Pavilion PV199DV User manual

FOR USE IN RESIDENTIAL OR MANUFACTURED HOME APPLICATIONS.
Installation must conform with local codes, or in the absence of local codes, the National Fuel Gas Code, ANSI Z223.1 / NFPA
54- latest edition and/or the Natural Gas and Propane Installation Code CSA B149.1- latest edition.
Where required by the authority having jurisdiction, the installation must conform to the Standard for Controls and Safety
Devices for Automatically Fired Boilers, ANSI/ASME CSD-1.
PB Heat reserves the right to discontinue, or change at any time, the designs and/or specifications of its products without
notice.
Contact Pavilion Customer Center at 1-855-443-8468, if you have any questions or concerns.
Requests to Installers
• In order to use the Combi Boiler safely, read
this installation manual carefully, and follow the
installation instructions.
• Failures and damage caused by erroneous work
or work not as instructed in this manual are not
covered by the Pavilion Limited Warranty.
• Check that the installation was done properly in
accordance with this Installation Manual upon
completion.
• After completing installation, either place this
Installation Manual and Owner’s Guide (the
warranty registration information included) in
a plastic pouch and attach it to the side of the
Combi Boiler (or the inside of the pipe cover
or recess box if applicable), or hand it to the
customer to retain for future reference. For the
warranty conditions and limitations, see the
Owner’s Guide.
CAUTION
If the information in these instructions is not
followed exactly, a fire or explosion may result
causing property damage, personal injury or
death.
• Do not store or use gasoline or other
flammable vapors and liquids in the vicinity of
this or any other appliance.
• WHAT TO DO IF YOU SMELL GAS
- Do not try to light any appliance.
- Do not touch any electrical switch; do not use
any phone in your building.
- Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions.
- If you cannot reach your gas supplier, call the
fire department.
• Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
WARNING
APMOR
LOW-LEAD
&T
TM
ILow NOx Approved by SCAQMD
14 ng/J or 20 ppm
(Natural Gas Only)
SBB819J
Rev. 12/19
CONDENSING GAS COMBI BOILER
Installation Manual
Models : PV199DV (GHQ-C3201WX-FF PB US)
PB HEAT, LLC

2
Contents
1 Before Installation 3
2 About the Combi Boiler 5
2.1 Included Accessories ............................ 5
2.2 Optional Accessories............................. 5
2.3 Field Purchased Accessories................. 6
2.4 Specifications ........................................ 7
2.5 Dimensions............................................ 10
2.6 External View ........................................ 12
3 Choosing an Installation Location 13
4 Installation Clearances 16
4.1 Indoor Installation................................. 16
4.2 For Quick Connect Multi-System.......... 16
5 Installation of the Combi Boiler 17
5.1 Mounting the Combi Boiler
to the wall ............................................. 17
5.2 Elevation Adjustment Above 2,000 ft... 18
5.3 Filling the condensate container
with water ............................................. 18
6 Venting the Combi Boiler 19
6.1 Venting Installation Sequence .............. 19
6.2 General Requirements.......................... 19
6.3 Select a Vent Type................................. 25
6.4 Vent Pipe Installation (Direct Vent) ....... 26
6.5 Vent Pipe Installation
(Non-Direct Vent).................................. 32
7 Connecting the Gas Supply 36
8 Connecting the DHW pipe 40
8.1 Installation............................................. 40
8.2 Water treatment................................... 42
9 Connecting the Heating Pipe 44
9.1 General Requirements.......................... 44
9.2 Low Water Cutoff (LWCO)..................... 44
9.3 Pressure Relief Valve............................. 45
9.4 Auto Feeder Connection....................... 46
9.5 Freeze Prevention ................................. 47
10 Connecting the Condensate Drain 48
11 Connecting Electricity 50
11.1 Combi Boiler.......................................... 50
11.2 Quick Connect Cord.............................. 51
11.3 Outdoor Reset Control with Outdoor
Temperature Sensor ............................. 53
12 Installer Mode (Parameter Settings) 59
13 Setting Temperature 66
14 Service Reminder 67
15 Setting the DIP Switches 68
16 Trial Operation 69
17 Checklist After Installation 72
18 Plumbing Applications 74
18.1 General Requirements.......................... 74
18.2 Only install Combi Boiler as a Water
Heater ................................................... 74
18.3 Zoned with Valves ................................. 75
18.4 Zoned with Pumps ................................ 76
18.5 Air Handler ............................................ 77
18.6 Recirculation System............................. 78
18.7 Quick Connect Multi System
Installation............................................. 79
19 Maintenance 80
19.1 Periodic Check....................................... 80
19.2 Procedure for Flushing the Plate Heat
Exchanger.............................................. 81
Contents

