Optoma EP910 SXGA+ Installation manual

Page 1 of 4
1_25_06
Baud Rate 9600
Data Bits 8
Parity N
Stop Bits 1
Flow Control None
Command Structure [Header][Package Size(n)][Command(c)] [Data 1]… [Data d]
Header: 2Bytes, "IR" fixed
Package Size: 2Bytes, Hexadecimal alphabets,n =c+d
Command: 3 Bytes, Hexadecimal alphabets
Data: d Bytes, d=0~248
Command Description Response Description
IR0500000 Response "IR0500000" after the projector received a inviald or failed command
IR0500001 Response "IR0500001" if the projector is cooling.
IR0500002 Response "IR0500002" if the value out of range
IR04002n AV Mute, n=0~1 IR03002 Response "IR03002" after command send successed
n=0: AV Mute OFF IR03002
n=1: AV Mute IR03002
IR04002? IR04002n
IR03003 sync Re-sync IR03003
IR04004n Freeze, n=0~1 IR03004
n=0: Unfreeze IR03004
n=1: Freeze IR03004
IR04004? IR04004n
IR04005n Blanking Color, n=0~1 IR03005
n=0: Blue IR03005
n=1: Black IR03005
IR04005? IR04005n
IR04006n Source Detect, n=0~2 IR03006
n=0, Auto IR03006
n=1, NA IR03006
n=2, Manual IR03006
IR04006? IR04006n
IR04008n Mute, n=0~1 IR03008
n=0: Mute OFF IR03008
n=1: Mute ON IR03008
IR04008? IR04008n
IR03009 Source IR03009
IR04010n Degamma, n=0~3 IR03010
IR03010? IR04010n
IR04011n Zoom, n=0~3 IR03011
n=0: Off
n=1: Zoom 1
n=2: Zoom 2
IR04011? IR04011n
IR05012nn Zoom Value, nn=F6~FF-00-01~0A(Hex Value) IR03012 User input value is from -10 to +10
IR04012? IR05012nn
IR03013 Menu IR03013
IR03014 Left IR03014
IR03015 Right IR03015
IR03016 Up IR03016
IR03017 Down IR03017
IR03018 Enter IR03018
IR03019 Keystone IR03019
IR0301A Display Format IR0301A
IR0301B Display Mode IR0301B
IR04020n Source Select, n=0~9 IR03020
n=0: D-sub Analog RGB IR03020
n=1: D-sub Component IR03020
n=2: D-sub SCART IR03020
n=3: DVI-Digital RGB IR03020
n=4: DVI-Analog RGB IR03020
n=5: NA IR03020
n=6: NA IR03020
n=7: Component IR03020
n=8: S-video IR03020
n=9: Composite Video IR03020
IR04020? IR04020n
PC send to Projector Projector Response to PC
Communication Settings
(Inviald Command or Command Failed)
EP910 RS232 Command Table V1.0
EP910 RS232

Page 2 of 4
Command Description Response Description
IR04030n Display Format, n=0~3 IR03030
n=0: 4:3 IR03030
n=1: 16:9 IR03030
n=2: Window IR03030
n=3: Native IR03030
IR04030? IR04030n
IR04031n Display Mode, n=0~4 IR03031
n=0: PC IR03031
n=1: Movie IR03031
n=2: Game IR03031
n=3: sRGB IR03031
n=4: User IR03031
IR04031? IR04031n
IR04032n Color Temperature, n=0~2 IR03032
n=0: Low IR03032
n=1: Medium IR03032
n=2: High IR03032
IR03032
IR04032? IR05032nn
IR04041n PIP Size, n=0~2 IR03041
n=0: Small
n=1: Normal
n=2: Large
IR04042n PIP Location, n= 0~4 IR03042
n=0: Left-Top
n=1: Right-Top
n=2: N
A
n=3: Left-Bottom
