Oxbox J951x u series User manual

J951X*D (95.0% AFUE)

Downﬂow Furnace

95.0% AFUESingle Stage Condensing Gas Furnaces

J951X*U (95.0% AFUE)

Upﬂow / Horizontal Furnace

INSTALLATION INSTRUCTIONS

WARNING

FIRE OR EXPLOSION HAZARD

• Failure to follow safety warnings exactly could result in serious injury, death or property

damage.

• Installation and service must be performed by a qualiﬁed installer, service agency or the gas

supplier.

• Do not store or use gasoline or other ﬂammable vapors and liquids in the vicinity of this or

any other appliance.

WHAT TO DO IF YOU SMELL GAS

• Do not try to light any appliance.

• Do not touch any electrical switch; do not use any phone in your building.

• Leave the building immediately.

• Immediately call your gas supplier from a neighbors phone. Follow the gas suppliers instructions.

• If you cannot reach your gas supplier, call the ﬁre department.

DO NOT DESTROY. PLEASE READ CAREFULLY & KEEP IN A SAFE PLACE FOR FUTURE REFERENCE.

TABLE OF CONTENTS

IMPORTANT SAFETY INFORMATION.............................. 3

REQUIREMENTS & CODES .............................................. 3

Combustion Air Quality..................................................... 4

Heating Load.................................................................... 5

Installation in a Garage .................................................... 5

Clearances to Combustible Materials............................... 5

Operation of Furnace During Construction....................... 5

COMBUSTION AIR & VENTING REQUIREMENTS .......... 6

Direct Vent Furnaces........................................................ 7

Conventional Vent Systems - Conﬁned Spaces............... 7

Air From Inside............................................................. 7

Outdoor Air from a Crawl Space or Vented Attic.......... 8

Outdoor Air Using Vertical Ducts.................................. 8

Outdoor Air Using Horizontal Ducts ............................. 8

Air Directly Through An Exterior Wall........................... 9

Alternate Method of Providing Air from Outside ........... 9

Conventional Vent Systems - Unconﬁned Spaces........... 9

Category IV Venting ......................................................... 9

Vent Pipe Material........................................................ 10

Vent Pipe Length & Diameter....................................... 10

Vent Pipe Installation.................................................... 10

Outdoor Terminations - Horizontal Venting .................. 11

Outdoor Terminations - Vertical Venting ...................... 12

Vent Freezing Protection.............................................. 12

Existing Installations..................................................... 12

Condensate Disposal ....................................................... 12

CIRCULATING AIR REQUIREMENTS............................... 13

Plenums & Air Ducts ........................................................ 13

Return Air Connections .................................................... 13

Upﬂow & Horizontal Furnaces...................................... 13

Downﬂow Furnaces...................................................... 14

Supply Air Connections.................................................... 14

Acoustical Treatments...................................................... 14

FURNACE INSTALLATION................................................ 14

General Requirements ..................................................... 14

Upﬂow Furnaces .............................................................. 14

Horizontal Furnaces ......................................................... 14

Downﬂow Furnaces.......................................................... 15

Installation on a Concrete Slab .................................... 15

Inducer & Venting Options ............................................... 15

Inducer Assembly Rotation .......................................... 16

Pressure Switch Tubing ............................................... 16

Alternate Pressure Switch Location ............................. 17

Accessories...................................................................... 17

Finish Flange................................................................ 17

Rubber Grommets........................................................ 17

PVC Components......................................................... 18

Typical Orientation................................................... 18

Alternate Orientation................................................ 18

Optional PVC Pipe Installation ..................................... 18

Condensate Drain Lines............................................... 18

Bottom Panel Removal..................................................... 19

Alternate Bottom Panel Removal ..................................... 19

GAS SUPPLY & PIPING..................................................... 20

Leak Check ...................................................................... 20

High Altitude Application (Natural Gas Only) ................... 20

Converting from Natural Gas to LP / Propane.................. 22

ELECTRICAL WIRING ....................................................... 23

Line Voltage Wiring .......................................................... 23

Grounding......................................................................... 23

Thermostat / Low Voltage Connections ........................... 24

Twinning........................................................................... 24

One stage heating........................................................ 24

Two stage heating........................................................ 25

Heat Anticipator................................................................ 25

START-UP & ADJUSTMENTS........................................... 25

Pre-Start Check List ......................................................... 25

Start-up Procedures ......................................................... 25

Verifying & Adjusting Input Rate....................................... 25

Verifying & Adjusting Temperature Rise .......................... 26

Verifying Burner Operation............................................... 26

Verifying Operation of the Supply Air Limit Switch ........... 26

System Operation............................................................. 26

(Gas) Heating Mode..................................................... 26

Cooling Mode ............................................................... 26

Manual Fan .................................................................. 26

Fault Conditions ............................................................... 27

OPERATING SEQUENCE.................................................. 27

Heating Cycle................................................................... 27

Cooling Cycle ................................................................... 27

Fan Mode ......................................................................... 27

MAINTENANCE.................................................................. 27

FIGURES & TABLES.......................................................... 29

Figure 29. J951X*U Cabinet Dimensions..................... 29

Figure 30. J951X*D Cabinet Dimensions..................... 29

Figure 31. Wiring Diagram ........................................... 30

Figure 32. Ladder Diagram .......................................... 31

Table 6. Gas Flow Rates.............................................. 32

Table 7. Gas Pipe Capacities....................................... 32

Table 8. High Altitude Deration – Propane Gas ........... 33

Table 9. Natural Gas Heating Values........................... 33

Table 10. High Altitude Deration – Natural Gas with

HIGH Heating Value .................................... 34

Table 11. High Altitude Deration – Natural Gas with

LOW Heating Value ..................................... 34

Table 12. Vent Termination Clearances....................... 35

Figure 33. Horizontal & Vertical Venting ...................... 36

Figure 34. Venting Options for Upﬂow Installations

(J951X*U Series) ........................................ 37

Figure 35. Venting Options for Horizontal Installations

(J951X*U Series) ........................................ 38

Figure 36. Venting Options for Downﬂow Installations

(J951X*D Series) ........................................ 39

TROUBLESHOOTING........................................................ 40

Table 13. Control Board Fault Conditions .................... 40

FURNACE COMPONENTS ................................................ 40

Table 14. Motor Control Board Fault Conditions .......... 40

Figure 37. J951X*U Component Locations.................. 41

Figure 38. J951X*D Component Locations.................. 41

INSTALLATION CHECKLIST............................................. 44

IMPORTANT SAFETY INFORMATION

INSTALLER: Please read all instructions before servicing

this equipment. Pay attention to all safety warnings and

any other special notes highlighted in the manual. Safety

markings are used frequently throughout this manual to

designate a degree or level of seriousness and should not

be ignored. WARNING - Indicates a potentially hazardous

situation that if not avoided, could result in personal injury or

death.CAUTION - Indicates a potentially hazardous situation

that if not avoided, may result in minor or moderate injury or

property damage.

WARNING:

The safety information listed in this manual must

be followed during the installation, service, and

operation of this unit. Unqualiﬁed individuals

should not attempt to interpret these instructions

or install this equipment. Failure to follow safety

recommendations could result in possible

damage to the equipment, serious personal

injury or death.

WARNING:

Improper installation, service, adjustment, or

maintenance may cause explosion, ﬁre, electrical

shock or other hazardous conditions which may

result in personal injury or property damage.

Unless otherwise noted in these instructions,

only factory authorized kits or accessories may

be used with this product.

WARNING:

Do not install this furnace if any part has been

submerged underwater. A ﬂooddamaged furnace

is extremely dangerous. Attempts to use the

furnace may result in ﬁre or explosion. A qualiﬁed

service agency should be contacted to inspect the

furnace and to replace any electrical or control

system parts that have been wet or under water.

• To minimize equipment failure or personal injury, it is

essential that only qualiﬁed individuals install, service, or

maintain this equipment. If you do not posses mechanical

skills or tools, call your local dealer for assistance.

• Follow all precautions in the literature, on tags, and on

labels provided with the equipment. Read and thoroughly

understand the instructions provided with the equipment

prior to performing the installation and operational

checkout of the equipment.

• Use caution when handling this appliance or removing

components. Personal injury can occur from sharp metal

edges present in all sheet metal constructed equipment.

• Do not store any of the following on, or in contact with,

the unit: Rags, brooms, vacuum cleaners, or other

cleaning tools, spray or aerosol cans, soap powders,

bleaches, waxes, cleaning compounds, plastics or plastic

containers, paper bags or other paper products, gasoline,

kerosene, cigarette lighter ﬂuid, dry cleaning ﬂuids, paint

thinners, or other volatile ﬂuids.

• The installer should become familiar with the units wiring

diagram before making any electrical connections to the

unit. See Figure 32 (page 31), Figure 33 (page 36) or

the unit wiring label.

• Always reinstall the doors on the furnace after

servicing. Do not operate the furnace without all doors

and covers in place.

REQUIREMENTS & CODES

WARNING:

The information listed below must be followed

during the installation, service, and operation

of this furnace. Failure to follow safety

recommendations could result in possible

damage to the equipment, serious personal

injury or death.

• This furnace must be installed in accordance with these

instructions, all applicable local building codes and the

current revision of the National Fuel Gas Code (NFPA54/

ANSI Z223.1) or the Natural Gas and Propane Installation

Code, CAN/CSA B149.1.

• Use only with type of gas approved for this furnace. Refer

to the furnace rating plate.

• Install this furnace only in a location and position as

speciﬁed on page 5.

• Provide adequate combustion and ventilation air to the

furnace space as speciﬁed on page 6,page 7,

page 8 & page 9.

• Provide adequate clearances around the vent air intake

terminal as shown in Figure 7 (page 11), Figure 8 (page

11), Figure 9 (page 12), & Figure 10 (page 12).

• Combustion products must be discharged outdoors.

