Vizio D32h-C0 User manual

VIZIO
USER MANUAL
Models D32h-C0

7hLs SUodXFW TXDlLȴes IoU(1(5*< 67$5 LQ Whe ȊIDFWoU\ deIDXlWȋ
seWWLQJ DQd WhLs Ls Whe seWWLQJ LQ ZhLFh SoZeUsDYLQJs ZLll Ee
DFhLeYedChDQJLQJ Whe IDFWoU\ deIDXlWSLFWXUe seWWLQJs oU
eQDElLQJ oWheUIeDWXUes ZLll LQFUeDse SoZeUFoQsXPSWLoQWhDW
FoXld e[Feed Whe lLPLWs QeFessDU\ Wo TXDlLI\ IoU(1(5*< 67$5
UDWLQJ )oUPoUe LQIoUPDWLoQoQWhe (1(5*< 67$5 SUoJUDP Jo
Wo eQeUJ\sWDUJoY
+DMΖ Whe +DMΖloJo DQd +LJh-DeȴQLWLoQMXlWLPedLD ΖQWeUIDFe
DUe WUDdePDUNs oUUeJLsWeUed WUDdePDUNs oI+DMΖ/LFeQsLQJ //C
MDQXIDFWXUed XQdeUlLFeQse IUoPDolE\ /DEoUDWoULesDolE\
DQd Whe doXEle-D s\PEol DUe WUDdePDUNs oIDolE\ /DEoUDWoULes
)oUD76 SDWeQWssee
hWWSSDWeQWsdWsFoP
MDQXIDFWXUed XQdeUlLFeQse IUoPD76 /LFeQsLQJ /LPLWed
D76 Whe 6\PEolD76 DQd Whe 6\PEol WoJeWheUDUe
UeJLsWeUed WUDdePDUNsDQd 7UX6XUUoXQd Ls DWUDdePDUN oI
D76 ΖQF kD76 ΖQF $ll 5LJhWs 5eseUYed

Welcome
THANK YOU FOR CHOOSING VIZIO
And congratulations on your new VIZIO HDTV.
To get the most out of your new VIZIO product, read these
instructions before using your product and retain them for future
reference. Be sure to inspect the package contents to ensure there
are no missing or damaged parts.
WHEN READING THIS MANUAL
This symbol identiȴes helpful tips.
This symbol alerts you to important warnings or notices
as part of the operating instructions.
IMPORTANT SAFETY INSTRUCTIONS
<our TV is designed and manufactured to operate within deȴned
design limits. Misuse may result in electric shock or ȴre. To
prevent your TV from being damaged, the following instructions
should be observed for the installation, use, and maintenance of
your TV. Read the following safety instructions before operating
your TV. Keep these instructions in a safe place for future
reference.
• To reduce the risk of electric shock or component damage,
switch o΍the power before connecting other components
to your TV.
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with dry cloth.
• Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus including ampliȴers
that produce heat.
• Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided
plug does not ȴt into your outlet, consult an electrician for
replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they e[it from the apparatus.
• Only use attachmentsaccessories speciȴed by the
manufacturer.

