IEC-G102-BP Series
Quick Installation Guide
Version 2.1, January 2021
Technical Support Contact Information
www.moxa.com/support

2021 Moxa Inc. All rights reserved.

- 2 -
Package Checklist
The IEC-G102-BP Series, which is an industrial next-generation IPS, is
shipped with the items listed below. If any of these items are missing or
damaged, please contact your customer service representative for
assistance.
•1 Industrial next-generation IPS
•1 USB-C to DB9 cable
•Quick installation guide (printed)
•Warranty card
Features
Advanced Industrial Networking Capability
•MAC and IP addresses policy enforcement
•IPS/IDS to monitor and prevent cyberthreats
•Virtual Patch mitigates the manual effort of having to patch devices
for vulnerabilities
•Industrial Protocol Whitelisting ensures the safety of industrial
equipment
•Efficient industrial device identification and network traffic analysis
•Hardened hardware for -40 to 75°C operating temperature (T model)

- 3 -
Panel Views of IEC-G102-BP Series
Front Panel
Top Panel
Rear Panel
Front Panel:
1. USB port for ABC-02-USB
2. Power input PWR1 LED
indicator
3. Power input PWR2 LED
indicator
4.
MANAGED status LED indicator
5. IPS/IDS state LED indicator
6. USB mount status and FAULT
LED indicator
7. BYPASS status LED indicator
8.
10/100/1000Mbps copper port
9. RESET and REBOOT button
10.
1000Mbps copper port speed
LED indicator
11.
10/100Mbps copper port
speed LED indicator
Top Panel:
1. Grounding screw
2. 4-pin
terminal block with latch
for two power inputs
3. Type-C serial console port
Rear Panel:
1. DIN-rail mounting kit

- 4 -
Mounting Dimensions
DIN-rail Mounting
In the package, the metal DIN-rail mounting kit is fixed to the back panel
of the IEC-G102-BP Series. Mount the IEC-G102-BP Series on the
corrosion-free mounting rail that adheres to the EN 60715 standard.
Suggested Installation Method
STEP 1:
Insert the upper lip of the DIN
-
rail
kit into the mounting rail.
STEP 2
:
Press the
IEC-G102-BP Series
to
wards the mounting rail until it
snaps into place.

- 5 -
Suggested Removal Method
STEP 1:
Pull down the latch on the DIN
-
rail
kit with a screwdriver.
STEP
2:
Slightly pull the
IEC-G102-BP
Series
forward and lift up to
remove it from the mounting rail.
Wall Mounting
For some applications, you will find it convenient to mount the
IEC-G102-BP Series on the wall, as shown in the following illustrations.
STEP 1:Remove the aluminum DIN-rail attachment plate from the rear
panel of the IEC-G102-BP Series, and then attach the wall mount plates
with M3 screws, as shown in the below figure.
STEP 2: Mounting the IEC-G102-BP Series on the wall
requires two screws. Use the
IEC-G102-BP Series
with
wall mount plates attached, as a guide to mark the
correct locations of t
he 2 screws. The heads of the
screws should be less than 6.0 mm in diameter, and
the shafts should be less than 3.5 mm in diameter, as
shown in the figure on the right.

- 6 -
Wiring Requirements
WARNING
Do not disconnect
modules or wires unless power has been
switched off or the area is known to be non
-hazardous. The
devices may only be connected to the supply voltage shown on
the type plate. The devices are designed for operation with a
Safety Extra
-Low Voltage. Thus, the
y may only be connected to
the supply voltage connections and to the signal contact with the
Safety Extra
-Low Voltages (SELV) in compliance with IEC950/
EN60950-1/ VDE0805.
ATTENTION
This unit is a built
-in type. When the
unit is installed in another
piece of equipment, the equipment enclosing the unit must
comply with fire enclosure regulation IEC 60950
-1/EN60950-1
(or similar regulation).
ATTENTION
Safety First!
Be sure to disconnect the power cord before installing and/or
wiring your
IEC-G102-BP Series.
Calculate the maximum possible current in each power wire and
common wire. Observe all electrical codes dictating the
maximum current allowable for each wire
size.
If the current goes above the maximum ratings, the wiring could
overheat, causing serious damage to your equipment.
Please read and follow these guidelines:
•Use separate paths to route wiring for power and devices. If power
wiring and device wiring paths must cross, make sure the wires are
perpendicular at the intersection point.
NOTE: Do not run signal or communications wiring and power wiring
through the same wire conduit. To avoid interference, wires with
different signal characteristics should be routed separately.
•You can use the type of signal transmitted through a wire to
determine which wires should be kept separate. The rule of thumb is
that wiring sharing similar electrical characteristics can be bundled
together.
•You should separate input wiring from output wiring.
•We advise that you label the wiring to all devices in the system.
•This product is intended for installation in Restricted Access Location.
WARNING
Hot Surface. Do not touch.