Connect this furnace to an approved vent system only,

as speciﬁed on page 9, page 10, page 11, & page

12.

• Never test for gas leaks with an open ﬂame. Use

a commercially available soap solution to check all

connections. See page 20.

• This furnace is designed to operate with a maximum

external pressure rise of 0.5 inches of water column.

Consult the rating plate for the proper circulating air ﬂow

and temperature rise. It is important that the duct system

be designed to provide the correct ﬂow rates and external

pressure rise. An improperly designed duct system can

result in nuisance shutdowns, and comfort or noise

issues.

• When supply ducts carry air circulated by the furnace

to areas outside the space containing the furnace, the

return air shall also be handled by duct(s) sealed to the

furnace casing and terminating in the conditioned space.

See page 13 .

• A gas-ﬁred furnace for installation in a residential garage

must be installed as speciﬁed on page 5.

• This furnace is not approved for installation in mobile

homes. Installing this furnace in a mobile home could

cause ﬁre, property damage, and/or personal injury.

• The Commonwealth of Massachusetts requires

compliance with regulation 248 CMR 4.00 and 5.00 for

installation of through – the – wall vented gas appliances

as follows:

1. For direct-vent appliances, mechanical-vent heating

appliances or domestic hot water equipment, where the

bottom of the vent terminal and the air intake is installed

below four feet above grade the following requirements

must be satisﬁed:

a.) A carbon monoxide (CO) detector and alarm shall be

placed on each ﬂoor level where there are bedrooms.

The detector shall comply with NFPA 720 (2005

Edition) and be mounted in the living area outside

the bedroom(s).

b.) A (CO) detector shall be located in the room that

houses the appliance or equipment and shall:

• Be powered by the same electrical circuit as the

appliance or equipment. Only one service switch

shall power the appliance and the (CO) detector;

• Have battery back-up power;

• Meet ANSI/UL 2034 Standards and comply with

NFPA 720 (2005 Edition); and Approved and listed

by a Nationally Recognized Testing Laboratory as

recognized under 527 CMR.

c.) A Product-approved vent terminal must be used,

and if applicable, a product-approved air intake must

be used. Installation shall be in strict compliance

with the manufacturer’s instructions. A copy of the

installation instructions shall remain with the appliance

or equipment at the completion of the installation.

d.) A metal or plastic identiﬁcation plate shall be mounted

at the exterior of the building, four feet directly above

the location of vent terminal. The plate shall be of

sufﬁcient size, easily read from a distance of eight

feet away, and read “Gas Vent Directly Below”.

2. For direct-vent appliances, mechanical-vent heating

appliances or domestic hot water equipment where the

bottom of the vent terminal and the air intake is installed

above four feet above grade the following requirements

must be satisﬁed:

a.) A (CO) detector and alarm shall be placed on each

ﬂoor level where there are bedrooms. The detector

shall comply with NFPA 720 (2005 Edition) and be

mounted in the living area outside the bedroom(s).

b.) The (CO) detector shall:

• Be located in the room that houses the appliance

or equipment;

• Be hard-wired or battery powered or both.

• Shall comply with NFPA 720 (2005 Edition).

c.) A product-approved vent terminal must be used,

and if applicable, a product-approved air intake must

be used. Installation shall be in strict compliance

with the manufacturer’s instructions. A copy of the

installation instructions shall remain with the appliance

or equipment at the completion of the installation.

The information listed below is for reference purposes only

and does not necessarily have jurisdiction over local or state

codes. Always consult with local authorities before installing

any gas appliance.

Combustion & Ventilation Air

• US: National Fuel Gas Code (NFGC), Air for Combustion and

Ventilation

• CANADA: Natural Gas and Propane Installation Codes

(NSCNGPIC), Venting Systems and Air Supply for Appliances

Duct Systems

• US and CANADA: Air Conditioning Contractors Association

(ACCA) Manual D, Sheet Metal and Air Conditioning

Contractors National Association (SMACNA), or American

Society of Heating, Refrigeration, and Air Conditioning

Engineers (ASHRAE) Fundamentals Handbook

Electrical Connections

• US: National Electrical Code (NEC) ANSI/NFPA 70

• CANADA: Canadian Electrical Code CSA C22.1

Gas Piping & Gas Pipe Pressure Testing

• US: NFGC and National Plumbing Codes

• CANADA: NSCNGPIC

General Installation

• US: Current edition of the NFGC and the NFPA 90B. For

copies, contact the National Fire Protection Association Inc.,

Batterymarch Park, Quincy, MA 02269; or American Gas

Association, 400 N. Capitol, N.W., Washington DC 20001 or

www.NFPA.org

• CANADA: NSCNGPIC. For a copy, contact Standard Sales,

CSA International, 178 Rexdale Boulevard, Etobicoke

(Toronto), Ontario, M9W 1R3 Canada

Safety

• US: (NFGC) NFPA 54–1999/ANSI Z223.1 and the Installation

Standards, Warm Air Heating and Air Conditioning Systems

ANSI/NFPA 90B.

• CANADA: CAN/CSA-B149.1 and .2–M00 National Standard

of Canada. (NSCNGPIC)

Combustion Air Quality

CAUTION:

Combustion air must not be drawn from a

corrosive atmosphere.

To maximize heat exchanger life, the combustion air must be

free of chemicals that can form corrosive acidic compounds

in the combustion gases. The recommended source of

combustion air is to use outdoor air. However, the use of

indoor air in most applications is acceptable except as listed:

• If the furnace is installed as a single pipe installation

in a conﬁned space, it is required that the necessary

combustion air come from the outdoors by way of attic,

crawl space, air duct, or direct opening. For Installations

in conﬁned spaces, see page 7 for combustion air

requirements.

• Installations in these locations may require outdoor air for

combustion, due to chemical exposures:

Commercial buildings

Buildings with indoor pools

Furnaces installed in laundry rooms

Furnaces installed in hobby or craft rooms

Furnaces installed near chemical storage areas

• Exposure to the following substances in the combustion

air supply may require outdoor air for combustion:

Permanent wave solutions

Chlorinated waxes and cleaners

Chlorine based swimming pool chemicals

Water softening chemicals

De-icing salts or chemicals

Carbon Tetrachloride

Halogen type refrigerants

Cleaning solvents (perchloroethylene)

Printing inks, paint removers, varnishes, etc.

Hydrochloric Acid

Cements and glues

Antistatic fabric softeners

Masonry acid washing materials

Heating Load

This furnace should be sized to provide the design heating

load requirement. Heating load estimates can be made

using approved methods available from Air Conditioning

Contractors of America (Manual J); American Society of

Heating, Refrigerating, and Air Conditioning Engineers; or

other approved engineering methods. Excessive oversizing

of the furnace could cause the furnace and/or vent to

fail prematurely.

The ductwork should be appropriately sized to the capacity of

the furnace to ensure its proper airﬂow rating. For installations

above 2,000 ft., the furnace should have a sea level input

rating large enough that it will meet the heating load after

deration for altitude.

Installation in a Garage

WARNING:

Do not place combustible material on or against

the furnace cabinet or within 6 inches of the

vent pipe. Do not place combustible materials,

including gasoline or any other ﬂammable vapors

and liquids, in the vicinity of the furnace.

This gas-ﬁred furnace may be installed in a residential garage

with the provision that the burners and igniter are located no

less than 18 inches (457mm) above the ﬂoor. The furnace

must be located or protected to prevent physical damage

by vehicles.

Clearances to Combustible Materials

This furnace is Design Certiﬁed in the U.S. and Canada

by CSA International or Underwriter’s Laboratories for the

minimum clearances to combustible materials. NOTE:

The furnace is listed for installation on combustible or non-

combustible ﬂooring. However, wood is the only combustible

ﬂooring allowed for installation. Downﬂow models must use

the appropriate subase kit when installing over a wood ﬂoor.

To obtain model number and speciﬁc clearance information,

refer to the furnace rating plate, located inside of the furnace

cabinet.

Access for positioning and servicing the unit must be

considered when locating unit. The need to provide clearance

for access to panels or doors may require clearance distances

over and above the requirements. Allow 24 inches minimum

clearance from the front of the unit. However 36 inches

is strongly recommended. See Figure 1 for minimum

clearance requirements.

Operation of Furnace During Construction

CAUTION:

Failure to follow these instructions will void the

factory warranty and may signiﬁcantly reduce

the life or the performance of the furnace, and/

or result in other unsafe conditions. It is the

responsibility of the installing contractor to insure

these provisions are met.

Operating gas furnaces in construction environments can

cause a variety of problems with the furnace. Proper use

of commercial portable space heating equipment during

construction is recommended. This gas furnace may be

used during construction if it is not in violation of any

applicable codes and the following criteria are met:

• The installation must meet all applicable codes. The furnace

must be permanently installed according to the instructions

supplied with the furnace. This includes the electrical supply,

gas piping, duct work, and venting. The furnace must be

controlled by a room thermostat properly installed according

to the instructions supplied with the furnace and thermostat.

The installation must include a properly installed air ﬁlter in

the return air duct, sealed to the furnace with no by-pass air.

The ﬁlter must be inspected frequently and replaced when

necessary.

• The furnace input rate and air temperature rise must be

checked and veriﬁed to be within the acceptable ranges as

marked on the furnace nameplate.

• Before occupying the structure: The air ﬁlter must be replaced

or cleaned, the duct work must be inspected and cleaned of

any construction debris, and the furnace must be cleaned and/

or repaired if found to be dirty, damaged, or malfunctioning in

any way by a qualiﬁed HVAC technician. The furnace shall

be inspected and approved by applicable local authority even

if this requires redundant inspections.

• Serial numbers for furnaces used during construction must

be submitted in writing (fax and email also acceptable). This

information will be used to track the long-term affects of the

use during construction on furnaces. Proof of this submittal

CLEARANCES TO COMBUSTIBLE MATERIALS

Left Side..................0 Inches To p ..........................0 Inches

Right Side ...............0 Inches Front ......................

