Modulens AGC 10 Manual

Modulens EN
Gas fired floor-standing condensing boiler
AGC 10/15
AGC 15
AGC 25
AGC 35
Installation and
Service Manual
300026081-001-08

Declaration of conformity
The device complies with the standard type described in
the EG declaration of conformity. It was manufactured and
commissioned in accordance with European directives.
The original declaration of conformity is available from the
manufacturer.

Contents
1 Safety instructions and recommendations ..............................................6
1.1 General safety instructions .................................6
1.2 Recommendations ................................................7
1.3 Liabilities ...............................................................8
1.3.1 Manufacturer’s liability .............................................8
1.3.2 Installer’s liability .....................................................8
2About this manual ......................................................................................9
2.1 Symbols used .......................................................9
2.1.1 Symbols used in the manual ...................................9
2.1.2 Symbols used on the equipment .............................9
2.2 Abbreviations ......................................................10
2.3 After Sales Service Internet Site .......................10
3 Technical specifications ..........................................................................11
3.1 Homologations ....................................................11
3.1.1 Certifications .........................................................11
3.1.2 Gas categories ......................................................11
3.1.3 Additional Directives ..............................................11
3.1.4 Factory test ...........................................................12
3.2 Technical specifications ....................................12
3.2.1 Sensor characteristics ...........................................13
4 Technical description ..............................................................................14
4.1 General description ............................................14
4.2 Main parts ............................................................14
4.3 Operating principle .............................................15
4.3.1 Skeleton Diagrams ................................................15
4.3.2 Circulation pump ...................................................17
4.3.3 Water flow rate ......................................................17
5 Installation ................................................................................................18
5.1 Regulations governing installation ...................18
5.2 Package list .........................................................18
5.2.1 Standard delivery ..................................................18
5.2.2 Accessories ...........................................................18
15/03/2016 - 300026081-001-08 1

5.3 Choice of the location ........................................19
5.3.1 Type plate .............................................................19
5.3.2 Positioning of the appliance ..................................20
5.3.3 Ventilation .............................................................21
5.3.4 Main dimensions ...................................................21
5.4 Positioning the appliance ..................................26
5.4.1 Positioning the boiler on its own ............................26
5.4.2 Fitting the boiler to a DHW tank ............................28
5.4.3 Positioning the boiler to the left or right of a DHW
tank .......................................................................29
5.4.4 Reversing the opening direction of the control panel
door .......................................................................29
5.5 Hydraulic connections .......................................30
5.5.1 Flushing the system ..............................................30
5.5.2 Hydraulic connection of the heating circuit ............31
5.5.3 Connection of the water circuit for domestic
use ........................................................................31
5.5.4 Connecting the expansion vessel .........................31
5.5.5 Connecting the condensate discharge pipe ..........32
5.5.6 Filling the condensate trap ....................................33
5.6 Gas connection ...................................................33
5.7 Flue gas system connections ............................34
5.7.1 Classification .........................................................35
5.7.2 Lengths of the air/flue gas pipes ...........................36
5.8 Installing the outside sensor .............................37
5.8.1 Choice of the location ............................................37
5.8.2 Connecting the outside sensor ..............................37
5.9 Electrical connections ........................................38
5.9.1 Control unit ............................................................38
5.9.2 Recommendations ................................................39
5.9.3 Access to the connection terminal ........................40
5.9.4 Position of the PCBs .............................................41
5.9.5 Connecting a direct heating circuit ........................42
5.9.6 Connecting a heating circuit and a domestic hot water
tank .......................................................................43
5.9.7 Connecting two circuits and a domestic hot water
tank .......................................................................47
5.9.8 Hot water storage tank connection ........................48
5.9.9 Pool connection .....................................................53
5.9.10 Connecting a mixed tank .......................................54
5.9.11 Connecting the options .........................................56
5.9.12 Connection in cascade ..........................................57
5.10 Electrical diagram ...............................................60
5.11 Filling the system ...............................................61
5.11.1 Water treatment ....................................................61
5.11.2 Filling the system ..................................................62
Contents
15/03/2016 - 300026081-001-08 2