• Do not apply pressure or throw objects at your TV. This may
compromise the integrity of the display. The manufacturer’s
warranty does not cover user abuse or improper
installations.
• The power cord must be replaced when using di΍erent
voltage than the voltage speciȴed. For more information,
contact your dealer.
• :hen connected to a power outlet, power is always ȵowing
into your TV. To totally disconnect power, unplug the power
cord.
• The lightning ȵash with arrowhead symbol within an
equilateral triangle is intended to alert the user to the
presence of un-isolated, dangerous voltage within the
inside of your TV that may be of suɝcient magnitude to
constitute a risk of electric shock to persons.
• Do not overload power strips and e[tension cords.
Overloading can result in ȴre or electric shock.
• The wall socket should be installed near your TV and easily
accessible.
• Only power of the marked voltage can be used for your TV.
Any other voltage than the speciȴed voltage may cause ȴre
or electric shock.
• Do not touch the power cord during lightning. To avoid
electric shock, avoid handling the power cord during
electrical storms.
• Unplug your TV during a lightning storm or when it will not
be used for long period of time. This will protect your TV
from damage due to power surges.
• Do not attempt to repair or service your TV yourself.
Opening or removing the back cover may e[pose you to
high voltages, electric shock, and other hazards. If repair
is required, contact your dealer and refer all servicing to
qualiȴed service personnel.
• WARNING: Keep your TV away from moisture. Do not
e[pose your TV to rain or moisture. If water penetrates into
your TV, unplug the power cord and contact your dealer.
• Use only with the cart, stand, tripod, bracket,
or table speciȴed by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
• Unplug this apparatus during lightning storms or when
unused for long periods of time.
• Refer all servicing to qualiȴed service personnel. 6ervicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been e[posed to rain or moisture, does
not operate normally, or has been dropped.
• Unplug the power cord before cleaning your TV.
• When moving your TV from an area of low temperature to
an area of high temperature, condensation may form in the
housing. Wait before turning on your TV to avoid causing
ȴre, electric shock, or component damage.
• A distance of at least three feet should be maintained
between your TV and any heat source, such as a radiator,
heater, oven, ampliȴer etc. Do not install your TV close to
smoke. Operating your TV close to smoke or moisture may
cause ȴre or electric shock.
• 6lots and openings in the back and bottom of the cabinet
are provided for ventilation. To ensure reliable operation of
your TV and to protect it from overheating, be sure these
openings are not blocked or covered. Do not place your
TV in a bookcase or cabinet unless proper ventilation is
provided.
• Never push any object into the slots and openings on your
TV cabinet. Do not place any objects on the top of your TV.
Doing so could short circuit parts causing a ȴre or electric
shock. Never spill liquids on your TV.
• Your TV should be operated only from the type of power
source indicated on the label. If you are not sure of the type
of power supplied to your home, consult your dealer or
local power company.

Continuous use in this case may result in ȴre or electric
shock.
• Do not use your TV if any abnormality occurs. If any smoke
or odor becomes apparent, unplug the power cord and
contact your dealer immediately. Do not try to repair your
TV yourself.
• Avoid using dropped or damaged appliances. If your TV
is dropped and the housing is damaged, the internal
components may function abnormally. Unplug the power
cord immediately and contact your dealer for repair.
Continued use of your TV may cause ȴre or electric shock.
• Do not install your TV in an area with heavy dust or high
humidity. Operating your TV in environments with heavy
dust or high humidity may cause ȴre or electric shock.
• Follow instructions for moving your TV. Ensure that the
power cord and any other cables are unplugged before
moving your TV.
• When unplugging your TV, hold the AC/DC power adapter,
not the cord. Pulling on the power cord may damage the
wires inside the cord and cause ȴre or electric shock. When
your TV will not be used for an e[tended period of time,
unplug the power cord.
• To reduce risk of electric shock, do not touch the connector
with wet hands.
• Insert batteries in accordance with instructions. Incorrect
polarities may cause the batteries to leak which can
damage the remote control or injure the operator. Do not
e[pose batteries to e[cessive heat such as sunshine, ȴre or
the like.
• If any of the following occurs, contact the dealer:
- The power cord fails or frays.
- Liquid sprays or any object drops into your TV.
- Your TV is e[posed to rain or other moisture.
- Your TV is dropped or damaged in any way.
- The performance of your TV changes substantially.
• This apparatus shall not be e[posed to dripping or
splashing and no objects ȴlled with liquids, such as vases,
shall be placed on the apparatus.
• The mains plug or appliance coupler is used as the
disconnect device, the disconnect device shall remain
readily operable.
• CAUTION - These servicing instructions are for use by
qualiȴed service personnel only. To reduce the risk of
electric shock, do not perform any servicing other than
that contained in the operating instructions unless you are
qualiȴed to do so.
The lightning ȵash with arrowhead symbol within an
equilateral triangle is intended to alert the user to the
presence of uninsulated DANGEROU6VOLTAGE within the
product’s enclosure that may be of suɝcient magnitude to
constitute a risk of electrical shock to persons.
h

