OPEL Combo
Owner’s Manual

OPEL Combo
Operation, Safety, Maintenance

Data specific to your vehicle
Please enter your vehicle’s data here to keep it easily accessible. This information is available in the sections "Service and maintenance"
and "Technical data" as well as on the identification plate.
Fuel
Designation
Engine oil
Grade
Viscosity
Tyre pressure
Tyre size Front Rear
Summer tyres
Winter tyres
Weights
Gross vehicle weight rating
– ECkerbweight
=Payload

Introduction
Your vehicle is an intelligent combination
of forward-looking technology, impressive
safety, environmental friendliness and
economy.
It now lies with you to drive your vehicle
safely and to see it performs perfectly. This
Owner’s Manual provides you with all the
necessary information to that end.
Make sure your passengers are aware of
the possible risk of accident and injury
which may result from improper use of the
vehicle.
You must always follow the specific laws of
the country in which you are located. These
could differ from the information in this
Owner’s Manual.
When this Manual refers to a workshop
visit, we recommend your Opel Service
Partner.
All Opel Service Partners provide first-class
service at reasonable prices. Experienced
mechanics trained by Opel work according
to specific Opel instructions.
The Owner’s Manual, infotainment system
instructions and vehicle service and
warranty booklet should always be kept
ready to hand in the vehicle glove
compartment.
Make use of the Owner’s Manual
zThe "In Brief" section will give you an
initial overview.
zThe table of contents at the beginning of
the owner’s manual and within the
individual chapters will show you where
everything is.
zIts index will help you find what you
want.
zYellow arrows in the illustrations serve as
points of reference or indicate some
action to be performed.
zBlack arrows in the illustrations indicate
a reaction or a second action to be
performed.
zThis Owner’s Manual depicts left-hand
drive vehicles. Operation is similar for
right-hand drive vehicles.
zThe Owner’s Manual uses the internal
engine codes. The corresponding sales
designations are found in the chapter
"Technical data".
zDirection references such as left or right,
forwards or backwards in the
descriptions always indicate the
direction of travel.
Symbols
6Continue reading on next page.
3signifies equipment not fitted to all
vehicles (model variants, engine options,
models specific to one country, optional
equipment, Genuine Opel Parts and
Accessories).
Page references are indicated with 3 . 3
means "see page".
9 Danger, 9Warning, Caution
We wish you many hours of pleasurable
driving
Adam Opel GmbH
9 Danger
Text marked 9 Danger provides
information on risk of endangering life.
Failure to comply with the instructions
could endanger life.
9 Warning
Text marked 9Warning provides
information on risk of accident or injury.
Failure to comply with the instructions
could lead to injury.
Caution
Text marked Caution provides
information on possible damage to the
vehicle Failure to comply with the
instructions could lead to vehicle
damage.

Contents In Brief ........................................................ 2
Keys, doors, windows ............................. 20
Seats, Interior .......................................... 38
Instruments ............................................. 66
Lighting ................................................... 84
Infotainment system .............................. 90
Climate control ....................................... 92
Driving and operation ......................... 100
Self-help, vehicle care .......................... 128
Opel Service, maintenance .................. 164
Technical data ..................................... 182
Index ...................................................... 198

2InBrief
In Brief
Picture no: 18079s.tif
Unlocking the vehicle: Turn the
key in the lock forwards or press
the qbutton on the radio remote
control 3
Pull on the door handle and open the door
or slide open the sliding door 3.
Sliding door 3 327. Key 320,
Electronic immobiliser 321,
Remote control 3 323,
Central locking system 3 324,
Anti-theft alarm system 3331,
Child locks 3327.
Picture no: 18080s.tif
Unlocking the tailgate 3: Turn the
key to the horizontal position or
press the qbutton on the remote
control 3
Press the button to open the tailgate.
When using the remote control, the tailgate
is only unlocked if the key slot in the button
is in the horizontal position.
If the key slot is in the vertical position, the
tailgate is always locked.
Remote control 3 323,
Central locking system 3 324,
Anti-theft alarm system 3331,
Tailgate 3328.

