MINIS80
TOP LOADING FULLY AUTOMATIC
WASHING MACHINE
INSTRUCTION MANUAL
Before using your washing machine ,
please read this manual carefully and
keep it for future reference
Before using your washing machine ,
please remove the packing box and all
other protection foam

正1
inlet
Part Name
Waterinlet hose
connector (1pc) powder spoon drain hose
rat board Safety cover + Hinge water inlet hose
Top cover
safety cover
wash tub
top frame
Body
power line outlet
parts

正2
Insert the water inlet pipe into
the water inlet valve, to the end
Insert the water inlet pipe into the water inlet valve,
to the end .
Installation of the washer
Installation of the water inlet hose ( one washer )
locking bar
waterinlet pipe
connnector
slider
Push down the slider , insert the waterinlet
pipe into the joint and push it upward ,
Hang the locking bar on the inlet pipe joint,
put down the slider and make the sound of
"crack"
Note:When using one washing machine, it is
forbidden to use the following three-way water inlet
and three-way water outlet
Two washing machines use one faucet
single water
pipe connector
three -way
water inlet
two water
pipe connector
Loosen the single water pipe connector,insert the three-way water inlet and
tighten .
Push down the slider , insert two water inlet pipes into the corresponding two
water inlet pipe connnectors
Water inlet pipe connect with the washing mahcine
After inserting , gently pull the water pipe outward
to ensure that the pipe is inserted in place.
Please use the new water inet pipe in the
attachments, Old water inlet pipe can not be reused

正3
Installation of the washe
Installation of drain hose
Install the drain hose into the drain hose connetor of the back of the washing
machine, and then place the drain hose orifice into the down drain orifice.
Drain hose should drain smoothly
The drain hose must be no higher than
2cm from the ground level . or it will cause
abnormal draining
Please do not tread on or squeeze the
drain hose
When the drain hose needs to be
lengthened, the appropriate drain
hose can be purchased separately.
The length of the drain hose should
not exceed 1.5 meters
When the drain hose does not need to be
too long, it can be removed from the
middle part. In order to drain smoothly,
the front section of the drain hose can be
obliquely cut.
When the lengthened drain hose is too
long, the drain hose can be removed
from the proper position.
Installation of three-way outlet Connect the drain hoses of two washing machines
to the drain hose joints respectively, and then insert the rubber three -way drain
port into the floor drain.

反1
≤1º
Installation of waterproof board
Installation of the washer
In order to use the washing machine correctly and safely, please install and
adjust the washing machine according to the instructions.
Remove the packaging
Remove the pack box ,take out the bottom
board of the cabinet
Open the lid of washer , take out accessories
Remove all other shipping material
bottom foam
Horizontal adjustmen
The washing machine is more than 50mm away from the wall, and the maximum
allowable inclination angle of the supporting surface is 1 degree. Inclination or
unevenness of the ground will cause unstable operation or sudden stop during
the washing machine working .Please use the following method to adjust
Horizontal determination
Hang the suspension rope with a heavy
hammer to confirm the of the horizontal
washing machine
Tilt the washing machine forward and insert the
bottom plate into the socket of the base.
Install the rat proof board on the base of washing
machine with cross screwdriver(two screws in the
attachment )

反2
Press this button to select the
program.
Normal /Speedy /Underwear/Spin/
ocks/Underpants/Self-cleaning
Use this button to select different
temperatures in the program
40 degree warm water washing
Suitable for washing small
pieces of clothing with
conventional materials
Normal temperature washing
Suitable for washing slight dirt,
sweat stains, etc.
90 degree high water temperature
washing
Cleaning and killing bacteria in tub
self-cleaning program
Selection of Water Temperature
at 60 and 90 Degrees
Suitable for washing underpants,
90 degree water temperature
boiling washing to kill germs
Underwear Program
underpants program
Water Temperature Selection
at 35 and 60 Degrees
Suitable for washing
underwear, bras, etc
Speedy program
Normal Program
socks program
Selection of Water Temperature
at 60 and 90 Degrees
Suitable for washing socks, 90
degree water temperature boiling
washing to kill germs
When the power supply is on, it will
automatically return to the power
supply disconnection after 10 minutes.
Switch on the power and start
running the washing machine
temperature
control
Spin
Underwear
Speedy
Normal
Self-cleaning
Underpants
Socks
Spin Program
Suitable for spinning
Program button
Power
Start Pause button
Temperature Selection
Button
Instructions
Program
Power
Start Pause
button
Press this button to pause while
running and press it again to
continue running

反3
Touch the program button, select the required program in turn, light
up the selected program, and display the washing temperature by
the digital tube when selecting the program 5 seconds later show
the remaining time of the program.
Bactericidal effect
Boiling wash clothes also have bactericidal effect. Boiling wash clothes can
remove the odor of clothes and most bacteria causing skin allergies, and ensure
that your clothes are always fresh and clean.
Bleaching effect
Because boiling washing clothes can even remove stubborn stains, the colour of
clothes will be brighter.
Cleaning effect
Because the cleaning effect of the boiling washing program is more than
60% higher than that of the ordinary program, the cleaning effect of the
boiling washing is still 20% higher even if only half of the detergent is added,
so the boiling washing program is one of the best washing methods.
Instructions
Touch the temperature button to select the temperature of the
current program. The digital tube shows the washing temperature
and the remaining time after 5 seconds.
Temperature
Program

Automatic power-off function：
After 10 minutes of startup, the program does not start, the power supply is automatically cut off,
the washing program is finished, and the power supply is automatically cut off by the washing machine.
Automatically alarm for 1 hour without handling, automatically cut off the power supply
Troubleshooting
Troubleshooting
Enter water
failure
Have not open the tap , stop water ,
low water pressure , water have
not reach the set water level after
20 minutes
Open the tap . Clean the netting according
to the method of “Cleaning the water inlet “
Drain failure
The drain hose is placed too high
or have not lay down the drian hose .
The drain hose is wrung or jammed
Check the drain hose , lay the drain hose
lowly . Press “Start/Pause ”button after
checking .Open the machine cover and
close the machine cover for alarm free
Open abnormal
Safety lid is open
Closed the lid
Water level up
on the highest
safety water level
PCB can Auto-precess
Sensor of water
lever abnormal
Please ask professional person to check
Stage frequency less than high
water level limit or exceed than
low water level limit , will shows
sensor of water lever error alarm
Pause abnormal
Pause time exceed 10 minutes
Please press the “Start” button
Temperature
sensor abnormality
Short Circuit of Temperature Sensor
Return to normal or switch to normal
temperature water automatically
water temperature
above the maximum
water temperature set
Water temperature above 93 degrees
To be cooled by water temperature or
automatically switch to high temperature
washing or shutdown
Abnormal heating
tube
Continuous heating for 30 minutes,
temperature rise less than 2 degrees
Automatically switch to high water
temperature program or shut down
Abnormal door
lock
Continuous action, or can not be
locked, can not be opened
Restart
Abnormal
communication
Poor contact between display panel
and drive panel
Ask professional maintenance personnel
to check whether the wiring is loose or not.
Note: After checking the above points, there are still abnormalities. Please unplug
the power plug and contact the distributor as soon as possible.
symptom cause relief

435*310*330mm
MINIS80
5.0L
0.8
8
15kg
1
SPECIFICATIONS
MODEL NO
Rated voltage /
Frequency
Rated wash /
spin capacity
Water level water
volume (about)
Influent water pressure
Rated input power Heating tube power
net weight
dimension
110V
60Hz
