MORTEX E30A2D005AAA Guide

MORTEXPRODUCTSINCFORTWORTH,TX76106Page1
USERS INFORMATION MANUAL
DOWNFLOW For Installation In:
SINGLE AND TWO STAGE 1. Manufactured (Mobile) Home 2. Recreational Vehicle
ELECTRIC FURNACE 3. Modular Homes & Buildings 4. Residential Homes
MODELS: E30 SERIES LIST OF SECTIONS – USERS INFORMATION MANUAL
1 – General 1 4 – Start Up & Shutdown Instructions 4
2 – Safety 2 5 – Owner Maintenance 4
3 – Owners Information & Seasonal Information 3
LIST OF SECTIONS – SERVICE AND MAINTENANCE MANUAL
1 – Safety 7 5 – Trouble Shooting 11
2 – Furnace Maintenance 8 6 – Blower Performance 14
3 – Furnace Controls 9 7 – Accessories Parts 22
4 – Sequence of Operation 9 8 – Replacement Parts 23
LIST OF FIGURES
1 – Component Locations 3 11 – Time Delay Relay Terminal Designations 11
2 – Return Air Louvered Door 5 12 – X-13 Motor Terminal Locations 11
3 – Return Air Louvered Door Filter Locations 5 13 – Heater Relay Terminal Designations 12
4 – Coil Cabinet Top Pleated Filter Location 6 14 –
Blower Mounting Plate and Screw Locations 12
5 – 97 FG “A” Coil Hanging Filter Location 6 15 – Replacement Parts Drawing 1/3 HP PSC Motor 23
6 – Replacing The Coil Cabinet Front Door 6 16 – Replacement Parts Drawing 1/3 HP X-13 Motor 24
7 – Control Box Cover 8 17 – Replacement Parts Drawing 1/2 HP X-13 Motor 25
8 – Blower Assembly and Mounting Screw Location 8 18 – Replacement Parts Drawing 3/4 HP X-13 Motor 26
9 – Control Box and Blower Component Locations 9 19 - Replacement Parts Drawing 1/2 HP PSC Motor 27
10 - PSC Motor Speed Tap Isolation Relay 10 20 - Replacement Parts Drawing 3/4 HP PSC Motor 28
LIST OF TABLES
1 – X-13 Motor Terminal Connections 11 8 - Blower Performance 3/4 HP - PSC Motor 21
2 – Factory Speed Tap Settings 13 9 - Accessory Parts List 22
3 – Blower Performance 1/3 HP – PSC Motor 14 10 – Replacement Parts List 1/3 HP – PSC Motor 23
4 – Blower Performance 1/3 HP – X-13 Motor 15 11 – Replacement Parts List 1/3 HP – X-13 Motor 24
5-1 – Blower Performance 1/2 HP - X-13 Motor 16 12 – Replacement Parts List 1/2 HP – X-13 Motor 25
5-2 – Blower Performance 1/2 HP - X-13 Motor 17 13 – Replacement Parts List 3/4 HP - X-13 Motor 26
6 – Blower Performance 3/4 HP - X-13 Motor 18 14 – Replacement Parts List 1/2 HP - PSC Motor 27
7-1 – Blower Performance 1/2 HP - PSC Motor 19 15 – Replacement Parts List 3/4 HP – PSC Motor 28
7-2 – Blower Performance 1/2 HP - PSC Motor 20
CONTACT INFORMATION
Contact us by mail: Manufactured and Distributed by Mortex Products Inc.
501 Terminal Rd www.mortx.com
Fort Worth, TX 76106
SECTION I: GENERAL
The following list includes important facts and information regarding
the electric furnace and its inclusions.
1. Furnace is rated at 240 volts AC at 60 Hertz
2. Furnace is the same cabinet size for all models
3. All furnaces are equipped with a blower for A/C or Heat Pump
operation.
4. This furnace is designed for downflow and horizontal
application.
5. This furnace must not be operated without furnace door
installed.
NOTE: This furnace and its components listed on the A/C and Heat
Pump equipment sticker were listed in combination as a system by
ETL for the United States.
USERS MUST READ ALL INSTRUCTIONS IN THIS MANUAL AND
THIS MANUAL MUST BE SAVED FOR FUTURE REFERENCE
FIRE OR ELECTRICAL HAZARD
Failure to follow the safety warnings exactly could result in
serious injury, death, or property damage.
A fire or electrical hazard may result causing property
damage, personal injury or loss of life.
Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance

MORTEXPRODUCTSINCFORTWORTH,TX76106Page2
SECTION II: SAFETY
This is a safety alert symbol. When you see this symbol
on labels or in manuals; be alert to the potential for personal
injury.
Understand and pay particular attention to the signal words
DANGER, WARNING, or CAUTION.
DANGER: indicates an imminently hazardous situation, which
if not avoided, will result in death or serious injury.
WARNING: indicates a potentially hazardous situation, which if
not avoided, could result in death or serious injury.
CAUTION: indicated a potentially hazardous situation, which if
not avoided, may result in minor or moderate injury. It is also
used to alert against unsafe practices and hazards involving
property damage.
SAFETY REQUIREMENTS
1. This electric furnace must be kept clear and free of
combustible materials, gasoline and other flammable
vapors and liquids.
2. Insulating materials may be combustible. The furnace
must be kept free and clear of insulating materials. The
furnace area must be examined when installed in an
insulated space or when insulation is added to be sure that
the insulation material has been kept away from the
furnace.
3. Follow the instructions exactly as shown in Startup and
Shutdown Section in this manual to properly Startup or
Shutdown this appliance.
4. If overheating occurs, turn off the power to the furnace
and contact a qualified contractor, installer, or service
agency.
5. NEVER - Store flammable materials of any kind near
your furnace. Gasoline, solvents and other volatile liquids
should be stored only in approved containers outside the
home. These materials vaporize easily and are extremely
dangerous.
6. NEVER – Store cleaning materials such as bleaches,
detergents, powder cleaners, etc. near the furnace. These
chemicals can cause corrosion of the furnace sheet metal
and the electric heaters, the blower and the electrical
controls.
7. NEVER – Use the area around the furnace as a storage
area for items which could block or obstruct the normal
air flow to the furnace or the space around the furnace.
The flow of air is required for safe and proper operation.
Never block or obstruct air openings used for ventilation
and cooling of the furnace electrical components.
8. Refer to the furnace rating plate for the furnace model
number, for the operating specifications for safe
operation.
9. Provide clearances for servicing ensuring service access is
allowed for the control box, electric elements and the
blower.
10.Failure to carefully read and follow all instructions in this
manual can result in malfunction of the furnace, death,
personal injury, and/or property damage.
11.If the furnace is installed in a residential garage it must be
installed so that the electric heaters are located not less
than 18 inches above the floor and the furnace must be
located or protected to avoid physical damage by
vehicles.
Any adjustment, service or maintenance by the home owner
and/or user may create a condition where the operation of
the product could cause personal injury or property damage.
Only qualified service personnel, a contractor, or an installer
may refer to the service and maintenance section of this
manual for assistance or for additional information on this
appliance.
This product requires periodic routine maintenance and
cleaning of the exterior surfaces by the homeowner or user
to remove dust and debris. Any additional service must be
performed by qualified personnel. This appliance must be
serviced and maintained as specified in these instructions
and/or to any applicable local, state, and national codes
including, but not limited to building, electrical, and
mechanical codes.
FIRE OR ELECTRICAL HAZARD
Failure to follow the safety warnings exactly could result in
serious injury, death, or property damage.
A fire or electrical hazard may result causing property
damage, personal injury or loss of life.
Do not use this furnace if any part has been under water. A
flood damaged furnace is extremely dangerous. Attempts
to use the furnace can result in a fire.
A qualified contractor, installer, or service agency must be
contacted to inspect the furnace for any water damage and
replace all components, control system parts, or electrical
parts that have been damaged. If enough damage is
p
resent
,
the furnace ma
y
need to be re
p
lace
d