†

4 Inches

Vent.........................0 Inches Back........................0 Inches

†Allow 24 in. minimum clearance for servicing. Recommended clearance

is 36 in.

Figure 1. Minimum Clearances to

Combustible Materials

TOP

FRONT

UPFLOW

APPLICATIONS

HORIZONTAL

APPLICATIONS

VENT

TOP

FRONT

DOWNFLOW

APPLICATIONS

SIDE

TOP

BOTTOM

VENT

FRONT

BACK BACK

SIDE

LEFT SIDE

RIGHT SIDE

shall be available for the ﬁnal inspection of the furnace prior

to occupancy.

• This furnace is designed to operate with return air temperatures

in ranges normally found in occupied residences, including

setbacks. Minimum continuous return temperature must not

be below 60° F (15° C). Occasionally a temporary return

temperature of 55° F (12° C) is acceptable. However, operation

with a return temperature below 55° F (12° C) is not allowed.

• The installing contractor and / or builder must:

— Comply with the requirements of this section.

— Complete the attached Use of Furnace During

Construction checklist.

— Email copy of completed Use of Furnace During

Construction checklist to [email protected]

— Leave original completed Use of Furnace During

Construction checklist with furnace.

— Disclose use of the furnace during construction to the

homeowner in advance of the sale.

COMBUSTION AIR & VENTING

REQUIREMENTS

WARNING:

CARBON MONOXIDE POISONING HAZARD

Failure to follow the steps outlined below

for each appliance connected to the venting

system being placed into operation could

result in carbon monoxide poisoning or death.

The following steps shall be followed with

each individual appliance connected to the

venting system being placed in operation,

while all other appliances connected to the

venting system are not in operation:

1.Seal any unused openings in the venting

system.

2.Inspect the venting system for proper size and

horizontal pitch, as required in the National Fuel

Gas Code, ANSI Z223.1/NFPA 54 or the CSA

B149.1, Natural Gas and Propane Installation

Codes and these instructions. Determine that

there is no blockage or restriction, leakage,

corrosion and other deﬁciencies which could

cause an unsafe condition.

3.As far as practical, close all building doors

and windows and all doors between the space

in which the appliance(s) connected to the

venting system are located and other spaces

of the building.

4.Close ﬁreplace dampers.

5.Turn on clothes dryers and any appliance

not connected to the venting system. Turn on

any exhaust fans, such as range hoods and

bathroom exhausts, so they are operating at

maximum speed. Do not operate a summer

exhaust fan.

6.Follow the lighting instructions. Place the

appliance being inspected into operation.

Adjust the thermostat so appliance is operating

continuously.

7.Test for spillage from draft hood equipped

appliances at the draft hood relief opening

after 5 minutes of main burner operation. Use

the ﬂame of a match or candle.

8.If improper venting is observed during any of

the above tests, the venting system must be

corrected in accordance with the National Fuel

Gas Code, ANSI Z223.1/NFPA 54 and/or CSA

B149.1, Natural Gas and Propane Installation

Codes.

9.After it has been determined that each

appliance connected to the venting system

properly vents when tested as outlined above,

return doors, windows, exhaust fans, ﬁreplace

dampers and any other gas-ﬁred burning

appliance to their previous conditions of use.

IMPORTANT INFORMATION:

• This furnace must be vented in compliance with

the current revision of the National Fuel Gas Code

(ANSI-Z223.1/NFPA54). Instructions for determining the

adequacy of an installation can be found in the current

revision of the NFGC (ANSI Z223.1 / NFPA54). Refer

to the NFGC for approved vent tables. Consult local

codes for special requirements. These requirements

are for US installations as found in the NFGC.

• Furnace installation using methods other than those

described in the following sections must comply with

the National Fuel Gas Code (NFGC) and all applicable

local codes.

• Requirements in Canada (B149.1) are structured

differently. In Canada, venting shall conform to

the requirements of the current (CAN/CSA B149.1)

installation codes. Consult local codes for special

requirements.

• Provisions must be made during the installation of

this furnace that provide an adequate supply of air

for combustion. The combustion air from the outside

needs to be clear of chemicals that can cause corrosion.

The inlet pipe should not be placed near corrosive

chemicals such as those listed on page 5.

WARNING:

Upon completion of the furnace installation,

carefully inspect the entire ﬂue system both

inside and outside the furnace to assure it is

properly sealed. Leaks in the ﬂue system can

result in serious personal injury or death due

to exposure of ﬂue products, including carbon

monoxide.

WARNING:

This furnace must not be vented with other

appliances, even if that appliance is of the

condensing type. Common venting can result

in severe corrosion of other appliances or their

venting and can allow combustion gases to

escape through such appliances or vents. Do

not vent the furnace to a ﬁreplace chimney or

building chase.

This condensing furnace is certiﬁed for installation either as

a Direct Vent (2-pipe) or Conventional (1-pipe) appliance.

Direct Vent appliances draw combustion air from the outdoors

and vent combustion products back outside. Installation

with air taken from around the furnace is often referred to

as Conventional installation - i.e. only the vent (exhaust)

pipe is provided.

Another important consideration when selecting one or

two pipe installation is the quality of the Indoor air which

can sometimes be contaminated with various household

chemicals . These chemicals can cause severe corrosion

in the furnace combustion system. A 2-pipe installation has

the additional advantage that it isolates the system from the

effects of negative pressure in the house.

CAUTION:

Exhaust fans, clothes dryers, ﬁreplaces and

other appliances that force air from the house

to the outdoors can create a negative pressure

inside the house, resulting in improper furnace

operation or unsafe conditions such as ﬂame roll

out. It is imperative that sufﬁcient air exchange

with the outdoors is provided to prevent

depressurization. Additional information about

how to test for negative pressure problems can

be found in the NFGC.

Air openings on top of the furnace and openings in closet

doors or walls must never be restricted. If the furnace is

operated without adequate air for combustion, the ﬂame roll-

out switch will open, turning off the gas supply to the burners.

IMPORTANT NOTE

This safety device is a manually reset switch. DO NOT

install jumper wires across these switches to defeat

their function or reset a switch without identifying

and correcting the fault condition. If a switch must be

replaced, use only the correct sized part speciﬁed in the

Replacement Parts List provided online.

Direct Vent Furnaces

Direct Vent (2-pipe) furnaces draw combustion air directly from

the outdoors and then vent the combustion products back

outside, isolating the entire system from the indoor space.

It is important to make sure that the whole system is sealed

and clearances to combustibles are maintained regardless

of the installation being in a conﬁned or unconﬁned space.

Conventional Vent Systems - Conﬁned Spaces

A conﬁned space is an area with volume less than 50 cubic feet

per 1,000 Btuh of the combined input rates of all appliances

drawing combustion air from that space. Furnace closets,

small equipment rooms and garages are conﬁned spaces.

Furnaces installed in a conﬁned space which supply heated

air to areas outside the space must draw return air from

outside the space and must have the return air ducts tightly

sealed to the furnace. Ducts must have cross - sectional

area at least as large as the free area of their respective

openings to the furnace space. Attics or crawl spaces must

connect freely with the outdoors if they are the source of air

for combustion and ventilation.

The required sizing of these openings is determined by

whether inside or outside air is used to support combustion,

the method by which the air is brought to the space, and by

the total input rate of all appliances in the space. In all cases,

the minimum dimension of any combustion air opening is

3 inches.

Air From Inside

If combustion air is taken from the heated space, the two

openings must each have a free area of at least one square

inch per 1,000 Btuh of total input of all appliances in the

conﬁned space, but not less than 100 square inches of free

area. See Example and Figure 2.

EXAMPLE

If the combined input rate of all appliances is less than or

equal to 100,000 Btuh, each opening must have a free

area of at least 100 in2. If the combined input rate of all

appliances is 120,000 Btuh, each opening must have a

free area of at least 120 in2.

TOTAL INPUT

RATING (BTUH)

MINIMUM FREE AREA

(EACH OPENING)

ROUND DUCT

DIAMETER

40,000 100 sq. In 12 inches

60,000 100 sq. In 12 inches

80,000 100 sq. In 12 inches

100,000 100 sq. In 12 inches

120,000 120 sq. In 13 inches

140,000 140 sq. In 14 inches

160,000 160 sq. In 15 inches

Figure 2. Combustion Air Drawn from Inside

Vent or

Chimney

Furnace

Water

Heater

12” Max.

See

Notes

See

Notes

NOTES:

Each opening must be

at least 100 sq. in. or

1 sq. in. per 1,000 Btuh

of total input rating,

whichever is greater.

Openings must start at

no more than 12 inches

from the top and bottom

of the enclosure.

Figure 3. Combustion Air Drawn from Outside

Through Vertical Ducts

TOTAL INPUT

RATING (BTUH)

MINIMUM FREE AREA

(EACH OPENING)

ROUND DUCT

DIAMETER

40,000 10 sq. In 4 inches

60,000 15 sq. In 5 inches

80,000 20 sq. In 5 inches

100,000 25 sq. In 6 inches

120,000 30 sq. In 6 inches

140,000 35 sq. In 7 inches

160,000 40 sq. In 8 inches

Air Duct must be

at least 1 sq. in.

per 4,000 Btuh of

total input rating.

Ducts must

extend above

attic insulation.

Air Duct must be

at least 1 sq. in.

per 4,000 Btuh of

total input rating.

