Mitsubishi LVP-XD10U User manual

English I
Data Projector
MODEL
LVP-XD10U
LVP-SD10U
OPERATING GUIDE
Thank you very much for purchasing this DLP™ Technology Projector.
Please read this operating guide to ensure a correct use of the device. After reading
this manual, keep it for future reference.
1. High brightness
2. High resolution
3. Compact size, light weight for portability
4. RGB input Terminal
5. Mouse Function
6. Mouse Emulation
7. Complies with VESA DDC1/2B specifications
Outline
This DLP™ Technology Projector can display
various computer signals and NTSC/PAL/
SECAM video signals.
Features

II English
COPYRIGHT
Copyright © 2001 by this company. All rights reserved. No part of this publication may be reproduced,
transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in
any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without
the prior written permission of this company.
DISCLAIMER
This company makes no representations or warranties, either expressed or implied, with respect to the
contents hereof and specifically disclaims any warranties, merchantability or fitness for any particular purpose.
Further, this company reserves the right to revise this publication and to make changes from time to time in the
contents hereof without obligation of this company to notify any person of such revision or changes.
WARNING
Use the attached specified power supply cord. If you use another power-supply cord, it may cause interference
with radio and television reception.
Use the attached VGA cable or serial mouse cable with this equipment so as to keep interference within the
limit of a FCC Class B device.
This apparatus must be grounded.
COMPLIANCE NOTICE
This Data Projector complies with the requirements of the EC Directive 89/336/EEC "EMC Directive" as
amended by Directive 93/68/EEC and 73/23/EEC "Low Voltage Directive" as amended by Directive 93/68/
EEC.
The electro-magnetic susceptibility has been chosen at a level that gains proper operation in residential areas,
on business and light industrial premises and on small-scale enterprises, inside as well as outside of the
buildings. All places of operation are characterized by their connection to the public low voltage power supply
system.
CAUTION
TO PREVENT SHOCK, DO NOT OPEN THE CABINET. NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. AND PLEASE READ ALL
OF THESE INSTRUCTIONS BEFORE YOU OPERATE YOUR PROJECTOR. SAVE THESE
INSTRUCTIONS FOR FUTURE REFERENCE .
zFor PLUGGABLE EQUIPMENT. The socket-outlet shall be installed near the equipment and shall be
accessible.
zDo not stand the projector. It may fall and cause serious injury and damage to the projector.
WARNING
USE THE ATTACHED VGA CABLE OR SERIAL MOUSE CABLE WITH THIS EQUIPMENT SO AS TO
KEEP INTERFERENCE WITHIN THE LIMITS OF A EN55022 CLASS B AND EN55013. PLEASE
FOLLOW WARNINGS INSTRUCTIONS.
WARNING
TO PREVENT FIRE OR SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE, DO NOT USE
THIS UNITS GROUNDED PLUG WITH AN EXTENSION CORE OR IN AN OUTLET UNLESS ALL THREE
PRONGS CAN BE FULLY INSERTED.

