Panasonic PT-TW340 User manual

Operating Instructions
Functional Manual
LCD Projector Commercial Use
Thank you for purchasing this Panasonic Product.
■Before operating this product, please read the instructions carefully, and save this manual
for future use.
■ Before using your projector, be sure to read “Read this rst!” (xpages 2 to 9).
Model No.
 PT-TW340
 PT-TW250
 PT-TX400
 PT-TX310
 PT-TX210
ENGLISH
TQBJ0699

Read this rst!
2 - ENGLISH
Read this rst!
WARNING: THIS APPARATUS MUST BE EARTHED.
WARNING: To prevent damage which may result in re or shock hazard, do not expose this appliance to rain
or moisture.
This device is not intended for use in the direct eld of view at visual display workplaces. To avoid
incommoding reexions at visual display workplaces this device must not be placed in the direct
eld of view.
The equipment is not intended for used at a video workstation in compliance BildscharbV.
The sound pressure level at the operator position is equal or less than 70 dB (A) according to ISO 7779.
WARNING:
1. Remove the plug from the mains socket when this unit is not in use for a prolonged period of time.
2. To prevent electric shock, do not remove cover. No user serviceable parts inside. Refer servicing to qualied
service personnel.
3. Do not remove the earthing pin on the mains plug. This apparatus is equipped with a three prong earthing
type mains plug. This plug will only t an earthing-type mains socket. This is a safety feature. If you are un-
able to insert the plug into the mains socket, contact an electrician. Do not defeat the purpose of the earthing
plug.
CAUTION: To assure continued compliance, follow the attached installation instructions. This includes using
the provided power cord and shielded interface cables when connecting to computer or peripheral
devices. Also, any unauthorized changes or modications to this equipment could void the user's
authority to operate this device.
Product information (for Turkey only)
EEE Yönetmeliğine Uygundur.
EEE Complies with Directive of Turkey.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT
TO RAIN OR MOISTURE.
o
AVERTISSEMENT:RISQUEDECHOCÉLECTRIQUE
NEPASOUVRIR.
WARNUNG:ZURVERMEIDUNGEINES
ELEKTRISCHENSCHLAGESGERÄTNICHTÖFFNEN.
ПРЕДУПРЕЖДЕНИЕ:ОПАСНОСТЬ ПОРАЖЕНИЯ
ЭЛЕКТРИЧЕСКИМ ТОКОМ НЕ ОТКРЫВАТЬ.
경고:감전 위험이 있으므로 열지마십시오.
The lightning ash with arrowhead symbol, within an equilateral triangle, is intended to alert the
user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may
be of sufcient magnitude to constitute a risk of electric shock to persons.
7The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the
product.
This is a device to project images onto a screen, etc., and is not intended for use as indoor lighting in a
domestic environment. Directive 2009/125/EC
Importer's name and address within the European Union
Panasonic Marketing Europe GmbH
Panasonic Testing Center
Winsbergring 15, 22525 Hamburg, Germany

Read this rst!
ENGLISH - 3
CAUTION (North/Middle/South America)
CAUTION: This equipment is equipped with a three-pin grounding-type power
plug. Do not remove the grounding pin on the power plug. This plug
will only t a grounding-type power outlet. This is a safety feature. If
you are unable to insert the plug into the outlet, contact an electrician.
Do not defeat the purpose of the grounding plug. Do not remove
FCC NOTICE (USA)
Declaration of Conformity
Model Number: PT-TW340 / PT-TW250 / PT-TX400 / PT-TX310 / PT-TX210
Trade Name: Panasonic
Responsible Party: Panasonic Corporation of North America
Address: Two Riverfront Plaza, Newark, NJ 07102-5490
General Contact: http://www.panasonic.com/contactinfo
Projector Contact: http://www.panasonic.net/avc/projector/
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
To assure continued compliance, follow the attached installation instructions and do not make any unauthorized
modications.
CAUTION:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the
following measures:
fReorient or relocate the receiving antenna.
fIncrease the separation between the equipment and receiver.
fConnect the equipment into an outlet on a circuit different from that to which the receiver is connected.
fConsult the dealer or an experienced radio/BD technician for help.
The user may nd the booklet “Something About Interference” available from FCC local regional ofces helpful.
FCC Warning:
To assure continued FCC emission limit compliance, follow the attached installation instructions. This includes
using the provided power cord and shielded interface cables when connecting to computer or peripheral
devices. Also, any unauthorized changes or modications to this equipment could void the user’s authority to
operate this device.
NOTIFICATION (Canada)
This class B digital apparatus complies with Canadian ICES-003.
WARNING:
• Not for use in a computer room as dened in the Standard for the Protection of Electronic Computer/Data
Processing Equipment, ANSI/NFPA 75.
• For permanently connected equipment, a readily accessible disconnect device shall be incorporated in the
building installation wiring.
• For pluggable equipment, the socket-outlet shall be installed near the equipment and shall be easily
accessible.
Notice (USA only):
• This product has a High Intensity Discharge (HID) lamp that contains mercury. Disposal may be regulated
in your community due to environmental considerations. For disposal or recycling information, please visit
Panasonic website: http://www.panasonic.com/environmental or call 1-888-769-0149.