6 Commissioning ........................................................................................63
6.1 Control panel .......................................................63
6.1.1 Description of the keys ..........................................63
6.1.2 Description of the display ......................................64
6.1.3 Access to the various browsing levels ..................66
6.1.4 Browsing in the menus ..........................................68
6.2 Check points before commissioning ................69
6.2.1 Preparing the boiler for commissioning .................69
6.2.2 Gas circuit .............................................................69
6.2.3 Hydraulic circuit .....................................................71
6.2.4 Electrical connections ...........................................71
6.3 Putting the appliance into operation ................71
6.4 Gas settings ........................................................72
6.4.1 Adapting to another gas type ................................72
6.4.2 Checking and setting combustion .........................73
6.4.3 Basic setting for the gas/air ratio ...........................77
6.5 Checks and adjustments after
commissioning ...................................................77
6.5.1 Displaying the parameters in extended
mode .....................................................................77
6.5.2 Setting the parameters specific to the
installation .............................................................78
6.5.3 Naming the circuits and generators ......................81
6.5.4 Setting the heating curve ......................................82
6.5.5 Finalizing work ......................................................84
6.6 Reading out measured values ...........................85
6.7 Changing the settings ........................................86
6.7.1 Language selection ...............................................86
6.7.2 Calibrating the sensors .........................................87
6.7.3 Professional settings .............................................88
6.7.4 Configuring the network ........................................97
6.7.5 Return to the factory settings ..............................100
7 Switching off the appliance ...................................................................101
7.1 Installation shutdown .......................................101
7.2 Antifreeze protection ........................................101
8 Checking and maintenance ...................................................................102
8.1 General instructions .........................................102
8.2 Chimney sweep instructions ...........................102
8.3 Customising maintenance ...............................103
8.3.1 Maintenance message ........................................103
8.3.2 Contact details of the professional for After Sales
Support ................................................................104
15/03/2016 - 300026081-001-08 3

8.4 Standard inspection and maintenance
operations .........................................................104
8.4.1 Checking the hydraulic pressure .........................105
8.4.2 Checking the expansion vessel ...........................105
8.4.3 Checking the ionization current ...........................105
8.4.4 Checking the tightness of the flue gas evacuation and
air inlet connections ............................................105
8.4.5 Checking combustion ..........................................105
8.4.6 Checking and closing the automatic air vent .......106
8.4.7 Checking the safety valve ...................................106
8.4.8 Checking the condensate trap ............................106
8.4.9 Checking the burner and cleaning the heat
exchanger ...........................................................107
9 Troubleshooting .....................................................................................108
9.1 Anti-hunting ......................................................108
9.2 Messages (Code type Bxx or Mxx) ..................108
9.3 Message history ................................................111
9.4 Faults (Code type Lxx or Dxx) .........................111
9.4.1 Deletion of sensors from the memory in the
PCB .....................................................................120
9.5 Failure history ...................................................121
9.6 Parameter and input/output check (mode
tests) ..................................................................121
9.6.1 Control system sequence ....................................124
10 Spare parts ..............................................................................................126
10.1 General ..............................................................126
10.2 Spare parts ........................................................127
10.2.1 Casing .................................................................127
10.2.2 Water unit ............................................................128
10.2.3 Control panel .......................................................129
10.2.4 Casing .................................................................129
10.2.5 Spare parts list ....................................................130
11 Appendix – Information on the Ecodesign and Energy Labelling
Directives ................................................................................................133
Contents
15/03/2016 - 300026081-001-08 4

15/03/2016 - 300026081-001-08 5

1 Safety instructions and
recommendations
1.1 General safety instructions
DANGER
This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have
been given supervision or instruction concerning
use of the appliance in a safe way and
understand the hazards involved. Children shall
not play with the appliance. Cleaning and user
maintenance shall not be made by children
without supervision.
DANGER
If you smell gas:
1. Do not use a naked flame, do not smoke, do
not operate electrical contacts or switches
( doorbell, light, motor, lift, etc..).
2. Shut off the gas supply.
3. Open the windows.
4. Trace possible leaks and seal them
immediately.
5. If the gas leak is before the gas meter,
contact the gas supplier.
DANGER
If you smell flue gases:
1. Switch the appliance off.
2. Open the windows.
3. Trace possible leaks and seal them
immediately.
1. Safety instructions and recommendations AGC 10/15 AGC 15 AGC 25 AGC 35
615/03/2016 - 300026081-001-08