English III
SAFETY INSTRUCTIONS
1. Read all of these instructions before you operate your projector and save them for future reference.
2. The lamp becomes extremely hot during operation. Allow the projector to cool for approximately 45
minutes prior to removing the lamp assembly for replacement. Do not operate the lamps beyond the rated
lamp life. Excessive operation of the lamps beyond the rated life could cause them to explode on rare
occasions.
3. Power is still available when the projector is in the standby mode. Never replace the lamp assembly or
any electronic components unless the projector is unplugged.
4. Do not attempt to service this product yourself, as opening or removing the covers may damage the
components inside and will void your warranty.
5. Do not place this product on an unstable cart, stand, or table. The product may fall, causing serious
damage to the product.
6. The Standard Remote Control contains a low-power laser that acts as a pointing device during
presentations. The light beam may cause injury if pointed directly into a person's eyes.
7. This product is capable of displaying inverted images for ceiling mount configurations. Please use suitable
equipment for mounting the unit and make sure it is securely installed.
8. Openings in the front or at the two sides are for ventilation. They must not be blocked or covered.
9. For ventilation reasons, the fan continues to operate for about 1 minute after the projector has been
powered off. Please do not unplug the power cord until the fan stops.
10. Do not look straight at the projector lens during operation. The intense light beam may injure your eyes.
COMPLIANCE NOTICE OF FCC
NOTE : THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A
CLASS B DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE
DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE IN A
RESIDENTIAL INSTALLATION. THIS EQUIPMENT GENERATES, USES AND CAN RADIATE RADIO
FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN ACCORDANCE WITH THE
INSTRUCTIONS, MAY CAUSE HARMFUL INTERFERENCE TO RADIO COMMUNICATIONS. HOWEVER,
THERE IS NO GUARANTEE THAT INTERFERENCE WILL NOT OCCUR IN A PARTICULAR
INSTALLATION. IF THIS EQUIPMENT DOES CAUSE HARMFUL INTERFERENCE TO RADIO OR
TELEVISION RECEPTION, WHICH CAN BE DETERMINED BY TURNING THE EQUIPMENT OFF AND ON,
THE USER IS ENCOURAGED TO TRY TO CORRECT THE INTERFERENCE BY ONE OR MORE OF THE
FOLLOWING MEASURES :
zREORIENT OR RELOCATE THE RECEIVING ANTENNA.
zINCREASE THE SEPARATION BETWEEN THE EQUIPMENT AND RECEIVER.
zCONNECT THE EQUIPMENT INTO AN OUTLET ON A CIRCUIT DIFFERENT FROM THAT TO WHICH
THE RECEIVER IS CONNECTED.
zCONSULT THE DEALER OR AN EXPERIENCED RADIO/TV TECHNICIAN FOR HELP.
Changes or modifications not expressly approved by Mitsubishi could void the user's authority to operate this
equipment.
COMPLIANCE NOTICE OF INDUSTRY CANADA
This Class B digital apparatus complies with Canadian ICES-003.

IV English
Table of Contents
Introduction .......................................................................................................................................... 1
Projector Features............................................................................................................................. 1
Description ........................................................................................................................................ 2
A FRONT (FIGURE) ..................................................................................................................... 2
BREAR(
FIGURE)........................................................................................................................ 2
C BOTTOM (FIGURE) .................................................................................................................. 3
Installation ......................................................................................................................................... 3
AP
OSITIONING............................................................................................................................. 3
BA
DJUSTABLE FEET .................................................................................................................... 4
Moving the Projector ......................................................................................................................... 4
Accessories....................................................................................................................................... 5
Connection ........................................................................................................................................... 6
AC
ONNECTING THE PROJECTOR TO COMPUTER/NOTEBOOK ......................................................... 6
Operation .............................................................................................................................................. 7
Turn On/Off Procedure...................................................................................................................... 7
AP
OWER ON ............................................................................................................................... 7
BS
TANDBY .................................................................................................................................. 7
External Control ................................................................................................................................ 7
A CONTROL PAD .......................................................................................................................... 7
B REMOTE CONTROL ................................................................................................................... 9
INSERTING BATTERIES IN THE REMOTE CONTROL.......................................................................... 10
Usage and Replacement of Lamp................................................................................................... 11
AL
AMP/TEMPERATURE STATUS LED INDICATOR ......................................................................... 11
BR
EPLACING THE LAMP ............................................................................................................. 13
OSD ................................................................................................................................................ 15
AD
ISPLAY PAGE ........................................................................................................................ 16
B IMAGE PAGE ........................................................................................................................... 17
CC
ONTROL PAGE ...................................................................................................................... 18
DS
OURCE PAGE ....................................................................................................................... 19
Other Correspondent Remote Functions and Messages................................................................ 20
Maintenance and Troubleshooting................................................................................................... 21
AL
AMP REPLACEMENT............................................................................................................... 21
BC
LEANING THE LENS ............................................................................................................... 21
CT
ROUBLESHOOTING ................................................................................................................ 22
Specifications..................................................................................................................................... 23
AO
PTICAL ................................................................................................................................. 23
BE
LECTRICAL............................................................................................................................ 23
CM
ECHANICAL .......................................................................................................................... 23
DP
RESET DISPLAY RESOLUTION TABLE...................................................................................... 23
APPENDIX .................................................................................................................................... 24
FEATURES AND CONNECTION ....................................................................................................... 24