Read this rst!
4 - ENGLISH
IMPORTANT: THE MOULDED PLUG (U.K. only)
FOR YOUR SAFETY, PLEASE READ THE FOLLOWING TEXT CAREFULLY.
This appliance is supplied with a moulded three pin mains plug for your safety and convenience. A 13 amp fuse is tted in
this plug. Should the fuse need to be replaced, please ensure that the replacement fuse has a rating of 13 amps and that it
is approved by ASTA or BSI to BS1362.
Check for the ASTA mark or the BSI mark on the body of the fuse.
If the plug contains a removable fuse cover, you must ensure that it is retted when the fuse is replaced. If you lose the fuse
cover, the plug must not be used until a replacement cover is obtained. Areplacement fuse cover can be purchased from an
Authorised Service Center.
If the tted moulded plug is unsuitable for the mains socket in your home, then the fuse should be removed and the plug cut
off and disposed of safely. There is a danger of severe electrical shock if the cut off plug is inserted into any 13 amp socket.
If a new plug is to be tted, please observe the wiring code as shown below.
If in any doubt, please consult a qualied electrician.
WARNING: THIS APPLIANCE MUST BE EARTHED.
IMPORTANT: The wires in this mains lead are coloured in accordance with the following code:
Green - and - Yellow: Earth
Blue: Neutral
Brown: Live
As the colours of the wire in the mains lead of this appliance may not correspond with the coloured markings identifying the
terminals in your plug, proceed as follows.
The wire which is coloured GREEN - AND - YELLOW must be connected to the terminal in the plug which is
marked with the letter E or by the Earth symbol or coloured GREEN or GREEN - AND - YELLOW.
The wire which is coloured BLUE must be connected to the terminal in the plug which is marked with the
letter N or coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal in the plug which is marked with the
letter L or coloured RED.
How to replace the fuse: Open the fuse compartment with a screwdriver and replace the fuse.
13A250V BS1363/A
HE-8
N
ASA
L

Read this rst!
ENGLISH - 5
WARNING:
POWER
The wall outlet or the circuit breaker shall be installed near the equipment and shall be easily acces-
sible when problems occur. If the following problems occur, cut off the power supply immediately.
Continued use of the projector in these conditions will result in re or electric shock.
zIf foreign objects or water get inside the projector, cut off the power supply.
zIf the projector is dropped or the cabinet is broken, cut off the power supply.
zIf you notice smoke, strange smells or noise coming from the projector, cut off the power supply.
Please contact an Authorized Service Center for repairs, and do not attempt to repair the projector yourself.
During a thunderstorm, do not touch the projector or the cable.
Electric shocks can result.
Do not do anything that might damage the power cord or the power plug.
If the power cord is used while damaged, electric shocks, short-circuits or re will result.
zDo not damage the power cord, make any modications to it, place it near any hot objects, bend it
excessively, twist it, pull it, place heavy objects on top of it or wrap it into a bundle.
Ask an Authorized Service Center to carry out any repairs to the power cord that might be necessary.
Completely insert the power plug into the wall outlet and the power connector into the projector
terminal.
If the plug is not inserted correctly, electric shocks or overheating will result.
zDo not use plugs which are damaged or wall outlets which are coming loose from the wall.
Do not use anything other than the provided power cord.
zFailure to observe this will result in electric shocks or re. Please note that if you do not use the provided
power cord to ground the device on the side of the outlet, this may result in electric shocks.
Clean the power plug regularly to prevent it from becoming covered in dust.
Failure to observe this will cause a re.
zIf dust builds up on the power plug, the resulting humidity can damage the insulation.
zIf not using the projector for an extended period of time, pull the power plug out from the wall outlet.
Pull the power plug out from the wall outlet and wipe it with a dry cloth regularly.
Do not handle the power plug and power connector with wet hands.
Failure to observe this will result in electric shocks.
Do not overload the wall outlet.
If the power supply is overloaded (ex., by using too many adapters), overheating may occur and re will result.
ON USE/INSTALLATION
Do not place liquid containers on top of the projector.
If water spills onto the projector or gets inside it, re or electric shocks will result.
If any water gets inside the projector, contact an Authorized Service Center.
Do not place the projector on soft materials such as carpets or sponge mats.
Doing so will cause the projector to overheat, which can cause burns, re or damage to the projector.
Do not set up the projector in humid or dusty places or in places where the projector may come into
contact with oily smoke or steam.
Using the projector under such conditions will result in re, electric shocks or components deterioration. Com-
ponents deterioration (such as ceiling mount brackets) may cause the projector which is mounted on the ceiling
to fall down.
Do not install this projector in a place which is not strong enough to take the full weight of the projec-
tor or on top of a surface which is sloped or unstable.
Failure to observe this will cause projector to fall down or tip over the projector, and severe injury or damage
could result.
Do not place another projector or other heavy objects on top of the projector.
Failure to observe this will cause the projector to become unbalanced and fall, which could result in damage or
injury. The projector will be damaged or deformed.
Installation work (such as ceiling mount bracket) should only be carried out by a qualied technician.
If installation is not carried out and secured correctly it can cause injury or accidents, such as electric shocks.
zDo not use anything other than an authorized ceiling mount bracket.
zBe sure to use the wire provided with the projector mount bracket for ceiling mount as an extra safety mea-
sure to prevent the projector from falling down (Install in a different location to the ceiling mount bracket).

