Panasonic RP-BTS30 Technical specifications

Basic Operating Instructions
Digital Wireless Stereo Earphones
Model No. RP-BTS30
E
SQT1252-2
M1215KZ2047
En
Dear customer
Thank you for purchasing this product.
Please read these instructions carefully before using this product, and save this
manual for future use.
More detailed operating instructions are available in “Operating
Instructions (PDF format)”.
To read it, download it from the website.
http://panasonic.jp/support/global/cs/accessories/oi/rp_bts30/
• Click the desired language.
●The Bluetooth®word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Panasonic Corporation is
under license.
Other trademarks and trade names are those of their respective owners.
●Other system names and product names appearing in this document are in
general the registered trademarks or trademarks of the respective developer
companies.
Note that the ™ mark and ®mark do not appear in this document.
Accessories
Please check and identify the supplied accessories.
1 USB charging cord 1 Carrying pouch 1 Earpieces set (L, S)
• M-size earpieces are attached
at the time of purchase.
About water resistance
IPX4 equivalent
Protected against splashing water.
(Securely close the USB lid.)
For the United Kingdom and Ireland customers
Sales and Support Information
Customer Communications Centre
• For customers within the U.K.:
0344 844 3899
• For customers within Ireland:
01289 8333
• Monday - Friday 9:00am - 5:00pm (Excluding public holidays).
• For further support on your product, please visit our website:
www.panasonic.co.uk
Direct Sales at Panasonic U.K.
• Order accessory and consumable items for your product with ease and
confidence by phoning our Customer Communications Centre -
Monday - Friday 9:00am - 5:00pm (Excluding public holidays).
• Or go on line through our Internet Accessory ordering application at www.pas-
europe.com
• Most major credit and debit cards accepted.
• All enquiries transactions and distribution facilities are provided directly by
Panasonic U.K.
• It couldn’t be simpler!
• Also available through our Internet is direct shopping for a wide range of finished
products. Take a browse on our website for further details.
Safety precautions
■Unit
• Avoid using or placing this unit near sources of heat.
• Do not listen with this unit at high volume in places where you need to hear
sounds from the surrounding environment for safety, such as at railroad
crossings, and construction sites.
• Do not block the ventilation of this unit with items such as cloth for long periods
of time while charging or while the power is on.
■Earpieces
• Keep the earpieces out of reach of children to prevent swallowing.
■Allergies
• Discontinue use if you experience discomfort with the earphones or any other
parts that directly contact your skin.
• Continued use may cause rashes or other allergic reactions.
■Precautions for listening with the Earphones
• Do not use your earphones at a high volume. Hearing experts advise against
continuous extended play.
• If you experience a ringing in your ears, reduce volume or discontinue use.
• Do not use while operating a motorised vehicle. It may create a traffic hazard
and is illegal in many areas.
• You should use extreme caution or temporarily discontinue use in potentially
hazardous situations.
This unit may receive radio interference caused by mobile telephones during use.
If such interference occurs, please increase separation between this unit and the
mobile telephone.
This unit is intended for use in moderate and tropical climates.
■USB
• Do not use any other USB charging cords except the supplied one.
Caution: Use only the supplied USB charging cord when connecting to a
computer.
Maintenance
Clean this unit with a dry and soft cloth.
• Do not use solvents including benzine, thinner, alcohol, kitchen detergent, a
chemical wiper, etc. This might cause the exterior case to be deformed or the
coating to come off.
Keeping the battery performance
• During the long period of disuse, full charge this unit once every 6 months to
keep the battery performance.
Troubleshooting guide
Before requesting service, make the following checks. If you are in doubt about
some of the check points, or if the remedies indicated do not solve the problem,
consult your dealer for instructions.
General
The unit does not respond
• Connect the unit to a computer using the USB charging cord. The unit will be
reset.
Power supply and charging
Cannot charge the unit
• Make sure the computer is turned on and is not on standby or sleep mode.
• Is the USB port you are currently using working properly? If your computer has
other USB ports, unplug the connector from its current port and plug it into one of
the other ports.
• If the measures mentioned above are not applicable, unplug the USB charging
cord and plug it in again.
