ORION PDP 84MPDP User manual

USER'S MANUAL
Thank you for your purchasing our Plasma display monitor.
Please read through this user's manual for safety before installing this product.
This product is manufactured for Plasma display model only.
84"
84MPDP
Made in Korea
Made in Korea
Seam less Multi PDP

Preparing
21
If you do not keep rules for safely and rightly using the
product, fire or injury may be occurred.
Warning
Features of Plasma monitor
Contents
Preparing
Keep it for safety 3
How to install the monitor (stand, hanger) 6
Designation 7
Connecting Cable 10
Buttons of remote controller 11
How to use basic menu 12
Connecting
Connecting PC 13
Connecting VCR 15
Connecting S-VHS 17
Connecting DVD 19
Connecting DIGITAL TV 21
Fundamental (Setting)
Adjusting video
DVD, VIDEO mode 23
PC mode 25
Splitting into multi-screen 27
Features (DVD, VIDEO mode)
Setting Picture Mode 28
Setting language 29
Adjusting Display Size 30
Features (PC mode)
Setting language 31
Setting Afterimage Anti Image Burn 32
Screen (PC mode)
Setting Auto-Tracking 33
Setting screen position 34
Setting frequency 35
Setting phase 36
Hot buttons of Remote controller
DISPLAY MODE 37
INPUT A,B,C,D 37
SLEEP 37
STILL 38
ASPECT 38
AUTO 38
Others
Before you consider it as a failure 39
About Plasma display panel 40
Specification 41
Resolution of PC video signal 42
Installation of the Monitor
To install as stand type 44
To install as wall mounting type 58
To install as wall mounting type(Vertical) 74
You can enjoy a wide full-flat screen with high brightness and high quality.
It clearly and finely displays the high quality image by PDP panel with a high
resolution of 1,640,000 pixels incomparable to general TVs.
It has no limit for location and move because of its thin shape.
It supports various inputs (VIDEO, DVD, DIGITAL TV, PC, etc.) for the
multimedia times.
Customers can enjoy their favorite programs by various screen-split features
simultaneously presenting several programs.
Thank you for your purchasing our 84" PDP monitor.
This manual describes how to use the product and notes for using.
Please read the manual before using it.
After reading the manual, keep it with the certificate for you to refer to it
whenever you want.
If you have any question or any problem is occurred, please contact to the
dealer or the A/S center immediately.
Pausing a screen for a long time may cause an afterimage effect.
Notice of users
A-grade device
It is a device for business purpose with safety registered for electromagnetic
interference, which user should be mindful of it.

Preparing
43
• If it operates abnormally, stop using it
immediately.
• Do not place any container with water or
liquid on it. If it flows into the inside, it
may cause electric shock or fire.
• Do not input any foreign material. It may
cause a failure or shorten its life span.
• Please contact to professional
construction companies for installing
hanger or wall. Otherwise, it may cause
device damage or injury.
• Do not touch with this device when
lightning. It may cause electric shock.
• Do not install it at any unstable location.
It may cause injury.
• Do not any work for damaging power
code or power plug. It may cause fire or
electric shock.
• Do not pull out the power plug with wet
hands. It may cause electric shock.
• Do not use for exceeding ratings of outlet
or device. It may cause failure.
• Do not modify (disassembly) it. It may
cause electric shock because high
voltage is flowing inside.
• Do not install it at any location touched
by the direct rays of the sun or near
heating device. It may shorten its life
span or cause failure.
• Do not cover over it with any thing or cover.
If the venting hole is blocked, its inside
temperature may be risen to cause
overheating into fire.
• Do not pull out or hang down the
connection cable. It may damage the
cord to cause fire or electric shock.
• Do not lean on this product or keep it
leaned. It may cause injury or failure.
• Do not place it at places with much
humidity, dust, oil, smoke, or steam. It
may cause failure.
• Pull out the power plug by holding the
plug. Otherwise, it may damage the
power cord to cause fire or electric
shock.
• If you do not use it for a long time, keep
the power plug pulled out of the outlet. It
may save the electricity.
• Do not place anything heavy on it. It may
cause failure.
• Be careful of the polarity of the battery. • Do not stand on this product. It may
cause injury.
• When moving it, disconnect the
connecting cable. Otherwise, it may
damage the cable to cause fire or
electric shock.
• Do not mix new batteries with old
batteries or do not use undesignated
ones. It may cause degrade its
performance.
KEEP IT FOR SAFETY
• Install this product at the safe and flat
surface.
• Do not place a candle with fire on this
product. It may cause electric shock or
fire.

