INTRODUCTION
The SD amplifier series is a harmonious marriage between MOOER’s famous digital preamp
technology and a new take on traditional solid-state Class A/B amplification techniques, that deliver
professional “tube like” performance, touch and feel, at entry level prices.
Each model in the SD series comes fully loaded with a whole host of special-features and effects, that
provide everything you need to craft incredible guitar tones for creating music on-stage or in the practice
room. These tones can be stored within 40 preset slots and easily recalled using the proprietary wireless
footswitch.
SD amps have a unique JAM section that contains a whole suite of tools for solo performers and
creative aficionados alike, such as an integrated looper, syncable drum machine and Bluetooth connection
for playback of your favourite audio tracks from an external device.
FEATURES
25 Digital preamp models based on MOOER’s unique digital preamp modelling technology,
coupled with a Class A/B power amp, delivers tube like tone and response
29 integrated stompboxes including 8 drive pedals, 9 modulation pedals, 5 delay pedals
(w/tap tempo), 6 reverb types and a precision chromatic tuner
JAM section provides the ultimate in solo performance and practice facilities. Including
a looper, syncable drum machine, AUX IN and Bluetooth connections for audio playback
40 preset slots to backup and recall your favourite tone settings. These can be easily recalled
using the proprietary wireless footswitch (incl. with SD75)
Independent control knobs for main amp parameters allows fast and intuitive tone setup
Professional custom guitar speaker delivers fantastic tone
Optional balanced output with integrated cabinet simulation for direct connection to
PA and audio interface (SD75 Only)
Independent headphone output with cabinet simulation for silent practice
Serial FX LOOP for easy integration with your favourite effects pedals
SPEAKER OUT for connection to external speaker cabinets
The combo amps currently available in 30Watt and 75Watt versions, house custom-built guitar speakers,
designed to deliver rich harmonics and enhanced feel with clarity, articulation and dynamics throughout the
amplifiers full volume range.
1

TOP PANEL LAYOUT
01
03
04 05 06
07 08 09 10 11 12 13
01 02 14 07 08 09 10 11 12 13
05 06
04 15
14
15
2
03

TOP PANEL LAYOUT
PRESET: Press to recall presets
01
BANK ▲▼: Press to change preset bank
02
INPUT: Connect guitar
03
AUX IN: Connect external media device for audio playback
04
PREAMP CONTROLS: Quickly dial in the tone of your preamp model. Each of these parameters
are stored per preset and the position of the knob does not represent the current parameter setting
when a preset is recalled. Turn any of these knobs to activate them. They will remain active until you
select a different preset, at which time it becomes inactive again.
05
PRESENCE – Preset brightness control
GAIN – Adjusts preamp model input gain
VOLUME – Adjusts preset volume
BASS – Adjusts preamp model low frequencies
MIDDLE – Adjusts preamp model mid frequencies
TREBLE – Adjusts preamp model high frequencies
MASTER: Global amplifier output volume control
06
EFFECT: Press to turn effect block on/off and enter respective effect editing menu.
OD/DS – Overdrive and distortion pedals
AMP- Preamp model and noise gate
MOD – Modulation pedals
DELAY – Delay effects
REVERB – Reverb effects
07
TUNER: Press to enter/exit the chromatic guitar tuner
08
SAVE: Press to save preset
09
SYSTEM: Press to enter/exit system settings menu
10
TAP : Press 2 or more times to operate TAP TEMPO. The DELAY effect’s delay time will synchronize
with the rhythm you enter using this button
11
PLAY: Press to return to the PLAY SCREEN
12
VALUE: Rotate and press to adjust settings within the various screens and menus
13
LCD SCREEN: Displays various screens and menus
14
15
3
: Stereo headphone output