Read this rst!
6 - ENGLISH
WARNING:
Do not cover the air intake port or the air exhaust port.
Doing so will cause the projector to overheat, which can cause re or damage to the projector.
zDo not place the projector in narrow, badly ventilated places.
zDo not place the projector on cloth or papers, as these materials could be drawn into the air intake port.
Do not place your hands or other objects close to the air exhaust port.
Doing so will cause burns or damage your hands or other objects.
zHeated air comes out of the air exhaust port. Do not place your hands or face, or objects which cannot
withstand heat close to this port.
Do not look and place your skin into the lights emitted from the lens while the projector is being used.
Doing so can cause burns or loss of sight.
zStrong light is emitted from the projector’s lens. Do not look or place your hands directly into this light.
zBe especially careful not to let young children look into the lens. In addition, turn off the power and discon-
nect the power plug when you are away from the projector.
Do not insert any foreign objects into the projector.
Doing so will cause re or electric shocks.
zDo not insert any metal objects or ammable objects into the projector or drop them onto the projector.
Never attempt to remodel or disassemble the projector.
High voltages can cause re or electric shocks.
zFor any inspection, adjustment and repair work, please contact an Authorized Service Center.
Do not allow metal objects, ammable objects, or liquids to enter inside of the projector. Do not allow
the projector to get wet.
Doing so may cause short circuits or overheating, and result in re, electric shock, or malfunction of the projec-
tor.zDo not place containers of liquid or metal objects near the projector.
zIf liquid enters inside of the projector, consult your dealer.
zParticular attention must be paid to children.
Use the ceiling mount bracket specied by Panasonic.
Defects in the ceiling mount bracket will result in falling accidents.
zAttach the supplied safety cable to the ceiling mount bracket to prevent the projector from falling down.
ACCESSORIES
Do not use or handle the batteries improperly, and refer to the following.
Failure to observe this will cause burns, batteries to leak, overheat, explode or catch re.
zDo not use unspecied batteries.
zDo not disassemble dry cell batteries.
zDo not heat the batteries or place them into water or re.
zDo not allow the + and
-
terminals of the batteries to come into contact with metallic objects such as neck-
laces or hairpins.
zDo not store or carry batteries together with metallic objects.
zStore the batteries in a plastic bag and keep them away from metallic objects.
zMake sure the polarities (+ and
-
) are correct when inserting the batteries.
zDo not use a new battery together with an old battery or mix different types of batteries.
zDo not use batteries with the outer cover peeling away or removed.
zRemove the empty batteries from the remote control at once.
zInsulate the battery using tape or something similar before disposal.
Do not allow children to reach the batteries.
zThe battery can cause personal injury if swallowed.
zIf swallowed, seek medical advice immediately.
If the battery uid leaks, do not touch it with bare hands, and take the following measures if necessary.
zBattery uid on your skin or clothing could result in skin inammation or injury.
Rinse with clean water and seek medical advice immediately.
zBattery uid coming in contact with your eyes could result in loss of sight.
In this case, do not rub your eyes. Rinse with clean water and seek medical advice immediately.