MORTEXPRODUCTSINCFORTWORTH,TX76106Page3
12.These instructions cover minimum requirements and
conform to existing national standards and safety codes.
In some instances these instructions exceed certain local
codes and ordinances, especially those who have not kept
up with changing mobile home, modular home and HUD
construction practices. These instructions are to be
followed and are the minimum requirement to perform
service or repairs on this appliance.
SECTION III: OWNERS INFORMATION
AND SEASONAL INFORMATION
How The Furnace Works
This furnace may be installed in the downflow position.
Figure 1 shows a typical model in the downflow position. The
furnace is equipped with a relay(s), time delay relay,
transformer, circuit breakers, and a blower assembly. The
transformer provides 24 VAC to the thermostat. When the
thermostat calls for heat the relay(s) energize sending 240
VAC thru the limit switches to the electric heaters causing
them to get hot. The indoor fan motor is then energized on the
low speed tap and the circulating blower draws cool air from
the living space(s), passes it across the heater coils and
circulates the warmed air through the duct work to the living
space(s). When the thermostat is satisfied the electric heaters
are de-energized. The blower is also de-energized and the
heating cycle has ended and the furnace is ready for the next
call for heat to start the next cycle.
The furnace is equipped with the controls necessary for proper
and safe operation. Circuit breakers and fuse location are
shown in Figure 1.
Examination of the furnace
The home owner should perform a visual examine the furnace
every month for any defects or problems. The items to be
inspected are:
1. The physical support of the furnace is sound without
sagging cracks, gaps, etc. around the base so as to provide
a seal between the support and the base.
2. The furnace casing for any obvious signs of deterioration
from rust or corrosion.
3. The return and supply duct connections are physically
sound and are sealed to the furnace casing.
4. The furnace must be serviced by qualified personnel
annually, preferably at the start of each heating season.
Figure 1: Circuit Breaker Locations
The Service Technician
The furnace’s best friend is a qualified service technician. If
the unit gives any indication of improper operation, call the
service technician. The service technician is allowed to
perform the normal routine care of your furnace. He can detect
potential problems and make corrections before trouble
develops. Preventative maintenance of this type will allow the
furnace to operate with minimal concerns to the homeowner
and will add years of comfort.
Warranty and Responsibilities
It is the sole responsibility of the homeowner to make certain
the furnace has been properly installed and adjusted to operate
properly.
The manufacturer warrants the furnace to be free from defects
in material or workmanship for a stated time in the warranty
agreement. The manufacturer will not be responsible for any
repair costs to correct problems due to improper setup,
improper installation, improper furnace adjustments, adding
parts that are not listed for use with this furnace, improper
operating procedures by the user or repairs performed by the
user / owner.
Some specific examples of service calls which will be
excluded from warranty reimbursement are:
1. Correcting faulty duct work in the home. This can be due
to not enough ducts or ducts are too small to provide
proper air flow through the furnace.
2. Correcting wiring problems in the electrical circuit to the
furnace.
3. Resetting circuit breakers or on/off switches used for
servicing.
4. Furnace problems caused by installation and operation of
any air conditioning unit, heat pump, or other air quality
devise which is not approved for use with this furnace.
5. Adjusting or calibrating the thermostat.
6. Problems caused by construction debris which has fallen
into the furnace.
7. Replacement of fuses.
8. Problems caused by dirty air filters.
9. Problems caused by restrictions in the return or supply air
flow causing low air flow.
FIRE OR ELECTRICAL HAZARD
Servicing heating/cooling equipment can be hazardous due
to electrical components.
Only trained and qualified personnel can service or repair
heating/cooling equipment. The home owner must never try
to perform service, repair or maintenance on this appliance.
Untrained service personnel can perform only basic
maintenance functions such as cleaning of exterior
surfaces and replacing the air filters.
Observe all precautions in the manuals and on the attached
labels when working on this appliance

MORTEXPRODUCTSINCFORTWORTH,TX76106Page4
The home owner should establish a firm understanding of
these responsibilities with the installer or service company so
there no misunderstanding at a later time.
While you are away
The furnace is equipped with safety shutoff devices which will
shut off the electric heaters in case of a malfunction. For this
reason it is never practical to assume the furnace will operate
unattended for a long period of time.
If you are planning to be away from home for a long period of
time have someone check on your home everyday, especially
when the outside temperatures will be below 35°F to ensure
the furnace is operating properly. This may prevent water
pipes from freezing.
The Furnace Fails to Operate Properly
If any abnormalities are observed while the furnace is
operating normally, perform the following checks:
1. Check the setting on the thermostat to make sure the
thermostat is set above the room temperature.
2. Check to see if the electrical power is turned on at the
circuit breakers at the main service circuit breaker box or
check any on/off switches that may be used for service
disconnect switches.
3. Check the 3 amp fuse on the inside of the control box to
determine if it has blown. A replacement fuse can be
purchased at where automotive fuses are sold.
4. Make sure the air filters are clean, return grilles are not
obstructed, and supply air registers are open.
If the cause of the malfunction is not obvious do not attempt to
service the furnace yourself. Call a qualified service
agency/company to repair the furnace.
When to Call For Service Assistance
Very often time can be saved if you give a service agency the
information about the furnace ahead of time. This will enable
the service agency to determine the specific components used
and possibly indentify the problem, thus arriving with the
parts to fix the problem.
SERVICE AGENCY INFORMATION
Fill in Below
COMPANY:
ADDRESS:
TELEPHONE (DAYTIME):
TELEPHONE (EMERGENCY)
NOTES:
SECTION IV: STARTUP AND SHUTDOWN
INSTRUCTIONS
Read the instructions below before trying to start the furnace.
A. BEFORE OPERATING; check around perimeter of the
BEFORE OPERATING; check around perimeter of the
furnace to make sure there are no flammable materials in
the area. If you smell vapors of any kind, DO NOT turn
on the power to the furnace until vapors have been
ventilated and removed from the area of the furnace.
B. CHECK THE FURNACE; visually check the furnace for
loose screws and/or panels that may be missing or have
fallen off.
C. CHECK DUCT CONNECTIONS; visually check the
connections of the ducts to the furnace to make sure there
are no gaps or holes and ducts are securely fastened to the
furnace.
Turn On / Start the Appliance
1. STOP! Read the safety information above before
proceeding.
2. Set the thermostat to the lowest setting.
3. Turn off all electrical power to the appliance at the main
service disconnect box.
4. Remove the upper and lower furnace door.
5. Turn off the circuit breakers on the appliance control box.
6. Remove the control box door.
7. Visually check the control box for loose wire connections
and faulty or loose components.
8. Visually check the blower compartment for obstructions
or loose debris.
9. Replace the control box door.
10. Turn the circuit breakers to the on position.
11. Replace the upper and lower furnace door.
12. Turn the circuit breakers in the main service disconnect
box to the on position.
13. Set the thermostat to the desired setting.
Shutting Down or Turning Off the Appliance
1. Set the thermostat to the lowest setting.
2. Turn off all electrical power to the appliance at the main
service disconnect box.
3. Remove the lower furnace door.
4. Turn off the circuit breakers on the appliance control box.
5. Replace the lower furnace door.
SECTION V: OWNER MAINTENANCE
All appliances need maintenance at the beginning of each
heating season in order to operate properly. The annual service
must be preformed by qualified service personnel. The
homeowner is expected to perform general cleaning of the
exterior surfaces, clean dust from the louvers in the return air
door and replacement of the air filters. Air filters must be
checked every month and replaced as needed. Figures 2 and 3
indicate the location of the air filters if you have a louvered
return air door.
Should overheating occur turn the circuit breakers on the
control box and the main electrical service entrance (Circuit
Breaker Box) to the off position. Call qualified service
personnel to troubleshoot and repair the furnace. DO NOT
allow the furnace to continue to cycle on the limit controls.
If you do not follow these instructions exactly, a fire may
result causing property damage, personal injury, and/or loss
of life.