BACK PANEL LAYOUT
01
02
04 05 06 07 08
03
01
02 03
04 0506 08
4

BACK PANEL LAYOUT
POWER: Toggles power on/off to the amplifier
01
AC IN: Connect 3 pin grounded AC power cord
02
POWER FUSE: Contains the main power protection fuse and a backup replacement fuse.
If the amplifier cannot power on, inspect the protection fuse and replace if necessary.
T500mA - 220V-240V
T1000mA- 100V-120V
03
AC VOLTAGE: Select correct setting for your current region. Please note that the correct
POWER FUSE must also be installed. DO NOT change this setting with a power cord
connected to your amplifier.
04
SPEAKER OUT: Connect to an external speaker with an impedance of 8Ω - 16Ω
05
EFFECTS LOOP : Easily integrate your favourite external effects by connecting them to
the effects loop
06
SEND – Effects send (preamp out) – Connect to the input of external effects
RETURN – Effects return (Power amp in) – Connect to the output of external effects
XLR OUT: Direct audio out with optional speaker cabinet simulation and ground lift
switch. For connection direct to PA or audio interface.
07
USB: Connect to computer for firmware updates
08
5

GETTING STARTED
Ensure the power switch
is set to OFF (O)
OFF
Connect a guitar to the
INPUT
MASTER
Set the MASTER control fully
counter-clockwise
ON
Set the power switch
to ON (I)
AC IN
Connect a 3 pin grounded
AC CORD to the AC IN
PLAY SCREEN
The PLAY SCREEN is the default screen of your SD amplifier and displays various information
You can return to the PLAY SCREEN at any time by pressing the PLAY button
BANK number PRESET number
PRESET name
OD/DS model
AMP model
MOD modelDELAY model REVERB model
01 02
03 04 05
6

SELECTING PRESETS
SD30/SD75 have 40 presets in total. These are organised into 10 banks (0 – 9) of 4 (A, B, C, D).
A B C D A B C D A B C D A B C DA B C D
There are 3 ways to change between presets.
2. Press BANK ▲▼ to select a bank

Press PRESET A B C D to select a preset.
3. Pair the wireless footswitch included with your amplifier
Press footswitches A + B simultaneously for BANK ▲
Press footswitches C + D simultaneously for BANK ▼
Press footswitch A, B, C, or D to select a corresponding preset
Preset
1. Rotate the VALUE control when on the PLAY SCREEN to scroll through presets.
5 6 7 8 9
A B C D
A B C D
0
CLUB CL
US CRUSH
GOT ME METAL
A B C D
1
WORKER PACIFIC JCMDS WATER
A B C D
2
FILTER
TREMELO
LOVE OD DEEPTREM
A B C D
3
HOLIDAY
80 CHORUS BROKEN D FATCLEAN
A B C D
4
HOTRIFF MODVERB TUBE OD OLDTIME
ANOTHER DREAMING DJENT FEELGOOD GYRATE FOREST
CRUSH
VOODOO HARMONY CRAZYBOY BRITPINK 77 PUNK RINGMAN SMOOTH COLD CL WHITE ECHO WAVE
RUMBLE
DUALCORE
7

EDITING PRESETS
Press the AMP button to enter the AMP edit screen
Rotate the VALUE control to select an amp model
You can use the AMP CONTROLS to adjust the main amp parameter settings
Press the value control to highlight other parameters such as NG and then rotate the VALUE
CONTROL to adjust the parameter setting.
Preamp model
Noise Gate Preamp controls
8

Press an effect button to navigate to it’s edit screen
Press this button again to toggle the effect on/off
Rotate the VALUE control to select an effect model
Press the VALUE control to highlight effect parameter
Rotate the VALUE control to adjust parameter settings
Press the PLAY button when you are finished editing to return to the PLAY screen. Don’t forget
to save your preset if you want to keep it.
EDITING PRESETS
EFFECT MODEL
PARAMETER VALUE
PARAMETER
9

SAVING PRESETS
Press the save button to enter the preset save screen
PRESET NUMBER
PRESET NAME
Rotate the VALUE control to select the target preset number. Press to accept
Enter your new preset name using the keypad. Press VALUE to select a character, rotate
VALUE to change it
Press the SAVE button to complete the saving procedure
Press the PLAY button to cancel saving
KEYPAD
10

PAIRING WIRELESS FOOTSWITCH
When the wireless footswitch is connected to SD30/SD75 It’s 4 footswitches
A, B, C, and D, directly mirror the functions of the PRESET buttons.
Ensure the SD amplifier is turned off
Press and hold footswitches C + D on the wireless controller
Power on the amplifier
Release the footswitches when the amplifier has finished booting up
Set WL-FS to ON in the SYSTEM SETTINGS
Preset
A B C D
11