Preparing
65
You can install it by 2 methods according to location or purpose. Select the location to install, purchase the device to install,
and inquire at the professional installer for installing.
You should purchase and install the exclusive device (stand, hanger). Otherwise, it may cause to damage the product or to
injureaperson.
How to install the monitor
It is easy to install at the mobile condition and convenient for
frequent moving by connecting wheels to the stand. It can be installed at the wall to utilize the wider space and at
the higher place.
How to install with a stand (optional) How to install with a hanger (optional)
Remote controller 2 batteries for
remote controller
(AAA type)
User's manual
Video connection
cable
1ea
Power cord 4ea
PC cable 1ea
POWERONPOWEROFF
AUTOSTILLSLEEP
UP
DOWN
LeftRight
F6
ASPECTF1F2PROG
MENU
ESC
DISPLAY
MODE
INPUTSELECT
PDP
REMOTECONTROL
84PDP
F3
INPUTAINPUTB
INPUTCINPUTD
ENTER
AB
CD
F4
F5
Signal cable 1ea
B-APL(1000mm)
Signal cable 1ea
A-APL(900mm)
Signal cable 1ea
S/W POWER(850mm)
Signal cable 2ea
C,D-APL(700mm)
DVI cable 2ea
C,D-DVI(800mm)
DVI cable 2ea
A,B-DVI(1200mm)
Checking components
• For the inside cleaning, please inquire at the dealer once a year.
• When caring, please disconnect the power plug from the outlet for safety.
• Clean the monitor screen with a soft cloth. Strong detergent or coarse cloth may damage or deform the
product.
1. Is the power plug connected to the outlet correctly?
2. Are there batteries at the remote controller?
3. Is the video device connected correctly?
• "No signal" message may be displayed on the screen. Check the connection again.
About Speakers
About Caring
Before using
• Customers can purchase speakers separately and should use other sound system.
• Monitor has no sound function.
Bracket Holder Switcher Bracket Terminal 2ea Remote controller
Sensor
Front_Side 2ea
Guide Pin 8ea
Hanger Bolt
Front_top
Installation accessories
Front_Down
Screw
M4 x 8L : 4ea
Screw
Nureing Knob : 2ea Screw
FLAT M4 x 6 MFNI : 2ea
Hook-16ea Eye Bolt 2ea
Screw
PAN M5 x 25L 16ea
Screw
FLAT M5 x 10 MFNI : 28ea
Screw M8 x 20L : 6ea

Preparing
87
A ID 1
1 2 3 4 5
1 2 3 4 5 1 2 3 4 5
1 2 3 4 5
B ID 2
C ID 3 D ID 4
SUB– APL MAIN– APLDVI
S/WPOWER
SUB– APL MAIN– APLDVI
S/WPOWER
SUB– APL MAIN– APLDVI
S/WPOWER
SUB– APL MAIN– APLDVI
S/WPOWER
AB
CD
Designation
Front side
ID Switch Setting
Rear side
Receiving glass:
Receive the operation signal from the
remote controller. Some obstacles may
cause the remote controller not to
operate.
1. Composite video input 2
- Composite video input
2. S-VHS input 2
-Y/C signal input
3. Composite video input 1
- Composite video input
4. S-VHS input 1
-Y/C signal input
5. DTV, DVD input 2
- Y, Pb/Cb, Pr/Cr input for DTV, DVD
6. DTV, DVD input 1
- Y, Pb/Cb, Pr/Cr input for DTV, DVD
7. PC input 2
-Computer analog video signal input
8. PC input 1
-Computer analog video signal input
9. Serial connector 2
-Software upgrade
10. Serial connector 1
-External communication input

Preparing
109
SUB – APL MAIN – APLDVI
S/W POWER
SUB – APL MAIN – APLDVI
S/W POWER
SUB – APL MAIN – APLDVI
S/W POWER
SUB – APL MAIN – APLDVI
S/W POWER
C–APLA–APLIR SENSORS/W POWERC–DVIA–DVIB–DVID–DVIB–APLD–APL
AB CD
Connecting Cable
IR Sensor
Switcher