MORTEXPRODUCTSINCFORTWORTH,TX76106Page5
Figure 2: Return Air Louvered Door Air Filter Location
Figure 3: Return Air Louvered Door 20” x 20” x 1” Air
Filters
Return Air Grille Air Filters
Follow these easy steps to replace the filters located in the
return air grille:
1. Follow the procedure “To Turn Off the Appliance” in
the Startup and Shutdown Instructions section of these
instructions.
2. Pull on the top of the return air louvered door (upper
door) until the door strike is removed from the door latch.
3. Let the top of the door fall towards you then lift up
slightly pulling towards you and set the door on the floor.
4. Turn the door upside down and pull the bottom frame out
of the door to gain access to the air filters.
5. Remove the air filters. These filters are disposable filters.
DO NOT attempt to clean the filters and reuse them.
6. Remove the new pleated air filters from the plastic wrap
they come in.
7. Slide the air filters in place in the door so both air filters
are installed as shown in Figure 3.
8. Replace the bottom door frame.
9. Lift the door up to the cooling cabinet and align the two
tabs on the bottom of the door with the two slots on the
center shelf. Refer to Figure 5.
10. Push the upper door forward until the strike on the cabinet
top flange has been inserted into the door latch on each
side the cabinet. Make sure the door is tight against the
cabinet. Refer to Figure 5.
11. Follow the instructions to “Turn On / Start the
Appliance” in the Startup and Shutdown section of these
instructions.
12. Follow the instructions to “Turn On / Start the
Appliance” in the Startup and Shutdown section of these
instructions.
Coil Cabinet Top Air Filters
Follow these easy steps to replace the filters located in the top
of the coil compartment:
1. Follow the procedure “To Turn Off the Appliance” in
the Startup and Shutdown Instructions section of these
instructions.
2. Pull on the top of either the return air louvered door
(upper door) or the solid door until the door strike is
removed from the door latch.
3. Let the top of the door fall towards you then lift up
slightly pulling towards you, then set the door on the
floor.
4. Remove the air filter at the top of the coil cabinet. The
20” x 24” x 1” filter is a disposable filter. DO NOT
attempt to clean the filter and reuse it. Refer to Figure 5
for filter location.
5. Remove the new 20” x 24” x 1” pleated air filter from the
plastic wrap they come in.
6. Slide the air filter into the filter rack at the top of the coil
cabinet as shown in Figure 5.
7. Lift the door up to the cooling cabinet and align the two
tabs on the bottom of the door with the two slots on the
furnace top cover. Refer to Figure 5.
8. Push the upper door forward until the strike on the cabinet
top flange has been inserted into the door latch on each
side the cabinet. Make sure the door is tight against the
cabinet. Refer to Figure 5.
9. Follow the “Turn On / Start the Appliance” in the
Startup and Shutdown Instructions section of these
instructions.

MORTEXPRODUCTSINCFORTWORTH,TX76106Page6
Figure 4: Coil Cabinet Top Return Pleated Air Filter
Location.
Figure 5: Reinstalling the Solid Coil Cabinet Door.
NOTE: Coil Filters are used with the 97-FG Frame and Grille
assemblies only.
Position filters over the coil as shown in Figure 6.
Homeowners must be instructed as to how to clean and
reinstall filters washable or replaceable filters for good
preventive maintenance. Care must be taken that the edges of
the washable or replaceable filter are resting on the protruding
edges of the metal plates at each end of the aluminum fins.
This allows a ½” gap between the filter and the coil surface to
prevent dirt from wicking from the filter to the coil.
Make sure the flow arrows on the air filter are pointing
towards the coil.
Figure 6: Replacing The Coil Cabinet Door.

MORTEXPRODUCTSINCFORTWORTH,TX76106Page7
SERVICE AND MAINTENANCE MANUAL
SECTION I: SAFETY
THE HOME OWNERS AND / OR APPLIANCE USERS
MUST STOP HERE!
This section has been designed to assist a qualified service
agency in performing service and maintenance on this
appliance.
The homeowners and/or the appliance user must never
attempt to perform any service or maintenance on the
appliance especially when it involves the removal or
adjustment of any parts and/or components.
The following safety rules must be followed when servicing
this furnace.
This is a safety alert symbol. When you see this symbol
on labels or in manuals; be alert to the potential for personal
injury.
Understand and pay particular attention to the signal words
DANGER, WARNING, or CAUTION.
DANGER: indicates an imminently hazardous situation, which
if not avoided, will result in death or serious injury.
WARNING: indicates a potentially hazardous situation, which if
not avoided, could result in death or serious injury.
CAUTION: indicated a potentially hazardous situation, which if
not avoided, may result in minor or moderate injury. It is also
used to alert against unsafe practices and hazards involving
property damage.
SAFETY REQUIREMENTS
1. This electric furnace may have a dual electrical supply
circuit. Make sure you check each electrical circuit with a
meter to be sure the power has been disconnected.
2. Insulating materials may be combustible. The furnace
must be kept free and clear of insulating materials.
3. Follow the instructions exactly as shown in Startup and
Shutdown Section in this manual to properly Startup or
Shutdown this appliance.
4. Make sure all moving parts have come to a complete stop
before attempting to perform any work once the furnace
door has been removed. Moving parts can cause serious
injury if clothing or body parts get caught in the moving
part.
The manufacturer or distributer will not be responsible for
any repairs due to improper parts changes, improper
maintenance, improper furnace adjustments or improper
modifications made by the homeowner and/or the appliance
user.
The manufacturer will not be responsible if the homeowner
and/or appliance user use this section of the instructions in
an attempt to perform maintenance or repairs to the furnace.
This practice is very dangerous and may result in a fire
causing property damage, personal injury, loss of life and/or
will void the appliance warranty.
Improper adjustment, service or maintenance may create a
condition where the operation of the product could cause
personal injury or property damage.
Refer to this manual for assistance or for additional
information consult the Technical Support Group.
This product must be serviced and maintained as specified
in these instructions and/or to any applicable local, state,
and national codes including, but not limited to building,
electrical, and mechanical codes.
FIRE OR ELECTRICAL HAZARD
Failure to follow the safety warnings exactly could result in
serious injury, death, or property damage.
A fire or electrical hazard may result causing property
damage, personal injury or loss of life.
ELECTRICAL SHOCK, FIRE HAZARD
Failure to follow the safety warnings exactly or
improper servicing could result in dangerous operation,
serious injury, property damage, and/or death.
Before servicing, disconnect all electrical power to the
furnace. Make sure you disconnect both power supplies
if the furnace has a dual power supply circuit. Dual
circuits may be used on the 8 kW, 10 kW, 12 kW,
15kW and 20kW furnaces.
When servicing controls, label all wires prior to
disconnecting to aid in proper reconnection of wires.
Verify proper operation after servicing by turning the
thermostat above the room temperature for a brief
period of time to ensure future furnace operation

MORTEXPRODUCTSINCFORTWORTH,TX76106Page8
SECTION II: FURNACE MAINTENANCE
The interior sections of the furnace must be cleaned and
adjusted by a qualified service contractor once a year or before
the start of each heating season. The following items must be
checked:
1. The blower wheel and motor for excessive dirt.
2. The electric heaters for wear, damage or corrosion.
3. The electrical components for excessive dust, dirt, wear,
or deterioration.
4. The supply air duct system for excessive dust, dirt or
debris
5. The return air duct system for excessive dust, dirt or
debris
6. All electrical wiring for wear, insulation cracks and/or
damage.
7. Check the air conditioning evaporator coil for dust, debris
or damage.
8. Check the evaporator coil drain pan for proper drainage to
prevent water backup into the furnace.
9. The furnace casing and all interior sheet metal panels or
dividers.
Furnace Cleaning Procedure
1. Follow the instructions exactly as shown in Startup and
Shutdown Section in this manual to properly shutdown
this appliance.
2. Remove the lower access door on the front of the furnace.
3. Remove the upper access door on the front of the
evaporator coil compartment.
4. Remove the screw on the right side of the control box
cover and remove the control box cover. Refer to Figure
8.
5. Remove the two screws on the right side of the blower
mounting plate and slide the blower out of the furnace.
Refer to Figure 9.
6. Use a vacuum cleaner and a small brush to remove any
dirt and debris from the blower compartment.
7. Check in the area below the blower compartment where
the heater elements are located and remove any dust, dirt
or debris from around the heater elements. Be careful not
to damage the heater elements with the vacuum hose or
the brush.
Figure 7: Control Box Cover
Figure 8: Blower Assembly and Mounting Screw Location
8. Check the blower wheel for dust and debris. Use the
brush and the vacuum cleaner to remove any dust or
debris from the wheel. Be careful not the move or
accidentally remove the blower wheel balance weight
located on the wheel blades. If it is moved or removed it
will cause the blower wheel to vibrate. If the wheel is
vibrating, you must replace it.
9. Check the blower motor for dust and debris. Be sure to
clean the openings on the motor housing as these
openings are used to cool the motor. If the dust, dirt or
debris has not been removed from these openings it will
cause the motor to run hotter than normal and will shorten
the life of the motor.
10. Check and clean with the brush and vacuum cleaner any
dust in the supply and return ducts as far as you can reach.
If these ducts look like they have an excessive amount of
dust, dirt or debris you should recommend to the home
owner or user to call a professional to properly clean the
duct system.
11. Check and clean any dust, dirt, or debris from all of the
controls and all of the surfaces in the control box. If dust
or dirt is left on the components they will operate at a
much hotter temperature causing premature component
failure.
12. Check the evaporator coil compartment for dirt, dust or
debris and remove any that exists.
FIRE HAZARD
NEVER PLACE A JUMPER BETWEEN “R” & “W”
Placing jumper wire between the RED and WHITE
thermostat wires at the furnace in order to override the
thermostat and energize the heater elements is an extremely
dangerous practice that can result in damage to the
thermostat, dangerous operation, serious injury, property
damage and/or death.