English 1
Introduction
Projector Features
A Image Resolution
Fully compatible with true SVGA (LVP-SD10U)/XGA (LVP-XD10U) and supports SXGA
using advanced intelligent compression technology. The advanced intelligent compression
technology enables it to present clear compression SVGA/XGA images without line
omission.
B Brightness
Provides superior brightness using TI's Digital Micromirror Device (DMD) and our own
optical design, with a geometric effect that increases light usage efficiency. By increasing
the light usage efficiency we can better reproduce the three basic colors (RGB) required for
color reproduction on a single DMD.
C Portability
This projector has a sophisticated shape, like that of an attached case, with a retractable
carrying handle that is extremely compact and lightweight. It helps you make powerful
presentations wherever you go with its 5-pound weight and B5 size.
D Keystone
The projection position is already set to the height of the line of vision; there is no keystone
effect. Even when projecting above or under the height of the line of vision, image distortion
(if any) can be adjusted using the hotkey "KEYSTONE" correction function.
E Multilanguage
The OSD (On Screen Display: information screens and menus) in 7 languages (English,
French, Dutch, Italian, German, Spanish and Simplified Chinese.) provides you with
additional information to help you make corrections with OSD operation in your native
languages.
F Auto Detect System
This projector can detect display signals from PCs with frequently used timing automatically,
or use the hotkey "AUTO" to do the optimization simultaneously. It does not require
complicated adjustments in order to project picture images from PCs.
G Ceiling Mount and Rear Screen Projection
The projector is equipped with a full mirror scan conversion function (vertical/horizontal
mirror), which allows the image to be reversed for ceiling mounting as well as for rear
projection applications.
1

2English
H AV box (Model name: VA-10U)
An AV box is optional, and users can attach one or two to the projector. Additionally, our AV
box video standard is compatible with:
If users want to watch CATV, an AV box will serve the need.
Description
A FRONT (figure)
Figure 1 Front view
B REAR (figure)
Figure 2 Rear view
NTSC U.S. and Canada standard
PAL Western Europe standard
SECAM France and Eastern Europe standard
NTSC4.43 Middle East standard
Ventilation
Hole
PROJECTION
LENS
COMPUTER IINPUT
D-SUB 15 PIN
AV BOX
CONNECTOR
CONTROL PAD
AC INLET
CONTROL PORT
(FOR MOUSE)

English 3
C BOTTOM (figure)
Figure 3 Bottom view
Installation
A Positioning
zThis projector is basically designed to project on a flat projection surface. It can
focus from 1.5m-12m and adjust the screen size like figure below.
Figure 4 Positioning
LAMP COVER
ADJUSTABLE FEET

4English
B Adjustable Feet
Picture tilt and projection angle can be adjusted by twisting Adjustable Feet. Projection
angle can be adjusted 2° to 8.5° degrees by rotating the front/center foot. The projector is
also equipped with left adjustable foot.
Figure 5 Adjustable feet (left/ right/ middle)
Moving the Projector
Use the carrying handle when moving the projector.
Replace the lens cover and rotate the feet fully clockwise (to shorten the feet) when moving
the projector to prevent damage to the projector.
Figure 6 Moving the projector
Caution
CautionCaution
Caution
The carrier bag (supplied) is intended to protect the projector from dust and scratches
on the surface of the cabinet. It is not designed to protect the projector from external
shock.
Do not transport the projector in an unsuitable transport case by using a courier or
transport service. This may cause damage to the projector.

English 5
Accessories
Please check and make sure your box contains everything listed below. If any pieces are
missing, contact your dealer.
Figure 7 Accessories
PROJECTION
LENS
VENTILATION
HOLE
CARRIERBAG
MANUAL
REMOTE CONTROL
Q
UICK
S
TART
C
ARD
POWER CONNECTOR
(2 PIN TO 3 PIN)
AAA BATTERIES
VGA CABLE
(P/N.: 246D016-10)
PS/2 MOUSE ADAPTER
(P/N.: 246D016-20)
SERIAL MOUSE ADAPTER
(P/N.: 246D016-30)
GENERAL CABLE
(P/N.: 246D096-40)
RCA CABLE
(AUDIO/VIDEO)
(ATTACHED TO VA-10U)
(P/N.: 246D016-50)
AUDIO CABLE
(ATTACHED TO VA-10U)
(P/N.: 246D016-60)
S-VIDEO CABLE
(ATTACHED TO VA-10U)
(P/N.: 246D016-70)
POWER CABLE (X3)
(P/N.: 246D017-10)
(P/N.: 246D017-20)
(P/N.: 246D017-30)

