OPTi Solar 250 User manual

Optikinetics Ltd.
38 Cromwell Road Luton LU3 1DN England
Phone +44 (0)1582 411413
Fax +44 (0)1582 400613
e-mail optiuk@optikinetics.com
Website www.optikinetics.co.uk
* If the thermal cut out engages, allow to cool, check and clear air inlets and outlets, and switch projector back on.
1
OPERATING INSTRUCTIONS
POWER RATING
350W MAX
FUSES
Mains: 220-240V~ T2A/250V (20 x 5mmØ)
110-120V~ T4A/250V (20 x 5mmØ)
12V~ : T4A/250V
OPERATING VOLTAGE
220-240V~ 50-60Hz or 110-120V~ 50-60Hz
ALL FAN INLET GRILLES MUST BE CLEAR WHEN THE
PROJECTOR IS IN USE. NEVER OBSTRUCT.
Failure will cause the projector to overheat, may cause
damage, and the thermal cut-out to switch projector off*.
AN EFFECT MUST ALWAYS BE IN THE GATE OF THE
PROJECTOR WHEN IN USE.
Failure may cause the plastic parts of the focussing lens
to melt.
THE PROJECTOR MUST ONLY BE USED WITHIN 90°
OF HORIZONTAL.
DO NOT TOUCH THE LAMP WITH BARE HANDS AND
NEVER TOUCH HOT LAMP.
Wear gloves or use a soft cloth or tissue.
DO NOT ATTEMPT TO SERVICE THE PROJECTOR
UNLESS YOU ARE QUALIFIED AND WORKING UNDER
THE DIRECTION OF THE MANUFACTURER.
The first step is to position the projector in a place from
which images can be projected onto the desired surface.
The projector must always be mounted using its bracket
and the air inlet grilles must be clear to allow airflow.
There are 4 methods of mounting:
2. Fixed with the hanging
bracket under the
projector onto an
immovable flat surface.
3. Mounted on top of a
flat surface by using
the hanging bracket as
an adjustable stand.
MOUNTING
A safety chain should be
fitted and secured, to an
immovable object, with a
maximum drop of 30cm (12"). All nuts, bolts, hanging
bracket knobs and other fixings must be securely tightened.
ADJUSTING THE BRACKET
1. Suspended from above
with its hanging bracket
firmly fixed to a strong
beam or Trilite truss.
PACKED BOX CONTENTS
Solar 250 Projector with 85mm Lens
2 metre IEC Lead
MAINS CONNECTION
4. Fixed with the hanging
bracket behind the
projector, at an angle,
bolted to an immovable
vertical surface.
IMPORTANT NOTES
Simply plug in the IEC lead
to the back of the projector
and switch to the ON
position.
When setting up the projector, to
project the image where required,
it may be necessary to adjust
the hanging bracket.
1. Loosen central knobs on
both sides and rotate
the bracket or projector into
the desired position.
2. Tighten knobs securely.
Before use check the voltage
selector switch, on the back of
the projector, is set to the
same voltage as your local
mains supply. If incorrect,
move to the correct voltage
position using a flat ended screw driver.
Switching On
Solar 250