JAM MODE
Your new SD amplifier is fully equipped with a 150 second looper and drum machine
which make fantastic tools for practice and solo performance. These features can be found in
JAM MODE.
When the wireless footswitch is connected to your shadow amp, the footswitches can be
used exactly the same way as the PRESET buttons to control the looper and drum machine.
Press B + C on the PRESET buttons or on your wireless footswitch to enter/exit JAM MODE
DRUM MACHINE
Select a drum pattern using the VALUE control
Set a tempo for your drum machine using the VALUE control or using PRESET D to
tap a tempo
Press PRESET C to start/stop the drum machine
If SYNC is set to ON, the drum machine will automatically begin when you start recording
with the LOOPER.
Synchronise drum
machine with looper
LOOPER playback
volume
LOOPER bar limit
DRUM pattern
DRUM playback
volume
DRUM tempo BPM
(beats per minute)
12

LOOPER
The looper in SD amps has 2 main operating modes. FREE LOOP and BAR LOOP.
FREE LOOP is exactly the same as our popular MICRO LOOPER. You can record and
overdub loops completely free of any tempo constraints.
RECORD – Press PRESET A to begin recording a loop
DUB – Press PRESET A during playback to toggle dub recording on/off and
add extra layers to your loop
STOP – Press PRESET B to stop playback of your loop
DELETE – Press and hold PRESET B to delete the loop currently in memory
PLAY- Press PRESET A to stop recording and immediately playback the
loop you just recorded. If the loop playback has been stopped but the loop
has not been deleted, you can also use this button to begin playback.
BAR LOOP restricts the length of the master loop to a set number of bars, depicted by the
LOOPER bar limit. This is useful because the drum will be in synchronization with your
loop and the count-in feature allows you to easily use the looper without the wireless
footswitch connected.
Set a tempo using the VALUE control or PRESET D
Set a LOOPER bar limit using the VALUE control
Press PRESET A to begin recording your master loop. The looper will count
you in for 1 bar before recording to make sure you are in time with the tempo
After the LOOPER bar limit has been reached, the looper will automatically
stop recording and
Record Play Dub Stop Delete
13

AUDIO PLAYBACK
SD amps have the ability to playback audio from your favourite external media device.
There are different ways to connect external devices with SD amps for music playback.
- AUX IN -
– BLUETOOTH CONNECTION –
Open the SYSTEM menu and select the button to turn on Bluetooth
Open your external device and ensure Bluetooth is active
Search for Bluetooth devices on your external device, your amp will appear
as “MOOER SDAMP”
Select “MOOER SDAMP” to connect to your SD amplifier
Control the playback volume from your external device
AUX IN
SYSTEM SETTINGS
Press the SYSTEM button to enter the system settings menu screen
Wireless footswitch
on/off
XLR OUT cab
sim on/off
Reset to factory
default settings
Bluetooth playback
connection on/off
Connect your external device to the AUX IN input using a 1/8” TRS stereo jack.
Control the playback volume from your external device.
14

SPECIFICATIONS
AMP MODELS: 25
EFFECTS BLOCKS: D S/OD MOD DELAY REVERB
EFFECTS: 8 9 5 6
LOOPER: 150 seconds
DRUM PATTERNS: 40
METRONOME: 10
PRESETS: 40
INPUT: 1 /4” mono audio jack
AUX IN: 1 /8” stereo audio jack
SEND/RETURN: 1/4” mono audio jack
LINE OUT: X LR (SD75)
HEADPHONE OUT: 1 /8” stereo audio jack
SPEAKER OUT: 8Ω-16Ω 30Watts 1/8” mono jack (unbalanced speaker cable)
8Ω-16Ω 75Watts 1/8” mono jack (unbalanced speaker cable)
POWER: 3 0 Watts (SD30)
75 Watts (SD75)
USB: T ype-B
POWER IN: 220V-240V AC 100V-120V AC
POWER FUSE: T500mA T1000mA
SPEAKER: 1 x 8" Custom 50W 8Ω Driver (SD30)
1 x 12" Custom 100W 8Ω Driver (SD75)
Dimensions: Sd30 > 420mm(L) x 217mm(D) x 368mm(H)
Sd75 > 570mm(L) x 275mm(D) x 465mm(H)
Weight: SD30: 8.3Kg
SD75: 16Kg
15

CN

DE

PT
