network Flashlink DA-AA User manual

network-electronics.com
Analogue Audio Distribution
Amplier
Rev. 5
Flashlink User Manual
DA-AA

DA-AA Rev. 5
DATE: 24 July 2008
Network Electronics AS, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: [phone] – Fax: [phone]
E-mail: [e-mail] – Web: http://www.network-electronics.com/
Technical specifications are subject to be changed without notice.
2
Revision history
The latest version is always available in pdf-format on our web-site:
http://www.network-electronics.com/
Current revision of this document is the uppermost in the table below.
Revision Replaces Date Change Description
5 4 2008-01-31 Added Declaration of Conformity.
4 3 2007-10-26 New front page and removed old logo.
3 2 2007-10-05 Added Materials Declaration and EFUP
2 1 29.07.05 Corrected description of connector module.
1 0 10.11.04 Changed page 8, output settings
0 A 25.05.04 Exchanged ANA1 and ANA2 on dip setting
A 21.10.03 Preliminary version

DA-AA Rev. 5
DATE: 24 July 2008
Network Electronics AS, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: [phone] – Fax: [phone]
E-mail: [e-mail] – Web: http://www.network-electronics.com/
Technical specifications are subject to be changed without notice.
3
Index
1. General......................................................................................................................................................4
2. Specifications............................................................................................................................................5
3. Configuration setup.................................................................................................................................6
OUTPUT CONFIGURATION...................................................................................................................8
Configuration of ANA1 output...................................................................................................................8
Configuration of ANA2 outputs.................................................................................................................8
4. Connector module..................................................................................................................................10
4.1 Mounting the connector module........................................................................................................11
5. Module status.........................................................................................................................................11
5.1 Front Panel - Status Monitoring ........................................................................................................12
6. Interface with GYDA and RS-422 command set................................................................................12
6.1 DA-AA Command table .....................................................................................................................12
General environmental requirements for Network flashlink®equipment...........................................13
Product Warranty .....................................................................................................................................14
Materials declaration and recycling information...................................................................................15
Materials declaration ................................................................................................................................15
Environmentally-friendly use period.......................................................................................................15
Recycling information...............................................................................................................................16
EC Declaration of Conformity .................................................................................................................17

DA-AA Rev. 5
DATE: 24 July 2008
Network Electronics AS, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: [phone] – Fax: [phone]
E-mail: [e-mail] – Web: http://www.network-electronics.com/
Technical specifications are subject to be changed without notice.
4
1. General
The flashlink ® DA-AA is a dual 4 output analogue Audio Distributor. The DA-AA can be configured as
either a dual 1x4 or a single 1x8 amplifier. The latter configuration is made by connecting the inputs in
parallel or using DIP switch on PCB. The Distribution amplifier has differential inputs and differential
outputs. Overall gain can be set by DIP switches or by potentiometer for high precision gain setting. The
gain range setting is from -12 to +12 dB. The input signal can be mixed to the other channel using a DIP
switch. The Distribution Amplifier handles analogue audio signals from 20Hz to 80 kHz. The DA-AA is
designed for all audio distribution purposes in studio, duplication and Broadcast applications.
Figure 1 – DA-AA – Analogue Audio Distribution Amplifier

DA-AA Rev. 5
DATE: 24 July 2008
Network Electronics AS, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: [phone] – Fax: [phone]
E-mail: [e-mail] – Web: http://www.network-electronics.com/
Technical specifications are subject to be changed without notice.
5
2. Specifications
Electrical Input:
Number of inputs: 2
Connector: DB15 balanced
Impedance: > 10k ohms
Maximum Input Level: +25 dBu
Common mode rejection: >70dB
Electrical Output:
Number of outputs: 8
Connector: DB25 balanced (Tascam DA88)
Frequency response: 20 Hz - 80 kHz ±0.2dB
Crosstalk: -100 dB
THD+N: > 100dB ref to 20 Hz-20 kHz @ 20dBu
Impedance: 40 ohms nominal. Maximum 55 ohms
Maximum Output Level: +25 dBu
Output voltage balance ratio: >30dB
Output common mode rejection: >50dB
Switched gain tolerance: 0.1dB
Gain: -12 to +12 dB
Features
High quality audio distribution.
•Configurable dual 1x4 or single 1x8 distribution amplifier.
•Left/right swapping capability
•Gain setting for professional and consumer equipment.
•DIP switch gain compensation 10kohms / 600 ohms load
•Precision gain adjustment
•High common mode rejection on both inputs and outputs.
•Inputs and outputs may be used with unbalanced equipment.
•The input signal can be mixed to the other channel or vice versa.
Control Interfaces:
Card edge LEDs for voltage monitoring, RS-422 with open protocol, SNMP Agent and WEB interface
with GYDA controller. Control system for access to setup and module status with BITE (Built-In Test
Equipment) for use with GYDA Control System
Electrical
Power: +5V / 0.1 W,
±15V / 1.9W

