OZtrail ELE-FF045S-G User manual

www.oztrail.com.au
Single and Dual Zone Fridge/Freezers
ELE-FF045S-G / ELE-FF080D-G
OWNERS MANUAL

2
CONTENTS
General Information & Safety Instructions.......3
Appliances and Accessories ...........................4
Getting Started................................................5
Operating your Fridge/Freezer ........................6
Temp Control/General Operation ....................8
Single Zone Operation.....................................9
Dual Zone Operation .....................................10
Using with Solar Panel or Generator.............12
Tips, Maintenance & Service.........................13
Troubleshooting.............................................14
Error Code .....................................................15
Specifications................................................15
Warranty Details ............................................16

3
GENERAL INFO & SAFETY INSTRUCTIONS
Read this manual thoroughly before first
use, even if you are familiar with this type of
product. The safety precautions enclosed
herein reduce the risk of fire, electric shock
and injury when correctly adhered to. Keep
the manual in a safe place for future reference,
along with purchase receipt and carton. If
applicable, pass these instructions on to the
next owner of the appliance.
Always follow basic safety precautions and
accident prevention measures when using an
electrical appliance, including the following:
ELECTRICAL SAFETY & CORD HANDLING
• Correct voltage: Make sure your local outlet
voltage and circuit frequency corresponds
to the voltage indicated on the appliance
rating label.
NOTE: Intended use: This is a portable
product, designed for private use. It is
exclusively designed for use in cars, caravans
and other vehicles including mobile homes,
campervans, rail cars and boats. It is designed
to cool food and beverages and to be set up in
dry, weather protected areas. It is not intended
for stationary extended use as e.g. a second
fridge at home.
• Safe connection: Insert the plug firmly into
a properly earthed AC mains or 12V DC
socket Do not alter the plug.
• Protect from moisture: To protect against
electric shock, do not immerse the cable,
plug or the appliance itself in water or other
liquid. Ensure your hands are dry before
handling the plug or switching on the
appliance. Do not use it on wet surfaces.
NOTE: Installation of AC in boats should be
carried out by a qualified electrician.
• Protect the power cable. Do not kink or
damage the power cable. Do not wrap it
around the appliance. Do not pull the unit
by the cable. Do not use the cable as a
handle, close a door on the cable or pull
the cable around sharp edges or corners.
Keep the cable away from heated surfaces.
• Never touch uninsulated cables with
bare hands. This applies especially to
handling AC cables.
• For installations in boats: If the device is
AC mains operated, it is important that the
system is protected by a fuse and an earth
leakage protection device.
• Always ensure that the correct voltage is
applied to the Fridge/Freezer. The voltage is
stated on the Fridge/Freezer’s data plate.
• Never obstruct vents to the Fridge/
Freezer’s compressor.
• Defrost the Fridge/Freezer on a regular
basis.
• Never use hard or sharp implements to
remove ice from the cooling compartment.
• Never use abrasive or solvent based
materials when cleaning the cooling
compartment.
• Do not use any electrical appliances
inside the cooling compartment.
NOTE: This appliance is not intended for use
by persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they
have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety. Children should be
supervised to ensure that they do not play with
the appliance.
• Do not expose to rain.
• This appliance is suitable for camping use.

4
ASSEMBLY AND PARTS
SINGLE ZONE FRIDGE/FREEZER
1. Internal Basket
2. Control Panel
3. Single Lid
4. Lid Latches
5. Carry Handle
6. Air Flow Vent
7. Power Input Panel
8. AC Power Cable (Page 7.)
9. DC Power Cable (Page 7.)
DUAL ZONE FRIDGE/FREEZER
1. Internal Baskets
2. Control Panel
3. Dual Lids
4. Lid Latches
5. Carry Handle
6. Air Flow Vent
7. Power Input Panel
8. AC Power Cable (Page 7.)
9. DC Power Cable (Page 7.)
3
3
1
1
3
4
4
5
5
6
6
7
7
2
2
6
6

