MINIMOTO
™
ATV
MINIMOTO
™
ATV
MINIMOTO™ ATV
Owner’s manual and safety instructions
Read this manual completely and carefully
before operating your electric MINIMOTO™
ATV. Keep this manual in a safe place for
future reference. Be sure you thoroughly
understand how to operate the compo-
nents of your MINIMOTO™ ATV.
NOTE: Throughout this manual there
are many “WARNINGS”. Be sure to
read and understand all of these “WARN-
INGS”. Please payextremely close atten-
tion to these areas as serious injury or
even death may result in failing to do so.
WARNING: This vehicle is a seri-
ous machine and should be treat-
ed with respect when riding it,
working on it, or simply being
near it.
This vehicle can obtain speeds that only
qualified riders of the proper age, size,
and maturity should attempt. That deci-
sion rests entirely on the observation and
discretion of the direct supervising adult.
IMPORTANT!!! Before we begin:
Like any wheeled vehicle, riding the MINI-
MOTO™ ATV can be extremely hazardous.
It is your responsibility to follow this manu-
al for the proper set up, inspection, riding
procedure, protective gear required, and
rules of the road to reduce the risk of seri-
ous injury.
The age recommendation is only an esti-
mate. If the rider is too small, too large,
or too old to comfortably fit on the MINI-
MOTO™ ATV, he/she should not attempt to
ride it. The minimoto™ ATV is not
designed for or intended to be used byof
anyone under the age of 10.
Keep away from small children.
2
FOR WEBSITE INFORMATION
OR REGISTRATION AND CUSTOMER
SERVICE GO TO
www.teamminimoto.com

MINIMOTO
™
ATV
WARNINGS:
This product is meant for outdoor use only
and only on private property. Never ride
your MINIMOTO™ ATV on public streets,
alleys, or other public roads or through-
fares. It must never be ridden in any area
that could potentially do harm to humans,
animals, or property damage.
Never ride around the vicinity of small chil-
dren who may enter your path.
Special notes for supervising adults of
the rider:
1) The decision to allow a rider to ride the
MINIMOTO™ ATV must be done with the
permission of a directly supervising adult.
The directly supervising adult must read
and follow all of the contents of the owners
manual before making this decision.
2) The rider must have previous experience
in riding electric powered vehicles before
attempting to ride the MINIMOTO™ ATV. It
is the responsibility of the supervising adult
to ensure the rider has the specific talent,
physical ability, and training before allowing
them to attempt to ride the ATV.
3) The MINIMOTO™ ATV is never to be rid-
den indoors. Indoor flooring and carpets
can be damaged from abrasive contact with
the tires. The manufacturer will not be
responsible for anyindoor damage if the
MINIMOTO™ ATV is used in this manner.
4) The MINIMOTO™ ATV is designed to run
on off-road surfaces. Grass, packed dirt,
and moderate off-road terrain are ideal rid-
ing surfaces by persons over the age of 10.
5) The rider of a MINIMOTO™ ATV should
always wear appropriate footwear. Open-
toed shoes should never be allowed. Keep
shoe laces and pant legs away and clear of
the wheels.
6) The rider must wear a safety helmet,
elbow and kneepads to avoid injury if
falling. Failure to wear a standard
approved helmet may result in serious per-
sonal injury or death.
7) The MINIMOTO™ ATV is never to be rid-
den by more than one person at a time. In
addition, it is not designed to pull or tow
anything behind it as it may result in serious
damage to the motor or internal parts. Do
not exceed the maximum capacity of 200
lbs (90 kg).
8) The MINIMOTO™ ATV cannot be used on
wet surfaces or in wet weather. Never
immerse anypartof the MINIMOTO™ ATV in
water. Moisture can damage the motor,
switches, and drive components.
9) The MINIMOTO™ ATV should never be
ridden in mud, water, ice, snow or sand. It is
not designed to be ridden in streets or on
paved surfaces either. Avoid riding on
extreme incline, declines, rocky surfaces,
curbs or jumps.
10) The electric motor can become hot
when in use. Do not touch it at anytime and
handle it carefully.
11) Never use your MINIMOTO™ ATV while
using personal radios or headphones.
12) Do not use your MINIMOTO™ ATV for
stunt riding, ramp jumping, acrobatics or
similar activities.
3