1.2 Recommendations
WARNING
4Installation and maintenance of the boiler
must be carried out by a qualified
professional in compliance with prevailing
local and national regulations.
4When working on the boiler, always
disconnect the boiler from the mains and
close the main gas inlet valve.
4After maintenance or repair work, check all
installations to ensure that there are no
leaks.
CAUTION
The boiler must be installed in a frost-free
environment.
Keep this document close to the place where the
boiler is installed.
Casing components
Only remove the casing for maintenance and repair
operations. Put the casing back in place after
maintenance and repair operations.
Instructions stickers
The instructions and warnings affixed to the appliance
must never be removed or covered and must remain
legible during the entire lifespan of the appliance.
Immediately replace damaged or illegible instructions and
warning stickers.
Modifications
Modifications may only be made to the boiler after the
written permission of De Dietrich Thermique to do so.
AGC 10/15 AGC 15 AGC 25 AGC 35 1. Safety instructions and recommendations
15/03/2016 - 300026081-001-08 7

1.3 Liabilities
1.3.1. Manufacturer’s liability
Our products are manufactured in compliance with the
requirements of the various applicable European
Directives. They are therefore delivered with [ marking
and all relevant documentation.
In the interest of customers, we are continuously
endeavouring to make improvements in product quality.
All the specifications stated in this document are therefore
subject to change without notice.
Our liability as the manufacturer may not be invoked in the
following cases:
4Failure to abide by the instructions on using the
appliance.
4Faulty or insufficient maintenance of the appliance.
4Failure to abide by the instructions on installing the
appliance.
1.3.2. Installer’s liability
The installer is responsible for the installation and
commissioning of the appliance. The installer must
respect the following instructions:
4Read and follow the instructions given in the manuals
provided with the appliance.
4Carry out installation in compliance with the prevailing
legislation and standards.
4Perform the initial start up and carry out any checks
necessary.
4Explain the installation to the user.
4If a maintenance is necessary, warn the user of the
obligation to check the appliance and maintain it in
good working order.
4Give all the instruction manuals to the user.
1. Safety instructions and recommendations AGC 10/15 AGC 15 AGC 25 AGC 35
815/03/2016 - 300026081-001-08

2 About this manual
2.1 Symbols used
2.1.1. Symbols used in the manual
In these instructions, various danger levels are employed to draw the
user’s attention to particular information. In so doing, we wish to
safeguard the user’s safety, highlight hazards and guarantee correct
operation of the appliance.
DANGER
Risk of a dangerous situation causing serious physical
injury.
WARNING
Risk of a dangerous situation causing slight physical
injury.
CAUTION
Risk of material damage.
Signals important information.
¼Signals a referral to other instructions or other pages in the
instructions.
2.1.2. Symbols used on the equipment
4Protective earthing
~Alternating current
Before installing and commissioning the device, read
carefully the instruction manuals provided.
Dispose of the used products in an appropriate recovery
and recycling structure.
This appliance must be connected to the protective earth.
D000241-C
AGC 10/15 AGC 15 AGC 25 AGC 35 2. About this manual
15/03/2016 - 300026081-001-08 9