Preparing
1211
POWER OFF:
Turn off the monitor
PROG:
Program download
SLEEP:
Set up the automatic OFF
ENTER:
Selectamenu/Movetoanother
submenu in some cases
:
Moving around the menu
INPUT A/B/C/D:
Switch the input signal of each split-screen
ESC:
Escape from the menu and the
set up
DISPLAY MODE:
Switch the screen-split mode
MENU:
Display the menu on the screen
AUTO:
Automatically adjust the video of PC
ASPECT:
Switch the screen aspect of the video image
STILL:
Pause the screen
POWER ON:
Turn on the monitor
POWER ON POWER OFF
AUTO STILL SLEEP
UP
DOWN
Left Right
F6
ASPECT F1 F2 PROG
MENU
ESC
DISPLAY
MODE
INPUT SELECT
PDP
REMOTE CONTROL
84PDP
F3
INPUT A INPUT B
INPUT C INPUT D
ENTER
AB
CD
F4
F5
Buttons of remote controller How to use the basic menu
Note:
• Use two 1.5V AAA-type batteries.
How to mount batteries
• Slide the cap at the rear side of the remote controller to open.
• Insert batteries with the correct polarity and close the cap.
When you press MENU button, the basic menu is displayed on the screen.
The basic menu has four items such as VIDEO, MULTI, FUNCTION, and SCREEN. Each item has its subitems.
When you select the desired item, that item is displayed in yellow.
MENU
ENTER
• When you press MENU button, the
menu is displayed on the screen.
Press MENU button.
MENU
• Press [MENU] button to exit from the menu.
If there is no operation for 10 seconds or longer, it automatically exits from the
menu.
Adjust brightness, contrast, fineness, hue, and color.
See 23~26 page.
Set the split mode of the screen.
See 27 page.
Set screen mode, screen size, language, OSD direction, and
afterimage removal. See 28~32 page.
Adjust auto, screen left/right position, frequency, and phase. It is
displayed at PC mode only. See 33~36 page.
Exit the menu.
PICTURE :
MULTI :
UTILITY:
DISPLAY:
•Movetothedesireditemby or
button and press ENTER button.
• You can move to the submenu to set
up by or button.
You can move around the menu by buttons.

Connecting
1413
POWER ON
INPUT A INPUT B
INPUT C INPUT D
• Connect to PC by cable as shown at the figure.
Connecting PC
When connecting to PC, connect the connector of the rear side of the monitor as follows:
SUB– APL MAIN – APLDVI
S/WPOWER
SUB– APL MAIN – APLDVI
S/WPOWER
SUB– APL MAIN – APLDVI
S/WPOWER
SUB– APL MAIN – APLDVI
S/WPOWER
AB
CD
Rear side of PC
Connectors of the rear side of the monitor
Connect PC.
POWER ON POWER OFF
AUTO STILL SLEEP
UP
DOWN
Left Right
F6
ASPECT F1 F2 PROG
MENU
ESC
DISPLAY
MODE
INPUT SELECT
F3
INPUT A INPUT B
INPUT C INPUT D
ENTER
AB
CD
F4
F5
PDP
REMOTE CONTROL
84PDP
Connect power cord correctly on the Monitor.
• Press [POWER ON] button of the remote controller or the main body to
turn on the monitor.
Press [POWER ON] button.
• Press [INPUT A] button to select PC1. When connected to PC2, select PC2.
• When you press the button, it is selected as the following order.
DVD1(DTV1) DVD2(DTV2) PC1 PC2 VIDEO1 VIDEO2
Press [INPUT A] button.
DISPLAY
MODE
AAB AB A
B
AB
C
AB
CD
• Press [DISPLAY MODE] button of the remote controller to select .
• Whenever you press [DISPLAY MODE] button, it is selected as follows:
A
Press [DISPLAY MODE] button.

Connecting
1615
POWER ON
INPUT A INPUT B
INPUT C INPUT D
• Connect to VCR by cable as shown at the figure.
When connecting to VCR, connect the connector of the rear side of the monitor as follows:
If there exists S-VHS connector at the VCR, refer to 'Connecting S-VHS' of the next page.
SUB– APL MAIN– APLDVI
S/WPOWER
SUB– APL MAIN– APLDVI
S/WPOWER
SUB– APL MAIN– APLDVI
S/WPOWER
SUB– APL MAIN– APLDVI
S/WPOWER
AB
CD
(R) AUDIO (L) S-VIDEO
OUT
IN
VIDEO
Rear side of VCR
Connectors of the rear side of the monitor
Connect VCR.
POWER ON POWER OFF
AUTO STILL SLEEP
UP
DOWN
Left Right
F6
ASPECT F1 F2 PROG
MENU
ESC
DISPLAY
MODE
INPUT SELECT
F3
INPUT A INPUT B
INPUT C INPUT D
ENTER
AB
CD
F4
F5
PDP
REMOTE CONTROL
84PDP
Connect power cord correctly on the Monitor.
• Press [POWER ON] button of the remote controller or the main body to
turn on the monitor.
Press [POWER ON] button.
• Press [INPUT A] button to select VIDEO1. When connected to VIDEO2,
select VIDEO2.
• When you press the button, it is selected as the following order.
DVD1(DTV1) DVD2(DTV2) PC1 PC2 VIDEO1 VIDEO2
Press [INPUT A] button.
Connecting VCR
DISPLAY
MODE
AAB AB A
B
AB
C
AB
CD
• Press [DISPLAY MODE] button of the remote controller to select .
• Whenever you press [DISPLAY MODE] button, it is selected as follows:
A
Press [DISPLAY MODE] button.