MORTEXPRODUCTSINCFORTWORTH,TX76106Page9
13. Check the evaporator condensate drain pan for any debris
and ensure the pan is properly draining by pouring water
into the drain to check it.
14. Remove any excess water that may have spilled from
checking the evaporator condensate drain.
15. Reinstall the blower assembly and secure the assembly
using the screws that was removed in step 5.
16. Reinstall the control box cover and secure it to the control
box with the screw that was removed in step 4.
17. Reinstall the lower access door on the furnace.
18. Reinstall the upper access door on the front of the
evaporator coil compartment.
19. Follow the instructions exactly as shown in Startup and
Shutdown Section in this manual to properly startup this
appliance.
SECTION III: FURNACE CONTROLS
This section discusses the furnace controls and how they
operate. Refer to Figure 10 for component locations.
1. The Limit Controls – Each electric heater element has a
limit control directly in front of it to sense overheating of
the element and open if the temperature gets above the set
point of the limit control.
2. The Heater Relays – The electric heater relays simply
turn the heater elements on and off. The relays are
controlled by the thermostat. On a call for heat 24 VAC is
sent to the relay(s) 24 VAC coil energizing the relay.
When the call for heat has been satisfied the 24 VAC is
removed from the relays 24 VAC coil de-energizing the
relay(s).
3. Cooling Time Delay Relay (TDR) – The cooling relay is
used only when 24 VAC is on the “G” terminal from the
thermostat. The relay controls the blower on time delay
and is adjustable from 0 – 30 seconds. The factory setting
is approximately 13 seconds.
4. Circuit breakers – The circuit breakers are designed as
over-current protection for the electric heaters only. The
circuit breakers MUST NEVER be used for over-current
protection for the transformer, 24 VAC circuit, or the
blower motor.
5. 3 Amp Fuse – This fuse is used for over-current
protection of the 24 VAC circuit.
6. Transformer – The transformer is used to step down
voltage from 240 VAC to 24 VAC. The transformer
provides the required 24 VAC for the system control
circuit.
7. Blower Motor Isolation Relay - This relay is used to
load the TDR when using an X-13 motor or for isolation
between the high and low speeds of a PSC motor. The
wiring has been designed so that the normally closed
contacts are used for heating and the normally open
contacts are used for cooling. The relay coil is energized
after the thermostat has a call from the “G” terminal
starting the time delay cycle on the time delay relay. Once
the time delay relay has reached the delay setting the relay
contacts close energizing the isolation relay coil. The
normally closed contacts on the isolation relay open and
the normally open contacts close, energizing the motor on
the selected cooling speed.
X-13Motor Isolation Relay - This relay is used on the X-13
motor as a load for the time delay relay so the relay will
operate properly. The wiring has been designed so that the
normally closed contacts are used for heating and the normally
open contacts are used for cooling. The relay coil is energized
after the thermostat has a call from the “G” terminal starting
the time delay cycle on the time delay relay. Once the time
delay relay has reached the delay setting the relay contacts
close energizing the isolation relay coil. The normally closed
contacts on the isolation relay open and the normally open
contacts close, energizing the motor on the selected cooling
speed.
SECTION IV: SEQUENCE OF OPERATION
Continuous Blower
The thermostat has a manual fan switch that can be moved to
the “On” position or it can be programmed for continuous fan
operation. This setting causes the thermostat to complete the
circuit between “R” and “G” terminals causing the time delay
relay to start the time delay cycle. Once the time delay relay
has completed the on-delay cycle the contacts will close
sending voltage to the isolation relay coil. The isolation relay
will close the normally open contacts (Terminals #2 and #4)
sending voltage to selected indoor blower motor speed tap
connected to terminal #4. The normally closed contacts
(Terminals #5 and #6) will open.
The indoor blower will operate continuously until the fan
switch on the thermostat has been switched from on to auto.
Figure 9: Component Locations
Intermittent Blower - Cooling
The thermostat has a manual fan switch that can be moved to
the “Auto” position or it can be programmed for auto fan
operation. When the thermostat calls for cooling, a circuit is
completed between the “R”, “Y” and “G” Terminals. The
indoor fan motor is energized from the “G” terminal on the
thermostat causing the time delay relay to start the on-time

MORTEXPRODUCTSINCFORTWORTH,TX76106Page10
delay. The time delay relay contacts will close the circuit to
the isolation relay coil after the on- delay is complete. The
isolation relay normally open contacts (Terminals #2 and #4)
will close and the motor will operate on the selected speed tap
that has been placed on terminal #4.
When the thermostat is satisfied the circuit between “R”, “Y”
and “G” will open. The time delay relay will open the circuit
to the isolation relay and the PSC blower motor will turn off.
The X-13 blower motor will have a 13 second off-delay. The
blower is now in the standby mode waiting for the next
cooling cycle
The Heating Cycle
When the thermostat is in the HEAT mode and the fan switch
on the thermostat is set to AUTO. The call for heat closes the
thermostat circuit between the “R” and “W” terminals. 24
VAC is sent from the “W” terminal, through the white
thermostat wire to the white pigtail wire on the furnace. 24
VAC is sent through the white pigtail wire to the 24 VAC coil
on the first heater relay. This signal energizes the heater relays
closing the contacts to the heaters. The blower low speed wire
is also connected to the first heater relay so the blower is
energized at the same time as the heater. The blower will
continue to operate until the thermostat is satisfied. When the
call for heat has been removed the “W” terminal is de-
energized and the heater relay opens turning off the heater and
the PSC blower motor. The X-13 blower motor will have a 13
second off-delay. The furnace is now in standby mode waiting
for the next heating cycle.
Some models have a black pigtail wire that is connected to the
24 VAC coil on the second heater relay. This pigtail wire is to
be used for second stage heat. It is connected to the thermostat
“W2” terminal. You must have a thermostat that has the
second stage heating feature “W2”. The second stage heat
cycle is enabled when the room temperature typically falls
more than 3 degrees below the thermostat set point. The
thermostat energizes the second heater to aid in heating the
room back to the thermostat set point. Once the room is within
1 degree of the thermostat set point the second stage heater is
de-energized until the thermostat calls for second stage heat
“W2” again.
The Cooling Cycle
When the thermostat calls for cooling
The thermostat closes the circuit between the “R”, “Y” and
“G” terminals. 24 VAC is sent from the “Y” terminal through
the yellow thermostat wire to the 24 VAC coil terminal on the
condenser contactor; energizing the contactor and starting the
compressor and outdoor fan motor. At the same time the “G”
terminal is sending 24 VAC through the green pigtail wire to
the indoor blower time delay relay. The time delay relay goes
through an 0-30 second on-delay, and then closes the contacts
sending 24 VAC to the isolation relay coil ( Terminals #1 and
#3). The isolation relay coil is energized closing the normally
open contacts (Terminals #2 and #4) and opening the normally
closed contacts (Terminals #5 and #6) sending 24 VAC to the
selected X-13 motor speed tap wire connected to isolation
relay terminal #4 or for PSC motors; sending 240 VAC to the
selected speed tap wire connected to isolation relay terminal
#4.
When the thermostat call for cooling has been satisfied the
thermostat opens the circuit between the “R”, “Y” and “G”
terminals. The 24 VAC signal is removed from the thermostat
“Y” terminal de-energizing condenser contactor. At the same
time the “G” terminal 24 VAC is removed from the green
pigtail wire de-energizing the TDR. The X-13 motor goes
through a 13 second off delay; then stops. The PSC motor
does not have a delay; so it stops. The cooling cycle is
complete, and the cooling unit is ready for the start of the next
cooling cycle.
The Motor Isolation Relay
This relay is used in conjunction with the motors to prevent
the possibility of the motors being energized on two speed
taps at the same time. This condition would burn out the motor
windings.
A black wire is connected from the circuit breaker to the
supply side of the normally open terminals on the relay. The
blower motor high speed tap wire is connected to the load side
(Terminal #4) normally open terminal on relay.
A red wire is connected from the heat relay to the normally
closed terminal on the relay. The load side (Terminal #6) of
the normally closed terminal is connected to the low speed tap
blower motor.
Figure 10: Motor Speed Tap Isolation Relay
For personal safety be sure to turn the electrical power
“OFF” at the main entrance (Circuit Breaker Box) and at the
control box circuit breakers before attempting any service or
maintenance operations. Home owners should never attempt
to perform any maintenance which requires opening the
furnace control box door.

