NCE 20LSSB Setup guide

20 Litre Electronic Microwave
Owner’s Instruction Manual
NCE20LSSB
Read the instructions carefully and keep for future reference
For all NCE product inquiries, please phone [phone]
or email [email protected].

Model:
NCE20LSSB
Rated Voltage:
230-240 V ~ 50 Hz
Rated Input Power (Microwave):
1150 W
Rated Output Power (Microwave):
700 W
Oven Capacity:
20 L
Turntable Diameter:
255 mm
External Dimensions:
440 x 332 x 259 mm
Net Weight:
Approx. 11.0 kg
2

To reduce the risk of fire, electric shock, injury to
persons or exposure to excessive microwave oven
energy when using your appliance, follow basic
precautions, including the following:
1. Warning: Liquids and other foods must not be heated
in sealed containers since they are liable to explode.
2. Warning: It is hazardous for anyone other than a
competent person to carry out any service or repair
operation that involves the removal of a cover which
gives protection against exposure to microwave energy.
3. This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children unless they are older than
8 and supervised.
4. Keep the appliance and its cord out of reach of
children less than 8 years.
5. Only use utensils that are suitable for use in microwave
6. The oven should be cleaned regularly and any food
deposits should be removed.
7. Read and follow the specific:"PRECAUTIONS TO
AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY".
8. When heating food in plastic or paper containers,
IMPORTANT SAFETY INSTRUCTIONS
WARNING
.ovens
3

9. If smoke is emitted, switch off or unplug the appliance
and keep the door closed in order to stifle any flames.
10. Do not overcook food.
11. Do not use the oven cavity for storage purposes.
Do not store items, such as bread, cookies, etc. inside
the oven.
12. Remove wire twist-ties and metal handles from
paper or plastic containers/bags before placing them in
the oven.
13. Install or locate this oven only in accordance with the
installation instructions provided.
14. Eggs in the shell and whole hard-boiled eggs should
not be heated in microwave ovens since they may
explode, even after microwave heating has ended.
15.This appliance is intended to be used in household
and similar applications such as:
-staff kitchen areas in shops, offices and other working
environments;
-by clients in hotels, motels and other residential type
environments;
-farm houses;
-bed and breakfast type environments.
16. If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
17. Do not store or use this appliance outdoors.
18. Do not use this oven near water, in a wet basement
or near a swimming pool.
19. The temperature of accessible surfaces may be high
when the appliance is operating. The surfaces are liable
to get hot during use. Keep cord away from heated
ir
keep an eye on the oven due to the possibility of ignition.
4

20. Do not let cord hang over edge of table or counter.
21. Failure to maintain the oven in a clean condition
could lead to deterioration of the surface that could
adversely affect the life of the appliance and possibly
result in a hazardous situation.
22.The contents of feeding bottles and baby food jars
shall be stirred or shaken and the temperature checked
before consumption, in order to avoid burns.
23. Microwave heating of beverages can result in
delayed eruptive boiling, therefore care must be taken
when handling the container.
24.The appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
25.Children should be supervised to ensure that they do
not play with the appliance.
26.The appliances are not intended to be operated by
means of an external timer or separate remote-control
system.
27.Accessible parts may become hot during use. Young
children should be kept away.
28.Steam cleaner is not to be used.
29.During use the appliance becomes hot. Care should
be taken to avoid touching heating elements inside the
oven.
30.Only use the temperature probe recommended for
this oven.(for ovens provided with a facility to use a
surface, and do not cover any vents on the oven.
5

without adequate ventilation as per installation instructions.
31. WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to avoid
touching heating elements. Children less than 8 years
of age shall be kept away unless continuously
supervised.
32.The microwave oven must be operated with the
decorative door open. (for ovens with a decorative door.)
33.The microwave oven must not be placed in a cabinet
READ CAREFULLY AND KEEP FOR FUTURE
REFERENCE
34.The microwave oven is intended for heating food and
beverages. Drying of food or clothing and heating of
warming pads, slippers, sponges, damp cloth and similar
may lead to risk of injury, ignition or fire.
temperature-sensing probe.)
6