Caution: danger, live parts.
Disconnect the mains power prior to any operations.
2.2 Abbreviations
43CE: Collective conduit for sealed boiler
4DHW: Domestic hot water
4Interscenario switch: Home automation switch that can be used
to centralise and control several scenarios
4Hi: Lower heating value LHV (Nett)
4Hs: Higher heating value HHV (Gross)
4PPS: Polypropylene hardly inflammable
4PCU: Primary Control Unit - PCB for managing burner operation
4PSU: Parameter Storage Unit - Parameter storage for PCBs
PCU and SU
4SCU: Secondary Control Unit - control panel PCB
4SU: Safety Unit - Safety PCB
43WV: 3-way valve
4HL: High Load - DHW tank with plate exchanger
4SL: Standard Load - DHW tank with coil
4SHL: Solar High Load - Solar DHW tank with plate exchanger
4SSL: Solar Standard Load - Solar DHW tank with coil
2.3 After Sales Service Internet Site
The QR code or flashcode is used to access the internet site
containing the documentation and technical information regarding the
product. The QR code also appears on the appliance’s nameplate.
1 2
M002628-A
2. About this manual AGC 10/15 AGC 15 AGC 25 AGC 35
10 15/03/2016 - 300026081-001-08

3 Technical specifications
3.1 Homologations
3.1.1. Certifications
CE identification no CE-0085CM0178
NOx classification 5 (EN 15502-1, EN 15502-2-1)
Type of connection Chimney: B23, B33
Flue gas outlet: C13(x), C33(x), C43(x), C53, C83(x),
C93(x)
3.1.2. Gas categories
Gas category Gas type Connection pressure (mbar)
II2ESi3P Natural gas H (G20) 20
Natural gas L (G25) 25
Propane (G31) 37
The boiler is preset in the factory to operate on natural gas H (G20).
¼For operation on another type of gas, see chapter: "Adapting
to another gas type", page 72.
3.1.3. Additional Directives
Apart from the legal provisions and Directives, the additional
Directives described in these instructions must also be observed.
For all provisions and Directives referred to in these instructions, it is
agreed that all addenda or subsequent provisions will apply at the
time of installation.
WARNING
Installation of the appliance must be done by a qualified
engineer in accordance with prevailing local and national
regulations.
AGC 10/15 AGC 15 AGC 25 AGC 35 3. Technical specifications
15/03/2016 - 300026081-001-08 11

3.1.4. Factory test
Before leaving the factory, each boiler is set for optimum performance
and tested to check the following items:
4Electrical safety
4Adjustment (CO2)
4Domestic hot water mode
4Water tightness
4Gas tightness
4Parameter settings
3.2 Technical specifications
Boiler type AGC 10/15 AGC 15 AGC 25 AGC 35
General
Nominal output (Pn)
Heating System (80/60 °C)
minimum-
maximum
kW 3,0 - 10,4 3,0 - 14,9 5,0 - 24,8 6,3 - 34,8
Nominal output (Pn)
Heating System (50/30 °C)
minimum-
maximum
kW 3,4 - 11,2 3,4 - 15,8 5,6 - 25,5 7,0 - 35,9
Nominal output (Pn)
Heating System (40/30 °C)
minimum-
maximum
kW 3,4 - 16,0 3,4 - 16,0 5,6 - 25,9 7,0 - 36.4
Nominal input (Qn)
Heating System (Hi)
minimum-
maximum
kW 3,1 - 10,5 3,1 - 15,0 5,2 - 25,0 6,5 - 35,1
Nominal input(Qn)
Heating System (Hs)
minimum-
maximum
kW 3,4 - 11,7 3,4 - 16,7 5,8 - 27,8 7,2 - 39,0
Nominal input (Qnw)
DHW System (Hi)
minimum-
maximum
kW 3,1 - 15,0 3,1 - 15,0 5,2 - 29,3 6,5 - 35,1
Nominal input (Qnw)
DHW System (Hs)
minimum-
maximum
kW 3,4 - 16,7 3,4 - 16,7 5,8 - 32,6 7,2 - 39,0
Heating efficiency under full load (Hi)
(80/60 °C)
- % 99,3 99,3 99,2 99,1
Heating efficiency under full load (Hi)
(50/30 °C)
- % 107,0 105,3 102,0 102,2
Heating efficiency under partial load
(Hi) (Return temperature 60°C)
- % 94,9 94,9 96,1 96,3
Heating efficiency under partial load
(EN 92/42) (Return temperature
30°C)
- % 110,2 110,2 110,1 110,6
Data on the gases and combustion gases
Gas consumption - Natural gas H
(G20)
minimum-
maximum m3/h 0,33 - 1,59 0,33 - 1,59 0,55 - 3,10 0,69 - 3,71
Gas consumption - Natural gas L
(G25)
minimum-
maximum m3/h 0,38 - 1,85 0,38 - 1,85 0,64 - 3,61 0,80 - 4,32
Gas consumption - Propane G31 minimum-
maximum m3/h 0,13 - 0,61 0,13 - 0,61 0,21 - 1,20 0,27 - 1,44
Mass flue gas flow rate minimum-
maximum
kg/h 5,3 - 25,2 5,3 - 25,2 8,9 - 49,3 11,1 - 57,3
Flue gas temperature minimum-
maximum
°C 30 - 65 30 - 65 30 - 80 30 - 75
Maximum counter pressure Pa 80 80 130 140
Characteristics of the heating circuit
3. Technical specifications AGC 10/15 AGC 15 AGC 25 AGC 35
12 15/03/2016 - 300026081-001-08