Ventilation Louvers

at each end of attic

Attic

Insulation

12" Max

Furnace

Water

Heater

Vent or

Chimney

Water

Heater

Vent or

Chimney

Furnace

Ventilation Louvers For

Unheated Crawl Space

Inlet Air

Ventilation Louvers

(each end of attic)

NOTE: Air openings shall

each have a free area of

not less than one square

inch per 4,000 Btuh of the

total input rating of all

equipment in the enclosure

Alter

nate

Air Inlet

Outlet

Air

Figure 4. Combustion Air Drawn from a Crawl

Space or Vented Attic

Figure 5. Combustion Air Drawn from Outside

Through Horizontal Ducts

TOTAL INPUT

RATING (BTUH)

MINIMUM FREE AREA

(EACH OPENING)

ROUND DUCT

DIAMETER

40,000 20 sq. In 5 inches

60,000 30 sq. In 6 inches

80,000 40 sq. In 7 inches

100,000 50 sq. In 8 inches

120,000 60 sq. In 9 inches

140,000 70 sq. In 10 inches

160,000 80 sq. In 10 inches

Furnace

Water

Heater

Air Ducts must be

at least 1 sq. in.

per 2,000 Btuh of

total input rating.

Vent or

Chimney

Air Duct

Outdoor Air from a Crawl Space or Vented Attic

When the openings can freely exchange air with the outdoors,

each opening shall have a minimum free area of 1 square

inch per 4,000 Btuh of total appliance input. The openings

shall exchange directly, or by ducts, with the outdoor spaces

(crawl or attic) that freely exchange with the outdoors. See

Figure 3 (page 8).

Outdoor Air Using Vertical Ducts

If combustion air is taken from outdoors through vertical

ducts, the openings and ducts must have a minimum free

area of one square inch per 4,000 Btuh of total appliance

input. See Figure 4 (page 8).

Outdoor Air Using Horizontal Ducts

If combustion air is taken from outdoors through horizontal

ducts, the openings and ducts must have a minimum free

area of one square inch per 2,000 Btuh of total appliance

input. Ducts must have cross - sectional area at least as

large as the free area of their respective openings to the

furnace space. See Figure 5.

Air Directly Through An Exterior Wall

If combustion air is provided directly through an exterior

wall, the two openings must each have free area of at least

one square inch per 4,000 Btuh of total appliance input.

See Figure 6.

TOTAL INPUT

RATING (BTUH)

MINIMUM FREE AREA

(EACH OPENING)

ROUND DUCT

DIAMETER

40,000 10 sq. In 4 inches

60,000 15 sq. In 5 inches

80,000 20 sq. In 5 inches

100,000 25 sq. In 6 inches

120,000 30 sq. In 6 inches

140,000 35 sq. In 7 inches

160,000 40 sq. In 8 inches

Figure 6. Combustion Air Drawn from Outside

Through an Exterior Wall

NOTE:

Each opening to outside

must be at least 1 sq. in. per

4,000 Btuh of total input rating.

12" Max.

Furnace

Water

Heater

Vent or

Chimney

12"

Max

See

Note

See

Note

Alternate Method of Providing Air from Outside

If acceptable under local Codes, it is permitted to provide

outside air using one opening (See NFGC). Generally,

conﬁned spaces must have two openings in the space for

combustion air. One opening must be within 12 inches of

the ceiling, and the other must be within 12 inches of the

ﬂoor. However, an alternative method recently adopted by

the NFGC uses one opening within 12 inches of the top of

the space. This method may be used if it is acceptable to

the local codes.

THE FOLLOWING CONDITIONS MUST BE MET:

1. The opening must start within 12” of the top of the structure

and connect with the out of doors through vertical or

horizontal ducts or be ducted to a crawl or attic space that

connects with the out of doors.

2. The opening must have a minimum free area of 1 sq.

in. per 3,000 Btu per hour of the total input rating of all

equipment located in the enclosure.

3. The free area must not be less than the sum of all the

areas of the vent connectors in the enclosure.

Conventional Vent Systems - Unconfined

Spaces

An unconﬁned space is an area including all rooms not

separated by doors with a volume greater than 50 cubic feet

per 1,000 Btuh of the combined input rates of all appliances

which draw combustion air from that space.

In general, a furnace installed in an unconﬁned space will not

require outside air for combustion. However, in homes built for

energy efﬁciency (low air change rates), it may be necessary

to provide outside air to ensure adequate combustion and

venting, even though the furnace is located in an unconﬁned

space. See Example below.

EXAMPLE

A space with a water heater rated at 45,000 Btuh input

and a furnace rated at 75,000 Btuh requires a volume of

6,000 cubic feet [50 x (45 + 75) = 6,000] to be considered

unconﬁned. If the space has an 8 foot ceiling, the ﬂoor

area of the space must be 750 sq. ft. (6,000 / 8 = 750).

Category IV Venting

WARNING:

Upon completion of the furnace installation,

carefully inspect the entire ﬂue system both

inside and outside the furnace to assure it is

properly sealed. Leaks in the ﬂue system can

result in serious personal injury or death due

to exposure of ﬂue products, including carbon

monoxide.

This furnace is classiﬁed as a “Category IV” appliance,

which requires special venting materials and installation

procedures. This section speciﬁes installation requirements

for Conventional (1-pipe) and Direct Vent (2-pipe) piping.

For 1- pipe installations, install vent piping as described in

this section and provide air for combustion and ventilation

according to page 6,page 7,page 8& page 9.

The length of vent and combustion air piping for either type

of installation are llisted in Table 1.

Category IV appliances operate with positive vent pressure

and therefore require vent systems which are thoroughly

sealed. They also produce liquid condensate, which is slightly

acidic and can cause severe corrosion of ordinary venting

materials. Furnace operation can be adversely affected by

restrictive vent and combustion air piping.

The inducer assembly on this furnace can be rotated to

vent the ﬂue products out of the top, left or right side. This

increases the ﬂexibility of which direction the vent pipe can

exit the furnace.

FURNACE

MODELS

(BTU)

FURNACE

INSTALLATION

SINGLE VENT PIPE LENGTH (FT.)

WITH 1 LONG RADIUS ELBOW†

DUAL VENT PIPE LENGTH (FT.)

WITH 1 LONG RADIUS ELBOW ON EACH PIPE†

OUTLET

2” DIAMETER

OUTLET

3” DIAMETER

INLET / OUTLET

2” DIAMETER

INLET / OUTLET

3” DIAMETER

38,000 Upﬂow 50 70 50 70

54,000 Upﬂow 70 90 70 90

Downﬂow 70 90 70 90

72,000 Upﬂow 50 90 50 90

Downﬂow 50 90 50 90

85,000 Upﬂow 60 90 60 90

90,000 Upﬂow 60 90 60 90

Downﬂow 60 90 60 90

108,000 Upﬂow N/A 90 N/A 90

115,000 Upﬂow N/A 90 N/A 90

120,000 Upﬂow N/A 90 N/A 90

†NOTES:

1.Subtract 2.5 ft. for each additional 2 inch long radius elbow, 5 ft. for each additional 2 inch short radius elbow, 3.5 ft. for each additional 3 inch long radius elbow,

and 7 ft. for each additional 3 inch short radius elbow. Subtract 5 ft for each 2” tee and 8 ft for each 3” tee.

2.Two 45 degree elbows are equivalent to one 90 degree elbow.

3.This table applies for elevations from sea level to 2,000 ft. For higher elevations, decrease pipe lengths by 8% per 1,000 ft of altitude.

4.A long radius elbow’s centerline radius is equal to or greater than 1.5 times the vent diameter.

Table 1. Vent Pipe Lengths

Vent Pipe Material

Vent and combustion air pipe and ﬁttings must be one of

the following materials in the list and must conform to the

indicated ANSI/ASTM standards.

MATERIALS STANDARDS

Schedule 40PVC ......................................................D1785

CPVC........................................................................D1784

PVC-DWV.................................................................D2665

SDR-21 & SDR-26....................................................D2241

ABS-DWV.................................................................D2661

Schedule 40 ABS .....................................................F628

Foam / Cellular Core PVC........................................F891

*PolyPro®by DuraVent .............................................ULC-S636

*When using PolyPro®, all venting and ﬁttings must be from the same

manufacturer with no interchanging of other materials. Refer to speciﬁc

instructions supplied with the PolyPro vent kits

When joining PVC to PVC, use cement that conforms to

ASTM standard D2564. PVC primer must meet standard

ASTM F656. When joining ABS to ABS, use cement that

conforms to ASTM standard D2235. When joining PVC

to ABS, use cement as speciﬁed in procedure from ASTM

standard D3138

In Canada, all plastic vent pipes and ﬁttings including any

cement, cleaners, or primers must be certiﬁed as a system

to ULC S636. However this requirement does not apply to

the ﬁnish ﬂanges or piping internal to the furnace.

Vent Pipe Length & Diameter

In order for the furnace to operate properly, the combustion

air and vent piping must not be excessively restrictive.

• The venting system should be designed to have the

minimum number of elbows or turns.

• Transition to the ﬁnal vent diameter should be done as

close to the furnace outlet as practical.

• Always use the same size or a larger pipe for combustion

air that is used for the exhaust vent.

Table 1 (page 10) indicates the maximum allowable pipe

length for a furnace of known input rate, when installed with

piping of selected diameter and number of elbows. To use

the table, the furnace input rate, the centerline length and

the number of elbows on each pipe must be known.

When estimating the length of vent runs, consideration must

be made to the effect of elbows and other ﬁttings. This is

conveniently handled using the idea of “equivalent length”.

This means the ﬁttings are assigned a linear length that

accounts for the pressure drop they will cause. For example:

a 2” diameter, long radius elbow is worth the equivalent of

2.5 feet of linear run. A 90 degree tee is worth 7 ft.

The equivalent lenghts of tees and various elbows are listed

in Table 1. Measure the linear length of your vent run and

then add in the equivalent length of each ﬁtting. The total

length, including the equivalent ﬁtting lengths, must be less

than the maximum length speciﬁed in the table.

Vent Pipe Installation

CAUTION:

Combustion air must not be drawn from a

corrosive atmosphere.