To Reduce the Risk of Injury to Persons
Grounding Installation
DANGER
Electric Shock Hazard
Touching some of the
internal components can
cause serious personal
injury or death. Do not
disassemble this
appliance.
WARNING
Electric Shock Hazard
Improper
Consult a qualified
electrician or serviceman
if the grounding instructions
are not completely
understood or if doubt exists
as to whether the appliance
is properly grounded.
If it is necessary to use an
extension cord, use only
a 3-wire
use of the gro undi n g
can result in electric shock.
Do not plug into an outlet
until appliance is properly
installed and grounded.
This appliance must be
grounded. In the event of
an electrical short circuit,
grounding reduces the
risk of electric shock by
providing an escape wire
for the electric current.
This appliance is equipped
with a cord having a
grounding wire with
a grounding plug. The
plug must be plugged into
an outlet that is properly
installed and grounded.
1. A short power-supply cord
is provided to reduce the risks
resulting from becoming
entangled in or tripping over a
longer cord.
2. If a long cord set or extension
cord is used:
1)The marked electrical rating
of the cord set or extension cord
should be at least as great as
the electrical rating of the
appliance.
2)The extension cord must be
a grounding-type 3-wire cord.
3)The long cord should be
arranged so that it will not drape
over the counter top or tabletop
where it can be pulled on
by children or tripped over
unintentionally.
extension cord.
7

CLEANING
Be sure to unplug the appliance from the power supply.
1. Clean the cavity of the oven after using with a slightly damp
cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighbouring parts must be
cleaned carefully with a damp cloth when they are dirty.
4. Do not use harsh abrasive cleaners or sharp metal scrapers
to clean the oven door glass since they can scratch the surface,
which may result in shattering of the glass.
5. Cleaning Tip---For easier cleaning of the cavity walls that the
food cooked can touch: Place half a lemon in a bowl, add 300ml
(1/2 pint) water and heat on 100% microwave power for 10
minutes. Wipe the oven clean using a soft, dry cloth.
UTENSILS
CAUTION
Personal Injury Hazard
It is hazardous for
anyone other than a
compentent person to
carry out any service
or repair operation that
involves the removal of
a cover which gives
protection against
exposure to microwave
energy.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold
water (250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is
warm, do not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.
See the instructions on "Materials you can use in
microwave oven or to be avoided in microwave oven."
There may be certain non-metallic utensils that are not
safe to use for microwaving. If in doubt, you can test the
utensil in question following the procedure below.
8

Materials you can use in microwave oven
Utensils Remarks
Aluminum foil Shielding only. Small smooth pieces can be used to cover thin parts of
meat or poultry to prevent overcooking. Arcing can occur if foil is too
close to oven walls. The foil should be at least 1 inch (2.5cm) away from
oven walls.
Follow manufacturer’s instructions. The bottom of browning dish must be
at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause
the turntable to break.
Microwave-safe only. Follow manufacturer's instructions. Do not use
cracked or chipped dishes.
Always remove lid. Use only to heat food until just warm. Most glass jars
are not heat resistant and may break.
Heat-resistant oven glassware only. Make sure there is no metallic trim.
Do not use cracked or chipped dishes.
Follow manufacturer’s instructions. Do not close with metal tie. Make
slits to allow steam to escape.
Use for short–term cooking/warming only. Do not leave oven unattended
while cooking.
Use to cover food for reheating and absorbing fat. Use with supervision
for a short-term cooking only.
Use as a cover to prevent splattering or a wrap for steaming.
Microwave-safe only. Follow the manufacturer’s instructions. Should be
labeled "Microwave Safe". Some plastic containers soften, as the food
inside gets hot. "Boiling bags" and tightly closed plastic bags should be
slit, pierced or vented as directed by package.
Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
Browning dish
Glass jars
Glassware
Oven cooking
bags
Paper plates
and cups
Paper towels
Parchment
paper
Plastic
Plastic wrap
Dinnerware
Materials to be avoided in microwave oven
Utensils Remarks
Aluminum tray
Food carton with
metal handle
Metal or metal-
trimmed utensils
Metal twist ties
Paper bags
Plastic foam
Wood
Metal shields the food from microwave energy. Metal trim may
cause arcing.
May cause a fire in the oven.
Plastic foam may melt or contaminate the liquid inside when exposed
to high temperature.
Wood will dry out when used in the microwave oven and may split
or crack.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing and could cause a fire in the oven.
9

A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
F
G
A
C B
ED
SETTING UP YOUR OVEN
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
Glass tray 1
Turntable ring assembly 1
Instruction Manual 1
Hub (underside)
Glass tray
Turntable ring assembly
a. Never place the glass tray upside down. The glass
tray should never be restricted.
b. Both glass tray and turntable ring assembly must
always be used during cooking.
c. All food and containers of food are always placed
on the glass tray for cooking.
d. If glass tray or turntable ring assembly cracks or
breaks, contact your nearest authorized service
center.
Turntable Installation
Turntable shaft
10

