and
violent vibration during spin
•Is the machine being placed
on a flat and solid ground?
•Has the Safety Cover been
put into the Spin Tub?
•Are there any clothes
dangling on the Spin Tub?
•Are there too many laundry
in the Spin Tub?

WASH
TIMER
BUZZER
SPIN
TIMER
BR
BR
CAPACITOR
RD
YL
OR
WH
WASH
MOTOR
SPIN
MOTOR
BK
GR
(YL/GR)
BL
GR
(YL/GR)
230V/50Hz
GR (YL/GR)
CONNECTOR POINT
RD =RED, OR =ORANGE, BL =BLUE, GY =GRAY, YL =YELLOW, BR =BROWN,
WH =WHITE, BK =BLACK, YL/GR =YELLOW/GREEN, PK =PINK
Wiring Diagram
OR
SAFETYSWITCH
GY
CONNECTORPOINT
RD
YL
YL
BL
RD
RD
PK
BL
OR
GY

*Do not attempt to repair the machine by yourself. Please
contact the authorized service center after checking the above
mentioned causes.
Maintenance
•Please unplug the power supply cord before cleaning the
machine.
•Clean the machine with a soft damp cloth.
•Do not spray water directly onto the machine.
•If the machine is too dirty, use neutral detergent to clean.
•Do not use petroleum-based detergent to clean the machine.
It will spoil its appearance.
•With frequent use, lint will be left behind in the Overflow
Filter and leaves deposits on clothes. To prevent this from
Happening, Lint filters must be cleaned frequently,
preferably at least once every 2 months, to maintain the
machine's peak performance.
Safety Precautions
•Avoid area exposed to snow, rain, or where humidity is high.
It may cause electric shock.
•Protect the switch area from water as it may cause
electric shock or fire.
•Avoid electric heater, candle light, cigarette light, bug smoker,
etc. near the machine. It may ignite or deform plastic part.
•Avoid using hot water > 50'C. It may deform plastic parts or
cause malfunction.
•Do not insert your hand inside the spin dryer basket while the
machine is in operation (Do not let children climb on the
machine or climb into the tub. Injury may occur).
•Do not drain the water out of the wash tub while the spin
dryer basket is in operation. Otherwise, the spin motor could
be damaged.

•Incorrect installation may cause severe noise and break
down.
•Set the machine on a flat and firm floor.
•A carpet must not obstruct the ventilation openings.
•Maintain a gap of more than 10 cm between the drain hose
and the wall.
Note: This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by
person(s) responsible for their safety. Children should be supervised
to ensure that they do not play with the appliance.
Taking Care of Your Device
Your device is a product of superior design and craftsmanship and
should be handled with care. The following suggestions will help
you protect your device:
•Keep children away from the machine.
•Keep machine away from heat-generating equipment.
Keep it away from direct sunlight.
•Do not put heavy or hot things on top of the machine.
•Do not wash laundry soaked with Petrol or organic solvents.
•Do not share one power outlet with other electrical
appliances. Keep the plug strip clean.
•Never put hands into the tub while it is operating.
•Do not place the machine in the bathroom. Such action may
damage the electrical insulation and cause body rust.
•Do not wash waterproof clothes such as raincoat. Abnormal
vibration may occur in the spin tub.
•In case the plug of the power supply cord is damaged, user
should not attempt to fix it without electrical knowledge. Please
call on authorized service center.
•The device must be repaired by Micromax authorized personnel
only. Repairing this device by yourself other than our authorized
service agents/centers goes against the warranty rules.
