Safety Regulations
4HandyCom PTT
GB
1. Safety Regulations
1.1. Correct Use
The HandyCom PTT is a handheld speaker microphone
intended for connecting to radio equipment. It is suited for
indoor and outdoor use combined with a radio set. The device
serves as a communication tool for first responders in
operations.
It is imperative that this operating manual be read and
observed when using the product. In particular, the safety
instructions, as well as the information for the use and
operation of the product, must be carefullyread and observed.
Furthermore, the national regulations applicable in the user's
country must be taken into account for a safe use.
Danger!
This product is supporting life and health. Inappropriate use,
maintenance or servicing may affect the function of the device
and thereby seriously compromise the user's life.
Before use the product operability must be verified. The
product must not be used, if the function test is unsuccessful, it
is damaged, a competent servicing/maintenance has not been
made, genuine MSA spare parts have not been used.
Alternative use, or use outside this specification will be
considered as non-compliance. This also applies especially to
unauthorized alterations to the product and to commissioning
work that has not been carried out by MSA or authorized
persons.
1.2. Liability Information
MSA accepts no liability in cases where the product has been
used inappropriately or not as intended. The selection and use
of the product are the exclusive responsibility of the individual

Safety Regulations
HandyCom PTT 5
DE GB
operator. Product liability claims, warranties also as
guarantees made by MSA with respect to the product are
voided, if it is not used, serviced or maintained in accordance
with the instructions in this manual.
1.3. Safety and Precautionary Measures to be Adopted
•Also read and observe the operating instructions for the
radio set and external accessories when you use it.
•The device can produce high sound pressures through
which it is possible to damage your hearing.
•Do not use the device in explosive atmospheres.
•Make sure that connecting cables do not get caught or
entangled on objects to avoid accidents.

Description
6HandyCom PTT
GB
2. Description
Fig. 1: Front view
1
j
ack socket for Nexus plugs 4 front PTT button
2 emergency button (optional) 5 earphone socket
3 microphone 6 lateral PTT button
3
4
5
6
2
1

Description
HandyCom PTT 7
DE GB
Fig. 2: Back view
1 rotary clothing clip 2 volume control
1
2

Use
8HandyCom PTT
GB
The device is made of impact-resistant synthetic material. Its
cable and housing are water-resistant, low-flammable and self-
extinguishing. It has a clothing clip, two PTT (Push-To-Talk)
buttons, a 3,5 mm jack socket and a jack socket for Nexus
plugs for connecting an external headphone or earphone as
well as an external headset. A separate emergency button is
available optionally. Both PTT buttons are connected in parallel
and have the same effect. The optimum distance for talking is
about 4 cm away. The radio set remains in transmit mode as
long as a PTT button is pressed. While an external earphone
or headset is connected, the loudspeaker or the loudspeaker,
microphone and earphone socket of the device remain off. The
clothing clip can be replaced by a button hook for the use in
vehicles.
3. Use
3.1. Volume Adjustment
You can use the volume control to adjust the volume in three
levels. The setting marked by the one dot gives the lowest
volume and the setting marked by the three dots gives the
highest volume.
(1) Adjust the volume to the level you require.
The volume adjustment also applies to external
earphones and headsets.

Use
HandyCom PTT 9
DE GB
3.2. Connection to the Radio Set
Notice!
Some radio sets still output a supply voltage to the accessory
connector even when the radio set is off. In such cases, it is
advisable to disconnect the HandyCom from the radio set
when not in use for prolonged periods in order to protect the
batteries of the radio set.
(1) Switch off the radio set.
(2) Adjust the volume to the lowest level (see chapter 3.1).
(3) Connect the HandyCom to the radio set.
(4) Switch the radio set back on and adjust the volume to the
level you require.
The device is ready-to-receive.
3.3. Connection of an External Earphone
Notice!
The jack plugs must comply with the JIS C 6560 standard
(concentric plug and jacks); non-compliant plugs may damage
the jack socket.
The device has an earphone socket for connecting a set of
headphones or earphones using a 3.5 mm jack plug.
(1) Open the protective cover on the earphone socket.
(2) Insert the jack plug into the earphone socket.
The jack plug is fitted until it clicks into place.
(3) To talk, you can continue to use the PTT button and
microphone on the device.
(4) Close the protective cover after using the external
earphone.

Use
10 HandyCom PTT
GB
3.4. Connection of an External Headset
You can connect an external headset to the jack socket for
Nexus plugs.
(1) Open the protective cover on the jack socket.
(2)Insert the Nexus jack plug into the jack socket.
The Nexus jack plug is fitted until it clicks into place.
Communication now takes place via the microphone
and earpiece in the headset.
(3) Close the protective cover, after using the external
headset, by firmly press down until fully closed.
3.5. Talking
(1) Press the PTT button to talk.
You can use the PTT button both on the side and on
the front.
(2) Speak loudly and clearly into the microphone.
(3) To finish transmit mode, release the PTT button.
3.6. Listening
The device is always switched to receive as long as the PTT
buttons are not pressed.