n=4: Right-Bottom
IR03045 Swap IR03045
IR04046n Screen, n=0~2 IR03046
n=0: Single
n=1: PIP Window
n=2:Split POP Screen
IR04041? IR04041n PIP Size, n=0-3
IR04042? IR04042n PIP Location, n= 0-4
IR04046? IR04046n Screen, n=0-2
IR05050nn V. Keystone, nn = D8 ~ FF-00 ~ 28 (Hex Value) IR03050 User input value is from -40 to +40
IR05051nn H. Keystone, nn = D8 ~ FF-00 ~ 28 (Hex Value) IR03051 User input value is from -40 to +40
IR04053n Projection, n=0~3 IR03053
n=0: Ceiling
n=1: Rear Ceiling
n=2: Front
n=3: Rear Front
IR04054n Brite Mode, n=0~1 IR03054
n=0: OFF
n=1: ON
IR04055n Image Shift, n=0~2 IR03055
n=0: OFF
n=1: Position 1
n=2: Position 2
IR04056n Auto Shutdown, n=0~6 IR03056
n=0: OFF
n=1: 1 min
n=2: 3 min
n=3: 5 min
n=4: 10 min
n=5: 20 min
n=6: 30 min
IR05057nn Language, nn = 00~0D IR03057
nn=00: English
nn=01: French
nn=02: German
nn=03: Spanish
nn=04: Italian
nn=05: Russian
nn=06: Portuguese
nn=07: Polish
nn=08: Dutch
nn=09: Traditional Chinese
nn=0A: Simplified Chinese
nn=0B: Japanese
nn=0C: Korean
nn=0D: Swedish
PC send to Projector Projector Response to PC
EP910 RS232

Page 3 of 4
Command Description Response Description
IR07058nnnn V. Image Shift, nnnn = FF7D~FFFF-0000-0001~0083(Hex Value) IR04058 User input value is from -131 to +131
IR04050? IR05050nn V. Keystone, nn = D8 ~ FF-00 ~ 28 (Hex Value)
IR04051? IR05051nn H. Keystone, nn = D8 ~ FF-00 ~ 28 (Hex Value)
IR04053? IR04053n Projection, n = 0~4
IR04054? IR04054n Brite Mode, n = 0~1
IR04055? IR04055n Image Shift, n = 0~2
IR04056? IR04056n Auto Shutdown, n = 0~6
IR04057? IR05057nn Language, n = 0~D
IR04058? IR07058nnnn V. Image Shift, nn = FF7D~FFFF-0000-0001~0083(Hex Value)
IR04061n White Peaking, n=0~A (Hex Value) IR04061n
IR05070nn Volume, nn = 00~14 (Hex Value) IR03070
IR04070? IR05070nn Volume, nn = 00~64 (Hex Value)
IR05071nn Treble, nn = 00~0F (Hex Value) IR03071
IR04071? IR05071nn Treble, nn = 00~64 (Hex Value)
IR05072nn Bass, nn = 00~0F (Hex Value) IR03072
IR04072? IR05072nn Bass, nn = 00~64 (Hex Value)
IR04073n Stereo/Mono, n=0~1 IR03073
n=0: Mono IR03073
n=1: Stereo IR03073
IR04073? IR04073n Stereo/Mono, n = 0 or 1
IR05080nn Brightness, nn = 00~64 (Hex Value) IR03080
IR05081nn Contrast, nn = 00~64 (Hex Value) IR03081
IR05082nn Color, nn = 00~64 (Hex Value) IR03082
IR05083nn Tint, nn = 00~64 (Hex Value) IR03083
IR05084nn Sharpness, nn = 00~06 (Hex Value) IR03084
IR05085nn Frquency, nn = 00~64 (Hex Value) IR03085
IR05086nn Tracking, nn = 00~64 (Hex Value) IR03086
IR05087nn H. Position, nn = 00~64 (Hex Value) IR03087
IR05088nn V. Position, nn = 00~64 (Hex Value) IR03088
IR04080? IR05080nn Brightness, nn = 00~64 (Hex Value)
IR04081? IR05081nn Contrast, nn = 00~64 (Hex Value)