- 7 -
Grounding the IEC-G102-BP Series
Grounding and wire routing help limit the effects of noise due to
electromagnetic interference (EMI). Run the ground connection from the
ground screw (M3 type) to the grounding surface prior to connecting
devices.
ATTENTION
This product
is intended to be mounted to a well-grounded
mounting surface such as a metal panel.
Wiring the Redundant Power Inputs
The IEC-G102-BP Series has two sets of power inputs—power input 1 and
power input 2. The top and side views of the terminal block connector are
shown below.
Top View
Side View
STEP 1:
Use a small flat
-
blade screwdriver to press
a wire locker.
STEP 2:
Insert a positive/negative DC wire into the
V+/V
- terminals respectively.
STEP 3:
Release the wire locker, and check
whether the wire is
fixed.
The power cord adapter should be connected to a socket outlet with an
earthing connection. The power cord and adapter must comply with Class
II construction.
This product is intended to be supplied by a UL Listed Power Adapter or
DC power source marked ‘L.P.S’ or ‘Limited Power Source’, rated 12 to 48
VDC, 0.605 A (min.), and Tma 75°C (min.). If you require further
assistance, please contact your Moxa representative.
Communication Connections
Each IEC-G102-BP Series has two types of communication port:
•1 TYPE-C console port (RS-232 interface, baudrate: 115200)
•2 10/100/1000BaseT(X) Ethernet ports
TYPE-C Console Port Connection
The IEC-G102-BP Series provides one TYBP-C console port located the
top on panel. Please connect the Moxa EtherCatch to a PC COM port using
a TYPE-C to DB9 connection cable, and then launch a console terminal
software, e.g. Moxa PComm Terminal Emulator, to access the
IEC-G102-BP Series console configuration utility.

- 8 -
TYPE-C to DB9 Cable Wiring
P1
P2
2
A5
BROWN
B5
GREEN
3
A6
RED
B6
BLUE
5
A7
ORANGE
B7
PURPLE
7
A8
YELLOW
B8
GREY
8
A3
BLACK
B3
WHITE
PIN Definition
Description
P1
P2
TXD
2
A5, B5
RXD
3
A6, B6
GND
5
A7, B7
CTS
7
A8, B8
RTS
8
A3, B3
10/100/1000BaseT(X) Ethernet Port Connection
The 10/100/1000BaseT(X) ports located on the IEC-G102-BP Series front
panel are used to connect to Ethernet-enabled devices. Most users will
choose to configure these ports for Auto MDI/MDI-X mode, in which case
the port’s pinouts are adjusted automatically depending on the type of
Ethernet cable used (straight-through or cross-over), and the type of
device (NIC-type or HUB/Switch-type) connected to the port. No matter
which case you are connecting, we share pinouts for both MDI (NIC-type)
ports and MDI-X (HUB/Switch-type) ports.
10/100Base T(x) RJ45 Pinouts
MDI Port Pinouts
MDI-X Port Pinouts
8-pin RJ45
Pin
Signal
1
Tx+
2
Tx-
3
Rx+
6
Rx-
Pin
Signal
1
Rx+
2
Rx-
3
Tx+
6
Tx-

- 9 -
1000BaseT RJ45 Pinouts
Pin
MDI
MDI-X
1
BI_DA+
BI_DB+
2
BI_DA-
BI_DB-
3
BI_DB+
BI_DA+
4
BI_DC+
BI_DD+
5
BI_DC-
BI_DD-
6
BI_DB-
BI_DA-
7
BI_DD+
BI_DC+
8
BI_DD-
BI_DC-
The Reset Button
The reset button has two features:
1. Reboot system: Press and hold the reset button for between 2 and 10
seconds. The MANAGED LED will begin to blink every second, which
means the system is rebooting.
2. Reset to factory default: Press and hold the reset button for more
than 10 seconds. The MANAGED LED will begin to blink every
half-second, which means the system is resetting itself to factory
default.
NOTE
DO NOT power off the device when loading default settings.
LED Indicators
The front panel of the IEC-G102-BP Series has several LED indicators. The
function of each LED is described in the following table:
LED
Color
State
Description
PWR1 Amber
On
Power is being supplied to power input P1
on the main module.
Off
Power is NOT being supplied to power
input P1 on the main module.
PWR2 Amber
On
Power is being supplied to power input P2
on the main module.
Off Power is NOT being supplied to power
input P2 on the main module.
MANAGED Green
On
The IEC-G102-BP Series is managed by
Security Dashboard Console.
Off
The IEC-G102-BP Series is NOT
managed by Security Dashboard
Console.
Blinking
1. When MANAGED LED is blinking
every 1 second, the IEC-G102-BP
Series is rebooting the system.
2. When the MANAGED LED is blinking
every 0.5 second, the IEC-G102-BP
Series is resetting to factory
defaults.
IPS/IDS Green
On
Intrusion Detection and Prevention
System is enabled.
Off
Intrusion Detection and Prevention
System is disabled.

- 10 -
LED
Color
State
Description
USB/F Green
On
An ABC-02-USB has been detected.
Blinking
USB data transmitting.
RED On Hardware or system fault.
BYPASS Amber
On
Hardware BYPASS is enabled.
Off
Hardware BYPASS is NOT enabled.
1000M Green
On
Ethernet link up.
Off
Ethernet link down.
Blinking
Data is being transmitted.
10/100M Green
On
Ethernet link up.
Off
Ethernet link down.
Blinking
Data is being transmitted.
Specifications
Input Current
0.605 A @ 12 V
0.297 A @ 24 V
0.143 A @ 48 V
Input Voltage
12/24/48 VDC, dual power input
Power Consumption
7.26 W (max.)
Operating Temperature
-10 to 60°C (14 to 140°F), standard models
-40 to 75°C (-40 to 185°F), wide-temp.
models
Storage Temperature
-40 to 85°C