5
GETTING STARTED
INSTALLATION
After unpacking the Fridge/Freezer check that
no parts are missing. Place the unit in a dry
place which is protected against splashing
water. Do not place directly adjacent to
sources of heat such as heating, gas ovens,
hot water, pipes or under the blazing sun.
It is important that your appliance is installed
and operated in accordance with these
instructions to guarantee its performance,
efficiency and operation.
APPLICATION & OPERATIVE
COOLING RANGE
The cooling compartment has varying
temperature zones. The values indicated on
the digital display are related to the middle of
the cabinet.
The Single Zone Fridge/Freezer is designed to
either refrigerate or freeze food. The Dual Zone
Fridge/Freezer can be used as either a fridge
or a freezer. The Fridge/Freezer may be used
for outdoor use such as for camping purposes.
If you wish to refrigerate medicines, first
check to ensure the Fridge/Freezer’s cooling
capacity meets the demands of the respective
medicines.
The Fridge/Freezer is designed to operate
in ambient temperatures between -10° and
+55° C in a maximum air humidity of 90% and
can operate continuously at an angle of 30°
maximum.
Note: The normal operation of the appliance
requires heat to be radiated away from the
condenser located at the end of the cabinet.
Adequate airflow is required around the
compressor at all times. (Fig. 1).
The cooling system has been designed to
operate correctly when the appliance is
positioned on angles up to 30 degrees. It
is recommended that the time the unit is
exposed to angles over 30 degrees is limited
to a maximum of four (4) hours continuous
operation. (Fig. 2).
Fig. 1
Fig. 2
30O
30O

6
OPERATING YOUR FRIDGE/FREEZER
POWER REQUIREMENTS
The Fridge/Freezer is designed to operate on
AC or DC voltage.
• AC input 220-240V AC at 50Hz to ac
adaptor (e.g. electrical power point)
• DC input 12V or 24V DC (e.g. car cigarette
lighter or car battery)
• If the Fridge/Freezer is operating when the
vehicle ignition is switched OFF, the Fridge/
Freezer will switch OFF automatically
unless vehicle is fitted with dual battery
system.
• The Fridge/Freezer will automatically switch
back ON when the vehicle is re-started
and the power source voltage reaches the
Battery Monitor cut-in setting.
OPERATING WITH 12/24V DC
• Plug the 12V/24V DC power cable into the
DC POWER socket (Fig 3.) on the end of
the Fridge/Freezer and then connect to the
vehicle cigarette lighter socket or suitable
12V or 24V DC power source.
• The Fridge/Freezer will automatically turn
on, there is no requirement to switch the
appliance on.
• The display will automatically show the
current internal cabinet temperature.
• For optimum performance and efficiency,
it is important that the Fridge/Freezer has
a reliable DC power source available.
Direct connection to the battery is
recommended and reduces the risk of
voltage dropping to the appliance.
• Use only the DC power cable supplied with
the Fridge/Freezer.
Important: If a DC extension cable is required
we recommended use of a 6mm dia. (AWG11)
4.58mm2Twin Sheath Two Core cable with
direct connection to the positive and negative
battery terminals with 15A inline
fuse protection.
12/24V DC POWER REQUIREMENTS
If your Fridge/Freezer is cutting out
prematurely, it could be due to:
1. The battery voltage protection being set too
high on the Battery Monitor
2. DC power cable and/or connections are
not suitable to carry the required current.
Check the power cable and all connections
and adjust the Battery Monitor on the
control panel if required.
• The Fridge/Freezer is equipped with a
multilevel Battery Monitor that protects
your vehicle battery against excessive
discharging when the Fridge/Freezer is
connected to 12V or 24V DC power source.
Important: When using the Fridge/Freezer
with DC power supply, we recommended
setting the Battery Monitor to LOW if Fridge/
Freezer not running off crank battery.
Note: A battery charger may only be
connected to the battery when the Fridge/
Freezer has been disconnected from the DC
power source.
• Over-voltage may cause damage to the
electronics of the Fridge/Freezer.
• Your Fridge/Freezer is equipped with
reverse polarity protection. It protects your
Fridge/Freezer against reverse battery
connection and short circuit.
• As a protection for your battery, the Fridge/
Freezer switches OFF automatically if the
power source voltage is insufficient. Fridge
will only restart when voltage reaches cut
in level.
Note: It is important that the correct cable size
and gauge is used for the installation of the
DC supply as over distance the voltage can
decrease if the incorrect cable size and gauge
cable is being used.
• Always consult a qualified automotive
electrician when using a DC extension cable.

