Onix 1832 User manual

Page 1
INTENDED USE OF THE TOOL
MADE IN TAIWAN
• Shorter than a credit card at 3.46" long
• Industry leading 415 ft/lbs. of MAX torque
The 1832 is intended to be used for removing and
fastening bolts and nuts with 1/2" drive impact
sockets only. Do not use this tool outside
of the designed intent. Never modify this tool for
any other purpose or use.
Model: Product Type:
ONYX 1/2" NANO ANGLE IMPACT
WRENCH - 415FT/LB
ONYX 1/2" NANO
ANGLE IMPACT WRENCH
- 415FT/LB
1832
DO NOT DISCARD – GIVE TO USER
WARNING
www.astrotools.com
PLEASE DO NOT RETURN ANY PRODUCT WITHOUT CALLING
1-800-221-9705 FOR INSTRUCTIONS
BEFORE USE
Study, understand and follow all instructions
provided with this product. Read these instructions
carefully before installing, operating, servicing or
repairing this tool. Keep these instructions in a safe
accessible place.
PRODUCT INFORMATION:
WARNING
Caution: To help prevent personal injury.
• Use of this product can expose you to chemicals
including ethylene glycol, gasoline vapors and engine
exhaust, which are known to the State of California to
cause cancer, birth defects, or reproductive harm.
For more information, visit www.P65Warnings.ca.gov.
Always wear ANSI approved safety equipment, safety
glasses and clothing when using this product. Study,
understand, and follow all instructions provided with
this product. Failure to read and follow all warnings and
operating instructions may result in damages and
serious injury or death.
• Always wear ANSI approved goggles when using this
product. (Users and Bystanders).
• Never use this tool for any application other than for
which it was designed.
• Only use accessories designed for this tool.
• Never alter or modify this tool in any way.
• Improper operation and/or maintenance of the tool,
modification of the tool, or use of the tool with
accessories not designed for it could result in serious
injury or death.
• Always select the correct accessories of the correct
size and design for the job that you are attempting to
perform.
• Always work in a clean, safe, well-lit, organized and
adequately equipped area.
• Do not begin repairs without assurance that vehicle is
in secure position, and will not move during repair.
1 YEAR LIMITED WARRANTY
• Astro Pneumatic Tool Co. warrants our products to the original
user against defective material or workmanship for a period of
1 year (except where noted on our price schedule) from the
date of 1st use. Astro reserves the right to determine whether
the product failed because of defective material, workmanship
or other causes and to charge back for missing parts.
Astro Pneumatic Tool Co., at its discretion, will repair products
covered under this warranty free of charge. The distributor
should direct the original user to return the product (with the
exceptions listed below) with the distributor’s name, address,
adequate proof of date of purchase or a copy of warranty card,
and a short note explaining the problem.
Failures caused by accident, alteration, or misuse are not
covered by this warranty.
• Astro Pneumatic Tool Co. or its authorized service
representatives must perform all warranty repairs. Any repair
to the product by unauthorized service representatives voids
this warranty. The rights under this warranty are limited to the
original user and may not be transferred to subsequent owners.
• This warranty is in lieu of all other warranties, expressed or
implied, including warranties of merchantability and fitness for
a particular purpose. Some states do not allow the exclusion
of limitations of incidental or consequential damages so the
above limitations may not apply to you.
Before use, check the parts diagram and part
number listing on page 4 to make sure all parts
are included. If any parts are missing or damaged,
please call your distributor.
SPECIFICATIONS:
Square Drive: 1/2"
Handle Type: Straight right angle
Clutch type: Oversized Hammer
Motor Housing: Aluminum w/ bed
liner finish
Air Exhaust: 360° Swivel Air Muffler
Air Inlet Thread: 1/4" NPT
Switch: 3-speeds in both F and R
Max Torque: 415 ft/lbs
Working Torque: 300 ft/lbs
Weight: 2.78 lbs
Length(from end to end): 3.46"
Height(from end to end): 10.4"
Free Speed: 9000 r.p.m.
Noise Level(sound pressure): 85 dB
Average Air Consumption: 4.2 CFM
Min. Hose Size: 3/8"