TELEVISION ANTENNA CONNECTION
PROTECTION
If an outside antenna/satellite dish or cable system is to be
connected to the TV, make sure that the antenna or cable system
is electrically grounded to provide some protection against voltage
surges and static charges.
Article 0 of the National Electrical Code, AN6I/NFP6A 0, provides
information with regard to proper grounding of the mast and
supporting structure, grounding of the lead-in wire to an antenna
discharge unit, size of the grounding conductors, location of
antenna discharge unit, connection to grounding electrodes, and
requirements of the grounding electrode.
Lightning Protection
For added protection of the TV during a lightning storm or when it
is left unattended or unused for long periods of time, unplug the TV
from the wall outlet and disconnect the antenna or cable system.
Power Lines
Do not locate the antenna near overhead light or power circuits, or
where it could fall into such power lines or circuits. Remember, the
screen of the coa[ial cable is intended to be connected to earth in
the building installation.
Ground Clamp
Antenna Lead In Wire
Antenna Discharge Unit
NEC 6ection 0-20
Grounding Conductors
NEC 6ection 0-2
Ground Clamps
Power 6ervice Grounding Electrode 6ystem
NEC ART 20, part H
Electric 6ervice Equipment

Table of Contents
1
Installing the TV .....................................................3
InspectingthePackageContents ...................... 3
InstallingtheTV .................................... 4
Installing the TV on the Stands ............................................. 4
Installing the TV on a Wall ..................................................... 6
Controls and Connections.....................................7
RearPanel......................................... 7
SidePanel......................................... 8
FrontPanel ........................................ 9
Remote Control.................................... 10
Replacing the Batteries........................................................ 11
Connecting Your Devices.....................................12
Connecting a Device ................................ 12
Connecting an Audio Device ......................... 15
Connecting an Audio Device - ARC .................... 17
Completing the First-Time Setup ........................18
Using the On-Screen Menu .................................19
Navigating the On-Screen Menu ...................... 19
Changing the Input Source .......................... 19
ChangingtheScreenAspectRatio .................... 20
Adjusting the Picture Settings ........................ 21
Adjusting the More Picture Settings ................................... 22
Adjusting the Color Temperature ....................................... 23
Adjusting the Picture Mode Edit Settings........................... 23
Saving a Custom Picture Mode ........................................... 24
Locking and Unlocking Custom Picture Modes.................. 24
Deleting a Custom Picture Mode ........................................ 25
Resetting a Preset Picture Mode......................................... 25
Adjusting the Color Calibration Settings ............................ 26
Adjusting the Color Tuner Settings..................................... 27
Adjusting the Audio Settings ......................... 30
Changing the Equalizer Settings ......................................... 31
Deleting the Custom Audio Mode....................................... 31
Setting Timers ..................................... 32
Setting the Sleep Timer........................................................ 32
Setting the Auto Power O΍Feature.................................... 32
Setting Up Channels ................................ 33
Selecting a Channel Source ................................................. 33
Finding Channels.................................................................. 33
Adding New Channels.......................................................... 34
Skipping Channels................................................................ 35
Changing the Audio Language ............................................ 36
Setting Up Closed Captioning ........................ 37
Changing the Appearance of Digital Closed Captions....... 37
Renaming Inputs (Using the Devices Menu) ............ 39
Changing the TV Settings ............................ 40
Viewing System Information ............................................... 40
Changing the On-Screen Menu Language.......................... 41
Setting the Time and Local Settings.................................... 41
Using the Parental Controls ................................................ 42
Accessing the Parental Controls Menu .......................... 42
Enabling or Disabling Program Ratings.......................... 42
Locking and Unlocking Channels.................................... 42
Blocking and Unblocking Content by Rating.................. 43
Changing the Parental Control Passcode....................... 43
Resetting the Content Locks ........................................... 43