This furnace has been certiﬁed for installation with zero

clearance between vent piping and combustible surfaces.

However, it is good practice to allow space for convenience

in installation and service.

• In the absence of local codes, the location of any

combustion air inlet relative to any vent terminal must

be at least 8 inches. This includes installations involving

more than one furnace.

• The quality of outdoor air must also be considered. Be

sure that the combustion air intake is not located near

a source of solvent fumes or other chemicals which can

cause corrosion of the furnace combustion system. (See

page 5 for a sample list of substances).

• Route piping as direct as possible between the furnace

and the outdoors. Horizontal piping from inducer to

the ﬂue pipe must be sloped 1/4” per foot to ensure

condensate ﬂows towards the drain tee or PVC trap.

Longer vent runs require larger pipe diameters. Refer to

the Inducer & Venting Options section on page 15 for

additional information.

• If a Direct Vent (2-pipe) system is used, the combustion

air intake and the vent exhaust must be located in the

same atmospheric pressure zone. This means both pipes

must exit the building through the same portion of exterior

wall or roof as shown in Figure 33 (page 36).

• Piping must be mechanically supported so that its weight

does not bear on the furnace. Pipe supports must be

installed a minimum of every ﬁve feet along the vent run

to ensure no displacement after installation. Supports

may be at shorter intervals if necessary to ensure that

there are no sagging sections that can trap condensate.

It is recommended to install couplings along the vent

pipe, on either side of the exterior wall (Figure 33). These

couplings may be required by local code.

• If breakable connections are required in the combustion

air inlet pipe (if present) and exhaust vent piping, then

straight neoprene couplings for 2” or 3” piping with hose

clamps can be used. These couplings can be ordered

through your local furnace distributor. To install a

coupling:

1. Slide the rubber coupling over the end of the pipe that is

attached to the furnace and secure it with one of the hose

clamps.

2. Slide the other end of the rubber coupling onto the other

pipe from the vent.

3. Secure the coupling with the second hose clamp, ensuring

that the connection is tight and leak free.

Outdoor Terminations - Horizontal Venting

• Vent and combustion air intake terminations shall be

installed as shown in Figure 7 & Figure 8 and in accordance

with these instructions:

• Vent termination clearances must be consistent with the

NFGC, ANSI 2223.1/NFPA 54 and/or the CSA B149.1,

Natural Gas and Propane Installation Code. Table 12

(page 35) lists the necessary distances from the vent

termination to windows and building air intakes.

• Vent and combustion air intake terminations must

be located to ensure proper furnace operation and

conformance to applicable codes. A vent terminal must

be located at least 3 feet above any forced air inlet located

within 10 feet. This does not apply to the combustion air

inlet of a direct vent (two pipe) appliance. In Canada,

CSA B149.1 takes precedence over these instructions.

See Table 12.

• All minimum clearances must be maintained to protect

building materials from degradation by ﬂue gases. See

(Figure 8).

• For optimal performance, vent the furnace through a wall

that experiences the least exposure to winter winds.

• The vent termination shall be located at least 3 ft.

horizontally from any electric meter, gas meter, regulator

and any relief equipment. These distances apply ONLY

to U.S. installations. In Canada, CSA B149.1 takes

precedence over these instructions.

Figure 7. Inlet & Exhaust Pipe Clearances

12” min. to maximum

expected snow level

(both pipes)

90° Elbow

Exhaust vent

option B

Exhaust vent

option A

Mounting kit faceplate

secured to wall with screws

(both pipes)

Combustion

air inlet

Exhaust vent

option C

18” Min.

36” Max.

8” Min.

36” Max.

(all positions)

Note 2

Mechanical draft

vent terminal

Direct vent

terminal

50,000 Btuh

or less

Forced air inlet

Direct vent

terminal - more

than 50,000 Btuh

Mechanical

draft vent

terminal

Mechanical

draft vent

terminal

Less

than

10 ft.

3 ft.

NOTES:

1. All dimensions shown are

minimum requirements.

2. Exterior vent terminations must

be located at least 12” above the

maximum expected snow level.

Note 2

4 ft

12 in.

9 in.

Note 2

Figure 8. Vent Locations

• Do not install the vent terminal such that exhaust is

directed into window wells, stairwells, under decks or into

alcoves or similar recessed areas, and do not terminate

above any public walkways.

• If venting horizontally, a side wall vent kit is available

according to the pipe diameter size of the installation. 2

inch and 3 inch kits are available. Refer to the technical

sales literature for part numbers. Please follow the

instructions provided with the kit.

• Concentric vent termination kits are available for use with

these furnaces. Refer to the technical sales literature for

kit numbers.

• When the vent pipe must exit an exterior wall close to

the grade or expected snow level where it is not possible

to obtain clearances shown in Figure 7, a riser may be

provided as shown in Figure 9 (page 12). Insulation is

required to prevent freezing of this section of pipe. See

Table 3 (page 15) for vent freezing protection.

Outdoor Terminations - Vertical Venting

Termination spacing requirements from the roof and from

each other are shown in Figure 10. The roof penetration must

be properly ﬂashed and waterproofed with a plumbing roof

boot or equivalent ﬂashing. Vent and combustion air piping

may be installed in an existing chimney which is not in use

provided that:

• Both the exhaust vent and air intake run the length of the

chimney.

• The top of the chimney is sealed and weatherproofed.

• The termination clearances shown in Figure 10 are

maintained.

• No other gas ﬁred or fuel-burning equipment is vented

through the chimney.

Vent Freezing Protection

CAUTION:

When the vent pipe is exposed to temperatures

below freezing (i.e., when it passes through

unheated spaces, chimneys, etc.) the pipe

must be insulated with 1/2 inch thick sponge

rubber insulation, Armaﬂex-type insulation or

equivalent. Insulating pipe is important to avoid

condensate icing.

• Table 2 lists the maximum length of ﬂue pipe that can

travel through an unconditioned space or an exterior

space. The total vent length must not exceed the lengths

noted in Table 1 (page 10). For Canadian installations,

please refer to the Canadian Installation Code (CAN/

CSA-B149.1 or 2) and/or local codes.

• For extremely cold climates or for conditions of short

furnace cycles (i.e. set back thermostat conditions)

the last 18 inches of vent pipe can be reduced. It is

acceptable to reduce from 3” to 2-1/2”, 3” to 2”, or 2” to

1-1/2” if the total vent length is at least 15 feet in length,

and the vent length is within the parameters speciﬁed in

Table 1. The restriction should be counted as 3 equivalent

feet. Smaller vent pipes are less susceptible to freezing,

but must not be excessively restrictive. The length of the

2 inch pipe must not be longer than 18 inches.

Figure 9. Alternate Horizontal Vent Installation

Support

NOTE: Vent Configuration to Provide

12" Minimum height above Snow Level.

1/2"

Armaflex

Insulation or

Equivalent

(if required)

12" Above

Maximum

Expected

Snow Level

19" Max.

(See Note)

Outside

Wall

Figure 10. Vertical Vent Termination

Combustion Air

Exhaust Vent

12” Above Maximum

Expected Snow Level

(Both pipes)

Elbows on the combustion air

inlet must be positioned pointing

away from the exhaust vent.

8" Min.

36" Max.

Plumbing Vent Roof Boot

(Both Pipes)

WINTER DESIGN

TEMPERATURE

MAXIMUM FLUE PIPE LENGTH (FEET)

IN UNCONDITIONED & EXTERIOR SPACES

WITHOUT INSULATION WITH INSULATION*

20 45 70

0 20 70

-20 10 60

*NOTE: Insulation thickness greater than 3/8 inch, based on an R value

of 3.5 (ft x F x hr) / (BTU x in.)

Table 2. Vent Protection

• If furnace is installed horiziontally, make sure the drainage

port on the in-line drain assembly is pointed downward

to ensure proper drainage of condensate. For J951X*U

series, see Figure 35 (page 38).

• To prevent debris or creatures from entering the

combustion system, a protective screen may be installed

over the combustion air intake opening. The screens hole

size must be large enough to prevent air restriction.

Existing Installations

When an existing furnace is removed from a vent system

serving other appliances, the existing vent system may not be

sized properly to vent the remaining appliances (For example:

water heater). An improperly sized venting system can result

in the formation of condensate, leakage, or spillage. The

existing vent system should be checked to make sure it is in

compliance with NFGC and must be brought into compliance

before installing the furnace.

NOTE: If replacing an existing furnace, it is possible you will

encounter an existing plastic venting system that is subject

to a Consumer Product Safety Commission recall. The pipes

involved in the recall are High Temperature Plastic Vent

(HTPV). If your venting system contains these pipes DO

NOT reuse this venting system! This recall does not apply

to other plastic vent pipes, such as white PVC or CPVC.

Check for details on the CPSC website or call their toll-free

number (800) 758-3688.

Condensate Disposal

The method for disposing of condensate varies according

to local codes. Consult your local code or authority having

jurisdiction. Neutralizer kit is available for use with this furnace.

Refer to the technical sales literature for part numbers. Please

follow the instructions provided with the kit.

This furnace has multiple options for positioning the vent

pipe as described in the, Vent and Inducer Assembly Options

section (page 15). Each of the condensate drain lines must

be J-trapped using ﬁeld supplied parts. After the condensate

lines are J-trapped, they may be combined together when

routed to the drain.

For Installations where there is limited clearance for the

J-Trap (such as an attic where it may be installed between

ceiling joists), either side of the J-Trap can be shortened to

a minimum of 3 Inches. See Figure 11 (page 15).

CIRCULATING AIR REQUIREMENTS

WARNING:

Do not allow combustion products to enter the

circulating air supply. Failure to prevent the

circulation of combustion products into the

living space can create potentially hazardous

conditions including carbon monoxide poisoning

that could result in personal injury or death.