7
DC Power Cable
(Can be Cigarette connection or Merit connection by
removing/replacing red twist cap (Fig.4))
OPERATING YOUR FRIDGE/FREEZER
OPERATING WITH 240V AC
• Plug the 240V AC power adaptor & cable
into the Fridge power socket (Fig. 3) on the
end of the Fridge/Freezer and then connect
to a suitable 240V AC power source.
• The Fridge/Freezer will automatically turn
on, there is no requirement to switch the
appliance on.
• The display will automatically show the
current internal cabinet temperature.
• The Fridge/Freezer is equipped with a
multivoltage internal power supply with
priority circuit or connecting to an AC
voltage power source of 240V.
CAUTION: Do not touch cables, plugs or
switches with wet hands or when your feet
are in contact with water! If you operate your
Fridge/Freezer on board a boat by means of
a shore connection to a 220-240V AC power
source, the power connection must include an
earth leakage RCD residual current device.
Fig. 3
Fig. 4
AC Power Adaptor

8
TEMP CONTROL/GENERAL OPERATION
When your Fridge/Freezer is first connected
to the AC or DC power input the appliance
will automatically switch on and the LCD
control panel will display the current cabinet
temperature, battery monitor and Eco setting
as well as the current input voltage.
• The Temperature Controller provides the
ability to set the desired temperature
level and display the current cabinet
temperature. The electronic controller has
been programmed to maintain an average
of the set temperature.
• The compressor will start up when the
internal cabinet temperature increases 0.5
to 1.5 degrees above the set temperature
and will run until the temperature is 0.5 to
1.5 degrees below the set temperature.
BATTERY DISPLAY
Voltage is measured at the input connection on
the side of the appliance.
Battery Display 12V 24V
9.6V or less 21.3V or less
9.7V to 10.3V 21.4V to 22.4V
10.6V to 11.0V 22.7V to 23.5V
11.1V to 11.7V 23.6V to 24.6V
11.8V to 12.4V 23.7V to 25.7V
12.5V or above 25.8V or above
*Values are for reference only and may be
subject to change depending on conditions
and power supply.

9
SINGLE ZONE OPERATION
1. Power On/Off Button
2. Battery Monitor Display
3. Temp Decrease Button
4. Temp Increase Button
5. Temp Display
6. Battery Protection Button
7. Battery Protection Display
8. Compressor Speed Button
9. Compressor Speed Display
POWER – OFF AND ON
1. Press power button & fridge will go into
standby mode then switch off after 5
seconds
2. Press the power button & fridge will re-start
with previously selected settings
ECO FUNCTION – SETTING
1. Press the compressor speed button & the
speed setting will go between ECO & MAX
CABINET TEMPERATURE – SETTING
1. Adjust Temperature by pressing the +
button to increase temp and the - button to
decrease temp
Note: Maximum temperature settings are from
-20°C to 20°C.
2. Temperature display will flash when
selecting temperature & return to solid
display when showing actual internal
temperature
BATTERY MONITOR – SETTING
1. Adjust the setting by pressing the Battery
Protection button until desired setting is
highlighted on display
12V DC Input Cut Out Cut In
HIGH 11.3V 12.6V
MEDIUM 10.1V 11.4V
LOW 9.6V 10.9V
24V DC Input Cut Out Cut In
HIGH 24.3V 25.7V
MEDIUM 22.3V 23.7V
LOW 21.6V 23.0V
High Med
• Battery Protection •
• Compressor Speed •
Max Eco
Low
High Med
• Battery Protection •
• Compressor Speed •
Max Eco
Low
3
4 2 5
8 9
1
7
6