Read this rst!
ENGLISH - 7
WARNING:
Do not disassemble the lamp unit.
If the lamp breaks, it could cause injury.
Lamp replacement
The lamp has high internal pressure. If improperly handled, an explosion and severe injury or accidents will
result.
zThe lamp can easily explode if struck against hard objects or dropped.
zBefore replacing the lamp, be sure to disconnect the power plug from the wall outlet.
Electric shocks or explosions can result if this is not done.
zWhen replacing the lamp, turn the power off and allow the lamp it to cool for at least 1 hour before handling
it otherwise it can cause burns.
Do not allow infants or pets to touch the remote control unit.
zKeep the remote control unit out of the reach of infants and pets after using it.
Do not use the supplied power cord with devices other than this projector.
zUsing the supplied power cord with devices other than this projector may cause short circuits or overheat-
ing, and result in electric shock or re.
Remove the depleted batteries from the remote control promptly.
zLeaving them in the unit may result in uid leakage, overheating, or explosion of the batteries.
CAUTION:
POWER
When disconnecting the power cord, be sure to hold the power plug and power connector.
If the power cord itself is pulled, the lead will become damaged, and re, short-circuits or serious electric
shocks will result.
When not using the projector for an extended period of time, disconnect the power plug from the wall
outlet and remove the batteries from the remote control.
Disconnect the power plug from the wall outlet before carrying out any cleaning and replacing the unit.
Electric shocks can result if this is not done.
ON USE/INSTALLATION
Do not place heavy objects on top of the projector.
Failure to observe this will cause the projector to become unbalanced and fall, which could result in damage or
injury. The projector will be damaged or deformed.
Do not put your weight on this projector.
You could fall or the projector could break, and injury will result.
zBe especially careful not to let young children stand or sit on the projector.
Do not place the projector in extremely hot locations.
Doing so will cause the outer casing or internal components to deteriorate, or result in re.
zTake particular care in locations exposed to direct sunlight or near stoves.
Always disconnect all cables before moving the projector.
Moving the projector with cables still attached can damage the cables, which will cause re or electric shocks to
occur.
Never plug headphones and earphones into <VARIABLE AUDIO OUT> terminal.
Excessive sound pressure from earphones and headphones can cause hearing loss.
ACCESSORIES
Do not use the old lamp unit.
If used it could cause lamp explosion.
If the lamp has broken, ventilate the room immediately. Do not touch or bring your face close to the
broken pieces.
Failure to observe this will cause the user to absorb the gas which was released when the lamp broke and which
contains nearly the same amount of mercury as uorescent lamps, and the broken pieces will cause injury.
zIf you believe that you have absorbed the gas or that the gas has got into your eyes or mouth, seek medical
advice immediately.
zAsk your dealer about replacing the lamp unit and check the inside of the projector.

Read this rst!
8 - ENGLISH
Brazil Only
Brasil Apenas
Manuseio de baterias usadas
BRASIL
Após o uso, as pilhas e /ou baterias deverão
ser entregues ao estabelecimento comercial
ou rede de assistência técnica autorizada.
Cobrir os terminais positivo (+) e negativo (-) com uma ta isolante adesiva, antes de depositar numa caixa
destinada para o recolhimento. O contato entre partes metálicas pode causar vazamentos, gerar calor, romper
a blindagem e produzir fogo. (Fig. 1)
Fig. 1
Como isolar os terminais
Não desmonte, não remova o invólucro, nem amasse a bateria. O gás liberado pela bateria pode irritar a
garganta, danicar o lacre do invólucro ou o vazamento provocar calor, ruptura da blindagem e produzir fogo
devido ao curto circuito dos terminais. Não incinere nem aqueça as baterias, elas não podem car expostas a
temperaturas superiores a 100 °C (212 °F). O gás liberado pela bateria pode irritar a garganta, danicar o lacre
do invólucro ou o vazamento provocar calor, ruptura da blindagem e produzir fogo devido ao curto circuito dos
terminais provocado internamente.
Evite o contato com o liquido que vazar das baterias. Caso isto ocorra, lave bem a parte afetada com bastante
água. Caso haja irritação, consulte um médico.
Remoção das baterias
1. Pressione a guia e levante a tampa. 2. Remova as baterias.
Fita Isolante
Fita Isolante
CAUTION:
MAINTENANCE
Ask your dealer about cleaning inside the projector once a year.
Continuous use while dust is accumulated inside the projector may result in re.
zFor cleaning fee, ask your dealer.

Read this rst!
ENGLISH - 9
To remove the battery
1. Press the guide and lift the cover. 2. Remove the batteries.
rTrademarks
fWindows, Windows Vista and Internet Explorer are registered trademarks or trademarks of Microsoft
Corporation in the United States and other countries.
fMac, Mac OS, OS X and Safari are trademarks of Apple Inc., registered in the United States and other
countries.
fHDMI, the HDMI logo and High-Denition Multimedia Interface is a trademark or registered trademark of HDMI
Licensing LLC.
fPJLink™ is a trademark or pending trademark in Japan, the United States, and other countries and regions.
fAdobe and Adobe Reader are trademarks or registered trademarks of Adobe Systems Inc. in the United States
and/or other countries.
fAll other names, company names, and product names mentioned in this manual are trademarks or registered
trademarks of their respective owners.
Please note that the ®and TM symbols are not specied in this manual.
rIllustrations in these operating instructions
fIllustrations of the projector, screen, and other parts may vary from the actual product.
rPage references
fReference pages in this manual are indicated as : (Æpage 00).
rTerms
fIn this manual, the “Wireless remote control unit” accessory is referred to as the “Remote control”.
fThe <INPUT/ENTER> button on the control panel is functioned as the <ENTER> button when the menu screen
is displayed. The operating procedure of menu screen is described as "Press the <ENTER> button" in this
manual in order to unify the control panel operation with the remote control operation.