WARNING
Page 2
Model: Product Type:
ONYX 1/2" NANO ANGLE IMPACT
WRENCH - 415FT/LB
1832
MAINTENANCE INSTRUCTION:
1.) LUBRICATION:
Before connection of the hose, apply 4 to 5
drops of a good quality air tool oil at the air
inlet. After 3 to 4 hours of operation, oiling may
be necessary again.
2.) TIGHTNESS OF PARTS:
Regularly check whether all connection parts
are fastened securely. Follow this procedure
daily before beginning work.
3.) STORAGE:
Avoid storing the tool in a location subject to
high humidity. If the tool is left unused, the
residual moisture inside the tool can cause rust.
Before storing and after operation, oil the tool at
the air inlet with a good quality air tool oil and
run it for a short period.
4.) DISPOSAL:
Follow national legislation of waste disposal.
5.) ORDERING SERVICE PART:
For further operational and handling information
or for replacement of parts and components,
contact the sales agent from where you
purchased the tool, or the service division of our
company, phone number 800-221-9705.
* When ordering parts and components, give
each part number, name, and quantities.
Users of this tool should review the chemical
composition of the work surface and any products
used in conjunction with this tool for any such
chemicals prior to engaging in any activity that
creates dust and/or microscopic particles.
Users should obtain the Material Safety Data Sheets
for all identified chemicals, either from the
manufacturer or their employer, and proceed to study,
understand, and follow all instructions and warnings
for exposure to such chemicals.
Some examples of these chemicals are: lead from
lead based paints; crystalline silica from bricks,
cement and other masonry products; and arsenic
and chromium from chemically treated lumber. A
listing of the chemicals can be obtained at
www.oehha.ca.gov under Propoisition 65.
In order to reduce their exposure to such chemicals,
users should always:
- work in well-ventilated areas.
- wear appropriate safety equipment and clothes that
are specifically designed to filter out microscopic
particles.
1. The tool shall not be used in potentially explosive
atmospheres.
2. Disconnect the air hose before changing or
adjusting any inserted tools.
3. Before using tool, please confirm all couplings
and plugs are fixed securely. An air hose that is
under pressure may lash out when disconnected
and could lead to serious injuries.
4. Prevent loose clothes, long hair or any other
personal accessories from coming close to
moving parts to reduce the risk of being caught,
trapped or drawn into the operation.
5. Excessive high air pressure that exceeds the
maximum pressure may cause injuries to user.
6. Exposure to strong vibration for extended time
may cause harm to operator.
7. WATCH YOUR STEP! Leaving excess hose
unattended near working area or walk path could
result in injury or death.
8. Wearing eye/face protection could reduce the
danger to person from high speed splinters
being emitted from the tool or work surface.
9. Wearing correct breathing protection will help
avoid inhaling dust or debris from work process
that can be harmful to your health.
10. High sound levels can cause permanent hearing
loss. Use hearing protection while operating tool.

Page 3
Model: Product Type:
ONYX 1/2" NANO ANGLE IMPACT
WRENCH - 415FT/LB
1832
SUGGESTED AIR LINE CONNECTION
Pitch pipe back toward air receiver
Compressor unit
Drain
Daily
Oil and Water Extractor should be at least 25 ft. from the compressor. Further if possible.
Drain Daily
Drain
Daily
Oil and Water
Extractor
Install drain at
each low point
PIPE SIZE, I.D. (Inches)
Air Flow
CFM
Length of Pipe (feet)
10
20
30
40
50
70
50
1/2"
3/4"
3/4"
1"
1"
1"
100
3/4"
3/4"
3/4"
1"
1"
1"
150
3/4"
3/4"
1"
1"
1"
1-1/4"
200
3/4"
1"
1"
1"
1-1/4"
The oil and water extractor should not be mounted on or near the air compressor.
The temperature of air is greatly increased during compression. As the air cools down to room
temperature, in the air line, on its way to the Air Power Tool, the moisture contained in it
condenses. Thus, for maximum effectiveness, the oil and water extractor should be mounted at
some point in the air supply system where the temperature of the compressed air in the line is
likely to be lowest. Air lines must be properly drained daily. Each low point in an air line acts as
a water trap. Such points should be fitted with an easily accessible drain. See diagram below.
Pitch all air lines back towards the compressor so that condensed moisture will flow back into
the air receiver where it can be drained off. Drain daily.
25 FEET OR MORE

372 Old US Highway 52 South
Mount Airy, NC 27030
811
Page 4
Model: Product Type:
ONYX 1/2" NANO ANGLE
IMPACT WRENCH - 415FT/LB
1832
Call 1.800.221.9705 for questions concerning performance of
the product or other inquiries.
PARTS BREAKDOWN
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
1832-01
1832-02
1822-03
1822-05
1822-04
1832-06
1832-07
1832-08
1832-09
1822-10
1832-11
1822-18
1822-19
1822-20
1822-21
1822-22
1822-23
1822-24
1822-25
1822-26
1822-27
1822-28
1822-29
1822-30
1822-31
1822-32
1832-27
1832-28
Socket Cap Screw W/Washer
Hammer Housing
Hammer Case Bushing
O-Ring
Retainer Ring
Drive Anvil
Hammer Pin
Hammer Cage
Hammer Cam
Hammer Housing Gasket
Housing
Ball Bearing R8
Front End Plate
Cylinder
Dowel Iiner
Rotor
Rotor Blade
Rear End Plate
Ball Bearing R8
Motor Housing Gasket
Housing Cap
O-Ring
E-Ring
Regulator Knob
Regulator Valve Detent Spring
Regulator Valve Detent Ball
O-Ring
Air Exhaust Deflector
Index Part No. QtyDescription
8
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
6
1
1
1
1
1
1
1
1
1
2
1
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
1832-29
1832-30
1832-31
1832-32
1832-33
1832-34
1832-35
1832-36
1832-37
1832-38
1832-39
1832-40
1832-41
1832-42
1832-43
Handle
Spring Pin
Conjunction Screw
O-Ring
Retainer Ring
Throttle Bushing
Throttle Valve
Throttle Spring
O-Ring
Air Inlet Bushing
Handle Grip
Spring Pin
O-Ring
Trigger Valve
Trigger
Index Part No. QtyDescription
1
2
1
1
1
1
1
1
2
1
1
1
1
1
1
Parts List