DA-AA Rev. 5
DATE: 24 July 2008
Network Electronics AS, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: [phone] – Fax: [phone]
E-mail: [e-mail] – Web: http://www.network-electronics.com/
Technical specifications are subject to be changed without notice.
6
3. Configuration setup
The DA-AA has two channels, ANA1 and ANA2. DIP switch 1 (ANA1) and 2 (ANA2) sets the
individual channel properties according to table:
1
8
-
12.5dB
Don’t Care On Off
-
11.5dB
-
10.9dB
-
9.9dB
-
6.0dB
-
4.2dB
-
2.7dB
0.0dB
+
2.7dB
+
4.2dB
+
6.0dB
+
9.9dB
+
10.9dB
+
11.5dB
+
12.5dB

DA-AA Rev. 5
DATE: 24 July 2008
Network Electronics AS, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: [phone] – Fax: [phone]
E-mail: [e-mail] – Web: http://www.network-electronics.com/
Technical specifications are subject to be changed without notice.
7
1
8
Don’t Care On Off
600 ohms load on outputs
10kohms load on outputs
Variable gain by potentiometer for accurate gain
setting -12dB to +12dB
6 7
5
4
3
2
_
+
Circuit diagram for advanced users

DA-AA Rev. 5
DATE: 24 July 2008
Network Electronics AS, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: [phone] – Fax: [phone]
E-mail: [e-mail] – Web: http://www.network-electronics.com/
Technical specifications are subject to be changed without notice.
8
OUTPUT CONFIGURATION
There are two groups of four outputs, ANA1 and ANA2 output. The two groups are individually
configured using DIP switch 3 and DIP switch 4. The switch sets which of the input that is connected to
the output.
Configuration of ANA1 output
Use dip switch SW4 / ANA1 for setting the outputs ANA1
1
2
ANA2 input to ANA1 outputs
Mix ANA1 and ANA2 inputs to ANA1 outputs
ANA1 input to ANA1 outputs
Mix ANA1 and ANA2 inputs to ANA1 outputs
SW4/ANA1
Configuration of ANA2 outputs
Use DIP switch SW3 / ANA2 for setting outputs ANA2
1
2
ANA2 input to ANA2 output2
Mix ANA1 and ANA2 inputs to ANA2 outputs
ANA1 input to ANA2 outputs
Mix ANA1 and ANA2 inputs to ANA2 outputs
SW3/ANA2

DA-AA Rev. 5
DATE: 24 July 2008
Network Electronics AS, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: [phone] – Fax: [phone]
E-mail: [e-mail] – Web: http://www.network-electronics.com/
Technical specifications are subject to be changed without notice.
9
Figure 2 – DA-AA board layout.

DA-AA Rev. 5
DATE: 24 July 2008
Network Electronics AS, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: [phone] – Fax: [phone]
E-mail: [e-mail] – Web: http://www.network-electronics.com/
Technical specifications are subject to be changed without notice.
10
4. Connector module
ANA2 input –
ANA2 input +
ANA1 input –
ANA1 in
p
ut +
ANA1 output 1 –
ANA1 output 1 +
ANA1 output 2 –
ANA1 output 2 +
ANA1 output 3 –
ANA1 output 3 +
ANA1 output 4 –
ANA1 output 4 +
ANA2 output 1 –
ANA2 output 1 +
ANA2 output 2 –
ANA2 output 2 +
ANA2 output 3 –
ANA2 output 3 +
ANA2 output 4 –
ANA2 output 4 +
Figure 6 - Overview of the ADC-AES-C1 connector module
The DA-AA has a dedicated connector module: ADC-AES-C1. This module is mounted at the rear of the
sub-rack. The module is shown in figure 6. J4 is the input DSUB connector, while J6 is the output
connector. Both connectors are FEMALE.
J4:
Function Pin
Analogue Audio ANA1 positive input (ANA1+) 7
Analogue Audio ANA1 negative input (ANA1-) 15
Analogue Audio ANA2 positive input (ANA2+) 10
Analogue Audio ANA2 negative input (ANA2-) 3
Ground 2, 5, 8, 11