10 - ENGLISH
Features of the Projector
Comfortable viewing in a bright
environment
▶The high contrast ratio 10 000 : 1 is
achieved in a compact body.
▶The low noise level 28 dB*1 supports
comfortable viewing during quiet scenes.
▶Supports comfortable viewing in a bright
room by pressing the <DAYLIGHT VIEW>
button on the remote control. (Daylight
View Lite function)
*1 When [Lamp control] is set to [ (Eco 2)]
Abundant Image correction Function
(Only for PT-TW340, PT-TW250, PT-TX400 and
PT-TX310)
▶H/V Keystone, Corner correction and
Curved correction functions allow you to
correct the image to t the screen.
Reduced maintenance costs
▶Maintenance costs are reduced by use of a
recommended lamp replacement interval of
8 000 H*1.
*1 When [Lamp control] is constantly set to
[ (Eco 2)] without switching to other modes
This time is only the target for replacement and not
the warranty time.
Quick Steps
For details, see the corresponding pages.
1. Set up your projector.
(xpage 26)
2. Connect with other devices.
(xpage 30)
3. Connect the power cord.
(xpage 34)
4. Power on.
(xpage 35)
5. Select the input signal.
(xpage 37)
6. Adjust the image.
(xpage 37)

ENGLISH - 11
Contents
Contents
Read this first! ............................................2
Chapter 1 Preparation
Precautions for use................................................. 14
Cautions when transporting.................................. 14
Cautions when installing....................................... 14
Security ................................................................15
Disposal................................................................15
Cautions on use ................................................... 16
Accessories..........................................................17
Contents of the supplied CD-ROM.......................17
Optional accessories ............................................18
About your projector............................................... 19
Remote control.....................................................19
Projector body......................................................20
Using the remote control........................................ 24
Inserting and Removing batteries......................... 24
Setting Remote control ID numbers.....................24
Chapter 2 Getting Started
Setting up................................................................. 26
Installation mode..................................................26
Parts for ceiling mount (Optional).........................26
Screen size and throw distance ........................... 27
Adjusting adjustable feet......................................29
Connecting............................................................... 30
Before connecting ................................................30
Connecting example : AV equipment ...................31
Connecting example : Computers ........................32
Chapter 3 Basic Operations
Powering on/off .......................................................34
Connecting the power cord .................................. 34
Power indicator.....................................................34
Powering On the Projector ...................................35
A PIN code input screen appears ........................ 35
Making adjustments and selections ..................... 36
Powering Off the Projector ...................................36
Projecting................................................................. 37
Selecting the input signal ..................................... 37
How to adjust the state of the image....................37
Basic operations by using the remote control..... 38
Using the automatic setup function......................38
Switching the input signal.....................................38
Switching the aspect ratio of the image................ 39
Using the keystone distortion and curved
correction functions...........................................39
Using the information function..............................40
Using the freeze function...................................... 40
Using the AV mute function ..................................40
Using the presentation timer function...................40
Switching the lamp power ....................................41
Using the digital zoom function ............................ 41
Controlling the volume of the speaker..................41
Switching the image mode...................................41
Using the mute function........................................ 42
Using the Daylight View Lite function...................42
Chapter 4 Settings
Menu Navigation...................................................... 44
Navigating through the menu...............................44
Main menu............................................................45
Sub-menu.............................................................46
[Input] menu............................................................. 48
Switching the input source ................................... 48
[Display] menu......................................................... 49
[Auto PC adj.].......................................................49
[Fine sync] ............................................................49
[H Position]...........................................................49
[V Position]...........................................................50
[H.Size].................................................................50
[Aspect] ................................................................50
[Project way].........................................................51
[Menu position].....................................................51
[Background display]............................................51
[System] ...............................................................51
[Color adjust] menu................................................. 52
[Image mode] .......................................................52
[Contrast]..............................................................52
[Brightness] ..........................................................52
[Color]...................................................................53
[Tint]......................................................................53
[Color temp.].........................................................53
[Red] / [Green] / [Blue].......................................... 53
[Sharpness]..........................................................54
[Daylight View]......................................................54
[Setting] menu .........................................................55
[On start]...............................................................55
[Standby mode]....................................................55
[High land]............................................................55
[Lamp control].......................................................56
[Cooling fast] ........................................................56
[Closed caption]....................................................56
[Key lock]..............................................................57
[Iris].......................................................................57
[Terminal].............................................................. 57
[Sound].................................................................57
[HDMI Setup]........................................................58
[Expand] menu.........................................................59
[Language] ...........................................................59
[Auto setup]..........................................................59
[Keystone] ............................................................61
Contents
Be sure to read “Read this rst!” from page 2.

