About this guide
This guide is a complement to Quick Start Guide. The Quick Start Guide provides instructions for quick setup, while this guide
provides details of each function and shows how to configure the smart phone appropriate to your needs.
When using this guide, please notice that features of the device may vary slightly depending on the model and software
version you have, and on your location, language, and Internet service provider. All screenshots, images, parameters and
descriptions documented in this guide are used for demonstration only.
Conventions
In this guide, the following conventions are used:
Convention Description
Smart phone/phone Stands for Neffos X1 Lite without any explanation.
Parameters Parameters provided in the screenshots are just references for configuring the smart phone, which may be
different from the actual situation. You can set the parameters according to your demand.
Underlined Italic and underlined words or phrases are hyperlinks. You can click to redirect to a specific section for more
details.
Screenshots The demonstrated screenshots may look a little different from the actual UI of your smart phone due to the
various firmware versions. Please just configure your phone based on the actual UI.
-> The menu structure which shows the path to enter the corresponding page. For example, Settings -> WLAN
means the WLAN function page is under the Settings menu.
Note: Ignoring the notes in the guide might result in a malfunction or damage to the device.

1Chapter 1 . Get started
Get started
This chapter introduces the smart phone’s hardware information and guides you how to
assemble your phone when you get started on using your new phone.
• Overview
• Buttons
• Put in the cards
• Initial setup
• Charge your phone
1. 1 Overview
Rear camera
Fingerprint
identification sensor
Front camera
Two-tone flashSIM/SD card tray
Volume buttons
Power button
Charging/data portEarpiece
Headphone jack
1
2
3
4
5
6
7
8
9
10
1
45
2 3
9
6
10
7
8
1. 2 Buttons
The buttons you use with Neffos include virtual ones and physical ones.
Power button
• Lock Neffos: Press the Power button to manually lock the screen. Locking your phone puts the display to
sleep, saves the battery and prevents unmeant operations on the screen. You can still receive phone calls,
text messages, alarms and notifications as well as listening to music and adjusting the volume. Neffos locks
1

2Chapter 1 . Get started
the screen automatically in a given period of inactivity. To adjust the time, go to Settings -> Display ->
Automatically lock.
• Unlock Neffos: Press the Power button to wake the screen. For additional security, you can require a swipe,
pattern, PIN, password or fingerprint to unlock you phone. Go to Settings -> Screen lock, fingerprint
and security -> Screen lock to choose a safe way to unlock your phone.
• Turn Neffos on: Press and hold the Power button until your phone vibrates and the screen turns on.
• Turn Neffos off: Press and hold the Power button, then tap Power off.
Note:
If your phone does not respond after holding down the Power button for 10 seconds, the battery may be empty. Connect
your phone to a charger to charge the battery.
Volume button
You can adjust the audio volume when you’re on the phone or listening to songs, movies or other media. You
can also use Volume button to take a picture or record a video. Refer to Take a photo and Record a video to
learn more.
Home button
Touch Home button to return to the default Home screen.
Back button
Touch Back button to return to the previous screen or close an application. When entering text, touch Back
button to close the onscreen keyboard.
You can go to Settings -> Smart settings -> Buttons settings to set the Back button on the left or on the
right of your phone.
Recent apps button
Touch Recent apps button to display recently used applications.
1. 3 Put in the cards
Insert Nano SIM cards and Nano SD card (optional)
With your phone turned off, eject the SIM card tray by inserting a paper clip or the pin provided into the hole
on the tray. Place the the SIM card(s) and SD card (optional) into the tray with the gold contacts face down and
then insert the tray back into the phone.
Note:
1. Your phone only supports nano-SIM cards. Contact your carrier for a new or replacement nano-SIM card. You can
insert 2 nano-SIM cards, or 1 nano-SIM card and 1 micro-SD card. For more information, see Dual SIM settings.
2. Please exercise caution when using the SIM ejector pin to avoid hurting your fingers or damaging your phone. Store
your pin in a safe place out of the reach of children to prevent accidental swallowing or injury.