DA-AA Rev. 5
DATE: 24 July 2008
Network Electronics AS, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: [phone] – Fax: [phone]
E-mail: [e-mail] – Web: http://www.network-electronics.com/
Technical specifications are subject to be changed without notice.
11
J6:
Function Pin
Analogue Audio ANA1 positive output 1 24
Analogue Audio ANA1 negative output 1 12
Analogue Audio ANA1 positive output 2 10
Analogue Audio ANA1 negative output 2 23
Analogue Audio ANA1 positive output 3 21
Analogue Audio ANA1 negative output 3 9
Analogue Audio ANA1 positive output 4 7
Analogue Audio ANA1 negative output 4 20
Analogue Audio ANA2 positive output 1 18
Analogue Audio ANA2 negative output 1 6
Analogue Audio ANA2 positive output 2 4
Analogue Audio ANA2 negative output 2 17
Analogue Audio ANA2 positive output 3 15
Analogue Audio ANA2 negative output 3 3
Analogue Audio ANA2 positive output 4 1
Analogue Audio ANA2 negative output 4 14
Ground 2, 5, 8, 11,16,19,22,26
4.1 Mounting the connector module.
The details of how the connector module is mounted, is found in the user manual for the sub-rack frame
FR-2RU-10-2.
This manual is also available from our web site: http://www.network-electronics.com/
5. Module status
The status of the module can be monitored in three ways.
1. GYDA System Controller (optional).
2. LEDs at the front of the sub-rack.
LED’s are mounted on the module itself, whereas the GYDA System Controller is a separate module
giving detailed information on the card status. The function of the LEDs are described in sections 5.1.
The GYDA controller is described in a separate user manual.

DA-AA Rev. 5
DATE: 24 July 2008
Network Electronics AS, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: [phone] – Fax: [phone]
E-mail: [e-mail] – Web: http://www.network-electronics.com/
Technical specifications are subject to be changed without notice.
12
5.1 Front Panel - Status Monitoring
The status of the module can be easily monitored visually by the LED’s at the front of the module. The
LED’s are visible through the front panel. The LED on top tells if the DA-AA is ok or not (green LED
means ok – red is alarm). The second LED gives the input signal status.
The DA-AA has 2 LEDs each showing a status corresponding.
Diode \ state Red LED Yellow LED Green LED No light
Status Module is faulty
Module is OK Module power is OK Module has no power
Input No signal present Signal present
6. Interface with GYDA and RS-422 command set
All commands follow the flashlink protocol and can be used for direct control access to the modul. The
control system can either be a GYDA-SC or a third-party control system with integrated flashlink
protocol. The module can also be manually controlled with a VT100 compatible terminal program.
The protocol can be found on our web page; http://www.network-electronics.com
6.1 DA-AA Command table
Command Response Comment
? See protocol description The “hello” command
Info Module status information
Status Give module status

DA-AA Rev. 5
DATE: 24 July 2008
Network Electronics AS, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: [phone] – Fax: [phone]
E-mail: [e-mail] – Web: http://www.network-electronics.com/
Technical specifications are subject to be changed without notice.
13
General environmental requirements for Network flashlink®equipment
1. The equipment will meet the guaranteed performance specification under the following environmental
conditions:
•Operating room temperature range 0°C to 40°C
•Operating relative humidity range up to 90% (non-condensing)
2. The equipment will operate without damage under the following environmental conditions:
•Temperature range -10°C to 50°C
•Relative humidity range up to 95% (non-condensing)

DA-AA Rev. 5
DATE: 24 July 2008
Network Electronics AS, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: [phone] – Fax: [phone]
E-mail: [e-mail] – Web: http://www.network-electronics.com/
Technical specifications are subject to be changed without notice.
14
Product Warranty
The warranty terms and conditions for the product(s) covered by this manual follow the General Sales
Conditions by Network Electronics AS. These conditions are available on the company web site of
Network Electronics AS:
www.network-electronics.com