12 - ENGLISH
[Logo] ...................................................................64
[Security] ..............................................................66
[Power management]...........................................67
[Filter counter] ......................................................68
[Test pattern].........................................................68
[Network]..............................................................69
[Remote control]...................................................70
[Factory default]....................................................70
[Memory Viewer] menu...........................................71
[Set Slide].............................................................71
[Slide Transition Effect].........................................71
[Sort Order]...........................................................71
[Rotate].................................................................71
[Best Fit] ...............................................................72
[Repeat]................................................................72
[Apply] ..................................................................72
[Info.] menu .............................................................73
[Info.] ....................................................................73
Network control.......................................................74
Network connections............................................74
Accessing from the Web browser.........................75
Using useful functions............................................ 79
Memory Viewer function.......................................79
USB Display function............................................81
Chapter 5 Maintenance
Power/Warning Indicators ...................................... 84
When an indicator lights up..................................84
Maintenance/replacement....................................... 86
Before performing maintenance/replacement...... 86
Maintenance.........................................................86
Replacing the unit.................................................88
Troubleshooting ......................................................91
Chapter 6 Appendix
Technical Information ............................................. 93
PJLink protocol.....................................................93
<SERIAL IN> terminal..........................................94
List of compatible signals.....................................97
Specications ..........................................................99
Dimensions............................................................101
Ceiling mount bracket safeguards....................... 102
Index.......................................................................103
Contents

ENGLISH - 13
Chapter 1 Preparation
This chapter describes things you need to know or check before using the projector.

14 - ENGLISH
Precautions for use
Cautions when transporting
fWhen transporting the projector, hold it securely by its bottom and avoid excessive vibration and impacts. Doing so may
damage the internal parts and result in malfunctions.
fDo not transport the projector with the adjustable feet extended. Doing so may damage the adjustable feet.
Cautions when installing
rDo not set up the projector outdoors.
The projector is designed for indoor use only.
rDo not set up the projector in the following locations.
fPlaces where vibration and impacts occur such as in a car or vehicle: Doing so may cause damage to internal components
or malfunction.
fNear the exhaust of an air conditioner: Depending on the conditions of use, the screen may uctuate in rare cases due
to the heated air from the air exhaust port or the hot or cooled air. Make sure that the exhaust from the projector or other
equipment, or the air from the air conditioner does not blow toward the front of the projector.
fPlaces with sharp temperature uctuations such as near lights (studio lamps): Doing so may shorten the life of the lamp, or
result in deformation of the outer case due to heat, which may cause malfunctions.
The operating environment temperature of the projector should be between 5 °C (41 °F) and 40 °C (104 °F) when using it
at elevations lower than 1 400 m (4 593') above sea level, and between 5 °C (41 °F) and 35 °C (95 °F) when using it at high
altitudes (between 1 400 m (4 593') and 2 700 m (8 858') above sea level).
fNear high-voltage power lines or near motors: Doing so may interfere with the operation of the projector.
rBe sure to ask a specialized technician when installing the product to a ceiling.
This requires an optional ceiling mount bracket. Be sure to use the Projector Mount Bracket together with the ceiling mount
bracket for high ceilings or low ceilings.
Model No.: ET-PKL100H (for high ceilings), ET-PKL100S (for low ceilings), ET-PKL430B (Projector Mount Bracket)
rWhen using the projector in the elevation of below 1 400 m (4 593'), make sure [High
land] is set to [Off].
Failure to do so may shorten the life of the internal parts and result in malfunctions.
rWhen using the projector in the elevation of above 1 400 m (4 593') and below 2 700 m
(8 858'), make sure [High land] is set to [On].
Failure to do so may shorten the life of the internal parts and result in malfunctions.
rDo not install the projector at elevations of 2 700 m (8 858') or higher above sea level.
Failure to do so may shorten the life of the internal parts and result in malfunctions.
rDo not tilt the projector or place it on its side.
Do not tilt the projector body more than approximately ±30 degrees vertically or ±15 degrees horizontally. Over tilting may
result in shortening the life of the components.
Within 15°
Within 15°
Within 30°
Within 30°
Chapter 1 Preparation - Precautions for use

ENGLISH - 15
rCautions when setting the projectors
fDo not stack the projectors.
fDo not use the projector supporting it by the top.
fDo not block the ventilation ports (intake and exhaust) of the projector.
fAvoid heating and cooling air from the air conditioning system directly blow to the ventilation ports (intake and exhaust) of
the projector.
fDo not install the projector in a conned space.
When placing the projector in a conned space, a ventilation and/or air conditioning system is required. Exhaust heat may
accumulate when the ventilation is not enough, triggering the protection circuit of the projector.
Security
Take safety measures against following incidents.
fPersonal information being leaked via this product.
fUnauthorized operation of this product by a malicious third party.
fInterfering or stopping of this product by a malicious third party.
Security instruction (Æpages 66, 76)
fMake your password as difcult to guess as possible.
fChange your password periodically.
fPanasonic or its afliate company never inquires a password directly to a customer. Do not tell your password in case you
receive such an inquiry.
fThe connecting network must be secured by rewall or others.
fSet a password for web control and restrict the users who can log in.
Note
fLAN function is not available for PT-TX210.
Disposal
When disposing of the product, ask your local authority or dealer about the correct methods of disposal.
The lamp contains mercury. When disposing of the used lamp unit, ask your nearest local authorities or dealer about proper
disposal of the unit.
Dispose of used batteries according to the instructions or your local disposal rule or guidelines.
over 500 mm
(19-11/16") over 1 000 mm
(39-3/8")
over 500 mm (19-11/16") over 200 mm
(7-7/8")
Chapter 1 Preparation - Precautions for use