Connecting
1817
POWER ON
INPUT A INPUT B
INPUT C INPUT D
• Connect to VCR by the supplied cable as shown at the figure.
When connecting to VCR, connect the connector of the rear side of the monitor as follows:
If you use S-VHS connector, you can enjoy the better video quality than VCR.
SUB– APL MAIN– APLDVI
S/WPOWER
SUB– APL MAIN– APLDVI
S/WPOWER
SUB– APL MAIN– APLDVI
S/WPOWER
SUB– APL MAIN– APLDVI
S/WPOWER
AB
CD
(R) AUDIO (L) S-VIDEO
OUT
IN
VIDEO
Rear side of S-VHS
Connectors of the rear side of the monitor
Connect S-VHS.
POWER ON POWER OFF
AUTO STILL SLEEP
UP
DOWN
Left Right
F6
ASPECT F1 F2 PROG
MENU
ESC
DISPLAY
MODE
INPUT SELECT
F3
INPUT A INPUT B
INPUT C INPUT D
ENTER
AB
CD
F4
F5
PDP
REMOTE CONTROL
84PDP
Connect power cord correctly on the Monitor.
• Press [POWER ON] button of the remote controller or the main body to
turn on the monitor.
Press [POWER ON] button.
• Press [INPUT A] button to select VIDEO1. When connected to VIDEO2,
select VIDEO2.
• When you press the button, it is selected as the following order.
DVD1(DTV1) DVD2(DTV2) PC1 PC2 VIDEO1 VIDEO2
Press [INPUT A] button.
Connecting S-VHS
DISPLAY
MODE
AAB AB A
B
AB
C
AB
CD
• Press [DISPLAY MODE] button of the remote controller to select .
• Whenever you press [DISPLAY MODE] button, it is selected as follows:
A
Press [DISPLAY MODE] button.

Connecting
2019
POWER ON
INPUT A INPUT B
INPUT C INPUT D
• Connect to DVD by the supplied cable as shown at the figure.
When connecting to DVD, connect the connector of the rear side of the monitor as follows:
SUB– APL MAIN– APLDVI
S/WPOWER
SUB– APL MAIN– APLDVI
S/WPOWER
SUB– APL MAIN– APLDVI
S/WPOWER
SUB– APL MAIN– APLDVI
S/WPOWER
AB
CD
(R) AUDIO (L)YCBCR
Rear side of DVD
Connectors of the rear side of the monitor
Connect DVD.
POWER ON POWER OFF
AUTO STILL SLEEP
UP
DOWN
Left Right
F6
ASPECT F1 F2 PROG
MENU
ESC
DISPLAY
MODE
INPUT SELECT
F3
INPUT A INPUT B
INPUT C INPUT D
ENTER
AB
CD
F4
F5
PDP
REMOTE CONTROL
84PDP
Connect power cord correctly on the Monitor.
• Press [POWER ON] button of the remote controller or the main body to
turn on the monitor.
Press [POWER ON] button.
• Press [INPUT A] button to select DVD1. When connected to DVD2, select
DVD2.
• When you press the button, it is selected as the following order.
DVD1(DTV1) DVD2(DTV2) PC1 PC2 VIDEO1 VIDEO2
Press [INPUT A] button.
Connecting DVD
DISPLAY
MODE
AAB AB A
B
AB
C
AB
CD
• Press [DISPLAY MODE] button of the remote controller to select .
• Whenever you press [DISPLAY MODE] button, it is selected as follows:
A
Press [DISPLAY MODE] button.

Connecting
2221
POWER ON
INPUT A INPUT B
INPUT C INPUT D
• Connect to DIGITAL TV receiver by the supplied cable as shown at the figure.
When connecting to DIGITAL TV, connect the connector of the rear side of the monitor as follows:
SUB– APL MAIN– APLDVI
S/WPOWER
SUB– APL MAIN– APLDVI
S/WPOWER
SUB– APL MAIN– APLDVI
S/WPOWER
SUB– APL MAIN– APLDVI
S/WPOWER
AB
CD
(R) AUDIO (L)YCBCR
Rear side of Set-top box
Connectors of the rear side of the monitor
Connect DIGITAL TV receiver.
POWER ON POWER OFF
AUTO STILL SLEEP
UP
DOWN
Left Right
F6
ASPECT F1 F2 PROG
MENU
ESC
DISPLAY
MODE
INPUT SELECT
F3
INPUT A INPUT B
INPUT C INPUT D
ENTER
AB
CD
F4
F5
PDP
REMOTE CONTROL
84PDP
Connect power cord correctly on the Monitor.
• Press [POWER ON] button of the remote controller or the main body to
turn on the monitor.
Press [POWER ON] button.
• Press [INPUT A] button to select DTV1. When connected to DTV2, select DTV2.
• When you press the button, it is selected as the following order.
DVD1(DTV1) DVD2(DTV2) PC1 PC2 VIDEO1 VIDEO2
Press [INPUT A] button.
Connecting DIGITAL TV
DISPLAY
MODE
AAB AB A
B
AB
C
AB
CD
• Press [DISPLAY MODE] button of the remote controller to select .
• Whenever you press [DISPLAY MODE] button, it is selected as follows:
A
Press [DISPLAY MODE] button.