2
Adjusting the Wide Mode (Aspect Ratio) ............................ 44
Controlling Other Devices with CEC.................................... 45
Turning the Power Indicator On or O΍............................... 46
Restoring the TV to Factory Default Settings ..................... 46
UsingtheGuidedSetupMenu ....................... 47
UsingtheInfoWindow.............................. 48
Using the USB Media Player................................49
Preparing Your USB Drive to Display USB Media .............. 49
Displaying USB Media .......................................................... 49
Removing the USB Drive from the TV................................. 49
Troubleshooting ................51
Speciȴcations .......................................................54
Legal & Compliance .............................................57

3
1
3
Installing the TV
INSPECTING THE PACKAGE CONTENTS
Before installing your new TV, take a moment to inspect the
package contents. Use the images below to ensure nothing is
missing or damaged.
VIZIO LED HDTV
Power Cord
Quick Start Guide
Remote Control
INPUT
EXIT
GUIDE
BACK
1
4
7
WIDE
MENU
OK
VOL
VOL
CH
CH
3
6
9
—
2
5
8
0
PACKAGE CONTENTS
TV Stands
(two identical stands)
4 [T3 30ɋmm
Phillips Screws

1
4
4
To install the stands:
Place the TV screen-down on a clean, ȵat surface. To prevent
scratches or damage to the screen, place the TV on a soft
surface such as a blanket and avoid any sharp edges.
INSTALLING THE TV
After removing the TV from the bo[and inspecting the package
contents, you can begin installing the TV. Your TV can be installed
in two ways:
• On a ȵat surface, using the included stand
• On a wall, using a VESA-standard wall mount (not included)
Installing the TV on the Stands
Your TV includes stands designed to support the weight of the TV
and keep it from falling over. However, the TV can still fall over if:
• It is placed on an uneven, unstable, or non-level surface
• It is pushed, pulled, or otherwise improperly moved
• If an earthquake occurs and the TV is not properly secured.
TV ON STAND

1
5
5
Insert the left and right stands into the base of the TV (the stands are identical).
Secure each stand to the TV with two (2) T3 30ɋmm Phillips screws (included). Insert the screws into the back of the TV and tighten them
using a Phillips screwdriver.
When you are ȴnished, place the TV on a stable, level surface.

1
6
6
Installing the TV on a Wall
To mount your TV on a wall, you will need a wall mount. Consult
the information below to ȴnd the appropriate mount for your TV
model:
Installing a TV on a wall requires lifting. To prevent
injury or damage to the TV, ask someone to help you.
D32h-C0
Screw Size: M4
Hole Pattern: 100ɋmm (V) [100ɋmm (H)
Weight w/o Stand: 11.02 lbs
Be sure the mount you choose is capable of supporting the weight
of the TV. After you have determined that you have the correct
mount for your TV, you can begin the installation.
To install your TV on a wall:
1. Disconnect any cables connected to your TV.
2. Place the TV face-down on a clean, ȵat, stable surface. Be sure
the surface is clear of debris that can scratch or damage the
TV.
3. Remove the base by loosening and removing the screws.
4. Attach your TV and wall mount to the wall, carefully following
the instructions that came with your mount.
Use only with a UL-listed wall mount bracket rated for the
weight/load of this TV.
WALL MOUNT SCREW LOCATIONS

2
7
REAR PANEL
Controls and Connections
Stereo Audio Out - Connect an RCA audio device, such as sound bar.
Optical Audio Out - Connect an optical/SPDIF audio device, such as
home audio receiver.
REAR PANEL
USB - Connect a USB thumb drive to play photos.
HDMI - Connect an HDMI device.
Component/Composite - Connect a component or composite device.
DTV/TV (Coaxial) - Connect a coaxial cable from a cable or satellite box,
or from an antenna.
HDMI - Connect an HDMI device.

2
8
SIDE PANEL
SIDE PANEL
POWER Press to turn the TV on.
Press and hold to turn the TV o΍.
INPUT Press to change the input source.