10
DUAL ZONE OPERATION
POWER – OFF AND ON
1. Press power button & fridge will go into
standby mode then switch off after 5
seconds
2 Press the power button & fridge will re-start
with previously selected settings
ECO FUNCTION – SETTING
1. Press the COMPRESSOR SPEED button &
the speed setting will go between ECO &
MAX
CABINET TEMPERATURE – SETTING
The temperature may be set independently
for each zone in the range -20° to +20°C.
The R/H (large) cabinet MUST be set
to equal to or higher than the L/H
(small) section
SETTING THE LEFT ZONE
1. Adjust Temperature by pressing the L BOX
+ button to increase set temp and the
L BOX - button to decrease set temp
2. Temperature display will flash when
selecting temperature & return to solid
display when showing actual internal
temperature
SETTING THE RIGHT ZONE
1. Adjust Temperature by pressing the
R BOX + button to increase set temp and
the R BOX - button to decrease set temp
2. Temperature display will flash when
selecting temperature & return to solid
display when showing actual internal
temperature
SHUTTING DOWN A SELECTED ZONE
The Dual cooling system will allow either zone
to be shut down independently to the other.
This is perfect for when the total cabinet space
is not required and provides improved power
efficiencies.
1. Press and hold the L BOX - and + buttons
together for 2-3 seconds and the L/H
Cabinet will stop cooling
2. Repeat the same step and the L/H Cabinet
will recommence operation
3. Press and hold the R BOX - and + buttons
together for 2-3 seconds and the R/H
Cabinet will stop cooling
4. Repeat the same step and the R/H Cabinet
will recommence operation
1. Power On/Off Button
2. Battery Monitor Display
3. Temp Decrease Buttons
4. Temp Increase Buttons
5. Temp Display
6. Battery Protection Button
7. Battery Protection Display
8. Compressor Speed Button
9. Compressor Speed Display
High Med
• Battery Protection •
• Compressor Speed •
Max Eco
Low
High Med
• Battery Protection •
• Compressor Speed •
Max Eco
Low
3
4 2 5
8 9
1
7
6

11
DUAL ZONE OPERATION
BATTERY MONITOR – SETTING
1. Adjust the setting by pressing the Battery
Protection button until desired setting is
highlighted on display
12V DC Input Cut Out Cut In
HIGH 11.3V 12.6V
MEDIUM 10.1V 11.4V
LOW 9.6V 10.9V
24V DC Input Cut Out Cut In
HIGH 24.3V 25.7V
MEDIUM 22.3V 23.7V
LOW 21.6V 23.0V

12
USING WITH SOLAR PANEL OR GENERATOR
USING WITH SOLAR PANELS
• The power consumption and efficiency of
your Fridge/Freezer makes it ideal to be
used in conjunction with solar panels to
provide recharging of the DC power source.
Solar panels will provide charge into the
battery during the daylight hours even while
the appliance is operating.
• As the output from solar panels changes
depending on the level of sunlight and
intensity, your Fridge/Freezer cannot be
connected directly to the solar panels. The
appliance must be connected to a suitable
DC battery and then the solar panels
connected to the battery.
• We recommend the use of the quality
regulated portable solar panel kits from
60 to 250 watts for use with your Fridge/
Freezer.
DO NOT connect the Fridge/Freezer directly
to the solar panel as it will not work.
Connection must be via the battery.
USING PORTABLE GENERATORS
• It is important that the correct generator
size is used with your Fridge/Freezer. An
incorrect generator or voltage output may
result in reduced performance or damage
to your Fridge/Freezer which may void your
appliance warranty.
• If connecting directly to an AC generator,
ensure that only a digital or inverter type
generator is used. These provide a more
reliable and constant 240V AC output
power source and are specifically designed
for use with electronic and other power
sensitive appliances.
• Most generators are fitted with a DC power
output socket - DO NOT connect your
fridge directly to the DC power output of
the generator as this will result in damage
to your Fridge/Freezer and void warranty.
• When charging the battery using a digital
or inverter type generator, we recommend
only using a ‘smart battery charger’ that
is fully automatic, spark proof and reverse
polarity protected. The battery charger is
connected directly to the AC power output
socket of the generator.