Fundamental (Setting)
2423
ENTER
MENU
MENU
ENTER
• Press [MENU] button to display the
menu.
• The currently set screen mode is
displayed at the top of the menu.
(DVD, VIDEO)
Adjusting video (DVD,VIDEOmode)
Adjust it only when 30 minutes or longer elapses after turning on the monitor.
Press [MENU] button.
Selecting ContrastSelecting Brightness Selecting Sharpness Selecting Color Selecting Hue
POWER ON POWER OFF
AUTO STILL SLEEP
UP
DOWN
Left Right
F6
ASPECT F1 F2 PROG
MENU
ESC
DISPLAY
MODE
INPUT SELECT
F3
INPUT A INPUT B
INPUT C INPUT D
ENTER
AB
CD
F4
F5
PDP
REMOTE CONTROL
84PDP
• Press or button to select the desired item.
• Whenever you press or button, it proceeds to Brightness Contrast
Fineness Hue Color.
• Select the desired item, and then press [ENTER] button.
Select the desired item.
•Press or button to adjust the value to what you want.
• After completing the adjustment, press [ENTER] button.
Adjust the value to what you want.
• Press [MENU] button to exit from the menu.
• If there is no operation for 10 seconds or longer, it automatically exits from the
menu.
Finish the adjustment.
Adjust the brightness to what you
want.
Adjust the contrast between the
object and the background.
Adjust the outline of the screen to
soft or sharp.
Adjust the skin color or the screen
color to natural.
Adjust the Hue of the screen to light
or dark.

Fundamental (Setting)
2625
ENTER
MENU
MENU
ENTER
• Press [MENU] button to display the
menu.
• The currently set screen mode is
displayed at the top of the menu. (PC)
Adjusting video (PC mode)
ItcanbesetatthePCmodeonly.
Adjust it only when 30 minutes or longer elapses after turning on the monitor.
Press [MENU] button.
Selecting ContrastSelecting Brightness
POWER ON POWER OFF
AUTO STILL SLEEP
UP
DOWN
Left Right
F6
ASPECT F1 F2 PROG
MENU
ESC
DISPLAY
MODE
INPUT SELECT
F3
INPUT A INPUT B
INPUT C INPUT D
ENTER
AB
CD
F4
F5
PDP
REMOTE CONTROL
84PDP
• Press or button to select the desired item.
• Whenever you press or button, it proceeds to Brightness Contrast
Fineness Video setting.
• Select the desired item, and then press [ENTER] button.
Select the desired item.
•Press or button to adjust the value to what you want.
• After completing the adjustment, press [ENTER] button.
Adjust the value to what you want.
• Press [MENU] button to exit from the menu.
• If there is no operation for 10 seconds or longer, it automatically exits from the
menu.
Finish the adjustment.
Adjust the brightness to what you
want.
Adjust the contrast between the
object and the background.
Selecting Picture ModeSelecting Sharpness
Adjust the outline of the screen to
soft or sharp.
Select User's setting and Default.

