OSEE 6800N-C2 User manual

6800N-C2 Frame
USER MANUAL

Product Information
Model: 6800N-C2 Frame
Version: V010000
Release Date: July 11th, 2008
Company
OSEE TECHNOLOGY CO., LTD.
Contact Information
Address: No.22 Building, No.68 zone, Beiqing Road, Haidian District,
Beijing, China
Post Code: 100094
Tel: [phone]
Fax: [phone]
Web: http://www.osee-dig.com/
E-mail: [email protected]

Contents
Chapter 1 Introduction.......................................................................................... 4
Features.............................................................................................................................................. 4
Chapter 2 Operation and Installation.................................................................... 5
2.1 Front Panel................................................................................................................................... 5
2.2 Rear Panel.................................................................................................................................... 5
2.3 Front Panal Operation.................................................................................................................. 6
1 Disassembly............................................................................................................................ 6
2 Assembly................................................................................................................................. 6
2.4 LED indicators............................................................................................................................. 6
Chapter 3 Specifications....................................................................................... 7
Reference Signal................................................................................................................................ 7
Power Supply Parameters .................................................................................................................. 7

6800N-C2 Frame - 4 -
6800N-C2 Frame
Chapter 1 Introduction
The 6800-C2 can house up any combination of modules out of 6800N Series modules osee company has
produced. Specially designed power supply unit ensures the high reliability of the system. Meanwhile
the redundant power supply is also available. 6800N series board can process video and audio signals,
and the process include A/D conversion, signal distribution, audio embedding and de-embedding, status
detection and etc.
The special design of cooling system on the front panel provides better cooling effect for system when
running in full load and in long-term operation. The airflow is directed from the front to the other side of
the frame to prevent a higher temperature of the system.
The frame include four cooling fans by air convection, two power supplies which have wide range of
voltage, a control board, and several connectors which are composed of genlock, com and Ethernet and
RS232.
Features
2RU standard chassis
Up to 20 single-slot modules or 10 dual-slot modules can be housed in the units
Front panel cooling system for increased ventilation
Redundant power supply with fail indication LED on front panel
The compact design of 6800-C2 also offers easy installation of 6800N series modules
FCC Caution:
Any Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:

6800N-C2 Frame - 5 -
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Chapter 2 Operation and Installation
2.1 Front Panel
1 2 3 4 5 1
Figure 2-1 the Front Panel of 6800-C2
Table 2-1 Description of every part in the front panel
Number Item Description
1 knob Used to assemble or disassemble the front panel
2 fans 4 pcs in total, used to help the frame ventilation
3 PS1 Power supply 1 indicator (green)
4 PS2 Power supply 2 indicator (green)
5 ALARM fans alarm indicator (red)
2.2 Rear Panel
1 2 1 3 4 5
Figure 2-2 the Rear Panel of 6800-C2
Table 2-2 Description of every connector in the rear panel
Number Item Description
1 PS1, PS2 Master and backup AC power supply connectors

6800N-C2 Frame - 6 -
Number Item Description
2 GNLCK reference signal input and loop
3 RS232 Standard RS232
4 ETHERNET RJ45, 100Mbps
COM Used as control connectors
2.3 Front Panel Operation
1 Disassembly
Grab the knobs, push them toward the direction between the two knobs, and pull the front panel, then,
you can realize the disassembly.
Figure 2-3 Disassembly of the front panel
2 Assembly
Grab the knobs, push them toward the direction between the two knobs, and push the front panel, then,
you can realize the assembly.
Figure 2-4 Assembly of the front panel
2.4 LED indicators
Table 2-3 Description of LED indicators in the front panel
Item Description
PS1 On: Power supply 1 is used
Off: Power supply 1 is not used
PS2 On: Power supply 2 is used
Off: Power supply 2 is not used
Alarm On: one or more fans have problems.
Off: all four fans work normally.

6800N-C2 Frame - 7 -
Chapter 3 Specifications
Reference Signal
Table 3-1 Specification of reference signal
Item Specification
Signal Format Analog color bar or analog black burst
Connector BNC (IEC169-8)
Impedance 75Ω
Input level 0.5 to 2 V
Power Supply Parameters
Table 3-2 Power Supply Parameters
Item Parameter
Voltage 100-240V（±10%）AC
Current >1.2A
Frequency 50-60Hz
Note: Specifications are subject to change without notice