3
1 Before Installation
Potential dangers from accidents during installation and use are divided into the following four categories.
Closely observe these warnings, they are critical to your safety.
Indicates an imminently hazardous situation which, if not avoided, will result in death
or serious injury.
Indicates a potentially hazardous situation which, if not avoided, could result in death
or serious injury.
Indicates a potentially hazardous situation which, if not avoided, may result in minor or
moderate injury.
Indicates a potentially hazardous situation which, if not avoided, may result in property
damage.
DANGER
WARNING
CAUTION
NOTICE
Checkup
Check the fixing brackets and vent pipe yearly for damage or wear. Replace if necessary.
DANGER
Precautions on Vent Pipe Replacement
The vent system will almost certainly need to be
replaced when this appliance is being installed.
Only use vent materials that are specified in this
Installation Manual for use on this appliance.
Refer to the “Venting the Combi Boiler” section
for details. If PVC, CPVC, or Category IV listed pipe
is already installed, check for punctures, cracks,
or blockages and consult with the vent pipe
manufacturer before reusing.
Improper venting may result in fires, property
damage or exposure to Carbon Monoxide.
Snow Precaution
If this product will be installed in an area where
snow is known to accumulate, protect the vent
termination from blockage by snow drifts or
damage from snow falling off of roofs.
Check the Power
The power supply required is 120 VAC, at 60 Hz.
Using the incorrect voltage may result in fire or
electric shock.
Check the Gas
• Check that the rating plate indicates the correct
type of gas.
• Check that the gas supply line is sized for
199,900 Btu/h.
Chemicals
This product can expose you to chemicals including
lead, lead compounds and carbon bisulfide which
are known to the State of California to cause
cancer, birth defects or other reproductive harm.
For more information go to
www.P65Warnings.ca.gov.
WARNING
Do Not Use Appliance for Purposes Other Than
Those Specified
Do not use for other than increasing the
temperature of the water supply, as unexpected
accidents may occur as a result.
Check Water Supply Quality
If the water supply is in excess of 12 grains
per gallon (200 mg/L) of hardness, acidic or
otherwise impure, treat the water with approved
methods in order to ensure full warranty
coverage.
CAUTION
• This appliance is suitable for combination
potable water and heating applications.
• Do not use this appliance if any part has been
underwater. Immediately call a qualified
service technician to inspect the appliance
and replace any part of the control system
and gas control which has been under water.
NOTICE
PV199DV (GHQ-C3201WX-FF PB US)
PV199DV (GHQ-C3201WX-FF PB US)
Before Installation