Fundamental (Setting)
2827
ENTER
ENTER
MENU
MENU
ENTER
• Press [MENU] button to display the menu.
• Press or button to select [MULTI]
menu, and then press [ENTER] button.
Splitting into multi-screen (DVD, VIDEO, PC mode)
You can display the desired screen format, and you can simultaneously display DVD, VIDEO, and PC according
to the split format of the screen. (As for PC mode, the screen menu is displayed at the menu screen.)
[DISPLAY MODE] button of the remote controller has the same function.
Press [MENU] button.
POWER ON POWER OFF
AUTO STILL SLEEP
UP
DOWN
Left Right
F6
ASPECT F1 F2 PROG
MENU
ESC
DISPLAY
MODE
INPUT SELECT
F3
INPUT A INPUT B
INPUT C INPUT D
ENTER
AB
CD
F4
F5
PDP
REMOTE CONTROL
84PDP
• Press or button to select
Display Mode.
Select ‘Display Mode.’
• Press or button to select the
desired split format. At this time,
'Select input' menu for monitor A, B, C
or D is displayed according to the
selected split format.
• You can select the input signal of
each Display Mode.
• After completing the adjustment,
press [ENTER] button.
Select the desired Display Mode.
• Press [MENU] button to exit from the menu.
• If there is no operation for 10 seconds or longer, it automatically exits from
the menu.
Finish selecting the Display Mode.
Monitor A Monitor B
Monitor C Monitor D
ENTER
ENTER
MENU
MENU
ENTER
• Press [MENU] button to display the menu.
• Press or buttontoselect
[FUNCTION] menu, and then press
[ENTER] button.
Setting Picture Mode (DVD, VIDEO mode)
You can select various screens with a professional's sense without user's adjustment.
As for PC mode, the menu screen is differently displayed.
Press [MENU] button.
POWER ON POWER OFF
AUTO STILL SLEEP
UP
DOWN
Left Right
F6
ASPECT F1 F2 PROG
MENU
ESC
DISPLAY
MODE
INPUT SELECT
F3
INPUT A INPUT B
INPUT C INPUT D
ENTER
AB
CD
F4
F5
PDP
REMOTE CONTROL
84PDP
•Press or button to select
Picture Mode.
Select ‘Picture Mode.’
•Press or button to select the
desired video setting. It proceeds to
Theater -> Outdoor-> User -> Default.
• After selecting, press [ENTER] button.
Select the desired Picture Mode.
• Press [MENU] button to exit from the menu.
• If there is no operation for 10 seconds or longer, it automatically exits from the
menu.
Finish the Picture Mode.

Fundamental (Setting)
3029
ENTER
ENTER
MENU
MENU
ENTER
• Press [MENU] button to display the menu.
• Press or buttontoselect
[FUNCTION] menu, and then press
[ENTER] button.
Adjusting Display Size (DVD, VIDEO mode)
You can enjoy a bigger screen by vertically magnifying 2.35:1 screen to 16:9 screen.
[ASPECT] button of the remote controller has the same function.
As for PC mode, the menu screen is differently displayed.
Press [MENU] button.
POWER ON POWER OFF
AUTO STILL SLEEP
UP
DOWN
Left Right
F6
ASPECT F1 F2 PROG
MENU
ESC
DISPLAY
MODE
INPUT SELECT
F3
INPUT A INPUT B
INPUT C INPUT D
ENTER
AB
CD
F4
F5
PDP
REMOTE CONTROL
84PDP
•Press or button to select
Display Size.
Select ‘Display Size.’
•Press or button to select the desired Display Size.
It proceeds to 16:9 -> 2.35:1.
16:9 : Default screen aspect.
2.35:1 : Vertically magnified mode.
• After selecting, press [ENTER] button.
Select the desired Display Size.
• Press [MENU] button to exit from the menu.
• If there is no operation for 10 seconds or longer, it automatically exits from
the menu.
Finish selecting the Display Size.
16 : 9 2.35 : 1
ENTER
ENTER
MENU
MENU
ENTER
• Press [MENU] button to display the menu.
• Press or button to select
[FUNCTION] menu, and then press
[ENTER] button.
Setting language (DVD, VIDEO mode)
You can set the language for the menu (OSD).
As for PC mode, the menu screen is differently displayed. See 31 page.
Press [MENU] button.
POWER ON POWER OFF
AUTO STILL SLEEP
UP
DOWN
Left Right
F6
ASPECT F1 F2 PROG
MENU
ESC
DISPLAY
MODE
INPUT SELECT
F3
INPUT A INPUT B
INPUT C INPUT D
ENTER
AB
CD
F4
F5
PDP
REMOTE CONTROL
84PDP
• Press or button to select
Language.
Select ‘Language.’
• Press or button to select the
desired language.
• After selecting, press [ENTER] button.
Select the desired language.
• Press [MENU] button to exit from the menu.
• If there is no operation for 10 seconds or longer, it automatically exits from
the menu.
Finish selecting the language.