16 - ENGLISH
Cautions on use
rTo get a good picture quality
fDraw curtains or blinds over windows and turn off any lights near the screen to prevent outside light or light from indoor
lamps from shining onto the screen.
fDepending on where the projector is used, heated air from an exhaust port or warm or cold air from an air conditioner can
cause a shimmering effect on screen.
Avoid use in locations where exhaust or streams of air from projector, other devices and air conditioners ow between the
projector and the screen.
fThe lens of projector is affected by the heat from the luminous source. Because of this, the focusing may not be stable right
after the power is turned on. Focusing is stabled after projecting image for 30 minutes and longer.
rDo not touch the surface of the projector lens with your bare hand.
If the surface of the lens becomes dirty from ngerprints or anything else, this will be magnied and projected onto the screen.
rLCD Panel
The display unit of this projector comprises three LCD panels. Although an LCD panel is a product of high-precision
technology, some of the pixels on the projected image may be missing or constantly lit. Please note that this is not a
malfunction.
Displaying a still image for a longer time may result in an after-image on the LCD panels. If this happens, display the all white
screen in the Test pattern for an hour or more.
rOptical components
Operating the projector in an environment with high temperature or heavy exposure to dust or tobacco smoke will reduce the
service life of the optical components, such as the LCD panel and polarizing plate, and may necessitate their replacement
within less than one year of use. For details, consult your dealer.
rLamp
The luminous source of the projector is a mercury lamp with high internal pressure.
A high pressure mercury lamp has following characteristics.
fThe brightness of the lamp will decrease by duration of usage.
fThe lamp may burst with sound or shorten life by shock or chipping.
fThe life of the lamp varies greatly depending on individual specicities and usage conditions. In particular, continuous use
over 6 hours and frequent on/off switching of the power greatly deteriorate the lamp and affect the lamp life.
fIn rare cases, the lamp burst shortly after the projection.
fThe risk of bursting increases when the lamp is used beyond its replacement cycle. Make sure to replace the lamp unit
consistently. (“When to replace the lamp unit” (x page 88), "Replacing the lamp unit" (xpage 89))
fIf the lamp bursts, gas contained inside of the lamp is released in a form of smoke.
fIt is recommended to store replacement lamps for contingency.
rComputer and external device connections
fWhen connecting a computer or an external device, read this manual carefully regarding the use of power cords and
shielded cables as well.
Chapter 1 Preparation - Precautions for use

ENGLISH - 17
Accessories
Make sure the following accessories are provided with your projector. Numbers enclosed < > show the number of accessories.
Wireless remote control unit <1>
(H2930094500) CD-ROM <1>
(H4100614500)
Power cord
(H2100144500) AAA/R03 or AAA/LR03 battery <2> (for remote control unit)
(H2100148500) RGB signal cable <1>
(H2100127501)
(H2100147500)
Attention
fAfter unpacking the projector, discard the power cord cap and packaging material properly.
fDo not use the supplied power cord for devices other than this projector.
fFor lost accessories, consult your dealer.
fStore small parts in an appropriate manner, and keep them away from young children.
Note
fThe type and number of the power cord depend on the country in which you purchased the product.
fThe model numbers of accessories are subject to change without prior notice.
Contents of the supplied CD-ROM
The contents of the supplied CD-ROM are as follow.
Instruction/list (PDF)
Operating Instructions – Functional Manual
Operating Instructions – Multi Projector Monitoring & Control Software
List of Compatible Projector Models
This is a list of projectors that are com-
patible with the Multi Projector Monitor-
ing & Control Software and its restric-
tions.
Software Multi Projector Monitoring & Control
Software (Windows)
This software allows you to monitor and
control multiple projectors connected to
the LAN.
- The Multi Projector Monitoring & Control Software is only for PT-TW340, PT-TW250, PT-TX400 and PT-TX310.
Chapter 1 Preparation - Precautions for use

18 - ENGLISH
Optional accessories
Options Model No.
Ceiling Mount Bracket ET-PKL100H (for high ceilings)
ET-PKL100S (for low ceilings)
ET-PKL430B (Projector Mount Bracket)
Replacement Lamp Unit ET-LAL500
Replacement Filter Unit ET-RFL300
D-SUB - S Video conversion cable ET-ADSV
Note
fThe model numbers of optional accessories are subject to change without prior notice.
Chapter 1 Preparation - Precautions for use