DA-AA Rev. 5
DATE: 24 July 2008
Network Electronics AS, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: [phone] – Fax: [phone]
E-mail: [e-mail] – Web: http://www.network-electronics.com/
Technical specifications are subject to be changed without notice.
15
Materials declaration and recycling information
Materials declaration
For product sold into China after 1st March 2007, we comply with the “Administrative Measure on the
Control of Pollution by Electronic Information Products”. In the first stage of this legislation, content of
six hazardous materials has to be declared. The table below shows the required information.
Toxic or hazardous substances and elements
組成名稱
Part Name
鉛
Lead
(Pb)
汞
Mercury
(Hg)
镉
Cadmium
(Cd)
六价铬
Hexavalent
Chromium
(Cr(VI))
多溴联苯
Polybrominated
biphenyls
(PBB)
多溴二苯醚
Polybrominated
diphenyl ethers
(PBDE)
DA-AA X O O O O O
O: Indicates that this toxic or hazardous substance contained in all of the homogeneous materials for
this part is below the limit requirement in SJ/T11363-2006.
X: Indicates that this toxic or hazardous substance contained in at least one of the homogeneous
materials used for this part is above the limit requirement in SJ/T11363-2006.
Environmentally-friendly use period
The manual must include a statement of the “environmentally friendly use period”. This is defined as the
period of normal use before any hazardous material is released to the environment. The guidance on how
the EFUP is to be calculated is not finalised at the time of writing. See
http://www.aeanet.org/GovernmentAffairs/qfLeOpAaZXaMxqGjSFbEidSdPNtpT.pdf for an unofficial
translation of the draft guidance. For our own products, Network Electronics has chosen to use the 50
year figure recommended in this draft regulation.
Network Electronics suggests the following statement on An “Environmentally Friendly Use Period”
(EFUP) setting out normal use:
EFUP is the time the product can be used in normal service life without leaking the hazardous materials. We expect the normal
use environment to be in an equipment room at controlled temperature range (0ºC - 40ºC) with moderate humidity (< 90%, non-
condensing) and clean air, not subject to vibration or shock.
Further, a statement on any hazardous material content, for instance, for a product that uses some tin/lead
solders:
Where a product contains potentially hazardous materials, this is indicated on the product by the appropriate symbol containing
the EFUP. The hazardous material content is limited to lead (Pb) in some solders. This is extremely stable in normal use and the
EFUP is taken as 50 years, by comparison with the EFUP given for Digital Exchange/Switching Platform in equipment in
Appendix A of “General Rule of Environment-Friendly Use Period of Electronic Information Products”. This is indicated by the
product marking:

DA-AA Rev. 5
DATE: 24 July 2008
Network Electronics AS, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: [phone] – Fax: [phone]
E-mail: [e-mail] – Web: http://www.network-electronics.com/
Technical specifications are subject to be changed without notice.
16
50
It is assumed that while the product is in normal use, any batteries associated with real-time clocks or battery-backed RAM will
be replaced at the regular intervals.
The EFUP relates only to the environmental impact of the product in normal use, it does not imply that the product will
continue to be supported for 50 years.
Recycling information
Network Electronics provides assistance to customers and recyclers through our web site
http://www.network-electronics.com.Please contact Network Electronics’ Customer Support for
assistance with recycling if this site does not show the information you require.
Where it is not possible to return the product to Network Electronics or its agents for recycling, the
following general information may be of assistance:
Before attempting disassembly, ensure the product is completely disconnected from power and signal
connections.
All major parts are marked or labelled to show their material content.
Depending on the date of manufacture, this product may contain lead in solder.
Some circuit boards may contain battery-backed memory devices.

DA-AA Rev. 5
DATE: 24 July 2008
Network Electronics AS, P.O.Box 1020, N-3204 Sandefjord, Norway. Tel.: [phone] – Fax: [phone]
E-mail: [e-mail] – Web: http://www.network-electronics.com/
Technical specifications are subject to be changed without notice.
17
EC Declaration of Conformity
Network Electronics AS
P.B. 1020, N-3204 SANDEFJORD, Norway
MANUFACTURER
AUTHORISED REPRESENTATIVE
(Established within the EEA) Not applicable
DA-AA
MODEL NUMBER(S)
Analogue Audio Distribution Amplifier
DESCRIPTION
LVD 73/23/EEC
EMC 2004/108/EEC
DIRECTIVES this equipment complies with
EN 55103-1:1996
EN 55103-2:1996
HARMONISED STANDARDS applied in order to
verify compliance with Directive(s)
TEST REPORTS ISSUED BY Notified/Competent Body Report no:
Nemko E07379.00
Not applicable
TECHNICAL CONSTRUCTION FILE NO
2008
YEAR WHICH THE CE-MARK WAS AFFIXED
TEST AUTHORIZED SIGNATORY
MANUFACTURER AUTHORISED REPRESENTATIVE
(Established within EEA) Date of Issue
2008-07-24
Place of Issue
Not applicable Sandefjord, Norway
Thomas Øhrbom
Name
Quality Manager
(authorised signature)
Position