Fundamental (Setting)
3231
ENTER
ENTER
MENU
MENU
ENTER
• Press [MENU] button to display the menu.
• Press or button to select
[FUNCTION] menu, and then press
[ENTER] button.
Setting language (PC mode)
You can set the language for the menu (OSD).
As for DVD or VIDEO mode, the menu screen is differently displayed. See 29 page.
Press [MENU] button.
POWER ON POWER OFF
AUTO STILL SLEEP
UP
DOWN
Left Right
F6
ASPECT F1 F2 PROG
MENU
ESC
DISPLAY
MODE
INPUT SELECT
F3
INPUT A INPUT B
INPUT C INPUT D
ENTER
AB
CD
F4
F5
PDP
REMOTE CONTROL
84PDP
• Press or button to select
Language.
Select ‘Language’.
• Press or button to select the
desired language.
• After selecting, press [ENTER] button.
Select the desired language.
• Press [MENU] button to exit from the menu.
• If there is no operation for 10 seconds or longer, it automatically exits from the
menu.
Finish selecting the language.
ENTER
ENTER
MENU
MENU
ENTER
• Press [MENU] button to display the menu.
• Press or buttontoselect
[FUNCTION] menu, and then press
[ENTER] button.
Setting Afterimage Anti Image Burn (PC mode)
It removes the afterimage which may be occurred by pausing the display for a long time.
It can be set at PC mode only.
Press [MENU] button.
POWER ON POWER OFF
AUTO STILL SLEEP
UP
DOWN
Left Right
F6
ASPECT F1 F2 PROG
MENU
ESC
DISPLAY
MODE
INPUT SELECT
F3
INPUT A INPUT B
INPUT C INPUT D
ENTER
AB
CD
F4
F5
PDP
REMOTE CONTROL
84PDP
•Press or button to select
‘Anti Image Burn.’
Select ‘Anti Image Burn.’
•Press or button to select the
desired screen effect.
It proceeds to None -> Rotated ->
Inverted -> White.
None : Disable Removing afterimage function
Rotated : Move one pixel per minute on the screen
Inverted : Using (When the Input Signal is not
connected)
White : Using (When the Input signal is connected)
• After selecting, press [ENTER] button.
Select the desired effect.
• Press [MENU] button to exit from the menu.
• If there is no operation for 10 seconds or longer, it automatically exits from the
menu.
Finish selecting the Anti Image Burn.

Fundamental (Setting)
3433
ENTER
ENTER
MENU
MENU
ENTER
• Press [MENU] button to display the menu.
• Press or button to select [Screen]
menu, and then press [ENTER] button.
Setting Auto-Tracking (PC mode)
It automatically controls the position of the PC screen displayed on the screen.
It can be set at PC mode only.
Press [MENU] button.
POWER ON POWER OFF
AUTO STILL SLEEP
UP
DOWN
Left Right
F6
ASPECT F1 F2 PROG
MENU
ESC
DISPLAY
MODE
INPUT SELECT
F3
INPUT A INPUT B
INPUT C INPUT D
ENTER
AB
CD
F4
F5
PDP
REMOTE CONTROL
84PDP
• Press or button to select
‘Auto-Tracking.’
Select ‘Auto-Tracking.’
• Press [ENTER] button. It
automatically controls the screen.
Press [ENTER] button.
• Press [MENU] button to exit from the menu.
• If there is no operation for 10 seconds or longer, it automatically exits from
the menu.
Finish setting the Auto-Tracking.
ENTER
ENTER
MENU
MENU
ENTER
• Press [MENU] button to display the
menu.
• Press or button to select [Screen]
menu, and then press [ENTER] button.
Setting screen position (PC mode)
When the PC screen is skewed or cut, you can adjust the position of the screen.
It can be set at PC mode only.
Press [MENU] button.
POWER ON POWER OFF
AUTO STILL SLEEP
UP
DOWN
Left Right
F6
ASPECT F1 F2 PROG
MENU
ESC
DISPLAY
MODE
INPUT SELECT
F3
INPUT A INPUT B
INPUT C INPUT D
ENTER
AB
CD
F4
F5
PDP
REMOTE CONTROL
84PDP
•Press or button to select
‘H-position’ or ‘V-position.’
H-Position : Adjust the left/right position of the screen
V-Position : Adjust the up/down position of the screen
Select ‘H-Position’ or ‘V-Position.’
•Press or button to adjust the
position until the screen comes to the
center.
• After adjusting, press [ENTER] button.
Press or button to adjust the position.
• Press [MENU] button to exit from the menu.
• If there is no operation for 10 seconds or longer, it automatically exits from
the menu.
Finish setting the screen position.