ENGLISH - 19
About your projector
Remote control
1
2
3
4
5
6
7
8
9
10
12
13
14
15
16
17
18
19
20
21
11
22
1 Power <v/b> button
Turns the projector on or off.
2 <COMPUTER 1> button
Switches the Computer 1 or Component signal to project.
3 <COMPUTER 2> button
Switches the Computer 2 signal to project.
- The <COMPUTER 2> button is only for PT-TW340,
PT-TW250, PT-TX400 and PT-TX310.
4 <VIDEO> button
Switches the Video signal or S-video signal to project.
5 <MEMORY VIEWER/USB DISPLAY> button
Switches the Memory Viewer signal or the USB Display
signal to project.
- The <MEMORY VIEWER/USB DISPLAY> button is only
for PT-TW340, PT-TW250, PT-TX400 and PT-TX310.
6 <ENTER> button/asqw buttons
Used to navigate through the menu screen.
7 <MENU> button
Open or close the On-Screen Menu. (xpage 44)
8 <ASPECT> button
Switches the aspect ratio of the image.
9 <FREEZE> button
Pauses the projected image and mute the audio
temporarily. (xpage 40)
10 <AV MUTE> button
Used to turn off the audio and video temporarily.
(xpage 40)
11 <D.ZOOM +/-> buttons
Zoom in and out the images. (xpage 41)
12 <VOLUME +/–> buttons
Adjusts the volume of the built-in speaker or audio
output. (xpage 41)
13 Remote control signal emitter
14 <AUTO SETUP> button
Executes Input search, Auto PC adj. and Auto Keystone
correction at the same time. (xpage 38)
15 <HDMI> button
Switches the HDMI signal to project.
16 <INFO.> button
Displays the [Info.] menu. (xpage 73)
17 <KEYSTONE> button
Displays the [Keystone] menu. (xpage 39)
18 <LAMP> button
Switches the settings of [Lamp control].
(Æpages 41, 56)
19 <P-TIMER> button
Operate the P-timer function. (xpage 40)
20 <IMAGE> button
Switches the image mode.
( x pages 41, 52)
21 <DAYLIGHT VIEW> button
Used to correct the image when the projector is used in a
bright surroundings.
( x pages 42, 54)
22 <MUTE> button
Used when temporarily turning off the audio.
(xpage 42)
Attention
fDo not drop the remote control.
fAvoid contact with liquids.
fDo not attempt to modify or disassemble the remote control.
fPlease observe the following contents that are described on
the back of the remote control unit (see the right picture).
1. Do not use a new battery together with an old battery.
2. Do not use unspecied batteries.
3. Make sure the polarities (+ and -) are correct when inserting the batteries.
fIn addition, please read the contents that are related to batteries in the "Read this rst!".
1. 请勿把旧电池和新电池一起使用。
2. 请勿使用不合规格的电池。
3. 确保电池安装正确。
原产地：中国
1.Do not use old battery with new one.
2.Do not use batteries other than the
type specified.
3.Be sure the batteries are inserted properly.
Made in China
Chapter 1 Preparation - About your projector

20 - ENGLISH
Attention
fDo not block the ventilation ports (intake and exhaust) of the projector.
WARNING
Keep your hands and other objects away from the air exhaust port.
fKeep your hand and face away.
fDo not insert your nger.
fKeep heat-sensitive articles away.
Heated air from the air exhaust port can cause burns or external damage.
Note
fThe remote control can be used within a distance of about 5 m (16'4-13/16") if pointed directly at the remote control signal
receiver. The remote control can control at angles of up to ± 30 ° vertically and ± 30 ° horizontally, but the effective control
range may be reduced.
fIf there are any obstacles between the remote control and the remote control signal receiver, the remote control may not
operate correctly.
fYou can operate the projector by reecting the remote control signal on the screen. The operating range may differ due to
the loss of light caused by the properties of the screen.
fWhen the remote control signal receiver is lit with a uorescent light or other strong light source, the projector may become
inoperative. Set the projector as far from the luminous source as possible.
Projector body
AC IN
4
1
11 1
23
11
5 9876 10
Side
Side
Front
Rear
Projection direction
1 Adjustable feet
Adjust the projection angle.
2 Projection Lens
3 Remote control signal receiver (front)
4 Air exhaust port
5 <AC IN> terminal
Connect the supplied power cord.
6 Security slot
This security slot is compatible with the Kensington
security cables.
7 Remote control signal receiver (rear)
8 Security chain hook
Attaches a burglar prevention cable, etc.
9 Rear terminals
10 Speaker
11 Air intake port / Air lter cover (xpage 86)
The air lter unit is inside.
Chapter 1 Preparation - About your projector