INSTALLATION
1. Make sure all the packing materials are removed from the inside of the door.
2. Inspect the oven after unpacking for any visual damage such as:
Misaligned Door
Damaged Door
Dents or Holes in Door Window and Screen
Dents in Cavity
If any of the above are visible, DO NOT use the oven.
3. This Microwave Oven weighs 11.5 kg and must be placed on a horizontal surface
strong enough to support this weight.
4. The oven must be placed away from high temperature and steam.
5. DO NOT place anything on top of the oven.
6. DO NOT remove the turn -table drive shaft.
7. As with any appliance, close supervision is necessary when used by children.
WARNING-THIS APPLIANCE MUST BE EARTHED.
1. The plug socket should be within easy reach of the power cord
2. This oven requires 1.1-1.15 KVA for its input.
Consultation with service engineer is suggested when installing the oven.
CAUTION: This oven is protected internally by ac 250V,10 Amp Fuse.
The accessible surface may be hot during operation.
11

This microwave oven uses modern electronic controls to adjust cooking parameters
to meet your needs better for cooking.
OPERATION
1. Clock Setting
When the microwave oven is electried,the oven will display "0:00", The buzzer will
ring once.
1) Press "CLOCK/PRE-SET" , the hour gures will ash;
2) Press " " or " " to adjust the hour gures,the input time should be within 0--23.
3) Press "CLOCK/PRE-SET", the minute gures will ash.
4) Turn " " or " " to adjust the minute gures, the input time should be within 0--59.
5) Press "CLOCK/PRE-SET" to nish clock setting. ":" will
has been nished.
Note:
1) The clock will not work if it is not set when powered.
2) During the process of clock setting, if you press " STOP/CLEAR ", the oven
will go back to the previous status automatically.
5) ash, The clock setting has
1)
2. Microwave Cooking
1) Press the "Microwave" key once, and "P100" will display.
2) Press "Microwave" for times or press " "and " " to select the
microwave power from100% to 10%. "P100", "P80", "P50", "P30", "P10" will display
in order.
3) Press "START/+30SEC/CONFIRM" to conrm.
4) Press " " or " "to adjust the cooking time.
(The time setting should be 0:05-95:00)
5) Press " START/+30SEC./CONFIRM " to start cooking.
NOTE: the step quantities for the adjustment time of the coding switch are as follows:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
Microwave Power Chart
Microwave Power 80% 50% 30% 10%100%
Display
12

4. Defrost By Weight
1) Press " WEIGHT/TIME DEFROST " once, the screen will display "dEF1".
2) Press " " or " " to select the food weight. The range of weight is 100-2000g.
3) Press " START/+30SEC/CONFIRM " key to start defrosting.
5. Defrost By Time
1) Press "WEIGHT/TIME DEFROST" twice, the screen will display "dEF2".
2) Press " " or " " to select the cooking time.The maximum time is 95 minutes.
3) Press "START/+30SEC/CONFIRM " key to start defrosting.
6.Multi-Stage Cooking
Maximum two stages can be set. If one stage is defrosting, it will be put in the rst stage
Example: if you want to defrost the food for 5 minutes, then to cook with 80% microwave
power for 7 minutes. The steps are as following:
1) Press "WEIGHT/TIME DEFROST " twice, the screen display "dEF2".
2) Press " " or " " to adjust the defrost time of 5 minutes;
3) Press"Microwave " once, the screen will display "P100".
4) Press " " or " " to choose microwave power till "P80" display;
5) Press "START/+30SEC/CONFIRM" to conrm, the screen will display "P80".
6) Press " " or " " to adjust the cooking time of 7 minutes;
7) Press "START/+30SEC/CONFIRM" to start cooking.
automatically. The buzzer will ring once after each stage and the next stage will begin.
1) In waiting state, press " START/+30SEC/CONFIRM " key to cook with 100% power
level for 30 seconds. Each press on the same key can increase 30 seconds. The
maximum cooking time is 95 minutes.
2) During the microwave cooking and the defrost by time process, press
3) In waiting state, turn " " to set cooking time with 100% microwave power, then
press " " to start cooking.
Note:
Under the states of auto menu and defrost by weight, cooking time cannot be increased
by pressing "START/+30SEC./CONFIRM".
press " "
" "
START/+30SEC/CONFIRM
"START/+30SEC/CONFIRM" to increase the cooking time.
3. Speedy Cooking
13