All return ductwork must be secured to the

furnace with sheet metal screws. For installations

in conﬁned spaces, all return ductwork must be

adequately sealed. When return air is provided

through the bottom of the furnace, the joint

between the furnace and the return air plenum

must be air tight.

The surface that the furnace is mounted on must

provide sound physical support of the furnace

with no gaps, cracks or sagging between the

furnace and the ﬂoor or platform.

Return air and circulating air ductwork must

not be connected to any other heat producing

device such as a ﬁreplace insert, stove, etc. This

may result in ﬁre, explosion, carbon monoxide

poisoning, personal injury, or property damage.

Plenums & Air Ducts

• Plenums and air ducts must be installed in accordance

with the Standard for the Installation of Air Conditioning

and Ventilating Systems (NFPA No. 90A) or the

Standard for the Installation of Warm Air Heating and Air

Conditioning Systems (NFPA No. 90B).

• On upﬂow furnaces, if the maximum airﬂow is 1,600 CFM

or more, two openings shall be used for return air to

comply with government mandated efﬁciency standards.

Downﬂow furnaces can only use one return opening.

• It is recommended that the outlet duct contain a removable

access panel. The opening should be accessible when

the furnace is installed in service and shall be of a size

that smoke or reﬂected light may be observed inside

the casing to indicate the presence of leaks in the heat

exchanger. The cover for the opening shall be attached

in a way that prevent leaks.

• If outside air is used as return air to the furnace for

ventilation or to improve indoor air quality, the system

must be designed so that the return air is not less than

60° F (15° C) during operation. If a combination of indoor

and outdoor air is used, the ducts and damper system

must be designed so that the return air supply to the

furnace is equal to the return air supply under normal,

indoor return air applications.

• When a cooling system is installed which uses the

furnace blower to provide airﬂow over the indoor coil, the

coil must be installed downstream (on the outlet side) of

the furnace or in parallel with the furnace.

• If a cooling system is installed in parallel with the

furnace, a damper must be installed to prevent chilled

air from entering the furnace and condensing on the heat

exchanger. If a manually operated damper is installed,

it must be designed so that operation of the furnace is

prevented when the damper is in the cooling position and

operation of the cooling system is prevented when the

damper is in the heating position.

• Seal all connections and joints with industrial grade

sealing tape or liquid sealant. Requirements for sealing

ductwork vary from region to region. Consult with local

codes for requirements speciﬁc to your area.

Return Air Connections

• In applications where the supply ducts carry heated air to

areas outside the space where the furnace is installed,

the return air must be delivered to the furnace by duct(s)

secured to the furnace casing, running full size and

without interruption. Do not use the back of the furnace

for return air.

• Position the furnace with the return air ductwork ensuring

even alignment of furnace (or coil casing) air opening

and return air duct. NOTE: The ductwork must have an

opening equal to that of the return air opening of the

furnace (or coil casing). See Figure 29 (page 29) or

Figure 30 (page 29) for return air opening size.

Upﬂow & Horizontal Furnaces

• The return air ductwork may be connected to the left side,

right side, or bottom of the furnace. NOTE: If using the left

or right side of the furnace for return air, the bottom panel

(Figure 32) must not be removed from the bottom of the

furnace.

WARNING:

The bottom panel of the furnace must be in place

when the furnace is installed with side return air

ducts. Removal of all or part of the base could

cause circulation of combustible products into

the living space and create potentially hazardous

conditions, includingcarbon monoxidepoisoning

that could result in personal injury or death.

• Side Return Installations: To attach the return air duct

to the left or right side of the furnace, punch out the 4

knockouts from the side of the furnace (Figure 30).

Using sharp metal cutters, cut an opening between all 4

knockouts to expose the blower assembly. Position the

return air duct over the opening and secure to the side

with sheet metal screws.

• Bottom Return Installations: If using the bottom of the

furnace for return air, the bottom panel (Figure 30) must

be removed from the bottom of the furnace. See page

19 for removal instructions. Position the furnace over

the return air duct and secure together with sheet metal

screws. Make sure the screws penetrate the duct and

furnace casing.

Downﬂow Furnaces

• To attach the return air duct to the furnace, bend the

ﬂanges on the furnace upward 90° with wide duct pliers.

See Figure 29 for furnace ﬂange locations. NOTE: If

system installation includes AC coil casing, bend the

ﬂanges on the coil casing upward 90° before attaching

the return air duct.

• Secure the return air ductwork to the furnace or coil

casing (if installed) with sheet metal screws. Make sure

the screws penetrate the sheet metal casing and ﬂanges.

Supply Air Connections

• The supply air must be delivered to the heated space by

duct(s) secured to the furnace or coil box casing, running

full size and without interruption.

• To attach the supply air duct to upﬂow & horizontal

furnaces, bend the ﬂanges on the furnace upward 90°

with wide duct pliers. See Figure 30 for furnace ﬂange

locations. NOTE: If system installation includes AC coil

casing, bend the ﬂanges on the coil casing upward 90°

before attaching the supply air duct.

• Position the supply air ductwork onto the furnace ensuring

even alignment of furnace air opening and supply air

duct. NOTE: The ductwork must have an opening equal

to that of the supply air opening of the furnace. See Figure

29 (page 29) and Figure 30 (page 29) for supply air

opening size.

Acoustical Treatments

Damping ducts, ﬂexible vibration isolators, or pleated media-

style ﬁlters on the return air inlet of the furnace may be used

to reduce the transmission of equipment noise eminating

from the furnace. These treatments can produce a quieter

installation, particularly in the heated space. However, they

can increase the pressure drop in the duct system. Care

must be taken to maintain the proper maximum pressure

rise across the furnace, temperature rise and ﬂow rate.

This may mean increasing the duct size and/or reducing the

blower speed. These treatments must be constructed and

installed in accordance with NFPA and SMACNA construction

standards. Consult with local codes for special requirements.

For best sound performance, install all the needed gaskets

and grommets around penetrations into the furnace, such

as for electrical wiring.

FURNACE INSTALLATION

J951X*U series gas furnaces offer a wide range of installation

options, including installation in the upﬂow or horizontal

positions with either right, left, or upﬂow return air. J951X*D

series gas furnaces may only be installed as a downﬂow

application.

General Requirements

• The furnace must be leveled at installation and attached

to a properly installed duct system. See Figure 1 (page

5) for the required clearances needed to move the

furnace to its installation point (hallways, doorways,

stairs, etc).

• The furnace must be installed so that all electrical

components are protected from water.

• The furnace must be installed upstream from a

refrigeration system. (If applicable)

• The cabinet plug must always be used to close the hole

in the side of the furnace when rotating the inducer.

• The furnace requires special venting materials and

installation procedures. See page 6,page 7,page

8, page 9, page 10, page 11, & page 12 for

venting guidelines and speciﬁcations.

Upﬂow Furnaces

WARNING:

The furnace must not be installed directly on

carpeting, tile, or any combustible material other

than wood ﬂooring.

J951X*U series gas furnaces are shipped with the bottom

panel installed as shown in Figure 30 (page 29). If the

furnace is installed with only side return air, the bottom panel

must not be removed. If the furnace is installed with bottom

return air, the bottom panel must be removed. See Bottom

Panel Removal on page 19.

Horizontal Furnaces

WARNING:

The furnace must not be installed directly on

carpeting, tile, or any combustible material other

than wood ﬂooring.

J951X*U series gas furnaces can be installed horizontally

(Figure 11) in an attic, basement, crawl space or alcove. It

can also be suspended from a ceiling in a basement or utility

room in either a right to left airﬂow or left to right airﬂow as

shown in Figure 12 (page 15).

These furnaces are shipped with the bottom panel installed.

If the furnace is installed horizontally, remove the bottom

panel from the furnace before attaching the duct system.

See Bottom Panel Removal on page 19.

If installing the furnace with an evaporator coil (in an attic), it

is required that a drip pan be placed under the furnace. If the

installation is on a combustible platform as shown in Figure

11, it is recommended that the drip pan extend at least 12

inches past the top and front of the furnace.

NOTE: Although it is not required to use a drip pan for heat

only applications, state and local codes may require it.

Figure 11. J951X*U Horizontal installation

on a Platform

Flue pipe vented

to outside

J-Trap

Height

3” Min.

Coil Plenum

Wood or

non-combustible

platform

Two-pipe installation shown

Combustion Air Condensate

Drain Lines

Lag

Bolt

Nuts (x2)

Washer

and

Lockwasher

Nuts (x2)

Threaded

Rod

Figure 12. J951X*U Horizontally Suspended

in an Attic

Figure 13. Furnace on a Concrete Slab

Concrete

Floor

Furnace

Sheet

Metal

Plenum

If suspending the furnace from the ceiling, assemble a

support frame (Figure 12) using slotted iron channel and full

threaded rod. Fasten the frame together with nuts, washers,

and lockwashers. Secure the support frame to the rafters with

lag bolts. The furnace can also be suspended using steel

straps around each end of the furnace. The straps should

be attached to the furnace with sheet metal screws and to

the rafters with bolts.

It is recommended for further reduction of ﬁre hazard that

cement board or sheet metal be placed between the furnace

and the combustible ﬂoor and extend 12 inches beyond the

front of the door and top of the furnace.

Downﬂow Furnaces

WARNING:

The furnace must not be installed directly on

carpeting, tile, or any combustible material other

than wood ﬂooring.

WARNING:

Failure to install the downﬂow sub-base kit may

result in ﬁre, property damage or personal injury.

To install an J951X*D series gas furnace on combustible

ﬂooring, a special sub-base is required. Downﬂow sub-base

kits are factory supplied accessories and are listed according

to the cabinet letter of the furnace. Refer to the technical sales

literature for part numbers. Please follow the instructions

provided with the kit.

A downﬂow sub-base kit is not necessary if the furnace is

installed on a factory or site-built cased air conditioning coil.

