Optoma TX7000 User manual

Optoma’s TX7000 provides performance and flexibility to
meet the most demanding large-venue installation
challenges. Powered with 4800 ANSI lumens and the
latest in image and color enhancement technologies, the
TX7000 ensures excellence in projection performance.
Standard, long and short throw lens options, optimized
with PureOptics ED-glass lens elements, create
consistently high picture quality at a wide range of
projection distances. Vertical and horizontal lens shift
further increases the extensive range of installation
options. With its wide array of inputs and management
options, the TX7000 is your ideal solution for large-venue
projection needs.
3D content can be viewed with active LCD shutter glasses when the projector is connected to a
computer with a compatible 3D graphics card. Please visit www.optoma.com for more information.
TX7000 | Installation Projector
Maximum Flexibility for
CustomizedInstallations
www.optoma.com
TX7000 FEATURES
4200 ANSI lumens of brightness project
crystal clear images that are easily viewable
by audiences seated in large venues such as
auditoriums and lecture halls
Flexible projector placement with extensive
vertical and horizontal lens shift
Three lens choices with easy-to-change
bayonet mounts createa wide range of
projection distances and image sizes
Remote monitoring and control capabilities
over a LAN network via integrated RJ45
connection – compatible with Crestron
RoomView™
Complete security features protectprojector
settings and lock out unauthorized users
1 Power LED Indicator
2 DVI-D
3 HDMI
4 USB
5 RJ-45
6 VGA 1-In
7 Audio-In (VGA 1)
8 VGA 2-In
9 Audio-In (VGA-2)Component
10 VGA-Out
11 Audio-Out
12 BNC (RGBHV/YPbPr)
13 Audio-In
14 Component
15 Audio-In
16 RS232
17 S-Video
18 Composite Video
19 Audio-In
20 +12V Triggers
21 Power
2 3
4
5
6 7 8 910 11
12 13
15 16
17 18
21
1
14
19 20
BNC
Format
Re-Sync
Source
Enter
Power
Video
Brightness
Menu
Left Mouse Button
DVI
Mouse Directional
Control
Right Mouse Button
VGA
S-Video
Keystone
Page Up
Page Down
Four Directional Keys
HDMI
Zoom-Out
Laser
Zoom-In
Display
Volume
AV Mute
Freeze
YPbPr

TX7000| Installation Projector
All Specifications are subject to change without notice. ©2010 Optoma Technology, Inc. DLP®and the DLP logo are
registered trademarks of Texas Instraments. All other names mentioned herein are property of their respective owners.
Lens Throw Options (PureOptics)
Standard Throw Lens
1.60 to 2.00:1
4.9’ to 23.0’ (1.5 to 7m)
36.8” to 216” (0.93 to 5.49m)
F=2.46-2.56, f=22.8-28.5 mm,
1.25x Manual Zoom and Focus
18.9 lbs (8.6 kg)
BX-DL200
Long Throw Lens
2.03 to 3.05:1
6.6’ to 65.6’ (2 to 20m)
30.6” to 457” (0.78 to 11.6m)
F=2.5-3.1, f=28.5-42.75 mm,
1.5x Manual Zoom and Focus
18.9 lbs (8.6 kg)
BX-DL300
Short Throw Lens
0.80:1
1.6’ to 9.8’ (0.5 to 3m)
30.0” to 184” (0.76 to 4.67m)
F=2.5, f=11.5 mm,
Manual Focus
19.1 lbs (8.7 kg)
BX-DL080
Throw Ratio (Distance/Width)
Projection Distance
Image Size (Diagonal)
Projection Lens
Weight w/Projector
Part Number
www.optoma.com
Specifications
Display Technology:
Resolution:
Maximum Resolution:
Brightness (Typical):
Contrast Ratio:
Lamp Type:
Lamp Life (STD/Bright)*:
Noise Level:
Remote Control:
Computer Compatibility:
Video Compatibility:
3D Compatibility:
Monitor Loop Through:
Aspect Ratio:
User Controls:
Keystone Correction:
Lens Shift:
Power Supply:
Power Consumption:
Weight:
Dimensions (W x H x D):
Operating Temperature:
Displayable Colors:
Projection Method:
Uniformity:
Security:
I/O Connectors:
Standard Accessories:
Optional Accessories:
Warranty:
UPC:
Single 0.7” DarkChip3™ DLP®Technology by Texas Instruments
Native XGA (1024 x 768)
UXGA (1600 x 1200)
4800 ANSI Lumens
2000:1 (Full On/Full Off)
330W P-VIP
Estimated at 3000/2000 Hours
31dB
Fully Featured IR Remote Control with Mouse and Laser Pointer
UXGA, SXGA+, WXGA, SXGA, XGA, SVGA, VGA Resized, VESA, PC and Macintosh Compatible
NTSC, PAL, SECAM, SDTV (480i/576i), EDTV (480p/576p), HDTV (720p, 1080i/p)
120Hz Frame Sequential 3D for Resolutions Up to 720p, 60Hz Field Sequential 3D for Resolutions Up to 480i
D-sub 15-Pin VGA Output (Functional in Both Normal and 5W Standby Modes)
Native 4:3 and 16:9 Compatible
Complete On-Screen Menu Adjustments in 23 Languages
± 30º Vertical
Vertical -15% to +50% Image Height, Horizontal ±10% Image Width
AC Input 100 - 240V, 50-60 Hz, Auto-Switching
430 Watts (Bright), 390 Watts (STD), <1 Watt (Standby)
18.1 lbs (8.2 kg) w/o Lens
16.9” x 7.1” x 13.4” (430 x 181 x 340 mm)
41 - 104°F (5 - 40°C), 85% Max Humidity, Adjustable Fan Speed for High Altitude Application
1.07 Billion
Front, Rear, Ceiling Mount, Table Top
85%
One Kensington®Lock Port, Keypad Lock, Security Bar
HDMI, DVI-D w/ HDCP, Two VGA-In, VGA-Out, Component Video, S-Video, Composite Video, Five BNC (RGBHV/YPbPr), Three Stereo
Mini Jack Audio-In, Two RCA Stereo Audio-In, Audio-Out, USB, RS-232, RJ45, and Two +12V Triggers
AC Power Cord, VGA to VGA Cable, USB Cable, Remote Control, Batteries for Remote, CD-ROM User’s Manual, Quick Start Card and
Warranty Card
Lens Throw Options, Wireless Dongle, Ceiling Mount, S-Video Cable, Audio-Out Adapter, HDMI Cable, DVI Cable, HDMI Cable, DVI Cable,
and Panoview™ Series Screens
3 Years Optoma Express Replacement Service, 1 Year on Lamp
796435 41 174 9
* Lamp life is dependent upon many factors, including lamp mode, display mode, usage, environmental conditions and more. Lamp brightness can decrease over time.
Home-TX7000-0810
NO FILTER
REQUIRED