1. Remove lamp cover screw on the
top of the projector and remove
lamp cover.
2. Remove internal lamp cover plate.
3. Remove old lamp without
touching with bare hands.
4. Replace with the appropriate new
lamp. (Taking care not to touch
with bare hands).
5. Replace and secure internal
lamp cover plate.
6. Replace and secure the
cover with screw.
Dispose of the old lamp in accordance with the local
regulations.
CHANGING FUSES
Mains fuse
CLEANING
After 3 months (or 500 hours) use, or when changing the
lamp, the optical system may need cleaning.
Switch off mains supply, disconnect the Projector from the
transformer and allow to cool for 30 minutes, then:
1. Remove cover plate screw and remove cover plate.
2. Use a soft tissue or lens cloth with a little
methylated spirit or pure alcohol to clean lenses.
3. To clean the mirror, first remove the lamp, as detailed
in previous section, then wipe clean.
The focussing lens may need
cleaning from time to time.
Use a soft tissue or cloth
with a little methylated spirit
or pure alcohol to clean the
lens.
Lens Cleaning
2
LAMP CHANGING
Switch off mains supply and allow to cool for 30 minutes,
then:
OPERATION
1. Ensure that all air inlets and outlets are clear of all
obstructions and the projector is not placed in a
position that may
compromise cool, dry
airflow.
2. Select the Effect and
appropriate Effect
Accessory.
3. Fit the Effect onto the
Effect Accessory as
described in the Effect
Accessory Instructions.
4. Place the Effect and Accessory into the gate of the
Projector by sliding into the rear gate runners.
The main effect should be fitted into the rear
gate runners for maximum life and object
illumination. Image altering effects like
Distortion Wheels can be fitted into the front
gate runners.
5. Once the Effect(s) and Effects
Accessories are in place (if powered),
plug into the 12V~ sockets on the side
of the Effects Projector.
Before switching on the Effects Projector:
This Effects Projector is designed exclusively for use with
the OPTI Solar Range of Effects Accessories and OPTI
Effects. Ask your dealer for a demonstration.
Switching on the Effects Projector:
Turn the Effects Projector on by connecting to the mains
and switching the supply on (as detailed in MAINS
CONNECTION).
1. Unscrew retaining screw cap.
2. Remove old fuse and replace
with new fuse.
3. Refit and tighten screw cap.
The mains fuse is fitted into
the rear IEC panel. Mains fuse
ratings are shown on page 1:
LAMP DISPOSAL
The 12V~ fuse is located on the side of the projector next
to the front part of the gate and between the Safety Chain
eye and the three 12V~ sockets.
The 12V~ outlets are protected by a 20mm x 5mmØ T4A/
250V time delay fuse.
12V~ fuse
1. Unscrew retaining screw cap.
2. Remove old fuse and replace with new fuse.
3. Refit and tighten screw cap.
213
Switch on the Effects Projector, point at the
projection surface and focus the image by
twisting the focussing lens to move it in and
out until the desired focus is achieved.
FOCUSING A PROJECTED IMAGE

3
Optikinetics Ltd.
38 Cromwell Road Luton LU3 1DN England
Phone +44 (0)1582 411413
Fax +44 (0)1582 400613
e-mail optiuk@optikinetics.com
Website www.optikinetics.co.uk
When using your projection equipment basic safety precautions should be followed, including the following:
1. Read and understand all instructions before using the equipment.
2. To avoid thermal ‘cut out’ or heat damage ensure all air inlets and outlets are clear of obstruction
before use.
3. Never use the appliance without an effect and effect accessory in the gate. Doing so will cause the
plastic parts in the focussing lens to melt.
4. Close supervision is necessary when any appliance is used by, or near, children. Do not leave appliance
unattended while in use.
5. Care must be taken, as burns can occur from touching hot parts.
6. The appliance switch is provided with the symbol ‘O‘ indicating ‘OFF’ and ‘l‘ indicating ‘ON‘.
7. Do not operate appliance with a damaged cord, or if the appliance has been dropped, or damaged,
until it has been examined by a qualified service person.
8. Position the cord so that it will not be tripped over, pulled, or come into contact with hot surfaces.
9. If an extension cord is necessary, a cord with a current rating at least equal to that of the appliance
should be used. Cords rated for less amperage than the appliance may overheat.
10. Always unplug appliance from electrical outlet before cleaning and servicing and when not in use.
Never yank cord to pull plug from outlet. Grasp plug and pull to disconnect.
11. Let appliance cool completely before packing. Loop cord loosely around appliance when storing.
12. To reduce risk of electric shock, do not immerse product in water or other liquids.
13. To reduce the risk of electric shock - do not dismantle this appliance. Take it to a qualified repairer
when servicing is required. Incorrect reassembly can cause electric shock when the product is
subsequently used.
14. The use of an accessory attachment not recommended by the manufacturer may cause a risk of fire,
electric shock, or injury to persons.
15. Connect this appliance to a grounded outlet.
16. Disconnect this unit from its source of supply before replacing the projection lamp.
17. The axis across the width of the projector should remain horizontal if possible. Tilting the projector
along this axis may reduce lamp life.
18. During focussing of the projected image beware of rotating the projection lens too far anti-clockwise,
as this may cause the lens to become separated from the projector, and perhaps dropped and broken
which may cause injury.
19. DO NOT attempt lamp replacement while the unit is still hot as there is a risk of burns from the lamp.
20. The procedures described in the Maintenance section must be carried out by qualified service
personnel who should work under the authority of the manufacturers recognised agent.
21. After any maintenance or cleaning all parts must be absolutely dry before refitting to the projector.
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
Solar 250
