Napoli Audio TFT-TV 9010 SD/USB User manual

User's manual
TFT-TV 9010 SD/USB
LCD Color Television Receiver

Table of Contents
1. Precautions
2. Accessories
3. Appearance
4. Description of Panel Buttons
5. Description of Buttons on Remote Control
6. Basic Operation Methods
7. Menu Operation
7.1. PICTURE
7.3. CLOCK
7.4. SYSTEM
7.5. PRESET
8. In order to receive clearer picture
10. Before you request for repair
11. Technical Parameters
7.2. OPTION
9. CARD mode operation
1
2
3
4
5
6
7
7
7
8
8
9
10
10
16
17

1. Precautions
Storage
1). Keep this product away from extremely hot or cold places. The storage temperature ranges
from -20 to 60 and the working temperature from -5 to 40 .
2). Do not use this product at damp environment like bathtubs, wash basins, kitchens,
washtubs, as well as basements, swimming pools or similar places.
3). Do not expose your TV set to high humidity, dust or oil smoke.
4). Do not throw or drop this product.
5). Do not subject this device to the inside of a case or strong vibrations, avoiding strong
collision.
6). Do not push on or scrub this product with sharp objects.
Maintenance
1). Disconnect all cables of this device at first before cleaning.
2). Wipe the enclosure, screen and keys using soft cloth with a little soft detergent on.
3). Do not use polishing cloth, abstergent, and all types of propellants or chemical detergents
like alcohol and benzene to clean your device.
Warning!
1. Do not watch television programs or turn your TV set on for your own and others' safety.
2. It is very dangerous to watch television programs or operate the TV set while driving.
1

Special Notice
Bright spots or dark spots may appear on the screen. This is a normal phenomenon associated
with the active matrix display technology and is not a sign of malfunction. Do not attempt to
maintain. For any failures, please turn off your TV set immediately and contact us or your
dealer. This device integrates a great deal of fine electronic components. Disassembly or
alternation may result in damages or breaks.
2. Accessories
* Open the package and make sure all the items are included.
1. Car adapter
2. AC adapter
3. 75 ohm antenna conversion cable
4. Remote control
5. AAA type batteries
6. AV conversion cable
Telescopic antenna
8. Base support
9. Operation Instructions
7.
2

3. Appearance
5
6
7
8
9
10
11
1
2
43
13
14
15
16
17
12
22
18
19
20
21
1. Telescopic antenna
2. TFT-LCD screen
3. Power indicator
Red: Standby
Green: Power-on
4. Remote-control receive window
5. CH+/ : Channel Select/Upward button
6. CH-/ : Channel Select/Downward button
7. OK/MUSIC: Confirm button/Music
Background button
8. VOL+/ : Volume up/Rightward button
9. VOL-/ : Volume down/Leftward button
10. SD/MMC/MS type CARD input port
11. USB connect Jack
12. Antenna input Jack
13. S.SHOW: Scan button
14. MUTE/PICT: Mute button/picture mode shift
button
15. EXIT: Return button
16. MENU: Menu button
17. /MODE: Standby/Operation mode shift button
18. AV Output
19. AV Input
20. Headphone jack
21. DC Input
22. Speaker
3

4. Description of Panel Buttons
1. CH+/ : Under TV mode, press as Channels +, under OSD MENU
or CARD mode, press as upward key.
2. CH-/ : Under TV mode, press as Channels -, under OSD MENU
or CARD mode, press as downward key.
3. OK/MUSIC: Under TV mode, keep pressing for 3 seconds for
Auto-search; Under CARD mode, press to confirm, when playing
slide show, press to turn ON/OFF the background music.
4. VOL+/ : Under TV mode, press as Volume up, under CARD mode, press as right selection
key, keep pressing (3 seconds) as Volume up key.
5. VOL-/ : Under TV mode, press as Volume down, under CARD mode, press as left
selection key, keep pressing (3 seconds) as Volume down key.
6. S. SHOW: Under CARD mode, when reading Picture or slide show, press to change next
mode. (only available under CARD mode)
7. MUTE/PICT: Under TV/CARD/AV mode, short press to switch between MUTE and normal
sound, keep pressing for 3 seconds to Picture mode switch.
8. EXIT: Under CARD mode, press to return step by step; Under TV/AV
mode, press to EXIT.
9. MENU: Under TV/AV mode, press as OSD MENU; under CARD mode, press to open
function MENU when reading picture or video, press to switch USB/CARD under main MENU.
10. /MODE: Under standby mode, press to turn ON. When the device is ON, press to
switch between TV/CARD/AV mode. Keep pressing 3 seconds for standby.
4