• If the charge time and operating time become shortened, the battery may have
run down. (Number of charging times of the installed battery: Approximately
300.)
LED does not light during charging / Charging takes longer
• Is the USB charging cord (supplied) connected firmly to the USB terminal of the
computer? (→1 “Charging”)
• Make sure to charge in a room temperature between 10 °C and 35 °C.
The power does not turn on
• Is the unit being charged? The power cannot be turned on during charging.
(→1 “Charging”)
Bluetooth®device connection
The device cannot be connected
• Delete the pairing information for this unit from the Bluetooth®device, then pair
them again. (→2 “Wireless pairing”)
Sound and audio volume
No sound
• Make sure that the unit and the Bluetooth®device are connected correctly.
(→2 “Wireless pairing”)
• Check if music is playing on the Bluetooth®device.
• Make sure that the unit is turned on and the volume is not set too low.
• Pair and connect the Bluetooth®device and the unit again. (→2 “Wireless
pairing”)
Low volume
• Increase the volume of the unit. (→3 “Enjoy !”)
• Increase the volume on the Bluetooth®device.
Sound from the device is cut off / Sound quality is bad
• Sound may be disrupted if signals are blocked. Do not fully cover this unit with
the palm of your hand, etc.
• The device may be out of the 10 m communication range. Move the device
closer to this unit.
• Remove any obstacle between this unit and the device.
• Switch off any wireless LAN device when not in use.
• A communication problem may arise if the battery is not fully charged. Charge
the unit. (→1 “Charging”)
Phone calls
You cannot hear the other person
• Make sure that the unit and the Bluetooth®enabled phone are turned on.
• Check if the unit and the Bluetooth®enabled phone are connected.
(→2 “Wireless pairing”)
• Check the audio settings of the Bluetooth®enabled phone. Switch the calling
device to the unit if it is set to the Bluetooth®enabled phone.
• If the volume of the other person’s voice is too low, increase the volume of both
the unit and the Bluetooth®enabled phone.
EU
Manufactured by:
Panasonic Corporation
Kadoma, Osaka, Japan
Importer for Europe:
Panasonic Marketing Europe GmbH
Panasonic Testing Centre
Winsbergring 11, 22525 Hamburg, Germany
Web Site: http://www.panasonic.com
© Panasonic Corporation 2015-2017
Part names
Left Right
Earphone
Remote controller
Earpiece
Microphone
LED indicator light
Charging terminal
USB lid
Clip
Charging Wireless pairing
！
1.5 hours
5 sec.
LED indicator light • Remote controller
• LED indicator light will blink.
Off
Red Blue
LED lighting colour
Enjoy !
㽈
♪
㽈
♪
6 hours
Power on/off
Operating time Auto power off
BEEP
5 min.
Press for 3 sec.
Off
Off
On Off
Remote controlling
Press for
2 sec.
Press for
2 sec.
How to wear the
earphones
SQT1252-2 (En)

To remove the battery when disposing
of this unit
The following instructions are not intended for repairing purposes but for
the disposal of this unit. This unit is not restorable once disassembled.
When disposing of this unit, take out the battery installed in this unit and recycle it.
Danger
As the rechargeable battery is specifically for this product, do not use it for any other
device.
Do not charge the removed battery.
• Do not heat or expose to flame.
• Do not leave the battery(ies) in a car exposed to direct sunlight for a long period of time with
doors and windows closed.
• Do not pierce the battery with a nail, subject it to an impact, or dismantle or modify it.
• Do not let the wires touch any other metal or each other.
• Do not carry or store the battery with a necklace, hair pin, or the like.
Doing so may cause the battery to generate heat, ignite, or rupture.
Warning
Do not place the removed battery, and other items within reach of infants.
Accidental swallowing of such an item may have an adverse effect on the body.
• In the event that you think such an item has been swallowed, consult a doctor immediately.
In the event of fluid leaking from the battery, take the following measure, and do not touch
the fluid with bare hands.
Fluid entering into an eye may cause loss of eyesight.
• Wash the eye with water immediately without rubbing it, and then consult a doctor.
Fluid getting on your body or clothes may cause inflammation of the skin or injury.
• Sufficiently rinse with clean water, and then consult a doctor.