MORTEXPRODUCTSINCFORTWORTH,TX76106Page11
SECTION V: TROUBLE SHOOTING
The following checks should be made before trouble shooting
the furnace controls for a no heat issue.
1. Check all of the circuit breakers. Make sure they are
turned to the “ON” position and have not tripped.
2. Check all fuses, especially the 3 amp fuse on the top right
side of the control box. If the fuse is blown, check the
wiring with an OHM meter for a short to ground. If
shorted, repair the short, and then replace the fuse.
3. Check any electrical switches that are external to the
furnace to make sure they are turned on.
4. Check all wiring connections, especially on any of the
components, to ensure they are securely fastened.
If you have 240 VAC coming out of the control box circuit
breakers and you have 24 VAC between the load side if the 3
amp fuse and ground, then continue on through the rest of the
checks.
X-13 Motor Check – Heating Mode
1.If the motor is not running, check for 240 VAC and 24
VAC at the motor terminals. If the 240 VAC and 24 VAC
is present at the motor terminals but the motor is not
operating, then replace the motor. Refer to Figure 12 and
Table 1 for terminal locations and definitions.
A. If 240 VAC is not present at the motor check for a
broken wire between the circuit breaker and the
motor.
B. If 240 VAC is present at the motor terminals continue
to the next check.
2. If 24 VAC is not present at the motor check for 24 VAC
across the heater relay coil.
A. If 24 VAC is present at the heater relay coil, the wire
going to the motor is bad and needs to be replaced.
B. If 24 VAC is not present at the heater relay coil check
the thermostat “W” circuit wire connections and the
thermostat.
X-13 Motor Check – Cooling Mode
1. If the motor is not running, check for 240 VAC and 24
VAC at the motor terminals.
A. If the 240 VAC and 24 VAC is present at the motor
terminals but the motor is not operating, then replace
the motor. Refer to Figure 12 and Table 1 for
terminal locations and definitions.
B. If 240 VAC is not present at the motor check for a
broken wire between the circuit breaker number one
and the motor.
C. If 240 VAC is present at the motor terminals continue
to the next check.
2. If 24 VAC is not present at the motor speed tap terminals;
check for 24 VAC at terminal #1 on the TDR
A. If 24 VAC is present at terminal #1, the wire going
to the motor is bad and needs to be replaced.
B. If 24 VAC is not present at terminal #1 check
terminal #3.
C. If 24 VAC is present at the terminal #3 replace the
TDR.
13
LOAD
1.5 AMP
MAX
CUT WIRE FOR 120/240VAC
.4 15
30 SECONDS
MADEIN
THE USA
ICM
HMPS00C2X30
DELAYON
MAKE
TIMER
CONTROLS
INPUT
19-240
VAC
Figure 11: Time Delay Relay (TDR) Terminals
Figure 12: X-13 Motor Terminals
Terminal Connection
CSpeedTapCommon‐24VACCommon
L SupplyVoltagetoMotor‐240VACLine1
G GroundConnection
N SupplyVoltagetoMotor‐240VACLine2
1LowSpeedTap‐24VAC
2Med‐LowSpeedTap‐24VAC
3MediumSpeedTap‐24VAC
4Med‐HighSpeedTap‐24VAC
5HighSpeedTap‐24VAC
Table 1: X-13 Motor Terminal Connections
Heater Element Is Not On
Check for 240 VAC between each of the heater elements. If
240 VAC is present, check the current draw on each heater. If
there is 200 – 250 VAC across the heaters but a heater is not
drawing the proper current or is showing almost no current
draw check the limit for that heater. If the limit is good but
there still is no current flow then, check to see if the heater is
defective.
The heater amps are as follows:
4 kW Heater = 16.7 amps
5 kW Heater = 20.8 amps
6 kW Heater = 25.0 amps
The heater design is as follows:
To avoid personal injury or property damage, make certain
that the motor leads cannot come into contact with non-
insulated metal com
p
onents of the unit.

MORTEXPRODUCTSINCFORTWORTH,TX76106Page12
The 5 kW model has one 5 kW heater element.
The 8 kW model has one heater with two 4 kW elements.
The 10 kW model has one heater with two 5 kW elements
The 12 kW model has one heater two 6 kW elements.
The 15 kW model has one heater with two 5 kW elements (top
heater) and one heater with one 5 kW element (bottom
heater).
The 17 kW model has one heater with two 6 kW elements (top
heater) and one heater with one 5 kW element (bottom
heater).
The 20 kW model has one heater with two 5 kW elements (top
heater) and one heater with two 5 kW elements (bottom
heater).
If 240 VAC is not present at the heater element but there is
240 VAC present between the load terminal of the heater relay
and L2 then check the limit control for an open limit and
replace the open limit control.
If 240 VAC is not present at the heater element or between the
load terminal of the heater relay and L2 but is present between
the line terminal of the heater relay and L2; then, replace the
heater relay.
DP - Double Pole Contactor
Figure 13: Heater Contactor Terminal Designations
Blower Motor FLA
1/3 HP X-13 Motor – 2.0
1/2 HP X-13 Motor – 4.1
3/4 HP X-13 Motor – 6.0
Replacing the Blower
1. Follow the instructions exactly as shown in Startup and
Shutdown Section in this manual to properly shutdown
this appliance.
2. Remove furnace lower front door and switch furnace
circuit breaker(s) to “OFF”.
3. Disconnect the plastic wire plug that has the wires that
goes to the motor terminals from the top right side of the
control box.
4. Remove the two screws on the right side of the blower
mounting plate.
5. Slide the blower out of the blower compartment and set
on the floor.
6. Remove the wires from the terminals. Be sure to write
down the motor terminal identifier and wire color so the
wires do not get mistakenly placed on the wrong
terminals.
7. Remove the blower housing from the mounting bracket
by removing the screws on the sides of the blower that
secure the blower to the bracket.
8. Insert the new blower housing into the blower mounting
bracket and secure to the bracket with the screws.
9. Connect the wires to the motor terminals so the wires are
connected to the same terminals on the new motor as they
were on the previous motor.
10. Slide the blower assembly into the blower deck and insert
the two screws on the right side of the mounting bracket.
11. Connect the pin plug to the pin plug on the top right side
of the control box.
12. Switch the circuit breakers to ON and replace furnace
front door.
13. Follow the instructions exactly as shown in Startup and
Shutdown Section in this manual to properly startup this
appliance.
14. Set the thermostat to the desired temperature.
Figure 14: Blower Mounting Plate Screw Locations
To avoid personal injury take precautions not come into
contact with non-insulated electrical components.
Avoid wearing loose clothing or any items that can come in
contact with moving parts, such as the blower wheel. .This
can cause serious personal injury