2
9
FRONT PANEL
REMOTE SENSOR & POWER INDICATOR
When using the remote, point it directly at this sensor.
The power indicator ȵashes on when the TV turns on, then goes out after
several seconds. To keep the power indicator on as long as the TV is on,
see
Turning the Power Indicator On or O΍ on page 46.
FRONT PANEL

2
10
REMOTE CONTROL
INPUT
EXIT
GUIDE
BACK
1
4
7
WIDE
MENU
OK
VOL
VOL
CH
CH
3
6
9
—
2
5
8
0
INPUT
Change the currently-displayed input.
ARROW
Navigate the on-screen menu.
EXIT
Close the on-screen menu.
WIDE
Switch the display mode.
MUTE
Turn the audio o΍or on.
BACK
Go to the previous on-screen menu.
MENU
Display the on-screen menu.
DASH
Use with number pad to manually enter a
digital sub-channel.
(For example, 18-4 or 18-5.)
CHANNEL UP/DOWN
Change the channel.
GUIDE
Display the info window.
LAST
Return to the channel last viewed.
NUMBER PAD
Manually enter a channel.
VOLUME UP/DOWN
Increase or decrease loudness of
the audio.
OK
Select the highlighted menu option.
V BUTTON
Open the USB photo viewer.
POWER
Turn TV on or o΍.

2
11
Replacing the Batteries;EŽƚƐƵƉƉůŝĞĚͿ
1. To remove the battery cover, press on the logo and slide the
cover out.
2. Insert two batteries into the remote control. Make sure that
the (+) and (-) symbols on the batteries match the (+) and (-)
symbols inside the battery compartment.
3. Replace the battery cover.

3
12
Connecting Your Devices
CONNECTING A DEVICE
Game Console
DVD/Blu-ray Player
Your TV can be used to display output from most devices.
1. Verify that your device has a video port that matches an
available port on the TV (HDMI-1, HDMI-2, Comp, etc.).
2. Turn the TV and your device o΍.
3. Connect the appropriate cable (not included) to the TV and the
device.
4. Turn the TV and your device on. Set the TV’s input to match the
connection you used (HDMI-1, HDMI-2, Comp, etc.).
BETTER
COMPONENT CABLE*• ANALOG
• HD VIDEO (1080p)**
• STEREO AUDIO
BEST
HDMI CABLE*• DIGITAL
• HD VIDEO (1080p)**
• HD AUDIO
GOOD
AV CABLE*• ANALOG
• VIDEO (480i)**
• STEREO AUDIO
** Maximum resolution.
BACK OF TV
BETTER
COAXIAL CABLE*• ANALOG
• HD VIDEO (1080i)**
• STEREO AUDIO
Cable/Satellite Box
* Cables not included.

3
13
COAXIAL CABLE
Coaxial cables are the traditional way of connecting
antennas and cable television signals to your TV. Coaxial
cables carry both audio and video signals through a
single connector.
AV CABLE
AV cables (or Composite cables) are the traditional way
of connecting your devices to your TV. Video signals are
sent over the yellow connector while audio is sent over
the red and white connectors.
GOOD BETTER
Y/V L R
• HD video resolutions up to 1080i
• Analog connection
• Audio and video signals
• Video resolutions up to 480i
• Analog connection
• Audio and video signals
CONNECTING A DEVICE - AUDIO AND VIDEO CABLE TYPES
Cable/Antenna

3
14
HDMI CABLE
HDMI is the intelligent, all-digital interface that delivers
both dazzling quality and unmatched ease of use. HDMI
technology transmits crystal-clear digital video along with
multi-channel surround audio. HDMI-connected devices
have the ability to automatically adjust themselves for
optimal viewing.
COMPONENT CABLE
Component cables are designed to carry HD (high
deȴnition) video signals along with additional audio
connections. Colors are delivered with color information
over three connectors for video (separated into red,
blue and green signals) and the left and right audio
connectors (red and white).
BETTER
Y/V Pb/Cb Pr/Cr LR
• HD video resolutions up to 1080p
• HD audio
• Digital connection
• Audio and video signals
• HD video resolutions up to 1080p
• Analog connection
• Audio and video signals
BEST