Fundamental (Setting)
3635
ENTER
ENTER
MENU
MENU
ENTER
• Press [MENU] button to display the
menu.
• Press or button to select [Screen]
menu, and then press [ENTER] button.
Setting frequency (PC mode)
It can be set at PC mode only.
Press [MENU] button.
POWER ON POWER OFF
AUTO STILL SLEEP
UP
DOWN
Left Right
F6
ASPECT F1 F2 PROG
MENU
ESC
DISPLAY
MODE
INPUT SELECT
F3
INPUT A INPUT B
INPUT C INPUT D
ENTER
AB
CD
F4
F5
PDP
REMOTE CONTROL
84PDP
• Press or button to select
‘Frequency.’
Select ‘Frequency.’
• Press or button to set the
desired frequency while watching on
the screen.
• After adjusting, press [ENTER] button.
Press or button to set the frequency.
• Press [MENU] button to exit from the menu.
• If there is no operation for 10 seconds or longer, it automatically exits from
the menu.
Finish setting the frequency.
ENTER
ENTER
MENU
MENU
ENTER
• Press [MENU] button to display the
menu.
• Press or button to select [Screen]
menu, and then press [ENTER] button.
Setting phase (PC mode)
It can be set at PC mode only.
Press [MENU] button.
POWER ON POWER OFF
AUTO STILL SLEEP
UP
DOWN
Left Right
F6
ASPECT F1 F2 PROG
MENU
ESC
DISPLAY
MODE
INPUT SELECT
F3
INPUT A INPUT B
INPUT C INPUT D
ENTER
AB
CD
F4
F5
PDP
REMOTE CONTROL
84PDP
•Press or button to select
‘Phase.’
Select ‘Phase.’
•Press or button to set the
desired phase while watching on the
screen.
• After setting, press [ENTER] button.
Press or button to set the phase.
• Press [MENU] button to exit from the menu.
• If there is no operation for 10 seconds or longer, it automatically exits from
the menu.
Finish setting the phase.

Hot buttons of Remote controller
3837
DISPLAY MODE button
• Whenever you press [DISPLAY MODE] button, it proceeds by the following
order.
You can select the desired split-screen format.
Hot buttons of Remote controller
Hot buttons of the remote controller help us directly setting functions without setting the menu. So, if you
are familiar with these buttons, it is convenient for you to use.
POWER ON POWER OFF
AUTO STILL SLEEP
UP
DOWN
Left Right
F6
ASPECT F1 F2 PROG
MENU
ESC
DISPLAY
MODE
INPUT SELECT
F3
INPUT A INPUT B
INPUT C INPUT D
ENTER
AB
CD
F4
F5
84PDP
DISPLAY
MODE
AAB AB A
B
AB
C
AB
CD
INPUT A, INPUT B, INPUT C, INPUT D button
• You can change the input signal of the split screen.
• Whenever you press each button, it proceeds by the following order.
DVD1(DTV1) DVD2(DTV2) PC1 PC2 VIDEO1 VIDEO2 DVD1
POWER ON POWER OFF
AUTO STILL SLEEP
UP
DOWN
Left Right
F6
ASPECT F1 F2 PROG
MENU
ESC
DISPLAY
MODE
INPUT SELECT
F3
INPUT A INPUT B
INPUT C INPUT D
ENTER
AB
CD
F4
F5
84PDP
Monitor A Monitor B
Monitor C Monitor D
INPUT A INPUT B
INPUT C INPUT D
SLEEP button
• You can set the monitor automatically turned off after a certain time span.
Whenever you press this button, it proceeds by the following order.
0min 30min 60min 90min 120min
POWER ON POWER OFF
AUTO STILL SLEEP
UP
DOWN
Left Right
F6
ASPECT F1 F2 PROG
MENU
ESC
DISPLAY
MODE
INPUT SELECT
F3
INPUT A INPUT B
INPUT C INPUT D
ENTER
AB
CD
F4
F5
84PDP
SLEEP
STILL
STILL button
• You can pause the screen such as a video.
• Whenever you press this button, 'STILL' and 'STILL disabled' are alternately
selected.
POWER ON POWER OFF
AUTO STILL SLEEP
UP
DOWN
Left Right
F6
ASPECT F1 F2 PROG
MENU
ESC
DISPLAY
MODE
INPUT SELECT
F3
INPUT A INPUT B
INPUT C INPUT D
ENTER
AB
CD
F4
F5
84PDP
16:9 2.35:1
ASPECT button
• It vertically expands the screen of DVD or VIDEO.
POWER ON POWER OFF
AUTO STILL SLEEP
UP
DOWN
Left Right
F6
ASPECT F1 F2 PROG
MENU
ESC
DISPLAY
MODE
INPUT SELECT
F3
INPUT A INPUT B
INPUT C INPUT D
ENTER
AB
CD
F4
F5
84PDP
ASPECT
AUTO
AUTO button
• It automatically adjusts the screen at the PC signal.
POWER ON POWER OFF
AUTO STILL SLEEP
UP
DOWN
Left Right
F6
ASPECT F1 F2 PROG
MENU
ESC
DISPLAY
MODE
INPUT SELECT
F3
INPUT A INPUT B
INPUT C INPUT D
ENTER
AB
CD
F4
F5
84PDP