A lithium-ion polymer rechargeable battery is built in to the left earphone. Please
discard according to local regulations.
When disposing this product, disassemble properly by following the procedure, and
remove the internal rechargeable battery.
• Disassemble after the battery runs out.
• When disposing of the battery, please contact your local authorities or dealer and ask for the
correct method of disposal.
A
1
A
2
B
3
B
4
1Hold the top of the left earphone (L), and put a straight-slot screwdriver
(commercially available) under the upper cover A
• Make sure to keep fingers away from the tip of the screwdriver.
• Select a screwdriver to be large enough for a space under the upper cover.
2Use the screwdriver for leverage, and push the upper cover Aupward
• Be careful not to touch the battery with the screwdriver.
3Hold the battery B, and remove it
4Pull off the battery Band separate it from the left earphone by cutting off
the wires, one by one, with scissors
• Insulate the wire parts of the removed battery with cellophane tape.
• Do not damage or dismantle the battery.
Specifications
■General
Power supply
DC 5 V, 500 mA
(Internal battery: 3.7 V (Li-polymer
90 mAh))
Operating time*1(SBC mode) Approx. 6 hours
Charging time*2(25 ºC) Approx. 1.5 hours
Charging temperature range 10 ºC to 35 ºC
Operating temperature range 0 ºC to 40 ºC
Operating humidity range 35%RH to 80%RH (no condensation)
Mass Approx. 20 g
Water resistant IPX4 equivalent
*1It may be shorter depending on the operating conditions.
*2Time taken to recharge from empty to full.
■Bluetooth®section
Bluetooth®system specification Ver. 4.1
Wireless equipment classification Class 2 (2.5 mW)
Frequency band 2402 MHz to 2480 MHz
Max RF power 4 dBm
Supported profiles A2DP, AVRCP, HSP, HFP
Supported codec SBC
Operating distance Up to 10 m
■Speaker section
Driver units 9 mm
■Terminal section
DC IN DC 5 V, 500 mA
■Microphone section
Type Mono
■Accessory section
USB charging cord 0.1 m
●Specifications are subject to change without notice.
Disposal of Old Equipment and Batteries
Only for European Union and countries with recycling systems
These symbols on the products, packaging, and/or accompanying
documents mean that used electrical and electronic products and
batteries must not be mixed with general household waste.
For proper treatment, recovery and recycling of old products and
used batteries, please take them to applicable collection points in
accordance with your national legislation.
By disposing of them correctly, you will help to save valuable
resources and prevent any potential negative effects on human
health and the environment.
For more information about collection and recycling, please contact
your local municipality.
Penalties may be applicable for incorrect disposal of this waste, in
accordance with national legislation.
Note for the battery symbol (bottom symbol):
This symbol might be used in combination with a chemical symbol. In
this case it complies with the requirement set by the Directive for the
chemical involved.
Declaration of Conformity (DoC)
Hereby, “Panasonic Corporation” declares that this product is in compliance with
the essential requirements and other relevant provisions of Directive 2014/53/EU.
Customers can download a copy of the original DoC to our RE products from our
DoC server:
http://www.doc.panasonic.de
Contact to Authorized Representative:
Panasonic Marketing Europe GmbH, Panasonic Testing Centre, Winsbergring 15,
22525 Hamburg, Germany
For Singapore only
Complies with
IDA Standards
DB01017
For Thailand only
This telecommunication equipment conforms to NTC/NBTC technical
requirement.
Limited Warranty (ONLY FOR AUSTRALIA)
Panasonic Warranty
1. The product is warranted for 12 months from the date of purchase. Subject to the conditions of this warranty
Panasonic or its Authorised Service Centre will perform necessary service on the product without charge for
parts or labour, if in the opinion of Panasonic, the product is found to be faulty within the warranty period.
2. This warranty only applies to Panasonic products purchased in Australia and sold by Panasonic Australia or
its Authorised Distributors or Dealers and only where the products are used and serviced within Australia or
it's territories. Warranty cover only applies to service carried out by a Panasonic Authorised Service Centre
and only if valid proof of purchase is presented when warranty service is requested.
