MPS LUMI Series Assembly instructions

Item Description
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
Batteries
Mercury-containing components
Liquid Crystal Displays (LCD) with a surface greater
than 100 sq cm
Cathode Ray Tubes (CRT)
Capacitors / condensers (Containing PCB/PCT)
Electrolytic Capacitors / Condensers measuring
greater than 2.5 cm in diameter or height
External electrical cables and cords
Gas Discharge Lamps
Plastics containing Brominated Flame Retardants
weighing > 25 grams (not including PCBs or PCAs
already listed as a separate item above)
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Components and waste containing asbestos
Components, parts and materials containing
refractory ceramic fibers
Components, parts and materials containing
radioactive substances
0
0
0
0
0
Include the cartridges, print heads, tubes, vent
chambers, and service stations 0
1
1
AC Power cord 1
For example, mercury in lamps, display backlights,
scanner lamps, switches, batteries 0
LCD 1
0
Notes
Quantity
of items
included
in product
With a surface greater than 10 sq cm
M/B, IO Board, Touchpad Module，Adapter board，LCD Tcon
board
5
lithium Battery 1
1.0 Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment.
1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as applicable.
1.3 The product includes large capacity storage devices,storage devices can be connectd by interface insertion way.
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions
for the disassembly of products to remove components and materials requiring selective treatment, as defined by EU
Product End-of-Life Disassembly Instructions
Product Category: Notebook
Marketing Name / Model
[List multiple models if applicable.]
MPS LUMI Series
Page 1

1. Remove the bottom shell screws * 11
2. Disassemble the D shell
3. Disassemble the battery strip and remove the battery screws * 5
4. Remove the SSD screws and remove the SSD
5. Disassemble the memory module and remove it
6. Remove the fan screws and remove the fan
7. Disassemble the screws of the heat dissipation module and remove the heat dissipation module
8. Disassemble the horn and remove it
9. Disassemble the antenna and remove it
10. Remove the IO cable, touchpad cable, keyboard cable, and screen cable
11. Remove the motherboard screws and remove the motherboard
12. Remove the IO board screws and remove the IO board
13. Remove the motherboard screws and remove the motherboard
14. Remove the rotating shaft screws and remove the AB component
15. Remove the screws from the AB component and remove the B shell
16. Remove the screen screws and remove the display screen and camera
17. Remove the shaft screws and remove the shaft
18. Disassemble the touchpad and remove it
1. Remove the screws from the D shell
2. Disassemble the battery strip and uesd a screwdriver remove the battery screws, heat dissipation module, fan, SSD, motherboard, and small board
screws.
Description #5
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).
Description #2 combination cut pliers #1
Description #3
Description #4
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
Description #1 Plum Screwdriver #1
Page 2

2.1, Battery disassembly
①Prepare shell c and screwdriver;
②Disassemble the battery strip;
③Use a screwdriver to unscrew the screw*5 which are used for fixing the battery ;
④Remove the battery.
Main board
IO board
Touch pad
Battery
Battery
Main board
IO board
Page 3

5. Adapter disassembly
①
Prepare scissors and adapters to be disassembled;
② Use scissors to forcefully cut along the gap of the adapter;
③
Separate the upper cover, lower cover, and circuit board.
3. Remove AB component
4. Remove the LCD camera and rotate the shaft
Adapter
LCD T-con Board
LCD
capacitance
LCD T-con Board
LCD
Adapter board
Page 4

IO board
Main board Touch pad
Battery
LCD T-con Board
LCD
Adapter
Page 5