13
TIPS, MAINTENANCE & SERVICE
TIPS AND SUGGESTIONS
• Fresh and frozen foods should not be
stored right beside each other in the
cabinet. Doing so may cause a fresh food
to freeze and/or spoil.
• When the appliance is being set at 0° or
lower temperatures, do not store glass
bottles or liquids such as beer, milk, juices
or soft drinks in the unit as these may
freeze and shatter, leak or burst.
• Items such as fruit and vegetables should
be stored closer to the top of the cabinet
as this area is normally slightly warmer. This
will reduce the risk of spoiling and ensures
that damage is not caused by being
crushed by heavier items.
• To improve the efficiency of your Fridge/
Freezer it is better to have the cabinet as
full as possible at all times. A full cabinet
will provide lower power consumption
over 24 hours than a half empty one.
When the cabinet is full there is little air
space between the goods so the cold air
is trapped, but when there is lots of air the
coldness cannot be captured and held. On
a trip it is a good idea to replace finished
products with bottles of water or similar.
This will fill the empty spaces and allow the
coldness to remain within the cabinet.
• Frequent door opening will allow warm
air to enter the cabinet. Keep the number
of times you open the door to a minimum
where possible.
• When located in the rear of a car or trailer,
it is recommended that the appliance be
kept away from direct sunlight to reduce
the risk of increased heat. It should also
be provided with suitable ventilation to
guarantee efficient power consumption
and performance. You must remember that
when a vehicle is parked in the sun that on
a day where the ambient temperature is
+30°C, the interior of the vehicle can reach
+55°C.
MAINTENANCE & SERVICE
Your Fridge/Freezer will be delivered cleaned
from the factory – you nevertheless should
clean prior to initial use. Take a cloth which
has been slightly moistened with lukewarm
water. Pay attention that no water drops
into the seals and possibly damages the
electronics. Dry off the Fridge/Freezer with a
cloth after cleaning. Clean your Fridge/Freezer
periodically and as soon as it is dirty.
ATTENTION:
• DO NOT use solvents or agents with sand
or acid parts for cleaning your Fridge/
Freezer.
• DO NOT use brushes, graters or hard sharp
tools to clean your Fridge/Freezer.
• Before cleaning, the power cable should
be disconnected and the Fridge/Freezer
switched OFF.
• Clean the Fridge/Freezer inside and out
with a damp cloth. For stubborn dirt, use
some sodium bicarbonate dissolved in
lukewarm water.
• After washing, rinse with clean water and
dry carefully.
• When storing your Fridge/Freezer for a long
period of time, DO NOT fully close the lid.
This will prevent mould and odours.
For additional queries, service and
maintenance please contact our After Sales
Support 1300 555 197. They will provide you
with expert advice on further information
you may require.
DISPOSAL
When it comes to the end of its working life,
your Fridge/Freezer should be disposed
of responsibly to ensure that it does not
contaminate the environment. It would be
advisable to contact your local council for
advice on the disposal of this unit.