3Chapter 1 . Get started
1. 4 Initial setup
Press and hold the Power button to turn on your phone, and then follow the onscreen instructions to complete
the initial setup. It is recommended to insert your SIM card before you start the initial setup.
1. Select your language, and then tap .
2. Proceed to Set up SIM cards screen. Follow the onscreen instruction to select a SIM for cellular data, calls
and text messages and then tap NEXT.
• If you have not inserted your SIM card before the initial setup, your phone will proceed to Insert SIM
cards in this step. Then you can insert your SIM card first. For more information, see Put in the cards.If
you do not want to insert your SIM card now, tap SKIP to move to the next step.
3. Proceed to Set up your Neffos X1 Lite screen. You can choose restore a backup or copy from a devide
or just tap Set up as new. Then your phone will automatically list available WLAN networks. Select the
network you want to connect to, and then enter the password to access the Internet. (This can take up
to 2 minutes.) Or you can tap Don’t use any network for setup -> CONTINUE and move to next step.
4. Proceed to Google services screen. The services are turned on by default. Tap NEXT.
5. Proceed to Date & time screen. Set the time according to your location and then tap NEXT.
6. Proceed to Name screen. Add your name to allow your phone to personalize some apps. Then tap NEXT.
7. Pcoceed to Protect your phone screen. Select a device protection feature and then follow the onscreen
instructions to complete. If you don’t want to set now, tap No, thanks and tap SKIP -> SKIP ANYWAY.
8. Pcoceed to Anything else screen. You can set up a few more things there, or you can just skip by tapping
Set up later.
9. Proceed to Terms And Conditions screen. Carefully read the terms and conditions and then tap AGREE.
10. Setup completed. Tap START USING YOUR PHONE.

4Chapter 1 . Get started
1. 5 Charge your phone
Connect the device to a power outlet using the included USB cable and power adapter.
1. Connect the USB cable into the Charging port.
2. Connect the USB cable to the power adapter, then plug the power adapter into a power outlet.
3. When the battery is full, unplug the power adapter from the power outlet and remove the USB cable from
your phone.
Note:
1. The battery is built into the phone and is not removable. Do not attempt to remove the battery yourself.
2. It is entirely normal that your phone may become warm after prolonged use or when exposed to high ambient
temperatures. If your phone becomes hot to the touch, stop charging it and disable unnecessary features. Place your
phone in a cool location and allow it to cool down to room temperature. Avoid prolonged contact with the surface
of your phone if it becomes hot.
3. When charging your phone, only use genuine Neffos batteries, chargers, and USB cables. Third-party accessories are
a potential safety hazard and may impair your phone’s performance. Avoid using your phone when it is charging. Do
not cover your phone or the power adapter.
4. A low battery warning will be displayed when the battery level is low. Your phone will turn off automatically when
the battery is nearly empty.
5. Charging times may vary depending on the ambient temperature and the remaining battery level.

5Chapter 2 . Basics
Basics
Learn about your smart phone’s basic feature.
• Touchscreen gestures
• Home screen
• Status icons
• Quick settings panel
• Notification panel
• Type text
• Take a screenshot
• Configure your fingerprint
• Change the theme
• Access applications
2. 1 Touchscreen gestures
Use simple touchscreen gestures to perform a variety of tasks, such as open applications, scroll through lists,
and zoom images.
Touch: Simply tap an item once. For example, touch to select an option or open an application.
Touch and hold: Touch and leave your finger on the screen for 2 seconds or more to activate onscreen items.
For example, touch and hold a widget on the Home screen to move it.
2

6Chapter 2 . Basics
Swipe: Place your finger on the screen, and drag your finger to the direction you want. For example, in the
Notifications panel, swipe left or right on a notification to dismiss it. Swipe vertically or horizontally to go to
other home screens, scroll through a document, and more.
Drag: Touch and hold an item and then move it to another position. For example, you can rearrange applications
and widgets on the Home screen.
Zoom out: Pinch two fingers together on the screen. For example, pinch two fingers together to zoom out on
a picture.