However, the plenum attached to the coil casing must be

installed so that its surfaces are at least 1” from combustible

construction.

Installation on a Concrete Slab

1. Create an opening in the ﬂoor according to the dimensions

in Table 3.

2. Position the plenum and the furnace as shown in

Figure 13.

Inducer & Venting Options

To increase installation ﬂexibility, the inducer assembly can be

rotated up to 3 different positions. Each variation has slightly

different requirements with regard to condensate disposal

and, in some cases, the need to seal the furnace cabinet.

IMPORTANT NOTE:

The Inducer Assembly must never be positioned to vent

downwards on horizontal installs.

Table 3. Cutout Dimensions

MODEL # DIM. “A” DIM. “B”

J951X054BD 16 5/8 19 1/4

J951X072CD 20 1/8 19 1/4

J951X090CD 20 1/8 19 1/4

NOTE: Dimensions shown in Inches.

“A”

“B”

Opening in concrete floor

Before using Table 4, the number of pipes (1-pipe or 2-pipe)

connected to the furnace must be known. Find the proper

furnace style (upﬂow, horizontal, or downﬂow) and then the

side that the pipes will exit from the furnace. Finally select

the option that properly matches your installation type. For

J951X*U series, see Figure 34 (page 37) & Figure 35 (page

38). For J951X*D series, see Figure 36 (page 39).

NOTE: It is important that Direct Vent (2-pipe) systems

maintain an airtight ﬂow path from the air inlet to the ﬂue

gas outlet. The furnace ships from the factory with two holes

in the cabinet for the air inlet and ﬂue gas outlet. In certain

conﬁgurations, it is necessary to remove and relocate a plastic

plug in the furnace cabinet. If changing the position of the air

inlet and ﬂue gas outlet, it is required that the previous hole

be closed off with the plastic plug to maintain air tightness

in the furnace. The hole locations for all furnace series are

shown in Figure 29 and Figure 30.

Inducer Assembly Rotation

WARNING:

Inducer rotation must be completed before

the furnace is connected to gas and electric. If

both utilities have been connected, follow the

shutdown procedures printed on the furnace

label and disconnect the electrical supply.

CAUTION:

It is good practice to label all wires prior to

disconnection. Wiring errors can cause improper

and dangerous operation.

1. Disconnect the electrical harness from the inducer

assembly.

2. Remove the inducer assembly ground wire from the blower

deck.

3. Remove 3 screws securing the inducer assembly to the

header box.

4. Rotate the inducer assembly to its new position.

5. Secure the inducer assembly to the header box by

reinstalling the three screws. If the inducer assembly is

rotated to the left or right side of the furnace, use the extra

screw provided in the parts package.

J951X*U & J951X*D SERIES - CONVENTIONAL (1 PIPE)

VENT

DIRECTION UPFLOW HORIZONTAL

RIGHT

HORIZONTAL

LEFT DOWNFLOW

Right Option 1 N/A N/A Option 9

Up N/A Option 5 Option 6 Option 10

Left Option 2 N/A N/A Option 11

J951X*U & J951X*D SERIES - DIRECT VENT (2-PIPE)

VENT

DIRECTION UPFLOW HORIZONTAL

RIGHT

HORIZONTAL

LEFT DOWNFLOW

Right Option 3 N/A N/A Option 12

Up N/A Option 7 Option 8 Option 13

Left Option 4 N/A N/A Option 14

Table 4. Vent & Inducer Blower Options

6. Remove the cabinet plug from side of furnace and reinstall

in hole on opposite side of cabinet.

7. Install in-line drain assembly and tubing.

8. Install all condensate drain lines. For J951X*U series,

see Figure 34 (page 37)& Figure 35 (page 38). For

J951X*D series, see Figure 36 (page 39).

9. Reconnect the electrical harness to the inducer assembly.

10. Reconnect the inducer assembly ground wire to the blower

deck or door.

11.Verify operation as detailed on the furnace label.

Pressure Switch Tubing

All upﬂow / horizontal furnaces have two switches, one

connected to the static tap on the inducer assembly and the

other to the collector box. Figure 14 displays the proper routing

of pressure switch tubing for J951X*U furnaces. Downﬂow

(J951X*D) furnaces require only one switch connected to

the inducer’s static tap as shown in Figure 15.

Figure 14. Pressure Switch Tubing for

Upﬂow Furnaces

Models J951X038U, J951X054U, J951X072U,

J951X090U, J951X108U, & J951X120U

Figure 15. Pressure Switch Tubing for

Downﬂow Furnaces

Models J951X054D, J951X072D, & J951X090D

Alternate Pressure Switch Location

In some inducer orientations, the inducer pressure switch may

interfere with gas pipe installation. Determine the side of the

cabinet the gas pipe will enter and see if the inducer pressure

switch needs to be moved. If the pressure switch interferes

with the gas pipe, use these instructions for relocating it to

an alternate location:

1. Shut off any electrical power to the furnace.

2. Label and disconnect the tubing and wires from the pressure

switch (Figure 16).

3. Remove two screws securing the pressure switch to the

inducer housing.

4. Remove the pressure switch from the mounts on the

inducer housing and relocate it to the other set of mounts

90° from previous location.

5. Secure the pressure switch with two screws.

6. Reconnect the tubes and wires to the pressure switch.

Accessories

The components below are included in the extra parts bag

that is supplied with the purchase of your furnace. Depending

on your particular installation, some of these components are

optional and may not be used. Please refer to the descriptions

and accompanying ﬁgures when installing these items.

NOTE: Some parts may not be supplied with each furnace.

Refer to the literature in the extra parts bag for the parts

included with the particular furnace.

Finish Flange

The ﬁnish ﬂange must be installed to vent the combustion

air pipe through the top of the furnace. NOTE: For proper

installation it is important that the pipe and screw holes in the

ﬁnish ﬂanges, gasket, and cabinet are aligned. See Figure 17.

1. Position ﬂange gasket over hole in the furnace cabinet.

2. Position finish flange on top of the flange gasket.

NOTE: Make sure the ﬂange is properly oriented so that

the FRONT lettering is located near the front of the furnace

as shown in Figure 17.

3. Secure ﬂange and gasket to cabinet with three ﬁeld supplied

sheet metal screws.

Rubber Grommets

The 2 1/4” rubber grommet is used to seal the opening

between the furnace cabinet and the 2” PVC vent pipe. The

rubber grommet should be installed in the 3” hole prior to

running the vent pipe out of cabinet. No sealants are required.

See Figure 18.

The 7/8” rubber grommet is used to seal the opening between

the furnace cabinet and the gas pipe. The rubber grommet

should be installed in the 1 5/8” hole prior to running the gas

pipe into the cabinet. No sealants are required.

The 3/4” rubber grommet is used if venting out the left side of

the cabinet and the drain tube is routed through the blower

deck. Remove the plastic plug from the hole and install the

grommet before routing the drain tube.

Figure 16. Alternate Pressure Switch Location

PRIMARY

LOCATION

ALTERNATE

LOCATION

Figure 17. Finish Flange

Finish

Flange

Gasket

Hole for

Flue

Vent Pipe

Hole f

or Inlet

Air Vent Pipe

FRONT

FRONT lettering must be

located near front

of furnace

Figure 18. Rubber Grommets

Ø 3/4” Rubber

Grommet

ø 2 1/4” Rubber Grommet

(see note)

ø 7/8” Rubber

Grommet

PVC Components

IMPORTANT NOTES:

• Before permanently installing these components, it is

recommended you dry-ﬁt them ﬁrst to ensure proper

ﬁt and alignment with other vent pipes.

• The 2” PVC components shown in Figure 19 are not

provided in the extra parts bag for *SC & *SL models.

However the PVC Trap (P/N 664659) can be purchased

thru your local distributor.

The 2” PVC tee, reducer, PVC Trap and 1/2” X 1/2” hose

barb are used when the inducer is rotated to vent out thru

the left or right side of the furnace cabinet. See Figure 19.

The 1/2” X 3/4” hose barb can be used to route the condensate

drain to the outside of the cabinet. It must be installed from

inside the cabinet with the threaded end inserted thru the 1

1/16” hole. The condensate drain should be connected to

the barbed end. Attach 1” PVC drain line to the threaded

end. See Figure 29 (page 29) or Figure 30 (page 29) for

hole location.

Typical Orientation

1. Install the PVC Tee vertically on the 2” vent pipe that is

extending out the side of the cabinet. Permanently bond

them together using appropriate primer and cement. Refer

to the typical orientation shown in Figure 19.

2. Install the reducer or PVC trap (if supplied) on the bottom

end of the PVC Tee. Permanently bond them together

using appropriate primer and cement.

3. Install the 1/2” x 1/2” hose barb on the 2” PVC reducer.

NOTE: Do not over tighten! Use an adequate amount of

Teﬂon tape on the threads. Do not use liquid sealants.

4. Verify all connections and joints for tight ﬁt and proper

alignment with other vent pipes.

Alternate Orientation

1. Install the 2” PVC Tee horizontally on the 2” vent pipe that

is extending out the side of the cabinet. Permanently bond

them together using appropriate primer and cement. Refer

to the alternate orientation shown in Figure 19.

2. Install the 2” PVC Elbow on the end of the 2” PVC Tee.

Permanently bond them together using appropriate primer

and cement.

3. Install the reducer or PVC trap (if supplied) on the bottom

end of the PVC Tee. Permanenly bond them together using

appropriate primer and cement.

4. Install the 1/2” x 1/2” hose barb on the 2” PVC reducer.

NOTE: Do not over tighten! Use an adequate amount of

Teﬂon tape on the threads. Do not use liquid sealants.

5. Verify all connections and joints for tight ﬁt and proper

alignment with other vent pipes.

