mikroElektronika Click User manual

2 3
click™
BOARD
www.mikroe.com
2. Soldering the headers
3. Plugging the board in
Once you have soldered the headers your
board is ready to be placed into the desired
mikroBUS™socket. Make sure to align the
cut in the lower-right part of the board with
the markings on the silkscreen at the
mikroBUS™socket. If all the
pins are aligned correctly,
push the board all the way
into the socket.
Turn the board upward again. Make sure
to align the headers so that they are
perpendicular to the board, then solder the
pins carefully.
Turn the board upside down so that
the bottom side is facing you upwards.
Place shorter pins of the header into the
appropriate soldering pads.
Before using your click™board, make sure
to solder 1x8 male headers to both left and
right side of the board. Two 1x8 male headers
are included with the board in the package.
4. Essential features
GNSS click™shares the same form factor of
Quectel’s L80 module which (used on GPS3
click™) and the same set of technologies:
automatic prediction of orbits from data stored
in internal ash (EASY™technology); and
adaptive adjusting of on/o time to balance
between positioning accuracy and power
consumption (AlwaysLocate™technology).
The module can also automatically switch
between the internal patch antenna and
external active antenna, keeping track of
positioning during the switching process.
1
GNSS click™carries Quectel’s L86 GNSS
module with a patch antenna along with an
external antenna connector. GNSS stands
for global navigation satellite system, a
term which encompasses both the United
States GPS and the Russian GLONASS
global positioning systems. The board
communicates with the target MCU through
mikroBUS™UART (TX, RX), CS (used here for
FON), and RST pins. The board uses a 3.3V
power supply only. A V_BAT connection pad
for a backup power supply is also available.
GNSS click™
1. Introduction
GNSS click™manual
ver 1.00
0100000074855

Quectel
L86
Quectel
L86
AN
RST
CS
SCK
MOSI
MISO
+3.3V
GND
PWM
INT
RX
TX
SCL
SDA
+5V
GND
MIKROBUS DEVICE CONN.
GND GND
E1
10uF
C1
100nF
GND
C2
100nF
E2
10uF
GND
VCC-3V3
GND
GND
LD1
R1
2K2
VCC-3V3 VCC-3V3
R2
3K3
GND
GND
LD2
CN1
P$1
P$2
SIGNAL
P$3
CN2 GND
VCC-3V3
R3
3K3
LD3
GND
R1
R2
Q2
PDTC114EU
R1
R2
Q1
PDTC114EU
VCC-3V3 RESET
TX
RX
GND
AADET
RESET
EXT_ANT
AADET
EXT_ANT
V_BCKP
PPS
PPS
V_BCKP
TX
RX
7
8
9
10
11
12 1
4
2
5
3
61PPSFORCE_ON
AADET_N
NC
RESET
EX_ANT
GND
V_BCKP
TXD1
VCC
RXD1
GND
U1
L86-M33
GND
VCC-3V3
VCC-3V3
VCC-3V3
J2
GND
FORCE_ON
R4
10K
VCC-3V3
R5
0R
FORCE_ON
8. Code examples
MikroElektronika oers free tech support
(www.mikroe.com/support) until the end of
the product’s lifetime, so if something goes
wrong, we’re ready and willing to help!
Once you have done all the necessary
preparations, it’s time to get your click™board
up and running. We have provided examples
for mikroC™, mikroBasic™and mikroPascal™
compilers on our Libstock website. Just
download them and you are ready to start.
.com
6. Dimensions
MikroElektronika assumes no responsibility
or liability for any errors or inaccuracies
that may appear in the present document.
Specication and information contained in
the present schematic are subject to change
at any time without notice.
Copyright © 2015 MikroElektronika.
All rights reserved.
mm mils
LENGTH 42.9 1690
WIDTH 25.4 1000
HEIGHT* 8.6 388.6
5. Schematic
9. Support
25.4 mm / 1000 mils
42.9 mm / 1690 mils
* without headers
10. Disclaimer
GNSS click™has a connector for an external
active antenna that could be used alongside,
or instead of the patch antenna that’s
already on the module. To get one, search for
“GPS antenna” at www.mikroe.com/store
7. External antenna connector