3. This warranty only applies if the product has been installed and used in accordance with the manufacturer’s
recommendations (as noted in the operating instructions) under normal use and reasonable care (in the
opinion of Panasonic). The warranty covers normal domestic use only and does not cover damage,
malfunction or failure resulting from use of incorrect voltages, incorrect installation, accident, misuse, neglect,
build-up of dirt or dust, abuse, maladjustment of customer controls, mains supply problems, thunderstorm
activity, infestation by insects or vermin, tampering or repair by unauthorised persons (including unauthorised
alterations), introduction of sand, humidity or liquids, commercial use such as hotel, office, restaurant, or other
business or rental use of the product, exposure to abnormally corrosive conditions or any foreign object or
matter having entered the product.
4. This warranty does not cover the following items unless the fault or defect existed at the time of purchase:
(a) Cabinet Part(s) (e) DVD, Blu-ray or Recordable Discs
(b) Video or Audio Tapes (f) Video / Audio Heads from wear and tear in normal use
(c) SD cards or USB devices (g) Information stored on Hard Disk Drive, USB stick or SD card
(d) User replaceable Batteries (h) DTV reception issues caused by TV Aerial / Cabling / Wall socket(s)
etc
5. Some products may be supplied with Ethernet connection hardware. The warranty is limited on such products
and will not cover
(a) Internet and or DLNA connection / setup related problems
(b) Access fees and or charges incurred for internet connection
(c) The use of incompatible software or software not specifically stipulated in the product operations manual;
and
(d) Any indirect or consequential costs associated with the incorrect use or misuse of the hardware, its
connection to the internet or any other device.
6. To claim warranty service, when required, you should:
• Telephone Panasonic’s Customer Care Centre on 132600 or visit our website referred to below and use
the Service Centre Locator for the name/address of the nearest Authorised Service Centre.
• Send or take the product to a Panasonic Authorised Service Centre together with your proof of purchase
receipt as a proof of purchase date. Please note that freight and insurance to and / or from your nearest
Authorised Service Centre must be arranged by you.
• Note that home or pick-up/delivery service is available for the following products in the major metropolitan
areas of Australia or the normal operating areas of the nearest Authorised Service Centres:
- Plasma/LCD televisions / displays (screen size greater than 103 cm)
7. The warranties hereby conferred do not extend to, and exclude, any costs associated with the installation, de-
installation or re-installation of a product, including costs related to the mounting, de-mounting or remounting
of any screen, (and any other ancillary activities), delivery, handling, freighting, transportation or insurance of
the product or any part thereof or replacement of and do not extend to, and exclude, any damage or loss
occurring by reason of, during, associated with, or related to such installation, de-installation, re-installation or
transit.
Panasonic Authorised Service Centres are located in major metropolitan areas and most regional centres of
Australia, however, coverage will vary dependant on product. For advice on exact Authorised Service Centre
locations for your product, please telephone our Customer Care Centre on 132600 or visit our website and use
the Service Centre Locator.
In addition to your rights under this warranty, Panasonic products come with consumer guarantees that cannot be
excluded under the Australian Consumer Law. If there is a major failure with the product, you can reject the
product and elect to have a refund or to have the product replaced or if you wish you may elect to keep the goods
and be compensated for the drop in value of the goods. You are also entitled to have the product repaired or
replaced if the product fails to be of acceptable quality and the failure does not amount to a major failure.
If there is a major failure in regard to the product which cannot be remedied then you must notify us within a
reasonable period by contacting the Panasonic Customer Care Centre. If the failure in the product is not a major
failure then Panasonic may choose to repair or replace the product and will do so in a reasonable period of time
from receiving notice from you.
THIS WARRANTY CARD AND THE PURCHASE DOCKET (OR SIMILAR PROOF OF PURCHASE)
SHOULD BE RETAINED BY THE CUSTOMER AT ALL TIMES
If you require assistance regarding warranty conditions or any other enquiries, please visit the
Panasonic Australia website www.panasonic.com.au or contact by phone on 132 600
If phoning in, please ensure you have your operating instructions available.
Panasonic Australia Pty. Limited
ACN 001 592 187 ABN 83 001 592 187
1 Innovation Road, Macquarie Park NSW 2113
PRO-031-F11 Issue: 4.0 01-01-2011