Optional PVC Pipe Installation

When running the 2” PVC pipe out through the top of the

J951X*U upﬂow furnace, there may be possible clearance

issues when transitioning the PVC pipe from 2” to 3”:

• If the size of the PVC ﬂue needs to be increased from 2”

to 3”, two, 2” x 45° PVC elbows may be used to achieve

the clearances needed between the coil box and the 2” x

3” coupling. See Figure 20.

• Install the 2” x 3” coupling in the vertical run only. If the

coupling is installed horizontally, it will allow water to build

up inside the furnace and cause a lock out condition.

• To avoid the clearance issue, it is recommended that the

furnace be vented through the left side or the right side of

the cabinet.

1/2” x 3/4”

Hose Barb

2” PVC Elbow

(Field Supplied)

2” PVC Te e

1/2” x 3/4”

Hose Barb

2” PVC Pipe from Inline

Drain Assembly

(Not Included)

INSTALLATION OF PVC COMPONENTS

(TYPICAL ORIENTATION)

INSTALLATION OF PVC COMPONENTS

(ALTERNATE ORIENTATION)

2” PVC Te e

2” PVC Pipe from Inline

Drain Assembly

(Not Included)

1/2” T

ubing (Field Supplied)

Drain Line Attached

to PVC Tr ap

(Do Not Tr ap)

1/2” Tubing (Field Supplied)

Drain Line Attached

to PVC Tr ap

(Do Not Tr ap)

PVC TRAP

Not Included in

*SC & *SL Models

PVC TRAP

Not Included in

*SC & *SL Models

Figure 19. PVC Components

Figure 20. Optional PVC Pipe Installation

2” x 450PVC

Elbow

2” PVC Pipe

2” x 3” PVC

Coupling

Coil Box

Condensate Drain Lines

If the furnace is installed in an area where temperatures

fall below freezing, special precautions must be made

for insulating condensate drain lines that drain to the

outdoors. If condensate freezes in the lines, this will

cause improper operation or damage to the furnace. It

is recommended that all drain lines on the outside of

the residence be wrapped with an industry approved

insulation or material allowed by local code.

• The method for disposing condensate varies according to

local codes. Consult your local code or authority having

jurisdiction.

• The condensate drain line must be trapped using a kit

(P/N- 922485) or ﬁeld supplied parts. After the drain trap,

condensate can continue to the drain by connecting to a

recommended 3/4” ID minimum drain line, but no smaller

than the original tubing ID supplied by the manufacturer.

The drain line should slope downward away from the

furnace to ensure proper drainage.

• The placement of the condensate drain lines will depend

on the conﬁguration selected in Table 4 (page 16). The

drain lines can be routed out the left or right side of the

furnace, but must maintain a downward slope to ensure

proper condensate drainage. The J-trap may need to be

rotated to the side that matches your setup.

For J951X*U series, see Figure 34 (page 37) & Figure

35 (page 38). For J951X*D series, see Figure 36 (page

39). To rotate the J-trap, loosen the clamp on the drain

tube, rotate the J-trap to either side, and retighten the

clamp.

• It is permissible to locate the trap away from the

furnace. The condensate drain system (J-trap and drain

tube) should be no more than 30 equivalent feet while

maintaining 1/4” per foot slope, and insulated if located in

an unconditioned space.

THREE GENERAL PRINCIPLES APPLY:

• Each condensate drain must be trapped separately using

a J-Trap or ﬁeld supplied loop. After individually trapping

the condensate lines, it is acceptable to combine the

drains.

• There must always be a drain attached to the collector at

the outlet of the secondary heat exchanger.

• There must always be a drain at the lowest point of the

venting system. NOTE: If using a condensate pump, the

furnace drain line must be installed above the pumps

water line.

EXCEPTIONS & CLARIFICATIONS TO THE

GENERAL RULES:

• If the vent exits the furnace horizontally, the vent may be

turned vertically with a tee. The drip leg formed by the

tee must include a drain. (Option 1, Option 3, Option 4,

Option 11, Option 12, & Option 14)

• In certain cases, it is permitted to drain the inducer back

into the top drain of the collector. This drain must not

sag in the middle. (Option 1, Option 3, Option 5, Option

7, Option 9, Option 10, Option 12, & Option 13)

Bottom Panel Removal

The steps listed below describe how to remove the bottom

panel from the furnace. See Figure 21.

1. Remove the door from the blower compartment.

2. Disconnect the wires from the blower motor plug.

3. Remove two screws securing the blower assembly to the

furnace.

4. Carefully pull the blower assembly out thru the front of the

furnace.

5. Remove all screws securing bottom panel to bottom of

furnace and front brace.

6. Lift up and slide bottom panel out through front of furnace.

7. Reinstall the blower assembly in reverse order.

Figure 21. Bottom Panel Removal

Bottom

Panel

Front

Brace

Door

Blower

Plug

Screws

Blower

Assembly

Screws

Alternate Bottom Panel Removal

If the bottom panel cannot be removed using the previous

instructions, the steps below are an alternate method for

removing the bottom panel. See Figure 22.

1. Remove the door from the blower compartment .

2. Remove all screws securing the bottom panel to the front

brace.

3. Remove two screws securing the furnace cabinet to the

blower deck.

4. Remove all screws securing the furnace cabinet to the

bottom panel.

5. Remove the screw securing the bottom corner of the

furnace cabinet to the front brace.

6. Carefully spread the bottom corner of the furnace cabinet

outwards while sliding the bottom panel out through the

front of the furnace.

7. Reassemble the furnace in reverse order.

Figure 22. Alternate Removal Method

Screws

Front

Brace

Bottom

Panel

Screws

Blower

Deck

Door

GAS SUPPLY & PIPING

WARNING:

FIRE OR EXPLOSION HAZARD

• Failure to follow safety warnings exactly could

result in serious injury, death or property

damage.

• Installation and service must be performed

by a qualiﬁed installer, service agency or the

gas supplier.

• Do not store or use gasoline or other

ﬂammable vapors and liquids in the vicinity

of this or any other appliance.

WHAT TO DO IF YOU SMELL GAS

• Do not try to light any appliance.

• Do not touch any electrical switch; do not

use any phone in your building.

• Leave the building immediately.

• Immediately call your gas supplier from a

neighbor’s phone. Follow the gas supplier’s

instructions.

• If you cannot reach your gas supplier, call

the ﬁre department.

• All gas piping must be installed in compliance with

local codes and utility regulations. In the absence of

local codes the gas line installation must comply with

the latest edition of the National Fuel Gas Code (ANSI

Z223.1) or (CAN/CSA B149.1) Installation Codes.

• Some local regulations require the installation of a

manual main shut-off valve and ground joint union

external to the furnace as shown in Figure 23 (page 21)

& Figure 24 (page 21). The shut-off valve should be

readily accessible for service and/or emergency use.

Consult the local utility or gas supplier for additional

requirements regarding placement of the manual main

gas shut-off.

• Per ANSI 21.47, A 1/8-inch NPT plugged tapping,

accessible for test gauge connection, must be installed

immediately upstream of the gas supply connection to

the furnace external to the cabinet. If local codes allow

the use of a ﬂexible gas appliance connector, always

use a new listed connector. Do not use a connector

that has previously serviced another gas appliance.

• Gas piping must never run in or through air ducts,

chimneys, gas vents, or elevator shafts.

• Compounds used on threaded joints of gas piping

must be resistant to the actions of LP propane gas.

• The main gas valve and main power disconnect to the

furnace must be properly labeled by the installer in

case emergency shutdown is required.

• Flexible gas connectors are not recommended for this

type of furnace but may be used if allowed by local

jurisdiction. Only new ﬂexible connectors may be

used. Do not use a connector which has previously

serviced another gas appliance.

• A drip leg should be installed in the vertical pipe run

to the unit. See Figure 23 or Figure 24.

Table 6 (page 32) lists gas ﬂow capacities for standard pipe

sizes as a function of length in typical applications based on

nominal pressure drop in the line.

The furnace may be installed with either left or right side gas

entry. When connecting the gas supply, provide clearance

between the gas supply line and the entry hole in the furnace

casing to avoid unwanted noise and/or damage to the furnace.

Typical gas hookups are shown in Figure 23 & Figure 24.

Leak Check

WARNING:

FIRE OR EXPLOSION HAZARD

Failure to follow safety warnings exactly could

result in serious injury, death or property

damage.

Never test for gas leaks with an open ﬂame.

Use a commercially available soap solution

made speciﬁcally for the detection of leaks

to check all connections. A ﬁre or explosion

may result causing property damage, personal

injury or loss of life.

After the gas piping to the furnace is complete, all connections

must be tested for gas leaks. This includes pipe connections

at the main gas valve, emergency shutoff valve and ﬂexible

gas connectors (if applicable). The soap and water solution

can be applied on each joint or union using a small paintbrush.

If any bubbling is observed, the connection is not sealed

adequately and must be retightened. Repeat the tightening

and soap check process until bubbling ceases.

IMPORTANT NOTE:

When pressure testing gas supply lines at pressures

greater than 1/2 psig (14 inch W.C.), the gas supply

piping system must be disconnected from the furnace

to prevent damage to the gas control valve. If the test

pressure is less than or equal to 1/2 psig (14 inch W.C.),

close the manual shut-off valve.

High Altitude Application (Natural Gas Only)

High altitude conversion with this furnace depends on

the installation altitude and the heating value of the gas.

Installation of this furnace at altitudes above 2,000 feet

shall be in accordance with local codes, or in the absence

of local codes, the National Fuel Gas Code, ANSI Z223.1/

NFPA 54 or National Standard of Canada, Natural Gas &

Propane Installation Code CSA B149.1. Please consult your

local code authority.

WARNING:

The reduction of input rating necessary for high

altitude installation may only be accomplished

with factory supplied oriﬁces. Do not attempt to

drill out oriﬁces in the ﬁeld. Improperly drilled

orifices may cause fire, explosion, carbon

monoxide poisoning, personal injury or death.