7Chapter 2 . Basics
Zoom in: Spread two fingers apart on the screen. For example, pinch two fingers out to zoom on a picture.
2. 2 Home screen
Your home screens are where you can find your favorite widgets and all your applications.
Status bar
Widget
APP screen indicator
APP shortcuts
Status bar: Displays notifications and status icons.

8Chapter 2 . Basics
Widget: Self-contained applications that run on the Home screen (not shortcuts).
APP screen indicator: Indicates which screen is displayed.
APP shortcuts: Shortcuts to your favorite applications.
Organize applications and widgets on the Home screen
On the Home screen, pinch two fingers together or touch and hold a blank area on the screen to access the
Home screen editor. You can:
• Add a widget to the Home screen
Add frequently used widgets to the Home screen for quick access.
1. On the Home screen, pinch two fingers together to open the Home screen editor.
2. Tap Widgets and select a widget. Touch and hold the widget and drag it to a blank area on the Home
screen.
3. Tap a blank area on the Home screen to quit the Home screen editor.
Note:
You must have enough space on the Home screen to add widgets. If there is not enough space, add another Home screen
or free up some space.
• Move a widget or icon
On the Home screen, touch and hold an application icon or widget and then drag them to the desired location.
• Delete a widget or icon
4. On the Home screen, touch and hold the application or widget you want to delete and then move it to
Remove in the status bar.
• Create a folder
Create Home screen folders to organize your applications by type. For example, you can create a Cameras
folder that contains all of your camera applications.
1. On the Home screen, drag an icon on top of another icon to create a folder containing both applications.
2. To rename the folder, open the folder, tap Unnamed Folder and enter the folder name.
2. 3 Status icons
The icons in the status bar at the top of the screen diaplay information about your phone’s status.
Status icons Indications
Battery low
Charging
Battery full
Battery saver
Signal strength
4G SIM 1 selected for cellular data
4G
SIM 2 selected for cellular data
No signal
EConnected over GPRS
3G Connected over 3G
4G Connected over LTE
Connected to a PC using USB cable

9Chapter 2 . Basics
Headset inserted
WLAN
Mobile data
Bluetooth
Hotspot
No SIM card installed
Screenshots
Mute mode enabled
Airplane mode enabled
Data saver
Bluetooth enabled
Download status
Uploading data
Alarms enabled
Call in progress
Missed calls
New messages
Do not disturb
2. 4 Quick settings panel
Swipe down from the top of any screen twice to open the Quick settings panel.
Note: On the Lock screen, swipe only once to open the Quick settings panel.
Touch the shortcut switches on the Quick settings panel to enable or disable the functions.
1. Settings: Tap to go to Settings.
2. Brightness slider: Use this slider to adjust the brightness of the screen

10Chapter 2 . Basics
3. WLAN: Tap to enable WLAN.
4. Bluetooth: Tap to enable Bluetooth.
5. Rotation: Tap to open auto-ratate which can switch the touchscreen from portrait to landscape when
you rotate your phone.
6. Location: Tap to enable location service.
7. Flashlight: Tap to enable flashlight.
8. Eye comfort: Tap to switch the screen color to eye comfort mode.
9. Screen indicator: Tap to change to next screen to view other options.
10. Airplane mode: Tap to enable airplane mode.
11. Mobile data: Tap to enable mobile data.
12. Do not disturb: Tap to silence your phone.
13. Battery saver: Tap to enable battery saver.
14. Screenshot: Tap to make a screenshot of the current page.
15. Silent: Tap to enable silent mode.
16. Edit: Tap to enter the edit page. You can drag the shortcut switches on the edit page to/from Quick
settings panel.
17. Float button: Tap to enable the float button.
18. Data saver: Turn on data saver to reduce data usage.
19. Nearby: Tap to scan for links from things nearby(need to open Bluetooth and Location).
20. Hotspot: Tap to enable hotspot.
2. 5 Notification panel
Notification panel collects all the notifications and alerts so that you can review them whenever you like.
• Open Notification panel: Swipe down from the status bar to open the Notification panel.
• View a notification: Tap an item to view the details. Or swipe the notification left or right to remove it from
the list. ( New notifications, such as missed calls and messages are displayed on the Lock screen. Double-tap it
to view the details.)
• Close Notification panel: Swipe up, or press the Back button or Home button.