6English
Connection
A Connecting the Projector to Computer/Notebook
Figure 8 Connection to PC
Figure 9 Connection to notebook
CONTROLPORT
OUTPUT
COMPUTER
INPUT
COMPUTER IN
CONTROLPORT
MOUSE ADAER
FOR PS/2 PORT
(SUPPLIED)
VGA CABLE
(SUPPLIED)
GENERAL CABLE
(SUPPLIED)
PS/2 PORT
INPUT
CONTROLPORT
COMPUTER
INPUT
VGA CABLE
(SUPPLIED)
COMPUTER
OUTPUT
PS/2 PORT
INPUT
MOUSE ADAPTER
FOR PS/2 PORT
(SUPPLIED)
CONTROL PORT
OUTPUT
GENERAL CABLE
(SUPPLIED)COMPUTERIN
2
MPUTER
OUTPUT

English 7
Operation
Turn On/Off Procedure
A Power on
Press the Standby/On key for 2 seconds to turn on the lamp. The LED will blink orange
during the warm up and will then light solid green.
z“INPUT SIGNAL DETECTED, ACTIVATING AUTO IMAGE” will be displayed on the screen after
the projector has identified the input signal;
z“SEARCHING” message will be displayed on the screen if there is no signal input;
z“SYNC IS OUT OF RANGE” message will be displayed on the screen if the horizontal frequency of
the input signal exceeds the range of the projector.
B Standby
Press the Standby/Onkey for 2 seconds to turnoff the lamp.The LED willthenblink green
and the lamp will shut down, but the fan will continue to run for about 1 minute to cool the
lamp. After the fan stops, the LED will turn to a light solid orange.
*Lamp Protection Procedure: If you try to turn on the lamp again while the LED is blinking, the projector
will ignore the command until it has cooled down for one minute.
External Control
A Control Pad
Hotkey
Figure 10 Hotkey control pad
REMOTE
RECEIVER
MENU
-KEYSTONE
+KEYSTONE
AUTO LAMP STATUS
INDICATOR
STANDBY/ON
INDICATOR
STANDBY/ON
3

8English
Menu operating
When you press MENU button into OSD menu, all hotkeys become menu operating buttons.
Figure 11 Menu control pad
MAIN UNIT FUNCTION
Auto To correct the size and phase of the projected image
automatically.
Keystone + To correct the upper distortion of the projected image when
keystone occurs.
Keystone - To correct the lower distortion of the projected image when
keystone occurs.
Menu To call the OSD menu.
Standby/On To turn the projection lamp on and off.
Standby/On
indicator
Functions as an indicator showing the standby status.
Lamp status
indicator
Lights or blinks when the lamp does not light.
REMOTE
RECEIVER
MENU EXIT
LAMP STATUS
INDICATOR
STANDBY/ON
INDICATOR
STANDBY/ON

English 9
B Remote Control
Figure 12 Remote control
The remote control allows you to operate the function keys on the projector and to emulate
mouse function when the projector is connected to a computer.
MAIN UNIT FUNCTION
Menu To correct the upper distortion of the projected image when
keystone occurs.
X
XX
X(Keystone +) To navigate through sub-pages or to increase the scale bar
number.
W
WW
W(Keystone -) To navigate through sub-pages or to decrease the scale bar
number.
Exit (Auto) To exit from the current page or OSD menu, and save setting
changes.
LASER
LED
STANDBY/ON
MENU
FREEZE
L-CLICK
MAGNIFY
RETURN
EXIT
R-CLICK
VOLUME
MUTE
BLANK
About laser beam
This remote control is class 2 (max. output 1 mW
laser diode 640 - 660 nm) laser equipment.
Beam Divergence : 3m distance about 5.0mm x
3.0mm (+/- 1.5mm)
CAUTION :
Pressing the LASER button on the provided
remote control emits a laser beam. Do not look into
the beam light directly. Do not point the laser beam
at people. Looking at the laser beam directly may
damage to your eyesight.
The use of controls or adjustments or procedures
other than those specified herein may result in
hazardous radiation exposure.
BACK SIDE