IR04082? IR05082nn Color, nn = 00~64 (Hex Value)
IR04083? IR05083nn Tint, nn = 00~64 (Hex Value)
IR04084? IR05084nn Sharpness, nn = 00~64 (Hex Value)
IR04085? IR05085nn Frquency, nn = 00~64 (Hex Value)
IR04086? IR05086nn Tracking, nn = 00~64 (Hex Value)
IR04087? IR05087nn H. Position, nn = 00~64 (Hex Value)
IR04088? IR05088nn V. Position, nn = 00~64 (Hex Value)
POWER ON and OFF
IR04090n Power, n=0~1 IR03090
n=0: Power OFF IR03090
n=1: Power ON IR03090
IR04090? IR04090n
IR07092nnnn Set ID, nnnn=0~9999 IR03092
IR04092? IR07092nnnn
IR03093 Lamp Reset IR03093
IR04094n Lamp Reminding, n=0~1 IR03094
n=0: OFF IR03094
n=1: ON IR03094
IR04094? IR04094n
IR04095? Read F/W Version IR07095nnnn Response command string and 4 alphabets
IR04096? Read ID IR07096nnnn Response command string and 4 digitals
IR04097? Read LampHour IR07097nnnn Response command string and 4 digitals
IR04098? Read Projector Status 1 IR1F098nnnn…n Response command string and 28 digitals
IR04099? Read Projector Status 2 IR31099nnnn…n Response command string and 34 digitals
IR07100nnnn Gain Red, nnnn = FF9C~FFFF-0000-0001~0064(Hex Value) IR03100
IR07101nnnn Gain Green, nnnn = FF9C~FFFF-0000-0001~0064(Hex Value) IR03101
IR07102nnnn Gain Blue, nnnn = FF9C~FFFF-0000-0001~0064(Hex Value) IR03102
IR07103nnnn Offset Red, nnnn = FF9C~FFFF-0000-0001~0064(Hex Value) IR03103
IR07104nnnn Offset Green, nnnn = FF9C~FFFF-0000-0001~0064(Hex Value) IR03104
IR07105nnnn Offset Blue, nnnn = FF9C~FFFF-0000-0001~0064(Hex Value) IR03105
IR04100? IR07100nnnn Gain Red, nnnn = FF9C~FFFF-0000-0001~0064(Hex Value)
IR04101? IR07101nnnn Gain Green, nnnn = FF9C~FFFF-0000-0001~0064(Hex Value)
IR04102? IR07102nnnn Gain Blue, nnnn = FF9C~FFFF-0000-0001~0064(Hex Value)
IR04103? IR07103nnnn Offset Red, nnnn = FF9C~FFFF-0000-0001~0064(Hex Value)
IR04104? IR07104nnnn Offset Green, nnnn = FF9C~FFFF-0000-0001~0064(Hex Value)
IR04105? IR07105nnnn Offset Blue, nnnn = FF9C~FFFF-0000-0001~0064(Hex Value)
PC send to Projector Projector Response to PC
EP910 RS232

Page 4 of 4
Command Description Response Description
IR03000 Response "IR03000" after PC received a inviald or failed command
IR04901? Request IP Configuration IR25901n n=AAAAAAAANNNNNNNNGGGGGGGGDDDDDDDDPC
A: IP Address from MSB to LSB(ex. 10.0.21.22->0A001516)
N: Subnet Mask
G: Gateway
D: DNS
P: DHCP Mode(0/1: Off/ON)
C: RJ-45 Connector State(0/1: Disconnect/Connect)
IR0A902nnnnnnn Send Email Alert
Byte1: Error State(0/1/2/3/4/5: Normal/Thermal Switch Error/Fan
Lock/Over Temperature/Lamp Hours Running Out/Lamp Fail)
Byte2~5: Lamp Hour 4 bytes Hex. string
B
y
te6~7: Tem
p
erature 2 b
y
tes Hex. strin
g
IR03902
IR0500010 Response "IR0500010" SMTP not ready