3In Brief
Picture no: 18081s.tif
Unlocking the leaf doors 3: Turn
the key to the vertical position or
press the q button on the remote
control 3
To open the right leaf door, pull on the
handle and pull open the door. To open the
left leaf door, turn the handle on the inside.
When using the remote control, the leaf
doors are only unlocked if the key slot in the
lock is in the vertical position.
If the key slot is in the horizontal position,
the leaf doors are always locked.
Remote control 3 323,
Central locking system 3 324,
Anti-theft alarm system 3331,
Leaf doors 3 329.
Picture no: 13189s.tif
To adjust front seat leg room 3:
Pull handle, slide seat, release
handle
After adjusting, move the seat until you
can feel it engage.
Seats 338, Seat position 339.
Picture no: 13714s.tif
To adjust front seat backrests:
Turn handwheel
Do not lean on seat backrest whilst
adjusting it.
Seats 338, Seat position 339.

4InBrief
Picture no: 12429s.tif
Front seat height 3: Pull lever at
side
Lift lever and relieve some weight from seat
to raise it or press down on seat with body
weight to lower it.
Never adjust the driver’s seat whilst driving.
It could move in an uncontrolled manner
when the lever has been pulled.
Seats 338, Seat position 339.
Picture no: 11536s.tif
To fold front seat backrest
forward 3: Raise release lever
Seats 338, Seat position 339.
Picture no: 13781s.tif
Adjust head restraint height 3of
front and rear outboard seats: Tilt
forward to release, hold in place,
adjust height and release again
Head restraint 340, Head restraint
position 341, Rear, centre head restraint 3
341.

5In Brief
Picture no: 18531s.tif
Pull out the seat belt and engage
it in the belt buckle
The seat belt must not be twisted and must
lie snugly against the body. The backrest
must not be tilted back too far (maximum
approx. 25).
To release belt, press red button on belt
buckle.
Three-point seat belts 348,
Airbag system 3356, Seat position 339.
Picture no: 18083s.tif
Adjust the exterior mirror
manually using the handle
Mirrors 334, Aspherical exterior mirrors
334, Folding the exterior mirrors 334.
Picture no: 18084s.tif
Electrical exterior mirror
adjustment 3
Select the corresponding exterior mirror
with the rocker switch and adjust with the
four-way switch.
Mirrors 334, Aspherical exterior mirrors
334, Folding the exterior mirrors 334,
Heated exterior mirrors 335.

6InBrief
Picture no: 18082s.tif
To adjust interior mirror by
swivelling
Swivel lever on underside of mirror housing
to reduce dazzle at night.
Mirrors 335.
Picture no: 18086s.tif
Steering wheel adjustment 3:
Swivel lever down, adjust height,
swivel lever up, engage
Adjust steering wheel only when vehicle is
stationary and steering column lock is
released.
Airbag systems 3 356.
Picture no: 13715s.tif
Exterior lights
Turn light switch
Press light switch
Push button
Lighting 384, Headlamp-warning device
317.
7=Off
8= Parking lamps
9= Dipped beam or main beam
0=Courtesylamp
>=Foglamps3
r= Fog tail lamp

7In Brief
Picture no: 18475s.tif
Headlamp flash, main beam and
dipped beam
Main beam, headlamp flash 385.
Picture no: 14054h.tif
Switch turn signal on
Turn signals 385.
Picture no: 15865s.tif
Hazard warning lamps
Operated with the ¨button.
Hazard warning flashers 386.
Headlamp flash = Pull stalk towards
steering wheel
Main beam = Push stalk forwards
Dipped beam = Push stalk forwards
again
Right = Lever upwards
Left = Lever downwards

8InBrief

9In Brief
Page
1Light switch .......................... 36, 384
2Side air vents ................................ 393
3Turn signals, headlamp flash,
dipped beam, main beam .. 36, 384
4Horn ...............................................313
5 Steering wheel remote control 3.390
6Instruments ................................... 366
7 Windscreen wipers,
windscreen washer system,
rear window washer system 3.....382
8Centre air vents .............................393
9Display 3for time, date,
outside temperature,
infotainment system 3................ 377
Page
10 Hazard warning lamps ................. 37
LED for anti-theft alarm system 3332
11 Infotainment system 3................ 390
12 Front passenger airbag 3........... 356
13 Glove compartment ..................... 363
14 Heating and ventilation system . 392
15 Air conditioning system 3........... 396
Heated rear window 3....... 314, 337
Air recirculation system 3............ 397
16 Ashtray 3...................................... 362
17 Accessory socket or
cigarette lighter ........................... 361
18 Seat heating 3............................. 340
Fuel selection switch
(natural gas/petrol) 3................ 3113
19 Accelerator pedal .......... 3106, 3108
Page
20 Brake pedal .................... 3106, 3118
21 Ignition switch with
steering wheel lock ...................... 316
22 Steering wheel adjustment 3....... 36
23 Clutch pedal 3........................... 3106
24 Bonnet release lever................... 3128
25 Headlamp range adjustment 3.. 387
Fog tail lamp ................................ 386
Fog lamps 3 ................................. 386
Instrument illumination ............... 387