Use
HandyCom PTT 11
DE GB
3.7. Use in vehicles
For use in vehicles, the device can be hooked onto a vehicle-
mounted holder.
(1) Replace the clothing clip by a button hook (as described in
chapter 4.3).
(2) Fit the vehicle-mounted holder in a suitable position in the
vehicle.
(3) Mount the button hook onto the vehicle-mounted holder
with the 3 screws supplied.
The button hook and vehicle-mounted holder are not supplied
as standard; please order separately.
3.8. Emergency Button (optional)
Notice!
A
n emergency button is only fitted on those HandyCom models
for which the associated radio set also has an emergency call
function.
The device has an option of a separate emergency button.
Pressing this button activates the emergency call from the
connected radio. Depending on the radio, this may require
programming of the external emergency call function. For
further information on this, please refer to the operating
instructions for the radio set concerned.

Maintenance and Cleaning
12 HandyCom PTT
GB
4. Maintenance and Cleaning
4.1. Maintenance
The device is maintenance-free.
4.2. Cleaning
Notice!
When cleaning under running water, hold the protective covers
closed on the jack sockets. For cleaning purposes, never use
caustic cleaning agents, alcohol or other corrosive substances
that might attack the housing.
(1) Remove loose dust with a soft brush.
(2) Wipe off any stubborn dirt with a damp lint-free cloth.
Use a little detergent if necessary.
(3) Wash the device under running water, if it has severe
soilings.
(4) Hold the device upright (cable from below) for about
30 seconds to allow the water to drain out completely
through the loudspeaker and microphone holes.
4.3. Change of the Clothing Clip
Notice!
The rear microphone aperture is unprotected once the clothing
clip is removed. Sharp objects could enter and cause
permanent damage. Therefore never use or store the
HandyCom without the clothing clip fitted.
You can use the clothing clip to fasten the device to clothing.
The clothing clip swivels and can be locked in steps of
45 degrees.

Maintenance and Cleaning
HandyCom PTT 13
DE GB
(1) Unlock the clothing clip by lifting up the catch spring.
(2) Slide the clothing clip out sideways.
(3) To fit the new clothing clip, slide it into the guide on the
case.
The clothing clip is fitted until you hear it snap into
place.
Fig. 3: Change of the clothing clip
1 Catch spring 2 clothing clip
2
1

Storage
14 HandyCom PTT
GB
4.4. Fault Checking
If in the device faults occur, you can check the following points.
•Check that the radio set is switched on.
•Check all cable connections.
•Check all connectors.
If this does not solve the problem, please send the speaker
microphone to MSA or to a MSA-approved repair company.
5. Storage
Store the HandyCom ideally in a dry place, free from dust and
dirt, at approx. 20° C. Protect apparatus against direct sunlight.
6. Disposal
If the device is definitely put out of operation, please pass it on
to a local recycling company for disposal.

Technical Data
HandyCom PTT 15
DE GB
7. Technical Data
Housing shock-resistant and self-extinguishing
plastic housing (IP code 67)
Dimensions 92 mm x 69 mm x 42 mm
Weight approx. 135 g
Connectors PUR cable, unstreched length 30 cm,
safety decoupler
Temperature range -30 °C to +70 °C
Humidity max. 93 %
Microphone:
Converter principle Electret, noise cancelling
Sensivity 18 mV/Pa
Speaker:
Converter principle dynamic
Nominal power
handling
1 W
Noise pressure level 80 dB at 0.5 W in 0.5 m distance
8. Approvals
Manufacturer: MSA EUROPE GmbH
Schlüsselstrasse 12
8645 Rapperswil-Jona, Switzerland
Product: HandyCom
Type of protection: Drop test according to EN 300 019-2-7
Class 7.3
Passed flame engulfment test
according to EN 137:2007

Ordering Information
16 HandyCom PTT
GB
9. Ordering
Information
Description Article No.
HandyCom PTT for Motorola:
MTP850 FuG
MTP830 FuG
MTP850 S
10157059
HandyCom PTT for Sepura:
STP 8000
STP 8100
STP 8200
STP 8030
STP 8038
STP 9000
10157058
Further radios: on request

