MobilMAX MX-Beacon1 User manual

1
MX-LOCare
BR1
MobilMAX
USER MANUAL
Thank you for purchasing the MX-LOCare® BR1 Bracelet
GPS Locator and/or MX-Beacon1. This manual shows how
to operate the de ice correctly. Make sure to read this
manual carefully before using this product. Please note
that specification and information are subject to change
without prior notice. Any change will be integrated in the
latest release. The manufacturer assumes no responsibility
for any errors and omissions in this document.
The content of your package includes:

2
-1. MX-LOCare® BR1
-2. MX-PowerEXT®
-3. MX-Beacon®
-4. USB cable
-5. Charger
-6. Warranty cards (for MX-LOCare® BR1Bracelet and
MX-Beacon® each): Bracelet ID, Telephone number for
bracelet, beacon ID and beacon serial number.
-7. SIM card has been pre-installed
-8. MX-LOCare® BR1 Torx Screw dri er

3
Contents
1. GENERAL INFORMATION ...................................5
1.1 HARDWARE DESCRIPTION ..................................5
1.2 LED LIGHT DEFINITION.......................................7
2. GETTING STARTED...........................................10
2.1 FUNCTIONS.....................................................10
2.2 BATTERY AND CHARGER...................................10
3. STARTUP.........................................................12
. MX-CLOUD
®
SERVER AND WEB ........................13
4.1 Registration and Login ............................. 13
4.2 Locator Management............................... 15
4.3 MX-Beacon® Management......................19
4.4 Real-time Tracking ................................... 20
4.5 History ..................................................... 21
4.6 Cursers and icons ..................................... 23
4.7 Member Center ....................................... 24
5. MX-LOCATE® APP ............................................26
5.1 Registration and Log In ............................ 26
5.2 Add New Locators .................................... 28
5.3 MX-Beacon® and System Configure......... 29
5.4 O er iew of Locator.................................31
5.5 History ..................................................... 36
6. HOW TO USE GPS LOCATOR DEVICE .................38
7. SAFETY INFORMATION ....................................38

4
8. CARE AND MAINTENANCE...............................41

5
1. General Information
The Bracelet works on existing GSM/GPRS network and
satellites. This product can locate and monitor any wearer
by SMS or GPRS.
1.1 Hardware Description
Front Face Back Side
MX-LOCare® Locator Description
1. Link LED Light (Blue)
2. MXConn
®
connector
3. SOS/ON Button
4. Power LED Light (Red)
5. GPS LED Light (Green)
6. Back Co er (SIM Co er)
7. Proximity Sensor
8. PowerOff Button

6
MX-PowerEXT® Description
1. Hook structure (to connect to the locator)
2. LED indicators
3. USB Connector
4. MXConn
®
Connector
Power Button Definition
Function Description
1. SOS/ON
Button
- Power On: Press 3 seconds to Power On
the de ice (The LED light “Red”, “Green”
and “Blue” will flash sequentially twice)
- SOS: Under Power On status, hold down
the button 3 seconds, all three LED lights
will flash until the locator sends out the
SOS Warning.
(Please refer to section 4.1.1 or 5.1 to
register from a web browser or
MX-Locate® APP respecti ely.)
2. Power Off
Button
The PowerOff button is a hole located in
the back of the Bracelet. Insert a small
paperclip in the hole in order to power off

7
the locator
1.2 LED Light Definition
1.2.1 Locator LED
LED Light Status definition
1. Link LED Light
(Blue)
Link status:
- Network Linked: light “ON” for 2
seconds and shuts “OFF” in 10 seconds.
- SIM Card Error or GSM Network
Failed: light flashes 3 times and shuts
“OFF” in 2 seconds.
- Network Searching: light “ON” in 0.5
seconds and shuts “OFF” in 2 seconds.
- Data Network Failed: light flashes 2
times and shuts “OFF” in 2 seconds.
2. GPS/Beacon
LED Light
(Green)
GPS status:
- Searching GPS Satellites: light “ON” in
0.5 seconds and shuts “OFF” in 2
seconds.
- Beacon Search Succeed
: light flashes 3
times and shuts “OFF” in 2 seconds.
- Positioning Succeed: light will turn
“ON” in 5 seconds after positioning
success and will keep flashing for 2
seconds and then will shut “OFF” in 10
seconds.

8
3. Power LED
Light (Red)
Battery status:
- Low Battery: light turns “ON” for 2
seconds and then shuts “OFF” for 10
seconds
- Charging: light flashes e ery 1 second.
- Fully Charged: light shows “ON”.
1.2.2 MX-PowerEXT® LED
LED Light Status definition
1. Charge LED
Light (White)
USB connected:
- When the battery of MX-PowerEXT®
itself is NOT fully charged: the 4 white
LEDs will flash sequentially from right
to left.
- When the battery of MX-PowerEXT®
itself is full: all the 4 white LEDs will be
on constantly.
USB NOT connected:
- When MX-PowerEXT® is connected to
the MX-LOCare® Bracelet: light will be
“ON” constantly, NOT all the 4 white
LEDs are “ON” the same time. The
number of LED’s on will indicate the
battery le el remaining in the
MX-PowerEXT®.
- When MX-PowerEXT® is NOT
connected to the MX-LOCare® Bracelet
:

9
4 white LEDs are “OFF".
2. Discharge
LED Light (Red)
When the MX-PowerEXT is Connected
to MX-LOCare® Bracelet:
- When the battery le el of
MX-LOCare® Bracelet is Not fully
charged: the Red LED will be “ON”.
- When the battery le el of
MX-LOCare® Bracelet is full: the Red
LED will be “OFF”
*Important - Please note that although
the Bracelet is IP-67 waterproof rated
the charging bank is not. At no time
should the MX-PowerEXT® be exposed
to any water or an
y liquid will oid the
warranty.
When the MX-PowerEXT is NOT
connected to MX-LOCare® Bracelet:
the Red LED on the power pack will be
“OFF”

10
2. Getting started
2.1 Functions
Periodic reporting or real time tracking functions are
generated from web or MX-Locate® downloadable
APP.
Location and acti ity history is easily accessed and
stored to check past records.
SOS Button sends out an emergency signal.
Up to 10 inbound/outbound GeoFences. Can be in
forms of circle, rectangle and polygon.
Detach alert using light laser when detached from
user.
G-sensor alert for impact and fall incidents
Indoor location aware technology with the aid of
MX-Beacon®
Safe zone boundaries further defined with the aid of
MX-Beacon®
MX-PowerEXT® (800mAh) extends the standby mode
and recharges the Bracelet easily without taking it off
the wearer
IP-67 waterproof design
2.2 Battery and Charger
For initial use charge the MX-PowerEXT® and the Bracelet
for 2 hours. To charge
the Bracelet, use the
charger and
MX-PowerEXT® at the
same time. Plug in the
power cable to the
MX-PowerEXT® and