10 In Brief

11In Brief
Page
1Side air vents ................................ 393
2 Front passenger airbag 3........... 356
3 Infotainment system 3................ 390
4Hazard warning lamps .................. 37
LED for anti-theft
alarm system 3.............................332
5Display 3for time, date,
outside temperature,
infotainment system 3................ 377
6Centre air vents .............................393
7Turn signals, headlamp flash,
dipped beam, main beam .. 36, 384
8Horn ...............................................313
9 Steering wheel remote control 3.390
10 Instruments ................................... 366
Page
11 Windscreen wipers,
windscreen washer system,
rear window washer system 3.....382
12 Light switch ........................... 36, 384
13 Headlamp range adjustment 3.. 387
Fog tail lamp ................................ 386
Fog lamps 3 ................................. 386
Instrument illumination ............... 387
14 Bonnet release lever ................... 3128
15 Ignition switch with
steering wheel lock ...................... 316
16 Steering wheel adjustment 3........ 36
17 Accelerator pedal .......... 3106, 3108
18 Brake pedal .................... 3106, 3118
19 Clutch pedal 3........................... 3106
Page
20 Seat heating 3............................. 340
Fuel selection switch
(natural gas/petrol) 3................ 3113
21 Accessory socket or
cigarette lighter ........................... 361
22 Ashtray 3...................................... 362
23 Air conditioning system 3........... 396
Heated rear window 3....... 314, 337
Air recirculation system 3............ 397
24 Heating and ventilation system . 392
25 Glove compartment .................... 363

12 In Brief
Control indicators
>Fog lamps 3,
366, 386.
A Engine electronics,
Immobiliser 3, Manual
transmission automated 3,
Fault,
321, 366, 3116.
ZExhaust gases 3,
367, 3115.
vAirbag systems 3,
Belt tensioners,
367, 350, 359.
IEngine oil pressure,
367.
OTurn signal lamps,
368, 385.
C
Main beam,
368, 385.
!Preheating 3, diesel particle
filter 3,
368, 3116.
TWinter programme of the
manual transmission
automated 3,
3103.
rFog tail lamp,
369, 386.
pAlternator,
369.
RBrake system,
clutch system 3,
369, 3179.
u
Anti-lock Braking System 3,
3119.
SEngine oil level 3,
370, 3175.
EPS Electric power steering 3,
370.
YFuel level,
370, 3111.

13In Brief
Picture no: 11548s.tif
Operate horn: Press jright or left
Airbag system 3356, Remote control on
steering wheel 3390.
Picture no: 14055h.tif
Windscreen wiper: Move lever
upwards
Windscreen wiper 382, Adjustable wiper
interval 3383, Further information 3160,
3179.
Picture no: 14056h.tif
Operating windscreen washer
system: Lever toward steering
wheel
Windscreen washer system 382, Further
information 3180, 3195.
&=Fast
%=Slow
$= Adjustable interval switching
§=Off

14 In Brief
Picture no: 14057h.tif
Rear window wiper 3and
Rear window washer system 3
operation
Rear window wipers and rear window
washer system 382, Further information
3179, 3180.
Picture no: 11549s.tif
Heated rear window 3, heated
exterior mirrors 3
Operated with the Übutton.
Climate control system 392, Heated rear
window 337.
Picture no: 13205s.tif
To clear fogged or icy windows
Turn the rotary switches for temperature
and air flow clockwise. Set air distribution
to V.Air conditioning system 3: Also press
button n.
Climate control 3392.
Wiper on = Push stalk forwards
Wiper off = Lever toward steering wheel
Washing = Push lever forward and hold