11Chapter 2 . Basics
Notification management
Go to Settings -> Notification manager, select the desired application. You can:
• Allow notifications: Turn the switch Allow notifications off to disable notifications for the application so as
to prevent unnecessary disturbances. Turn the switch on to enable notifications for the application.
• Treat as priority: Let this application’s notifications to be heard when Do not disturb is set to Priority only.
• Show silently: Don’t make sound, vibrate, or peek these notifications into view on the current screen.
2. 6 Type text
Enter text
Use Android input method to enter text.
1. Tap , or touch and slide to a letter to type uppercase. Double-tap for caps lock.
2. Enter numbers, punctuations and symbols.
3. Enter a comma.
Tap and hold to open the input options menu.
4. If you have several keyboards, you can tap to switch to the last one you used. You can also touch and
hold it to choose the keyboard you need.
5. Enter a space, or double-tap the space bar quickly to end a sentence with a period.
6. Enter a period.
Tap and hold to enter a symbol.
7. Enter emoticon.
8. Delete the characters to the left of the cursor.
Edit text
• Revise text: Tap the text to position the insertion point and start revising.
• Select text: Tap and hold the text field to display the selection options(cut/copy/share/select all). Drag
to select more or less text.
Spell checker
You can turn on the Spell checker feature to help you enter correct words.
1. Go to Settings -> Language & input -> Spell checker.
2. Turn the switch on.

12Chapter 2 . Basics
Switch input method
1. On the Home screen, tap Settings -> Language & input -> Keyboard and input methods.
2. Select an input method you need.
2. 7 Take a screenshot
Press the Power button and Volume-down button at the same time to take a screenshot.
2. 8 Configure your fingerprint
Use the fingerprint sensor to unlock the screen, take photos and unlock apps.
Add a fingerprint for the first time
For added security and to ensure that you can still access your data if your phone fails to recognize your
fingerprint, you will need to set a backup screen lock method when configuring fingerprint unlock.
1. Go to Settings -> Screen lock, fingerprint and security -> Fingerprint management.
2. Select Pattern or PIN or Password, and then follow the onscreen instructions to set a screen lock
password.
3. Once you have configured the password, tap Add fingerprint.
4. Place your fingertip on the fingerprint sensor. Press down lightly on the sensor until your phone vibrates.
Repeat this step using different parts of your fingertip until your phone has successfully added your
fingerprint.
5. Once you have added your fingerprint, tap DONE.
Note:
When recording your fingerprint, make sure the fingerprint sensor and your fingers are dry and clean.
Add, delete or rename your fingerprint
Add multiple fingerprints to make it easier to unlock your phone. You can also delete or rename your fingerprints.
1. Go to Settings -> Screen lock, fingerprint and security -> Fingerprint management.
2. Enter the screen lock pattern/password/PIN.
3. In the Fingerprint list section, you can:
• Tap Add fingerprint to add a new fingerprint. You can add up to five in total.
• Tap a previously added fingerprint to rename or tap to delete it.
4. After you enter several fingerprint, there is a list showing all the recorded fingerprint. When you place your
fingertip on the fingerprint sensor, the corresponding place turns grey, which helps you easily find the
fingerprint.
Use fingerprint to take photos or record videos
When using the camera, touch the fingerprint sensor to take a picture or record a video.
1. Go to Settings -> Screen lock, fingerprint and security -> Tap to capture .
2. Turn the switch on to enable the function.
Use fingerprint to access locked applications
Use a Pattern,PIN, Password or fingerprint to lock the selected app(s) to ensure privacy.
1. Go to Settings -> Screen lock, fingerprint and security -> App lock.