Boiler type AGC 10/15 AGC 15 AGC 25 AGC 35
Water content (ex expansion vessel) l 1,9 1,9 1,9 2,5
Water operating pressure minimum kPa (bar (MPa)) 80 (0,8) 80 (0,8) 80 (0,8) 80 (0,8)
Water operating pressure (PMS) maximum kPa (bar (MPa)) 300 (3,0) 300 (3,0) 300 (3,0) 300 (3,0)
Water temperature maximum °C 110 110 110 110
Operating temperature maximum °C 90 90 90 90
Electrical characteristics
Power supply voltage VAC 230 230 230 230
Power consumption - Full load maximum W 101 101 116 132
Electrical protection index IP21 IP21 IP21 IP21
Other characteristics
Weight (empty) kg 56 56 56 50
3.2.1. Sensor characteristics
Outside sensor
Temperature in °C -20 -16 -12 -8 -4 0 4 8 12 16 20 24
Resistance in Ω 2392 2088 1811 1562 1342 1149 984 842 720 616 528 454
Outlet sensor circuit B+C
Domestic hot water sensor
Temperature in °C 0 10 20 25 30 40 50 60 70 80 90
Resistance in Ω 32014 19691 12474 10000 8080 5372 3661 2535 1794 1290 941
Boiler sensor
Return sensor
Temperature in °C -20 -10 0 10 20 25 30 40 50 60 70 80 90 100 110
Resistance in Ω 98932 58879 36129 22804 14773 12000 9804 6652 4607 3252 2337 1707 1266 952 726
AGC 10/15 AGC 15 AGC 25 AGC 35 3. Technical specifications
15/03/2016 - 300026081-001-08 13

4 Technical description
4.1 General description
Gas fired floor-standing condensing boiler
4High efficiency heating.
4Low pollutant emissions.
4Top of the range electronic DIEMATIC iSystem control panel.
4Flue gas evacuation via a forced flue, chimney, bi-flow, 3CE or
3CEP type connection.
4Optional domestic hot water production in combination with a
DHW tank.
The boiler is fitted with an interior light. The interior light
comes on in the following cases:
4The boiler is switched on: The lighting is switched on
for 10 minutes.
4The boiler is switched off: The lighting is switched on
for 30 minutes.
4.2 Main parts
1Flue gas discharge pipe
2Flue gas measuring point
3Heat exchanger
4Ignition/ionization electrode
5Box for the control PCBs
6Control panel
7Command module
8Water pressure sensor
9Circulation pump
10 Hydroblock
11 3-way valve
12 Safety valve
13 Casing
14 Expansion vessel
15 Combined venturi and gas valve unit
16 Fan
17 Air intake silencer
18 Mixer pipe
C003072-C
18
19
16
17
15
14
13
12
11
1234
10
9
5
6
7
8
4. Technical description AGC 10/15 AGC 15 AGC 25 AGC 35
14 15/03/2016 - 300026081-001-08

