INSTALLATION GUIDE
FIELDPOINT BUS EXTENDER CABLE
The FieldPoint Bus Extender Cable lets you mount a FieldPoint bank in two or three rows.
With the Bus Extender Cable, you can mount rows of modules with terminal blocks
together (bottom-to-bottom) or with terminal blocks apart (top-to-top). Mounting modules
with terminal blocks together lets you use one wiring conduit for two rows of modules.
Caution You should not use more than two FieldPoint Bus Extender Cables
per FieldPoint bank.
Caution Disconnect power from the network module and terminal bases
before you install the Bus Extender Cable. Do not disconnect a Bus Extender
Cable while the FieldPoint bank is powered on.
Follow these instructions to install a FieldPoint bank with a Bus Extender Cable:
1. Choose a configuration for your FieldPoint bank. Figure 1 shows configuration
examples with two rows. You can use up to three rows.
Figure 1. FieldPoint Bank Configuration Options
2. Install your network module and terminal bases. Figure 2 shows how to mount terminal
bases with their terminal blocks together. Figure 3 shows how to mount terminal bases
with their terminal blocks apart. For more detailed information on mounting these
devices to a DIN rail or panel, refer to the documentation that came with your
FieldPoint network modules and terminal bases.
™
Terminals BlocksTogether Terminals Blocks Apart
network module I/O modules more I/O modules
more I/O modules network module I/O modules
FieldPoint Bus Extender Cable 2 www.natinst.com ©National Instruments Corporation 3 FieldPoint Bus Extender Cable
3. If you plan to mount the cable to a wall or panel, drill pilot mounting holes, as shown
in Figures 2 and 3.
Note Securing the cable to the wall or panel helps prevent accidental
disconnection.
Figure 2. Mounting with Terminal Blocks Together
TerminalsTogether. Dimensions are given in inches [millimeters].
[170]
6.70
max
[355]
14.0
max
[28.2]
1.11
[44.6]
1.76
[31.2]
1.23 [31.2]
1.23 [26.7]
1.05
female end
male end
Cable
Mounting
Holes
(drill pilot
holes in
these
locations)
Other
Terminal
Bases
(if installed)
Other
Terminal
Bases
(if installed)
and network
module
[14.9]
0.59
Figure 3. Mounting with Terminal Blocks Apart
4. Install your Bus Extender Cable. The female end of the cable plugs into the terminal
base closer to the network module, and the male end plugs into the terminal base farther
from the network module. The cables are keyed to prevent improper installation.
5. If you drilled holes in Step 3, secure the Bus Extender Cable by driving a screw through
the mounting tab holes and into the pilot holes. Place the plastic spacers (included with
the cable) behind the mounting tab. Use the thin spacers when the FieldPoint bank is
mounted directly to a wall or panel. Use the thick spacers when the FieldPoint bank
is mounted on a DIN rail.
Terminals Apart. Dimensions are given in inches [millimeters].
[50.8]
2.00
max
[236]
9.30
max
[28.2]
1.11
[44.6]
1.76
[31.2]
1.23 [31.2]
1.23 [26.7]
1.05
female
end
male
end
Cable
Mounting
Holes
(drill pilot
holes in these
locations)
Other
Terminal
Bases
(if installed)
and network
module
Other
Terminal
Bases
(if installed)
[14.9]
0.59
FieldPoint Bus Extender Cable 2 www.natinst.com ©National Instruments Corporation 3 FieldPoint Bus Extender Cable
3. If you plan to mount the cable to a wall or panel, drill pilot mounting holes, as shown
in Figures 2 and 3.
Note Securing the cable to the wall or panel helps prevent accidental
disconnection.
Figure 2. Mounting with Terminal Blocks Together
TerminalsTogether. Dimensions are given in inches [millimeters].
[170]
6.70
max
[355]
14.0
max
[28.2]
1.11
[44.6]
1.76
[31.2]
1.23 [31.2]
1.23 [26.7]
1.05
female end
male end
Cable
Mounting
Holes
(drill pilot
holes in
these
locations)
Other
Terminal
Bases
(if installed)
Other
Terminal
Bases
(if installed)
and network
module
[14.9]
0.59
Figure 3. Mounting with Terminal Blocks Apart
4. Install your Bus Extender Cable. The female end of the cable plugs into the terminal
base closer to the network module, and the male end plugs into the terminal base farther
from the network module. The cables are keyed to prevent improper installation.
5. If you drilled holes in Step 3, secure the Bus Extender Cable by driving a screw through
the mounting tab holes and into the pilot holes. Place the plastic spacers (included with
the cable) behind the mounting tab. Use the thin spacers when the FieldPoint bank is
mounted directly to a wall or panel. Use the thick spacers when the FieldPoint bank
is mounted on a DIN rail.
Terminals Apart. Dimensions are given in inches [millimeters].
[50.8]
2.00
max
[236]
9.30
max
[28.2]
1.11
[44.6]
1.76
[31.2]
1.23 [31.2]
1.23 [26.7]
1.05
female
end
male
end
Cable
Mounting
Holes
(drill pilot
holes in these
locations)
Other
Terminal
Bases
(if installed)
and network
module
Other
Terminal
Bases
(if installed)
[14.9]
0.59