MORTEXPRODUCTSINCFORTWORTH,TX76106Page13
Series Model Sp Tap Nom-Tons CFM Coil Range (See Coil Face Velocity Chart Below) Max kW Blower Setting
E30A2DxxxAAA Low 2.0-2.5 950 12
or Med 2.5-3.0 1100 15
E30A2DxxxABB High 3.0-3.5 1400 20 Factory Setting High
T-1 1.5 580 5
T-2 2.0 750 8
or T-3 2.5 925 8
T-4 3.0 1120 10
T-5 3.5 1300 12 Factory Setting T-5
T-1 2.0 800 12
T-2 2.5 950 15
or T-3 3.0 1120 15
T-4 3.5 1260 17 Factory Setting T-4
T-5 4.0 1380 20
T-1 3.0 1080 17
T-2 3.5 1300 20
or T-3 4.0 1440 20 Factory Setting T-3
T-4 4.0 1520 20
T-5 5.0 1680 20
E30A2**** 1/2 HP PSCMotor
E30B3**** 1/3 HP X-13 Motor
E30B4**** 1/2 HP X-13 Motor
E30B5**** 3/4 HP X-13 Motor
(+) Metering device, Piston, TXV Voltage Correction < 240V
(++) Refrigerant Connection, 0P, 2P, 3P, 4P or 6P .96 =230 Volts
xxx Designates Kilowatts, 015 = 15kW .92 =220 Volts
CFM Shown with Dry Coil and Filter in place, Wet Coil Correction 4-6% .87 =208 Volts
Coil Series CFM Face Area Nominal FPM Coil Models(See Note Below) Max FPM Note
750 3.11 242 96-8(Z,5,G,8,W)2(+)-(++)P 300
925 3.32 279 96-(R,M)(2,3,4)4(+)-(++)P 300
1120 3.56 315 96-8(Z,2,3,4,5,G,8,W)(3,5)(+)-(++)P 320
1300 4.06 321 96-(8,R,M)(Z,2,3,4,5,G,8,W)(4,6)(+)-(++)P 325
97-Series 1380 4.44 311 97-(8,R,M)(Z,2,3,4,5,G,8,W)(5,7)(+)-(++)P 325
1440 5.33 270 98-(8,R,M)(Z,2,3,4,5,G,8,W)(7,10)(+)-(++)P 330
1520 5.78 263 98-(8,R,M)(Z,2,3,4,5,G,8,W)(8,11)(+)-(++)P 330
1520 6.22 245 98-(8,R,M)(Z,2,3,4,5,G,8,W)(9,12)(+)-(++)P 330
1680 6.67 252 98-(8,R,M)(Z,2,3,4,5,G,8,W)(10,13)(+)-(++)P 330
1680 7.11 237 98-(8,R,M)(Z,2,3,4,5,G,8,W)(11,14)(+)-(++)P 330
1680 7.56 223 98-(8,R,M)(Z,2,3,4,5,G,8,W)(12,15)(+)-(++)P 330
1680 8.00 210 98-(8,R,M)(Z,2,3,4,5,G,8,W)(13,17)(+)-(++)P (See Example) 330
CFM = (kW x 3412) x (Voltage CorrectionLess Than240V) x 1.08 /TR
E30B3DxxxAAA
ElectricFurnace temperature rise (TR)can be used to determine airflow delivered.This resultcan then be
used to determine FPMvelocityacross the coil face area using the chart below. Set Furnace (Isolate the
HeatPump,justoperate the Furnace) to run all the heater strips and then check return air and supplyair
temperature.Make sure all strips are operating.The difference is the TR
Note: When setting up the speed tap on the E30B furnaces with the X-13 motor the coil face area must be taken into account so asnot to exceed
330 Feet Per Minute of air across the coil. Anything higher will blow water off the coil and will be the responsibility of the installing contractor.
Air Velocity Formula: CFM / Coil Face Area = Air FPM. Example of Coil Complete Model # 98-8G13Y-0P.
98-Series
WARNING
Exceeding these
nominal and / or
maximum allowances
may cause water blow
off from the coil, which;
may damage furnace,
void furnace warranty
and limit liability from
those damages
Coil Face Velocity Formula & Maximum Allowances when using the X-13 Motor
96-Series
Example:CFM= (15kWx3412) x.96 x1.08 /56 TR
51180 x.96 x1.08 /56 =948 CFM
E30B3DxxxABB
E30B4DxxxAAA
E30B4DxxxABB
E30B5DxxxAAA
E30B5DxxxABB
Factory Speed Tap Settings @ .3 ESP with Filter and Coil
96-Series, 97-Series, 98-Series
96-Series, 97-Series, 98-Series
96-Series (Do Not use T-5 w/96-),
97-Series, 98-Series
98-Series only
Table 2: Factory Speed Tap Settings

MORTEXPRODUCTSINCFORTWORTH,TX76106Page14
SECTION VI: BLOWER PERFORMANCE
SPDTAP
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9
1
LO
1042 1036 1030 1024 1018 1006 911 708 542 386
MEDIUM
1210 1205 1199 1194 1189 1137 1036 769 601 427
HI
1550 1498 1427 1357 1273 1169 1048 924 704 526
CFMwithCoil98‐8Z7W‐OPLO
982 976 970 964 951 898 721 609 511 357
withCabinet97‐FLSB‐27MEDIUM
1196 1190 1180 1149 1100 1037 951 680 569 405
or97‐FLSF‐27 HI
1509 1440 1371 1285 1203 1133 880 792 684 482
CFMwithCoil98‐8Z7W‐OPLO
1011 1008 994 965 916 758 669 588 447
withCabinet97‐FSOB‐27 MEDIUM
1215 1189 1153 1104 1040 973 739 639 511 377
HI
1455 1394 1326 1260 1184 1081 852 703 585 441
CFM‐WITH‐Coil98‐8G7W‐OPLO
955 952 949 946 928 890 724 648 532 364
withCabinet97‐FLSB‐27 MEDIUM
1175 1170 1164 1143 1100 1025 964 716 558 405
or97‐FLSF‐27 HI
1536 1463 1403 1328 1249 1155 1075 900 716 493
CFMwi thCoil98‐8G7W‐OPLO
1010 1013 1001 975 930 874 688 587 463 363
withCabinet97‐FSOB‐27 MEDIUM
1205 1184 1153 1110 1048 975 751 640 496 367
HI
1553 1482 1407 1328 1244 1154 1039 747 608 438
CFMwi thCoil96‐8G4W‐OPLO
964 961 958 952 928 881 708 609 470 355
withCabinet97‐FLSB‐21MEDIUM
1195 1185 1154 1122 1072 1013 820 680 556 405
or97‐FLSF‐21 HI
1535 1479 1407 1331 1250 1180 1094 812 658 487
CFMwithCoil96‐8G4W‐OP LO
1005 999 979 943 881 758 641 561
wi thCabinet97‐FSOB‐21 MEDIUM
1197 1163 1113 1060 999 916 708 633 490 367
HI
1418 1352 1292 1213 1119 1062 946 698 549 409
EXTERNALSTATICPRESSURE(ESP)INCHESWCDUCT
CFM‐NO‐COIL
Table 3: Blower Performance -10 X 9 Morrison Wheel - 1/3 HP 3 SPD PSC Motor (With Air Filters)

MORTEXPRODUCTSINCFORTWORTH,TX76106Page15
SPDTAP
0.10.20.30.40.50.60.70.80.9 1
LO
935 763 680 560 498 437 347
MED‐LO
968 881 810 756 680 566 531 446 382
MEDIUM
1074 1022 953 904 842 789 663 623 565 475
MED‐HI
1192 1131 1079 1042 971 914 862 748 697 519
HI
1429 1372 1327 1285 1227 1176 1128 1072 941 602
LO
813 742 655 596 490 436 349
MED‐LO
913 864 806 742 673 593 521 438 379
MEDIUM
1050 990 939 885 843 813 726 642 568 471
MED‐HI
1150 1096 1082 1002 958 913 857 806 737 533
HI
1360 1314 1267 1227 1182 1134 1096 1002 885 564
CFMwithCoilLO
745 689 595 513 453 393 323
98‐8Z7W‐OPMED‐LO
859 800 745 641 581 527 458 401 384
withCabinet MEDIUM
978 926 872 832 721 655 600 563 514 420
97‐FLSB‐27MED‐HI
1066 1023 965 923 875 793 709 655 596 439
or97‐FLSF‐27 HI
1276 1237 1197 1150 1117 1061 977 798 668 500
CFMwithCoilLO
721 655 556 490 462 382 321
98‐8Z7W‐OPMED‐LO
832 775 717 623 556 528 470 404 352
withCabinet MEDIUM
939 898 845 793 701 633 623 559 502 413
97‐FSOB‐27 MED‐HI
1037 994 956 901 832 752 697 655 554 453
HI
1231 1178 1146 1101 1058 1003 832 741 615 466
LO
764 689 586 507 460 399 332
MED‐LO
855 807 733 632 571 521 478 416 367
MEDIUM
990 923 878 825 741 672 628 574 520 440
MED‐HI 1085 1031 988 929 878 789 725 663 603 474
HI 1291 1247 1202 1160 1117 1073 1020 821 665 524
CFMwithCoilLO
721 655 566 507 451 374 315
98‐8G7W‐OPMED‐LO
828 756 705 623 561 529 462 404 359
withCabinet MEDIUM
948 898 845 778 705 641 595 553 502 406
97‐FSOB‐27 MED‐HI
1048 1003 965 907 851 771 701 637 562 431
HI
1252 1227 1166 1139 1090 1026 871 709 618 466
CFMwithCoilLO
731 634 577 473 368 394 290
96‐8G4W‐OPMED‐LO
827 754 703 629 530 520 457 383 312
withCabinet MEDIUM
937 870 812 769 698 620 590 540 474 403
97‐FLSB‐21MED‐HI
1030 967 919 877 816 784 673 615 591 472
or97‐FLSF‐21 HI
1230 1194 1136 1086 1046 998 947 784 634 500
CFMwithCoilLO
731 678 587 503 458 398 333
96‐8G4W‐OPMED‐LO
848 792 739 630 562 527 483 419 387
withCabinet MEDIUM
956 913 868 820 719 657 597 572 524 447
97‐FSOB‐21 MED‐HI
1051 1012 962 923 875 766 711 661 603 458
HI
1251 1216 1169 1132 1093 1053 986 770 643 510
EXTERNAL STATIC PRESSURE (ESP) INCHES WC DUCT
CFM‐NO‐COIL‐
OPENTOP,
SOLIDDOOR
CFM‐WITH‐Coil
98‐8G7W‐OP
with97‐FLSB‐27
or97‐FLSF‐27
CFM‐NO‐COIL‐
SOLIDTOP,
LOUVERED
DOOR
Table 4: Blower Performance -10 X 9 Morrison Wheel - 1/3 HP 5 SPD X-13 Motor (With Air Filters)