5. Description of Buttons on Remote Control
/
: the number of TV channel increases.
: the number of TV channel decreases
/ : To select program and adjust for selected program.
OK/MUSIC: Under CARD mode, press to confirm, when playing slide show, press as ON/OFF
for the background music.
PICT: Picture mode shift.
POWER: Power on/off.
MENU: MENU/CARD mode, in main interface, press as USB and CARD multi-media switch.
Press to open function menu when playing files.
MUTE: Mute button.
CALL: Press this button to display the character of program currently watching.
SLEEP: Selecting the switch off time within 120 minutes.
MODE: Press this button to switch between TV/CARD/ AV mode.
SEARCH: Under TV mode, keep pressing(3 seconds) as Auto search (TV mode only).
: Return button.
S.SHOW: Scan button.
0 9 (Digital key), -/--(Channel shift):
On TV mode, use to choose the TV channel (TV mode only).
P. ADJ: Picture adjust.
VOL+: Volume +.
VOL-: Volume -.
5

6. Basic Operation Methods
Basic interface connection
6.1 Connection of Power Supply:
Align the power supply plug on AC adapter with the jack on the
machine rear cover marked with DC.
6.2 Connection of Antenna Cable:
Align one end of the attached a ntenna cab le plug in the antenna
jack on TV set and the other end plug in the external antenna jack.
6.3 Connection of AV convert Cable:
6.3.1.AV input: Insert the external video cord into the yellow port of the AV convert cable, the
left sound track into the white port and the right sound track into the red port. Then plug the AV
convert cord in AV IN jack.
75ohm antenna conversion line
AV conversion cable
6

6.3.2.AV output: Insert the external video cord into the yellow port of
the AV convert cable, the left sound track into the white port and the
right sound track into the red port. Then plug the AV convert cord in
AV OUT jack (AV OUT only in CARD mode) .
7. Menu Operation
Press MENU to display options as follows:
PICTURE OPTION CLOCK SYSTEM PRESET
7.1. PICTURE
CONTRAST, BRIGHT, COLOR, SHARP and TINT displays on the screen as below description:
Press or to select the item Press or to adjust
Notice:
7.2. OPTION
7.2.1.Press or to select the item LANGUAGE:
or
Only when displaying the picture of NTSC system, it will show the character of TINT in the
Picture menu.
LANGUAGE, CALENDAR and GAME displays on the screen as below description:
Press to select multi language of OSD.
7

7.2.2.Press or to select the item CALENDAR:
When play games under weak or no signal, the game bar will twist slightly. It is recommended
to switch to video status before you playing the game again.
7.3. CLOCK
TIME, ON-TIME, OFF-TIME, ATTENTION, BESPOKE TIME and POSITION will display on the
screen as below description:
7.4. SYSTEM
COLOR-SYS, SOUND-SYS, BLUE BACK, HORIZONTAL, VERTICAL and ZOOM displays on
the screen as below description:
7.4.1.Press or to select the item COLOR-SYS:
Press or to select CALENDAR. Press or adjust year, and press or adjust month.
7.2.3.Press or to select the item GAME:
Press or then game begins, then press to move leftward, to rightward, to quick
down and to rotate the game by 360 degrees. Press POWER to exit game and resume to
TV or VIDEO status.
Notice
Press or to select item, Press or to setup.
Notice
If you wish to setup other item, TIME must be setup. All items is 24 hours the most.
Then press to revolve the screen in the order of AUTO, PAL and SECAM. Please choose
8

Then press , the SOUND-SYS displays in the order of BG5.5M, I6.0M, DK6.5M and L6.5M.
7.4.2.Press or to select the item SOUND-SYS:
7.4.3.Press or to select the item BLUE BACK:
Press or can realize the ON / OFF of BLUE BACK under no signal.
7.4.4.Press or to select the item HORIZONTAL:
Press or can realize HORIZONTAL, press again to resume the picture.
7.4.5.Press or to select the item VERTICAL:
Press or can realize VERTICAL flip, press again to resume the picture.
7.4.6.Press or to select the item ZOOM:
or
7.5. PRESET
POSITION, REMEMBER, BAND, SWAP, FINE, SEARCH and AUTO-SEARCH will display on
the screen as below description:
Notes
1. Please set the SOUND-SYS at local one.
2. In case with picture while without sound or with noise, please check the SOUND-SYS for
correct setup first.
Press can realize the selection of picture modes: 4:3 mode, and 16:9 mode.
carefully this system correctly. Otherwise, it may cause achromatic or inferior color. It is
recommended to select on AUTO position.
9