Inhaltsverzeichnis
HandyCom PTT 17
DE DE
Inhaltsverzeichnis
1. Sicherheitsvorschriften ..................................................... 18
1.1. Bestimmungsgemäße Verwendung........................... 18
1.2. Haftung ...................................................................... 19
1.3. Sicherheitshinweise ................................................... 19
2. Beschreibung ..................................................................... 20
3. Gebrauch ............................................................................ 22
3.1. Lautstärkeeinstellung................................................. 22
3.2. Anschluss an das Funkgerät ..................................... 23
3.3. Anschluss eines externen Ohrhörers......................... 23
3.4. Anschluss eines externen Headsets.......................... 24
3.5. Sprechen ................................................................... 24
3.6. Hören ......................................................................... 24
3.7. Einsatz im Fahrzeug .................................................. 25
3.8. Notruftaste (optional) ................................................. 25
4. Wartung und Reinigung .................................................... 26
4.1. Wartung ..................................................................... 26
4.2. Reinigung................................................................... 26
4.3. Wechsel des Kleiderclip............................................. 26
4.4. Störung ...................................................................... 28
5. Lagerung............................................................................. 28
6. Entsorgung ......................................................................... 28
7. Technische Daten .............................................................. 29
8. Zulassungen ....................................................................... 29
9. Bestellangaben................................................................... 30

Sicherheitsvorschriften
18 HandyCom PTT
DE
1. Sicherheitsvorschriften
1.1. Bestimmungsgemäße Verwendung
Das HandyCom ist ein Handmikrofon-Lautsprecher zum
Anschluss an Funkgeräte. Es ist geeignet für Außen- und
Innenanwendungen in Verbindung mit einem Funkgerät. Das
Gerät dient als Kommunikationsmittel für Einsatzkräfte im
Einsatz.
Die vorliegende Gebrauchsanleitung ist für die Nutzung des
Produkts zwingend zu lesen und zu beachten. Insbesondere
die darin enthaltenen Sicherheitshinweise sowie die Angaben
zu Einsatz und Bedienung des Produkts müssen aufmerksam
gelesen und beachtet werden. Zusätzlich sind die im
Verwenderland geltenden nationalen Vorschriften zum
sicheren Betrieb des Gerätes zu berücksichtigen.
Gefahr!
Das Produkt ist möglicherweise eine lebensrettende oder
gesundheitserhaltende Schutzvorrichtung. Eine
unsachgemäße Verwendung, Wartung oder Instandhaltung
des Gerätes kann die Funktion des Gerätes beeinträchtigen
und dadurch Menschenleben ernsthaft gefährden.
Vor dem Einsatz ist die Funktionsfähigkeit des Produktes zu
überprüfen. Das Produkt darf nicht eingesetzt werden, wenn
der Funktionstest nicht erfolgreich war, Beschädigungen
bestehen, eine fachkundige Wartung/Instandhaltung fehlt
oder wenn keine Original-Ersatzteile verwendet wurden.
Eine andere oder darüber hinausgehende Benutzung gilt als
nicht bestimmungsgemäß. Dies gilt insbesondere auch für
eigenmächtige Veränderungen am Produkt und für
Instandsetzungsarbeiten, die nicht von MSA bzw. autorisiertem
Personal durchgeführt wurden.

Sicherheitsvorschriften
HandyCom PTT 19
DE DE
1.2. Haftung
In Fällen einer nicht bestimmungsgemäßen oder nicht
sachgerechten Verwendung des Produktes übernimmt MSA
keine Haftung. Auswahl und Nutzung des Produktes liegen in
der ausschließlichen Verantwortung der handelnden Personen.
Produkthaftungsansprüche, Gewährleistungsansprüche und
Ansprüche aus etwaigen von MSA für dieses Produkt
übernommenen Garantien verfallen, wenn es nicht
entsprechend der Gebrauchsanleitung eingesetzt, gewartet
oder instand gehalten wird.
1.3. Sicherheitshinweise
•Beachten Sie auch die Bedienungsanleitung des
Funkgerätes und vom externen Zubehör, wenn Sie es
verwenden.
•Das Gerät kann hohe Schalldrücke erzeugen durch
welche es zur Beschädigung des Gehörs kommen kann.
•Setzen Sie das Gerät nicht in explosionsgefährdeten
Bereichen ein.
•Achten Sie darauf, dass die Anschlusskabel nicht an
Gegenständen hängen bleiben oder sich verfangen um
Unfälle zu vermeiden.

Beschreibung
20 HandyCom PTT
DE
2. Beschreibung
A
bb. 1: Vorderansicht
1 Klinkenbuchse für Nexusstecker 4 Vordere Sendetaste
2 Notruftaste (optional) 5 Ohrhörerbuchse
3 Mikrofon 6 Seitliche Sendetaste
3
4
5
6
2
1
