Olevia 565H User manual

565H
The Perfect Balance of Quality and Value
Olevia 5SerieS
565H
Exceptional Quality Video Performance
Comprehensive Features
> 6-Megapixel 1080p Brillian
LCoS™ Light Engine
> 65" Diagonal with 170° Viewing
Angle
> High-Definition TV & PC Inputs -
ATSC/QAM Clear Digital,
Component, HDMI, DVI with
HDCP
> Standard Definition TV Inputs -
Dual NTSC Tuner, Component,
VGA, S-Video and Composite
> PIP/Split Screen/POP Modes
> DNX Video Processing by
Pixelworks™
> User-Friendly Menu System
> 90% Fill Factor to Eliminate
Pixelation
> Variety of Aspect Ratio Modes
> 4ms Response Time
> Universal Remote Control
> D2 Audio Processing
Olevia 565H LCoS™ HDTV
If you’re ready to move up to the highest quality, large screen high-definition TV, the 65-inch
LCoS™ Olevia 565H HDTV is the ideal choice for home or business — packed with the industry’s
top technology and innovative Olevia-first features. Delivering best-in-class video and audio, its
heart is the 6-megapixel Brillian™ UltraContrast™ LCoS light engine. Three 1920x1080 pixel LCoS
microdisplays, each with 90% fill factor (or use of the active pixel area), 4ms response time and up
to 4000:1 Sequential Contrast Ratio [(300:1 (typ.) ANSI Contrast)], ensure that rainbow effects and
screen-door appearance of alternative technologies are eliminated. Video processing is powered
by state-of-the-art PixelWorks®DNX™ (Digital Natural Expression) technology. Additionally, the
565H features both DVI & HDMI inputs enabling support from 480i to 1080p content, three digital/
analog tuners (1-ATSC/2-NTSC) for over-the-air broadcast TV signals, support for QAM Clear Digital
Cable input, plus a super-wide 170-degree viewing angle. Its rich set of video and audio connectors
enable the Olevia 565H to display everything — high-definition digital broadcast and digital cable
TV and widescreen movies (up to 1080p resolution), standard analog TV, action sports, video games,
and home videos — with stunningly crisp and vibrant imagery, and realistic and immersive sound.
This 65-inch HDTV can even double as a computer display with 1920x1080 resolution utilizing the
VGA, DVI, or HDMI inputs. The 565H horizontal (or bottom) mounted speakers complement its
D2 Audio surround sound audio processor, which makes theater-quality digital audio part of this
outstanding new entertainment experience — all thanks to Olevia.
Olevia 5 Series — Quality-Rich HDTV For Today and Tomorrow
The 565H is one of the Olevia 5 Series HDTVs designed expressly to deliver outstanding quality and
comprehensive features. Vibrant image quality, powerful digital tuner technology and built-in RS-232
control, for connection with a home automation system, make the Olevia 5 Series ideal for virtually
any content and any environment — now and in the future. And, as with all Olevia 5 and 7 Series
TVs, the 565H features:
Color Calibrated Light Engine — Calibrated color quality and a full range of brightness, contrast, color,
tint, sharpness and mode controls available to tune image quality.
User-Friendly On-Screen Display — Text-based menus simplify use and preset video and lighting
modes are available for different environments.
Universal Remote Control — Control up to seven (7) devices with a simple and ergonomically
designed backlit remote control.
OleviaCare™ — Live, in-house technical and customer support personnel assure a total quality
experience — every time.

Copyright 2006 Syntax-Brillian Corporation. All Rights Reserved. M0906-04
Olevia 65" LCoS HDTV Specifications
To learn more, visit us at www.olevia.com
Olevia 5SerieS
Front
Back
Side-Left
Inputs / Outputs
565H
Product designs and specifications are subject to change without notice.
OUTPUT
Composite
Video
S-Video S-Video
Sub-
Woofer
VIDEO 2
VIDEO 3
Component
VIDEO 4
Component
VIDEO 5
Tuner 1
Analog
Tuner 2
Digital
Digital
Audio
Out
Service
Access
VIDEO 8
Audio In VIDEO 7 VIDEO 6
HDMI
DVI VGA
Optical
Panel
Video Input
Audio Output
Video Output
Audio
Compatibility
Power
Other Features
Additional Features
Dimensions (WxHxD)
Net Weight
Regulatory Approval
Lamp Type
Warranty
Size
Display Area
Aspect Ratio
Brightness
Contrast Ratio
Viewing Angle
Response Time
HDMI
DVI
Component Input
VGA Input
S-Video Input
AV Input
Analog Tuner
Digital Tuner
Headphone
Audio Output
Digital Output
Sub Woofer
AV
Speakers
Video
PC
Voltage
Consumption
Front Panel
Remote
Firmware Port
65”
1920x1080p Resolution
16:9
375 cd/m²
Up to 4000:1 (sequential), 300:1 ANSI (typ)
170° horizontal, 50° vertical
4ms
1 HDMI w/ HDCP
1 DVI w/ HDCP + 1 R/L RCA Audio
2 Component + 2 R/L RCA Audio
RGB 15 D-sub with + R/L RCA Audio
3 S-Video with R/L RCA Audio
3 Composite Video with R/L RCA Audio
1 RF (2 Tuners)
1 RF
1 Stereo Mini Jack
2 R/L RCA Audio
1 SPDIF
1 Subwoofer RCA out
1 Composite Video
15 W per Channel, 4 Stereo Speakers
480i, 480p, 720p, 1080i, 1080p @ 60Hz
Optimized for 1920x1080 @ 60Hz Operation ; other PC resolutions supported
110Vac 60Hz, 240Vac, 50 Hz
330 Watts
Power, Menu, Source, Channel up/down, Volume up/down
Multifunction Universal Remote Control
RS-232
Parental Control, Closed Captioning, 3:2 Pull Down, 2:2 Pull Down,
3D Comb Filter, Sleep Timer, Separate IR Remote Button Command input
selection, Discreet IR, Aspect Ratio Selection, Linear and Panoramic Scaling,
Calibrated Color and Gamma, Brightness, Contrast, Color, Tint, and Sharpness
Controls, Picture-in-Picture and Split-Screen Modes.
60” W x 45” H x 21” D
122 lbs
CSA C22.2 No. 950-95, FCC Class B (EMI)
150 W, UHP Type, 4,000 hours lifetime
One year parts and labor with one year free on-site