7.5.1.Press or to select POSITION, and press to set.or
7.5.2.Press or to select REMEMBER, and press or to select ON, this channel will be
displayed when selected. When REMEMBER is OFF, this channel will not be displayed.
7.5.3. or orPress to select BAND ,and then press to switch of V-L,V-H and U.
7.5.4. or orPress to select SWAP, then press to select the channel No . Press MENU
to confirm SWAP.
7.5.5. or to orPress select FINE. Then press to adjust channel frenquency by little.
7.5.6. or orPress to select SEARCH. Then press to start searching forthward or
backward.TV searching indicater bar will turn to green from red after search TV signal. TV
storage system will identify as no signal if TV channel are on too weak signal.
7.5.7. or orPress to select AUTO-SEARCH. Press to start auto searching from
channel 0 in turns of V-L , V-H and UHF. Station of sufficient strength will be memorized and
searching stops.
10

8. In order to receive clearer picture
1) .Set the desired OSD language by pressing LANG.
2). Ensure the COLOR-SYS, SOUND-SYS is correct by checking from SYSTEM menu.
3). Select AUTO-SEARCH in PRESET menu, and start auto search TV signal.
4. Adjust the length, angle and direction of the telescopic antenna to obtain optimum image.
Notice
In case the signal intensity is too weak, the image will remain inferior whatever you adjust the
antenna, and cause loud noise wave, shaking image and inferior sound, etc., which is not TV
fault. If the image remains inferior when using telescopic antenna, please try to use the external
antenna or CATV.
9. CARD mode operation
1. The right usage memory facility (USB&CARD)
The device supports almost all types of USB, Multi Media Card (MMC), SD, Merory Stick (MS)
in the market.
1. The memory of different USB & CARD are require within 8G.
2. The device is able to read JPEG, MP3, WMA, VCD, AVI ect. (but do not support DIVX3. 11
format and AC3 audio compress format)
1. Able to play very smoothly when data stream is below 1000KBP/S, it might pause when the
data stream is above 1000KBP/S
Notice
11

2. The USB plug of this device do not support Multi-media devices such as Card reader,
portable hard drive, MP3, MP4.
3. When facing problems from the device, please unplug the device for 5 seconds then re-start
(reset)
4. Please re-plug in again if the U disk can not be identified.
2. Playing multi-media files
Press 'MODE', switch to CARD mode, in the interface there are 'PHOTO', 'MUSIC', 'VIDEO',
'SLIDE SHOW' and 'SETUP'. Insert USB or CARD (if USB and CARD are inserted at the same
time, press MENU from the main interface to select either USB or CARD).
2.1. Reading Picture
2.1.1 Reading Picture
Use the direction key to select 'PHOTO', then press 'OK' to open file, press upward/downward
to select picture, press 'OK' to read. When reading Picture, press 'S.SHOW' to change the
impact of the display. Press 'MENU' for function menu; use left/right direction key to select
function, press 'OK' to confirm; Press 'MENU' twice to show picture attribute; Press 'MENU'
three times to exit. When reading picture files, press direction key for fast operation
of the following functions:
Left direction key: anticlockwise 90
Right direction key: clockwise 90
Up direction key: up/down mirror
Down direction key: left/right mirror
After all the above operations, press 'S.SHOW' to cotinue to read pictures.
12

2.1.2 Reading Picture
Use direction key to select 'PHOTO', press 'OK' to open file from the memory source; press
right direction key to read 12 picture menu. Press direction key to select picture, press 'OK' to
read.
2.1.3 Multimedia file list fast switch
Use direction key to select 'PHOTO', press 'OK' to open file from the memory source; press left
direction key to switch between 'PHOTO', MUSIC', 'VIDEO' and 'SLIDE SHOW'.
Function Menu
/ : Play/ pause
: Stop
: Next
: Previous
: Repeat, press 'OK' to selection repeat all, repeat list, repeat 1 and repeat OFF respectively.
: Circumgyrate; press 'OK' to selection ON/OFF; press left/right direction key for 90
Circumgyrate;
: Zoom: press 'OK' to select zoom; zoom2, zoom3, zoom4, zoom 1/2, zoom 1/3, zoom 1/4
and zoom OFF respectively; press direction to move picture.
'
Notice
Background music can not be open while reading picture, other function will not work when
using zoom function.
2.2 Play music
Press direction key to select 'MUSIC', press 'OK' to open file from memory source; press
13