7. Pre-set Function
1) Set the clock rst. (Consult the instructions of clock setting.)
2) Input the cooking program. Maximum two stages can be set. Defrosting should not be
set in preset function.
Example: if you want to cook with 80% microwave power for 7 minutes.
a. Press "Microwave" once;
b. Press " " or " " to choose 80% microwave power till "P80" display;
c. Press "START/+30SEC/CONFIRM" to conrm;
d. Press " " or " " to adjust the cooking time of 7 minutes;
After the above steps, please do not press "START/+30SEC/CONFIRM". Then do as
following:
3) Press "CLOCK/PRE-SET". The hour gures will ash;
4) Press " " or " " to adjust the hour gures, the input time should be within 0--23.
5) Press "CLOCK/PRE-SET", the minute gures will ash.
6) Press " " or " " to adjust the minute gures, the input time should be within 0--59.
7) Press "START/+30SEC./CONFIRM" to nish setting. ":" will light up, buzzer will ring
twice when the time arrives, then cooking will start automatically.
Note: clock must be set rst. Otherwise the pre-set function will not work.
8. Auto Menu
1) In waiting state, press " " to choose the menu from "A-1" to "A-8".
2) Press "START/+30SEC/CONFIRM " to conrm the menu you choose.
3) Press " " or " " to choose the food weight.
4) Press "START/+30SEC./CONFIRM " to start cooking.
14

The menu chart:
100g(with water 800ml)
200g
400g
600g
200g
400g
200ml
400ml
Menu Weight Power
A-1
REHEAT
A-3
FISH
A-2
VEGETABLE
A-5
PASTA
A-4
MEAT
A-7
PIZZA
A-6
POTATO
A-8
SOUP
200g
400g
600g
200g
300g
400g
250g
350g
450g
250g
350g
450g
50g(with water 450ml)
100
200
400
600
200
400
200
400
200
400
600
200
300
400
250
350
450
250
350
450
50
Display
100%
100%
80%
80%
100%
100%
80%
100%
AUTO
15

10. Inquiring Function
1) In cooking state of microwave. Press "Microwave"
2) During cooking state, press "CLOCK / PRE-SET" to check the current time. It will
3) In preset state, press "CLOCK / PRE-SET" to inquire the preset time, and the preset
time will display for 3 seconds.
11. Specification
(1) "START/+30SEC/CONFIRM" must be pressed to continue cooking if the door is
opened during cooking;
(2) Once the cooking programme has been set , "START/+30SEC/CONFIRM" is not
pressed in 1 minute. The current time will be displayed. The setting will be cancelled.
(3) The buzzer sounds once by efcient press, inefcient press will be no responces.
the current power will be displayed
for 3 seconds.
display for 3 seconds..
Lock: In waiting state, press "STOP/CLEAR" for 3 seconds, there will be a long "beep"
denoting entering the children-lock state and screen will display " ".
Lock quitting: In locked state, press "STOP/CLEAR" for 3 seconds, there will be a long "beep"
denoting that the lock is released.
9. Lock Function for Children
16

BEFORE YOU CALL FOR SERVICE
1. If the oven will not perform at all, the display does not appear or the display
disappears:
a) Check to ensure that the oven is plugged in securely. If it is not, remove the plug
from the outlet, wait 10 seconds and plug it in again securely.
b) Check the premises for a blown circuit fuse or a tripped main circuit breaker. If
these seem to be operating properly, test the outlet with another appliance.
2. If the microwave power does not function:
a) Check to see whether the timer is set.
b) Check to make sure that the door is securely closed to engage the safety
interlocks. Otherwise, the microwave energy will not flow into the oven.
IF NONE OF THE ABOVE RECTIFIES THE SITUATION, THEN CONTACT THE
AUTHORIZED SERVICE AGENT.
Note:
The appliance is for household use for heating food and beverages using
electromagnetic energy and for indoor use only.
RADIO INTERFERENCE
Microwave oven may cause interference to your radio, TV, or similar equipment. When
interference occurs, it may be eliminated or reduced by the following procedures.
a. Clean the door and sealing surface of the oven.
b. Place the radio, TV, etc. as far away from your microwave oven as possible.
c. Use a properly installed antenna for your radio, TV, etc. to get a strong signal
reception.
17

TROUBLE SHOOTING
According to Waste of Electrical and Electronic Equipment
(WEEE) directive, WEEE should be separately collected and
treated. If at any time in future you need to dispose of this
product please do NOT dispose of this product with household
waste. Please send this product to WEEE collecting points
where available.
It is forbidden to run the unit without any food inside.
It is very dangerous.
18