19 Automatic air vent
4.3 Operating principle
4.3.1. Skeleton Diagrams
nBoiler self-standing
1Heat exchanger
2Hydroblock
3Heating flow
4Primary DHW tank flow
5Primary DHW tank return
6Heating return
73-way valve
8Circulation pump
9Expansion vessel
C003073-C
1
2
8
9
7
3 4 5 6
AGC 10/15 AGC 15 AGC 25 AGC 35 4. Technical description
15/03/2016 - 300026081-001-08 15

nBoiler with 100HL / 220SHL type domestic hot water
tank
1Heat exchanger
2Hydroblock
3Heating flow
4Plate exchanger inlet
5Plate exchanger outlet
6Heating return
73-way valve
8Circulation pump
9Expansion vessel
10 Domestic hot water outlet
11 Domestic cold water inlet
12 Plate heat exchanger
13 Domestic hot water pump
14 Domestic hot water tank
19 Safety valve
nBoiler with 100SL / 160SL / 200SSL type domestic hot
water tank
1Heat exchanger
2Hydroblock
3Heating flow
4Coil exchanger inlet
5Coil exchanger outlet
6Heating return
73-way valve
8Circulation pump
9Expansion vessel
15 Domestic hot water outlet
16 Domestic cold water inlet
17 Domestic hot water tank
18 Domestic water coil
19 Safety valve
M002513-F
1
2
8
9
7
3
10
12
13
14
456
11
19
M002514-D
1
2
8
9
7
3
15 16
17
18
456
19
4. Technical description AGC 10/15 AGC 15 AGC 25 AGC 35
16 15/03/2016 - 300026081-001-08

4.3.2. Circulation pump
The boiler is fitted with a modulating pump which is regulated by the
control panel as a function of ΔT.
The graph shows the manometric height at various outputs. The
parameters MIN.PUMP SPEED and MAX.PUMP SPEED are used to
modify the pump settings.
4If flow noise can be heard in the system, it is possible to reduce
the maximum pump speed with the parameter MAX.PUMP
SPEED (First of all, vent the heating system).
4If circulation in the radiators is too low or the radiators do not fully
heat up, increase the minimum pump speed with the parameter
MIN.PUMP SPEED.
nPump specifications
10/15 - 15 - 25 kW boilers
HManometric height available for the heating circuit
QWater flow
Useful output (ΔT 20 K)
A10 kW
B15 kW
C20 kW
D25 kW
35 kW boilers
HManometric height available for the heating circuit
QWater flow
AUseful output 35 kW (ΔT 20 K)
4.3.3. Water flow rate
The boiler’s modulating control system limits the maximum difference
in temperature between the heating flow and return and the maximum
speed at which the flow temperature increases. In this way, the boiler
does not require a minimum water flow rate.
H (mbar)
C003452-E
Q (l/h)
0 200 400 600 800 1000 1200
0
100
200
300
400
500
600
700
800
B
A
C
D
1037834623440
00 200 400 600 800 1000 1200 1400
1465
1600
100
200
300
400
500
600
700
H (mbar)
Q (l/h)
A
L000697-A
AGC 10/15 AGC 15 AGC 25 AGC 35 4. Technical description
15/03/2016 - 300026081-001-08 17

5 Installation
5.1 Regulations governing installation
WARNING
Installation of the appliance must be done by a qualified
engineer in accordance with prevailing local and national
regulations.
5.2 Package list
5.2.1. Standard delivery
The delivery includes:
4The boiler, fitted with a connection cable
4Outside sensor
4Installation and Service Manual
4User Guide
5.2.2. Accessories
Various options are available depending on the configuration of the
installation.
Boiler options
Description package
Condensates neutralisation station DU13
Condensates neutralisation station without lift pump BP52
Flue gas safety thermostat JA38
adapter 80/125 HR38
3-way internal valve kit JA6
External circuit kit JA7
Reduced elbow kit JA43
Propane conversion kit AGC 15 JA39
Propane conversion kit AGC 25 JA40
Propane conversion kit AGC 35 JA41
5. Installation AGC 10/15 AGC 15 AGC 25 AGC 35