MORTEXPRODUCTSINCFORTWORTH,TX76106Page16
SPDTAP
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
LO
984 922 851 799 740 604 578 497 423 365
MED‐LO
1149 1096 1051 995 933 870 795 891 658 604
MEDIUM
1397 1344 1293 1250 1200 1148 1105 1048 982 699
MED‐HI
1630 1584 1533 1493 1443 1392 1352 1258 1136 702
HI
1736 1712 1661 1612 1570 1515 1432 1321 1184 704
CFMwithCoilLO
875 818 764 718 611 558 507 455 419 372
98‐8G7W‐OPMED‐LO
1027 996 952 897 858 752 688 634 615 497
withCabinet MEDIUM
1241 1212 1176 1129 1090 1051 997 867 713 545
97‐FLSB‐27MED‐HI
1440 1411 1371 1328 1285 1232 1155 1062 734 593
OR97‐FLSF‐27 HI
1546 1506 1474 1415 1349 1270 1186 1079 702 603
CFMwithCoilLO
845 811 753 682 611 563 522 467 407 364
98‐8G7W‐OPMED‐LO
1032 990 949 897 838 800 730 677 607 477
withCabinet MEDIUM
1238 1191 1155 1107 1068 1033 991 809 660 492
97‐FSOB‐27 MED‐HI
1419 1380 1340 1294 1217 1145 1068 839 665 486
HI
1506 1445 1389 1313 1241 1166 1079 824 646 483
CFMwithCoilLO
884 817 771 722 616 568 536 472 417 380
98‐8W7W‐OPMED‐LO
1040 984 955 893 864 756 698 656 630 494
withCabinet MEDIUM
1251 1216 1170 1134 1079 1045 1009 860 685 570
97‐FLSB‐27MED‐HI
1450 1410 1380 1335 1303 1221 1139 1056 737 580
or97‐FLSF‐27 HI
1549 1506 1457 1410 1335 1246 1165 1056 741 648
CFMwithCoilLO
878 811 771 714 625 558 536 478 417 377
98‐8W7W‐OPMED‐LO
1035 981 943 891 852 797 702 652 609 474
withCabinet MEDIUM
1223 1190 1151 1111 1072 1018 940 842 647 523
97‐FSOB‐27MED‐HI
1422 1378 1325 1262 1159 1062 983 868 665 523
HI
1478 1416 1338 1277 1174 1095 992 845 657 513
CFMwithCoilLO
897 842 796 733 619 566 522 470 408 361
98‐8W12W‐OPMED‐LO
1054 1013 961 925 874 798 680 623 572 533
withCabinet MEDIUM
1281 1237 1202 1154 1111 1071 1012 902 723 613
97‐FLSB‐39MED‐HI
1478 1453 1414 1374 1333 1271 1191 1094 752 596
or97‐FLSF‐39 HI
1581 1522 1477 1421 1350 1270 1180 1070 777 657
CFMwithCoilLO
885 825 763 704 612 553 522 459 392 357
98‐8W12W‐OPMED‐LO
1043 986 941 891 858 735 687 630 573 504
withCabinet MEDIUM
1240 1178 1139 1100 1076 1013 945 800 679 520
97‐FSOB‐39MED‐HI
1456 1404 1359 1322 1256 1190 1087 845 712 535
HI
1550 1485 1426 1355 1294 1221 1104 874 735 534
EXTERNALSTATICPRESSURE(ESP)INCHESWCDUCT
CFM‐NO‐COIL
Table 5-1: Blower Performance -10 X 9 Morrison Wheel - 1/2 HP 5 SPD X-13 Motor (With Air Filters)

MORTEXPRODUCTSINCFORTWORTH,TX76106Page17
SPDTAP
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
CFMwithCoilLO
884 824 774 692 595 560 507 460 391 360
98‐8G12W‐OPMED‐LO
1035 992 954 893 844 783 692 640 545 474
withCabinet MEDIUM
1250 1211 1170 1127 1083 1037 982 834 675 520
97‐FLSB‐39MED‐HI
1449 1415 1376 1345 1289 1218 1127 884 708 535
or97‐FLSF‐39 HI
1547 1511 1462 1402 1326 1245 1159 976 724 531
CFMwithCoilLO
862 817 752 672 619 560 525 458 395 381
98‐8G12W‐OPMED‐LO
1013 967 925 887 824 744 692 636 563 435
withCabinet MEDIUM
1209 1173 1125 1098 1050 1000 865 748 578 484
97‐FSOB‐39MED‐HI
1415 1376 1321 1255 1175 1099 924 767 609 479
HI
1478 1428 1362 1279 1195 1110 915 755 600 484
CFMwithCoilLO
899 837 784 724 609 570 519 455 388 360
98‐8Z12W‐OPMED‐LO
1040 1004 964 909 851 751 700 640 616 493
withCabinet MEDIUM
1258 1235 1185 1143 1099 1060 1000 848 704 533
97‐FLSB‐39MED‐HI
1484 1441 1393 1353 1316 1245 1137 1012 679 551
or97‐FLSF‐39 HI
1570 1531 1488 1415 1344 1279 1170 1070 736 562
CFMwithCoilLO
851 813 759 708 618 555 523 458 394 362
98‐8Z12W‐OPMED‐LO
1021 982 934 884 837 740 684 636 573 452
withCabinet MEDIUM
1210 1170 1138 1092 1052 999 922 751 613 469
97‐FSOB‐39MED‐HI
1419 1385 1344 1279 1210 1083 1010 774 621 480
HI
1503 1458 1393 1312 1230 1103 1019 785 629 486
CFMwithCoilLO
856 795 740 680 572 536 502 450 398 358
96‐8W4W‐OPMED‐LO
1002 965 920 866 819 712 650 619 630 502
withCabinet MEDIUM
1204 1163 1128 1093 1048 1007 952 785 667 581
97‐FLSB‐21MED‐HI
1383 1364 1332 1291 1248 1184 1099 837 696 528
or97‐FLSF‐21 HI
1468 1458 1424 1368 1300 1219 1126 1019 700 536
CFMwithCoilLO
816 775 708 672 557 557 507 444 398 357
96‐8W4W‐OPMED‐LO
988 926 876 836 791 692 633 630 596 423
withCabinet MEDIUM
1163 1114 1087 1038 1002 959 895 680 653 477
97FSOB‐21MED‐HI
1355 1323 1281 1224 1147 1081 977 736 653 483
HI
1433 1381 1314 1243 1166 1082 989 740 656 493
EXTERNALSTATICPRESSURE(ESP)INCHESWCDUCT
Table 5-2: Blower Performance -10 X 9 Morrison Wheel - 1/2 HP 5 SPD X-13 Motor (With Air Filters)