14
TROUBLESHOOTING
Issue Possible Solutions
The Fridge/Freezer will not turn on
Check the unit is switched ON – Press the power button to turn on
Check the power source (voltage may be too low)
Check the power cable and all connections from the power source
to Fridge/Freezer
The contents of the fridge are freezing The temperature has been set too low, therefore increase the temperature
setting.
Poor refrigeration performance
Too much food has been put inside the unit
Temperature of the food put inside the fridge is too high
Ensure lid is closed properly
Ensure power source has sufficient voltage
There is poor ventilation around the fridge
Ambient temperature is very high
Temperature is not set correctly
There is a “water flow” type of noise from inside
the unit This is normal, caused by the flow of refrigerant
There is a noise from the unit
Ensure unit is on a flat level surface
Check for vibrations in surrounding objects
Fridge/Freezer does not work and display does
not illuminate
There is no voltage present in the 12V/24V cigarette lighter socket in your
vehicle. The ignition must be switched ON in most vehicles to apply current
to the cigarette lighter socket
No voltage present in the AC voltage socket. Try using another plug socket
The 240V AC adaptor is defective. This can be replaced by contacting after
sales support on 1300 555 197.
Fridge/Freezer does not work and display does
not illuminate when operating from the 12V/24V
cigarette lighter socket with ignition switched ON.
The cigarette lighter socket fuse in vehicle is defective and must be replaced
The cigarette lighter socket in vehicle must be cleaned or the plug has not been
assembled correctly.
The display shows an error message (F1)
and the Fridge/Freezer does not cool
Connected to DC power source, the Fridge/Freezer has switched off.
This may be due to low voltage. Check Battery Monitor setting is on LOW.
Re-start vehicle to increase battery voltage level. Test and charge battery
The Fridge/Freezer has switched off due to an internal fault. Contact After Sales
Support 1300 555 197

15
ERROR CODE INFORMATION
SPECIFICATIONS
Error
Code Possible Cause Solution
F1 Low voltage to fridge
DC - Increase voltage of DC power source/Check all connections
AC - Replace defective 240V AC Power adaptor
F2 Condensor Fan Faulty Contact After Sales Support 1300 555 197 to arrange repair
F3 Compressor over pressure Disconnect power to fridge for 20 minutes & attempt re-start
F4 Compressor not kicking in Contact After Sales Support 1300 555 197 to arrange repair
F5 Over Temperature of the compressor & electronics Disconnect power to fridge for 20 minutes & attempt re-start
F7 Temperature Sensor Faulty Contact After Sales Support 1300 555 197 to arrange repair
Model ELE-FF045S-G ELE-FF080D-G
Capacity 45lt Single Zone 80lt Dual Zone
Weight 21kg 29kg
Dimensions 621mm W x 485mm D x 469mm H 880mm W x 570mm D x 455mm H
Compressor LG BSA025LAVV LG BSA025LAVV
Current Draw 3.75A 12V/1.875A 24V 3.75A 12V/1.875A 24V
Cooling Range +20oC to -20oC +20oC to -20oC
Power Input 45W 60w
Insulation PU Foam PU Foam
Material Metal Cabinet & Lid, Aluminium Lining Metal Cabinet & Lid, Aluminium Lining

Made in China
Designed & Imported by:
Adventure Trading Australia Pty Ltd,
71 Charles Ulm Place,
Eagle Farm, QLD 4009
AUSTRALIA
P: 1300 362 921
OZtrail®is a registered trademark of
Adventure Trading Australia Pty Ltd
www.oztrail.com.au
facebook.com/OZtrailAustralia
WARRANTY
Adventure Trading Australia P/L warrants this product against defects for a period of two years
from the date of purchase. Adventure Trading Australia P/L will repair or replace the product, at
its discretion, should a warrantable defect arise within the warranty period. If the exact model is
unavailable a model of equivalent nature will be substituted at our discretion. This warranty excludes
faults and failures caused by improper use and abuse; fair wear and tear; or failure to follow
instructions regarding care and maintenance. Products used for a commercial nature are not covered
by this warranty against defects. A warranty may be claimed by returning the product to its place of
purchase, with a detailed proof-of-purchase clearly showing the date and detail of the purchase or
contacting Adventure Trading Australia P/L directly.
You can contact Adventure Trading Australia P/L Customer Service by phone on 1300 555 197,
in writing: PO Box 1110, Eagle Farm QLD 4009. The benefits under Adventure Trading Australia P/L
warranty against defects are in addition to other rights and remedies under law in relation to goods
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced
if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
For more detailed information and an explanation of these terms see www.oztrail.com.au/warranty or
email [email protected]