IR03903 Set Network Module to Default IR03903
IR22904n Setting IP Configuration
n=AAAAAAAANNNNNNNNGGGGGGGGDDDDDDDD
A: IP Address from MSB to LSB(ex. 10.0.21.22->0A001516)
N: Subnet Mask
G: Gateway
D: DNS
IR03904
IR04905n Setting DHCP Mode, n=1/0 : DHCP ON/OFF IR03905
Additional Resources
Byte1: Power State 0/1/2: Power OFF/Power ON/Cooling IR04090n
Byte2: Error State
0/1/2/3/4/5: Normal/Thermal Switch Error/Fan Lock/ Over
Temperature/Lamp Hours Running Out/Lamp Fail
Byte3~6: Lamp Hour String 4 digitals, (MSB~LSB)
Byte7: Current Source 0~9: D-sub Analog RGB~Composite Video
Byte8: Display Format 0/1/2/3: 4:3/16:9/Window/Native
Byte9: Display Mode 0/1/2/3/4: PC/Movie/Game/sRGB/User
Byte10: Digital Source 0/1: OFF/ON
Byte11~12: Volume 00~14 (Hex Value) IR05070nn
Byte13~14: Treble 00~0F (Hex Value) IR05071nn
Byte15~16: Bass 00~0F (Hex Value) IR05072nn
Byte17~18: Brightness 00~64 (Hex Value) IR05080nn
Byte19~20: Contrast 00~64 (Hex Value) IR05081nn
Byte21~22: Color 00~64 (Hex Value) IR05082nn
Byte23~24: Tint 00~64 (Hex Value) IR05083nn
Byte25: AV Mute 0/1: AV Mute OFF/AV Mute
Byte26: Freeze 0/1: Unfreeze/Freeze
Byte27: Mute 0/1: OFF/ON
Byte28: Stereo/Mono 0/1: Mono/Stereo IR04073n
Byte29: Lamp Litted 0/1: Fail/Success
Byte1: Screen 0/1/2: Single/PIP Window/Split Screen
Byte2: PIP Size 0/1/2: Small/Normal/Large
Byte3: PIP Location 0/1/2/3/4: Left-Top/Right-Top/Center/Left-Bottom/Right-Bottom
Byte4: Projection Mode 0/1/2/3/4: Ceiling/Rear Ceiling/Front/Rear Front
Byte5: Auto Shutdown 0/1/2/3/4/5/6: OFF/1 min/3 min/4 min/10 min/20 min/30 min
Byte6: Brite Mode 0/1: OFF/ON
Byte7: Image Shift 0/1/2: OFF/Position 1/Position 2
Byte8~11: V. Image Shift FF7D~FFFF-0000-0001~0083(Hex Value) User input value is from -131 to +131
Byte12~13: Zoom Value F6~FF-00-01~0A(Hex Value) User input value is from -10 to +10
Byte14: White Peaking 0~A (Hex Value) IR04061n
Byte15: Blanking Color 0/1: Blue/Black
Byte16: Lamp Reminding 0/1: OFF/ON
Byte17~18: Language 00~0D IR05057nn
Byte19~20: Sharpness 00~06 (Hex Value) IR05084nn
Byte21~22: Frequency 00~64 (Hex Value) IR05085nn
Byte23~24: Tracking 00~64 (Hex Value) IR05086nn
Byte25~26: V. Position 00~64 (Hex Value) IR05088nn
Byte27~28: H. Position 00~64 (Hex Value) IR05087nn
Byte29~30: Color Temperature 00/01/02: Low/Medium/High IR04032n
Byte31~32: V. Keystone D8 ~ FF-00 ~ 28 (Hex Value) User input value is from -40 to +40
Byte33~34: H. Keystone D8 ~ FF-00 ~ 28 (Hex Value) User input value is from -40 to +40
Byte35: Degamma 0~3 (Hex Value)
Byte36: Zoom 0/1/2: OFF/Zoom 1/Zoom 2
(IR04099?)Projector status 2, bytes description
Network Module Response to ProjectorProjector Send to Network Module (IRxx9xx…)
(IR04098?)Projector status bytes description