10 English
Inserting Batteries in the Remote Control
Be sure to follow instructions in placing batteries into the remote control units.
zPush and slide the lid in the direction of the arrow.
zInstall two ‘AAA’ batteries as indicated inside the battery compartment.
zReplace the lid and snap it into place.
Main Unit Function
Standby/On Turns the projection lamp on and off.
Freeze Pressing this button displays a still (frozen) picture.
Magnify Pressing this button partially magnifies a displayed picture.
(Move the picture with the Disk Pad after pressing the Magnify button.)
Disk Pad When the OSD menu is active, Disk Pad acts as ST selecting device.
When the on-screen menus are not active, it works as mouse pad.
When the magnify function is active, use disk pad to move through the
picture.
Menu To call the OSD Menu.
To enter sub-pages.
To select items.
Blank The blank screen is displayed by pressing Blank. And the blank
screen will be revealed partially from top to bottom by pressing Blank
again.
Source Selects the input source.
Mute Mutes the sound.
Volume Adjusts the volume. The sound gets louder or quieter by pressing the
"+" or "-" button.
Laser Laser-pointer-on button. Use as a stick (for indication).
Mouse Left-Click When operating in the mouse emulation mode, it registers a left
mouse click.
Mouse Right-
Click
When operating in the mouse emulation mode, it registers a right
mouse click.
Exit To leave current OSD Pages.
WXDrag To move Left/Right among OSD items.
Caution
CautionCaution
Caution
zAvoid excessive heat and humidity.
zDo not mix new and old or different types of batteries.

English 11
Figure 13 Battery replacement process
Remote Control Range
The range for operation is about 10 m (about 32 feet ) when the remote control points to the
projector. The distance from the screen back to the projector must be less than 10 m (about
32 feet). Depending on the type of the screen, the distance will be different.
Figure 14 Range
Usage and Replacement of Lamp
The light source lamp has a limited service life.
The picture will become dark or the color will fade after the lamp has been used for a long
time. In such cases, continued use of the lamp could cause a malfunction. Replace the lamp
with a new one.
A Lamp/temperature Status LED Indicator
1. Lamp in excess of service hours
When the LED light is a continuous green, it means the lamp has exceeded 900 service
hours. After this light appears, it is advisable to replace the projection lamp as soon as
possible.
1. "PLEASE CHANGE A NEW LAMP. AND RESET THE LAMP TIMER" will be displayed on the screen if
the lamp has been operated for 900 hours (see figure 15).

12 English
2. "PLEASE CHANGE A NEW LAMP. THE POWER WILL TURN OFF AFTER 20 HOURS" will be displayed
on the screen if the lamp has been operated for 980 hours. The "20" will count down (see figure 16).
3. "PLEASE CHANGE A NEW LAMP" will blink on the screen together with a green LED if the lamp has been
operated for more than 1000 hours (see figure 17). The power will turn off automatically after 15 seconds.
All three of the above messages will not display for more than 15 seconds, but each message will be
displayed whenever you turn on the lamp.
2. Lamp is not well attached
If the LED blinks rapidly, it indicates that the lamp is not attached properly.
3. Temperature is too high
If the projector’s internal temperature is too hot to operate safely, the LED will blink slowly
for one minute and then the lamp will turn off automatically.
4. Normal status
If the LED light is off, it means the lamp and temperature inside the projector are normal.
Figure 16 Lamp replacement warning signal Figure 17 Lamp replacement warning signal
Caution
The lamp indicator will light when the lamp becomes too hot. Turn off the power and let
the projector cool for 45 minutes, then turn it on again. If the indicator is still shining,
contact your dealer.
Figure 15 Lamp replacement warning signal

English 13
B Replacing the Lamp
Replacing the lamp
When replacing the lamp, turn off the projector and unplug the AC cord. Wait 45 minutes so
that the lamp can cool. When this high-pressure lamp is hot, it may explode if it is improperly
handled.
Lamp Replacement Procedure
Caution
zDispose of used lamps in accordance with local authorities.
zAs the lamp is made of glass, do not apply shocks to it or scratch it.
zAlso, do not use an old lamp, as this could cause the lamp to explode.
zIf it seems that the lamp has exploded (for example, an explosive sound is heard), disconnect
the power cord from the outlet and ask your dealer to replace the lamp. The lamp is covered
by a front glass panel and an air-tight structure, but, in rare cases, the reflector and the inside
of the projector may be damaged by scattered, broken pieces of glass, which could cause
injury while being handled.
zFor replacement lamps, please contact your dealer. (Model name: VLT-X10LP)
1. Turn the main power switch off and disconnect the power cord
from the outlet.
2. Remove the lamp cover.
zIf hot, the lamp could cause burns. Wait for about 45
minutes until lamp has cooled down.
zLoosen a screw and remove the cover.
3. Loosen the 2 screws and pull the handle to remove the lamp.
zIf the screw is not loosened completely, you could hurt
your fingers.
zDo not insert your hand into the box after the lamp has
been removed. (There are optical parts inside which, if
touched, could result in color unevenness, etc.)