MORTEXPRODUCTSINCFORTWORTH,TX76106Page18
SPDTAP
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
LO
1225 1174 1121 1077 1036 976 924 877 740 629
MED‐LO
1429 1386 1345 1308 1245 1220 1158 1115 1070 608
MEDI UM
1569 1529 1476 1438 1403 1368 1313 1260 1109 707
MED‐HI
1785 1740 1711 1664 1619 1592 1488 1359 1137 967
HI
2129 2057 2017 1959 1838 1733 1603 1432 1225 1183
CFMwithCoi l LO
1104 1059 1012 975 930 876 780 719 662 581
98‐8W7W‐OPMED‐LO
1292 1244 1214 1184 1136 1098 1053 981 773 584
andCabinetMED I UM
1400 1365 1334 1301 1263 1219 1168 1070 780 592
97‐FLSB‐27MED ‐HI
1596 1569 1521 1468 1392 1301 1204 1087 811 604
or97‐FLSF‐27 HI
1743 1659 1615 1505 1425 1341 1236 1106 809 582
CFMwithCoi l LO
1067 1017 978 942 889 805 758 703 661 518
98‐8W7W‐OPMED‐LO
1268 1229 1199 1158 1109 1075 1012 826 675 536
withCabinet MED I UM
1374 1343 1311 1278 1224 1163 1053 812 708 524
97‐FSOB‐27 MED‐HI
1549 1481 1409 1338 1258 1189 1087 848 669 481
HI
1611 1529 1460 1383 1297 1199 1115 889 708 578
CFMwithCoi l LO
1104 1085 1025 979 936 882 786 719 682 580
98‐8W12W‐OPMED‐LO
1309 1266 1232 1197 1156 1119 1074 1010 790 606
withCabinet MED I UM
1429 1390 1350 1323 1281 1234 1203 1124 801 629
97‐FLSB‐39MED ‐HI
1607 1573 1539 1497 1430 1332 1256 1152 815 637
or97‐FLSF‐39 HI
1751 1663 1607 1533 1455 1372 1270 1160 811 619
CFMwithCoi l LO
1104 1059 1023 974 935 902 841 723 676 563
98‐8W12W‐OP MED‐LO
1285 1246 1211 1175 1126 1104 1065 874 711 561
withCabinet MED I UM
1404 1350 1327 1294 1251 1211 1145 1005 718 535
97‐FSOB‐39 MED‐HI
1601 1538 1468 1400 1327 1241 1148 888 719 541
HI
1725 1613 1530 1442 1360 1283 1190 1088 739 576
CFMwithCoi l LO
1111 1072 1019 976 931 877 781 712 680 548
98‐8G12W‐OPMED‐LO
1289 1255 1226 1185 1143 1105 1066 938 732 556
withCabinet MED I UM
1415 1367 1345 1308 1270 1226 1170 1072 751 573
97‐FLSB‐39MED ‐HI
1594 1571 1519 1449 1380 1294 1205 1043 736 551
or97‐FLSF‐39 HI
1716 1643 1563 1511 1411 1317 1228 1088 748 596
CFMwithCoi l LO
1084 1038 996 952 899 813 748 705 823 494
98‐8G12W‐OP MED‐LO
1262 1227 1187 1150 1112 1067 1014 775 621 488
withCabinet MED I UM
1373 1341 1314 1265 1207 1134 1032 807 638 489
97‐FSOB‐39 MED‐HI
1513 1455 1373 1309 1247 1150 1067 793 672 509
HI
1557 1484 1417 1337 1271 1172 1055 835 885 533
CFMwithCoi l LO
1106 1072 1026 969 938 878 774 721 676 532
98‐8Z12W‐OPMED‐LO
1299 1266 1222 1186 1139 1100 1057 938 752 539
withCabinet MED I UM
1416 1377 1341 1309 1271 1241 1181 1067 740 539
97‐FLSB‐39MED ‐HI
1603 1588 1540 1476 1390 1336 1232 1095 748 545
or97‐FLSF‐39 HI
1741 1667 1607 1532 1435 1350 1253 1148 1165 558
CFMwithCoi l LO
1088 1019 1007 967 924 870 824 716 621 507
98‐8Z12W‐OP MED‐LO
1270 1240 1200 1143 1110 1077 990 747 612 496
withCabinet MED I UM
1371 1340 1303 1265 1210 1138 1019 796 627 506
97‐FSOB‐39 MED‐HI
1555 1487 1424 1331 1270 1148 1037 792 675 494
HI
1613 1543 1445 1385 1279 1200 1083 924 700 507
EXTERNAL STATIC PRESSURE (ESP) INCHESWC DUCT
CFM‐NO‐COI L
Table 6: Blower Performance -10 X 9 Morrison Wheel - 3/4 HP 5 SPD X-13 Motor (With Air filters)

MORTEXPRODUCTSINCFORTWORTH,TX76106Page19
SPDTAP 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
LO 982 979 976 962 932 894 835 711 598 502
MEDIUM 1417 1404 1369 1333 1291 1242 1177 1085 959 579
HI 1771 1704 1624 1544 1448 1372 1270 1167 1037 738
CFMwithCoilLO 944 931 918 904 863 834 692 590 525 438
98‐8G7W‐OPMEDIUM 1317 1293 1255 1210 1169 1099 1013 918 656 579
withCabinet HI 1620 1563 1499 1432 1362 1293 1195 1066 812 608
97‐FLSB‐27OR97‐FLSF‐27
CFMwithCoilLO 935 926 901 862 818 717 650 603 513 395
98‐8G7W‐OPMEDIUM 1307 1260 1205 1143 1088 1013 923 737 642 563
withCabinet HI 1519 1445 1362 1298 1225 1138 1054 950 732 594
97‐FSOB‐27
CFMwithCoilLO 957 951 942 911 866 822 699 635 446 383
98‐8W7W‐OPMEDIUM 1345 1308 1266 1207 1155 1085 998 902 699 546
withCabinet HI 1600 1542 1478 1415 1336 1242 1134 1028 908 694
97‐FLSB‐27or97‐FLSF‐27
CFMwithCoilLO 956 925 891 852 800 697 641 608 521 393
98‐8W7W‐OPMEDIUM 1271 1222 1166 1117 1055 983 796 721 634 565
withCabinet HI 1438 1369 1304 1232 1166 1090 1008 811 705 615
97‐FSOB‐27
CFMwithCoilLO 932 919 913 893 860 808 752 674 555 450
98‐8W12W‐OPMEDIUM 1336 1303 1279 1234 1172 1111 1030 948 793 678
withCabinet HI 1683 1615 1552 1465 1386 1303 1208 1100 987 771
97‐FLSB‐39or97‐FLSF‐39
CFMwithCoilLO 961 934 902 863 811 752 675 596 505 379
98‐8W12W‐OPMEDIUM 1302 1243 1197 1134 1061 988 910 764 632 488
withCabinet HI 1488 1415 1339 1268 1182 1101 1013 910 709 543
97‐FSOB‐39
CFMwithCoilLO 955 940 922 884 838 786 714 593 510 396
98‐8G12W‐OPMEDIUM 1331 1289 1236 1181 1118 1055 960 874 690 511
withCabinet HI 1607 1538 1461 1362 1284 1191 1096 1003 861 706
97‐FLSB‐39or97‐FLSF‐39
CFMwithCoilLO 950 925 891 845 797 745 669 556 485 374
98‐8G12W‐OPMEDIUM 1272 1207 1151 1096 1022 948 875 768 589 511
withCabinet HI 1411 1354 1285 1222 1140 1063 986 875 726 567
EXTERNALSTATICPRESSURE(ESP)INCHESWCDUCT
CFM‐NO‐COIL
Table 7-1: Blower Performance -10 X 9 Morrison Wheel - 1/2 HP 3 SPD PSC Motor (With Air filters)

MORTEXPRODUCTSINCFORTWORTH,TX76106Page20
SPDTAP
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
CFMwithCoilLO
959 953 947 916 870 815 732 643 547 451
98‐8Z12W‐OPMEDIUM
1367 1331 1283 1233 1155 1105 1017 921 763 585
wi thCabinet HI
1641 1579 1506 1425 1340 1238 1150 1053 934 736
97‐FLSB‐39or97‐FLSF‐39
CFMwithCoilLO
957 939 904 862 810 755 653 585 502 384
98‐8Z12W‐OPMEDIUM
1281 1217 1170 1111 1048 975 902 704 637 553
wi thCabinet HI
1448 1387 1314 1242 1175 1094 1006 916 732 578
97‐FSOB‐39
CFMwithCoilLO
946 940 913 890 850 807 701 613 555 445
96‐8W4W‐OPMEDIUM
1319 1279 1229 1192 1155 1080 991 897 711 552
wi thCabinet HI
1590 1534 1467 1396 1313 1223 1127 1028 904 731
97‐FLSB‐21or97‐FLSF‐21
CFMwithCoilLO
942 920 885 835 789 708 630 573 494 364
96‐8W4W‐OPMEDIUM
1264 1203 1150 1090 1025 950 883 709 634 542
wi thCabinet HI
1428 1348 1283 1208 1129 1049 969 890 704 607
97FSOB‐21
EXTERNALSTATICPRESSURE(ESP)INCHESWCDUCT
Table 7-.2: Blower Performance -10 X 9 Morrison Wheel - 1/2 HP 3 SPD PSC Motor (With Air filters)