direction key to select file, press 'OK' to play. Function menu will appear, use direction key
to select function, then press 'OK' to confirm.
Function menu
: Repeat; press 'OK' to select repeat 1, repeat list, reapeat all, repeat OFF.
: Next
: Previous
/ : Play/pause
2.3 Play movie
Press direction key to select 'VIDEO', press 'OK' to open file from the memory source, press
direction key to select file, press 'OK' to play. Then press 'MENU' for function menu, use
direction key to selection functions, then press 'OK' to confirm.
Function menu
/ : Play/pause
: Stop
: Next
: Previous
: Fast backward
: Fast forward
: Repeat; press 'OK' to select repeat all, repeat list, repeat 1 and repeat OFF.
2.4 Slide show
Use direction key to select 'SLIDE SHOW', press 'OK' to open file from the memory source;
14

press direction key to select file, press 'OK' to play. Then press MENU for function menu,
use direction key to select functions, then press 'OK' to confirm. While playing, press 'OK'
to turn ON/OFF background music, press 'VOL+ and VOL-' to adjust volume. Press MENU
twice to view Picture attribute; press MENU three times to exit. (function menu remains
unchanged in slide show and reading picture, for operation methods please refer to function
menu manual under reading picture.)
The display languages of file name and movie name appeares to be simplified Chinese,
traditional Chinese and international standard character, if languages display are not the above
character or character over 8 digits, disorder characters will appear.
Notice
2.5 Setting
Use direction key to select 'SETUP', use / select up/down, use / select left/right, then
press 'OK' to confirm.
2.5.1 Effect: enter to select the mode of display picture or play slide show.
2.5.2 Frequency: time setting for change picture display.
2.5.3 TV system: the TV system of external monitor must be the same to this device, setting
can be made under this section.
2.5.4 OSD language: select OSD language.
2.5.5 Default: return to factory default, OSD language and other section will return to factory
default setting.
15

10. Before you request for repair
Phenomena below does not necessarily mean failure with TV set. Please check following
before you request for repair.
Phenomena Possible Causes
No picture, no sound
No image
No sound
Dark picture
Unclear or unstable image
Improper connection with AC adapter or Care adapter. Useof
unauthorized power supply. TV set is on standby status.
Whether the correct Channel selected. Automatically set up the
Receiving Channel again. Any new place is subject to re-setup
of channels.
Whether the volume is turned to the end or the Sound System is
incorrect. Whether earphone plugged in. Whether ERASE
functions under too weak signal.
Whether brightness and contrast adjusted correctly; Whether
environment temperature is too low.
Whether antenna adjusted correctly;
Maybe too weak signal received at the receiving place.
Whether the antenna is in proper direction;
Maybe received the building or reflected signals nearby.
Superposed image
Maybe under wave interference of automobile motor, train, high
voltage line and neon light.
Snowstorm
Achromatic or flashing color Whether color adjusted well, whether the decoloration actions
under the Color system with too weak proper signal.
Upside down or lateral inverted
picture Improperly adjusted Horizontal or Vertical in the remote control.
16

11. Technical Parameters
Product Name: LCD Color TV Receiver
Display Device: Color TFT-LCD
Receiving frequency range: 48.25MHz~863.25MHz
Screen Size: 9 inches
Resolution: ( ) ( )
Audio Output: ()
Loudspeaker: two 4.5cm round loudspeaker.
Connecting Terminal: External antenna input jack, earphone jack, Audio / Video (AV)
input/output jack, External power supply jack.
Applicable Power Supply: Two options:
1. AC Power supply AC adapter
2. Car adapter 12V 12-24V
Power Consumption: about 10W
Outer Dimension: 243.9mm 163.4mm 36mm
Weight: about 700g
640 H RGB 234 V
0.5W Max
17

WARNING:
This manual is for your reference only. The information in the Manual is subject to change
without prior notice. The company reserves the right to explain for any unknowns, errors or
omissions.
No elements are recoverable inside your device. Do not attempt to open it to improve your
TV set. The high-tension supply inside may cause dangers. The maintenance and
adjustment of your TV set must be operated by professionals.
WARNING:
To prevent injury, this apparatus must be securely attached to the floor/wall in accordance
with the installation instructions.
The mains plug is used as the disconnect device, the disconnect device shall remain
readily operable, and it shall be disconnected from the mains completely.
The plug is used as disconnect device form the mains supply, the plug shall remain readily
operable.
The apparatus should not be exposed to dripping or splashing and that no objects filled with
liquids, such as vases, shall be placed on the apparatus.
No naked flame sources, such as lighted candles, should be placed on the apparatus.
For some descriptions with , the mark indicates the corresponding feature is
available.
18