14 English
Figure 18 Lamp replacement: Step 1, Step 2, Step 3
4. Replace the lamp with a new one and fix it using the same
screw.
zFirmly tighten the lamp screw. Loose screws could result
in a poor connection, which could cause the unit to
malfunction.
5. Install the lamp cover and fix it using a screw.
zTo prevent burns, install the lamp cover and secure it
using the screw.
zDo not turn on the power with the lamp cover removed.
zWhenever the lamp is replaced, reset the total operation
time of the lamp. Do not reset if the lamp has not been
replaced.
zDo not reset the timer without changing the lamp, as
this can cause the lamp to break.
Press the lamp cover back with a few strength to
make sure the cover fits to the projector without leaks.

English 15
Resetting Lamp Timer
If replacing the lamp before reaching 1000 hours of operation, carry out the following
procedure.
If replacing the lamp after 1000 hours of operations, carry out the following procedure.
OSD
Main OSD Menu
This Menu is not displayed when the signal is not
input.
Press the "Menu" key and the main OSD menu
structure will display as shown on the right (Fig.
19). Whenever AV box is attached, 4 sub-pages
will display in the menu: Display page, Image
page, Control page, and Source page. However,
if the input is from a PC and no AV box is
attached, Source page will not display in the
menu.
Press the "Menu" key again to enter Display page items, or press "W" (KEYSTONE-) or "X"
(KEYSTONE+) to select the sub-pages. (The main OSD menu will automatically disappear
if no key is pressed within 10 seconds).
OSD FUNCTION
Press the Standby/On button for 2 seconds to turn on
the lamp.
Press the MENU button to display the OSD menu,
and use the "X" (KEYSTONE+) or "W" (KEYSTONE-
) buton to select the Control page. Then press the
Menu button again to highlight the Lamp item.
zThe MENU is not displayed when the signal
is not input.
Press the "X" (KEYSTONE+) or "W" (KEYSTONE-)
button and the lamp usage time will display on the
bottom of the screen.
Within 3 seconds, press the MENU button to reset the
usage time.
OSD FUNCTION
Press the Standby/On button for 2 seconds to turen
on the lamp.
Within 15 seconds after "AFTER 2 MINUTES,
SYSTEM WILL POWER OFF" is displayed, press the
MENU button twice consecutiely.
Press the Standby/On button for 2 seconds to turn off
the lamp.
Figure 19 Main OSD menu
Auto Pre <- or -> to re et.
Language
En Fr De It E Du 中
Mirror Normal V-Inv H-Inv H/V-Inv
Auto Off 0 (Stop) 0
Lamp Hour 985.5 Hour

16 English
Press the "Exit" (AUTO) button to leave the current sub-page, and press "Exit" (AUTO) the
button again to leave the main OSD menu (at the same time the settings are saved).
A Display Page
When a PC is the input source, there will be only four items on this page: Keystone,
Brightness, Contrast, and Color Balance (Fig. 20). On the other hand, when the input source
is Video or S-video, there will be 4 other items on this page: Keystone, Brightness, Contrast,
and Sharpness (Fig.21).
Press the "Menu" button again to scroll through the items; press "" (KEYSTONE-) or ""
(KEYSTONE+) to adjust the item scale, or press the "Exit" (AUTO) button to go back to the
main OSD page.
Input status PC input without AV box PC input with AV box Video input with AV box
Sub-page Display
Control
Display
Control
Source
Display
Control
Source
Figure 20 Display sub-page when the input
source is PC (with/without AV box)
Figure 21 Display sub-page when the input
source is video or s-video
Setting effects
Keystone (Decrease) (Increase) Source is PC
Brightness (Dark) (Bright)
Contrast (Lower) (Higher)
Color
Balance
(Red) (Blue)
Sharpness (Soft) (Sharp) Source is Video