13Chapter 2 . Basics
2. Turn on the switch and then choose Fingerprint and follow the onscreen instruction. Choose the
apps that you want to use fingerprint to unlock and turn the switch on. Then you will need to use your
fingerprint unlock the selected apps before you can access them.
2. 9 Change the theme
Personalize your phone’s Home screen using a wide range of themes and wallpapers.
1. On the Home screem, tap Themes, select a theme, and then tap Apply.
2. Tap and you can select the theme packs, wallpapers, icons, sounds, fonts, boot animations and system
style.
2. 10 Access applications
Launch and switch between applications
• From the Home screen: Touch an icon to launch the corresponding application.
• From the Locked screen: Swipe up to launch the camera application. You can configure lock screen
shortcut in Settings -> Screen lock, fingerprint and security -> Lock screen shortcut.
• Switch to another application: Touch the Home button to return to the Home screen, and then touch the
icon of the application you want to open.
Viewing recently used applications
Touch Recent apps button to display the list of recently used applications.
• View more applications: Swipe up or down on the screen to view more recently used applications.
• Open an application: Touch a thumbnail to open the corresponding application.
• Close an application: Swipe left or right on a thumbnail to close the corresponding application, or you can
tap on a thumbnail to close it.
Uninstall applications
Free up space on your phone and boost performance by removing unused applications.
On the Home screen, tap and hold the application you want to uninstall and tap . You can also go to
Settings -> Apps, select the application you want to uninstall and touch UNINSTALL.
Note:
Some pre-installed system applications cannot be removed.

14Chapter 3 . Connection
Connection
Share your phone data with others by various kinds of connections.
• Connect to Internet
• Connect to computer
• Bluetooth
• Share your mobile data with other devices
3. 1 Connect to Internet
Connect to the Internet using WLAN or mobile data to surf the web, play games, and use instant messaging
applications.
Connect to a WLAN network
If appears in the status bar, you are connected to a WLAN network. Neffos reconnects anytime you return
to the same location.
1. Swipe down from the status bar to open the Quick settings panel.
2. Tap and hold WLAN to open the WLAN settings screen.
3. Tap the switch to turn it on. A list of available WLAN networks will be displayed.
4. Select the WLAN network you want to connect to, and then enter the password if needed. (You can also
turn WLAN on in Settings -> WLAN.)
Connect to mobile data
1. Swipe down from the status bar to open the Quick settings panel.
2. Tap and hold to enter the cellular data settings.
3. Turn on the Cellular data switch. (You can also tap . When it lights up, mobile data is enabled.)
Note:
1. Before using mobile data, ensure that you have a data plan with your carrier.
2. If a WLAN connection to the Internet isn’t available, apps and services may transfer data over your carrier’s cellular
network, which may result in additional fees. Contact your carrier for information about you cellular data plan rates.
3. Disable mobile data when not required in order to save battery power and reduce data usage.
3. 2 Connect to computer
Transfer the data on your phone to your computer or transfer the data on your computer to your phone.
1. Connect your phone to a computer using a USB cable.
2. On the Notification panel, tap USB for charging.
3. Select a USB connection mode (Charging/File transfers/Photo transfer(PTP)/MIDI) depending on your
needs. (If no connection type is specified, your phone will remain in charging mode.)
3. 3 Bluetooth
You can share data on your phone with other devices using Bluetooth.
Enable Bluetooth and pair your phone with another device
3