4
Please read if installing in Massachusetts
Massachusetts requires manufacturers of Side
Wall Vented products to provide the following
information from the Massachusetts code:
• A hard wired carbon monoxide detector with
an alarm and battery back-up must be installed
on the floor level where the gas equipment is to
be installed AND on each additional level of the
dwelling, building or structure served by the side
wall horizontal vented gas fueled equipment.
• In the event that the side wall horizontally vented
gas fueled equipment is installed in a crawl space
or an attic, the hard wired carbon monoxide
detector with alarm and battery back-up may be
installed on the next adjacent floor level.
• Detector(s) must be installed by qualified licensed
professionals.
• APPROVED CARBON MONOXIDE DETECTORS:
Each carbon monoxide detector shall comply with
NFPA 720 and be ANSI/UL 2034 listed and IAS
certified.
• SIGNAGE: A metal or plastic identification plate
shall be permanently mounted to the exterior of
the building at a minimum height of eight (8) ft
above grade directly in line with the exhaust vent
terminal for the horizontally vented gas fueled
heating appliance or equipment. The sign shall
read, in print size no less than one-half (1/2) in. in
size, “GAS VENT DIRECTLY BELOW. KEEP CLEAR
OF ALL OBSTRUCTIONS”.
• EXEMPTIONS to the requirements listed above:
- The above requirements do not apply if the
exhaust vent termination is seven (7) ft or more
above finished grade in the area of the venting,
including but not limited to decks and porches.
- The above requirements do not apply to a
product installed in a room or structure separate
from the dwelling, building or structure used in
whole or in part for residential purposes.
• This installation manual shall remain with the
product at the completion of the installation.
See the latest edition of Massachusetts Code
248 CMR for complete verbiage and also for
additional (non-vent related) requirements (248
CMR is available online). If your installation is NOT
in Massachusetts, please see your authority of
jurisdiction for requirements that may be in effect
in your area. In the absence of such requirements,
follow the National Fuel Gas Code, ANSI Z223.1/
NFPA 54 and/or CAN/CSA B149.1, Natural Gas and
Propane Installation Code.
Before Installation

5
Anchoring Screw (× 7)
Outdoor Temperature Sensor (× 1)
Owner’s Guide (including Warranty)
Installation Manual (this document) (1 each)
Pressure Relief Valve for Heating
(ASME Certified) (3/4 in., 30 psi) (× 1)
Wall Mounting Bracket (× 1)
Anchoring Screw & Anchor for Outdoor
Temperature Sensor (2 each)
2 About the Combi Boiler
The following accessories are included with the
Combi Boiler.
Check for any missing items before starting
installation.
2.1 Included Accessories
Quick Connect Cord (× 1)
[Stock Code: 1809]
PVC Concentric Termination (× 1)
2 in. (50 mm): [Stock Code: 1813]
3 in. (75 mm): [Stock Code: 1813-1]
2 in. SV Conversion Kit (× 1)
[Stock Code: 1814]
• 90° Elbow
(With Inlet Screen)
• 2 in. × 3 in. Increaser
coupling
• 2 in. Pipe
• Installation Manual
(Check List)
Bird Screen for 2 in. (50 mm) PVC
[Stock Code: 1816]
Bird Screen for 3 in. (75 mm) PVC
[Stock Code: 1817]
3 in. (75 mm) Horizontal Hood Termination
[Stock Code: 1818]
The accessories listed below are not included
with the Combi Boiler, but may be necessary for
installation.
2.2 Optional Accessories
NOTE Additional vent pieces are available;
consult the latest product catalogue
for details.
About the Combi Boiler

6
Universal Concentric Vent Kit
[Stock Code: 1819]
Low Profile Termination Kit
2 in.: [Stock Code: 1820]
3 in.: [Stock Code: 1820-1]
ULC S636 / UL 1738
certified for use in both
Canada and USA
Plastic Rain Cap
[Stock Code: 1821]
Not approved for use in
Canada.
Neutralizer (× 1)
[Stock Code: 1822]
Manifold Kit (× 1)
[Stock Code: 1827]
2.3 Field Purchased Accessories
Service Valve Kit
with Pressure Relief Valve (1 each)
Not supplied from PB Heat. Isolation valves may be
purchased separately from an authorized wholesaler.
The following are required specification for Isolation
valves.
1. Comply with Lead Free installation requirement.
2. Certified to NSF/ANSI 61.
3. Shall facilitate isolation of the Combi Boiler from the
water line.
4. 3/4” FTP Unions for connection to Combi Boiler.
5. 3/4” size connection for water lines (Cold and
Domestic hot water lines).
6. Equipped with purge and drain valve for hose
connection and tethered brass cap.
7. Equipped with the 3/4” connection for optional
pressure relief valve (150psi).
Scale Inhibitor (1 each)
Damage to the Heat
Exchanger caused by Scale
Build-up is not covered
by the Pavilion Limited
Warranty.
To prevent the Heat
Exchanger damage, the
water must be treated with
a Southeastern Filtration
Scale StickTM, 3M Aqua-
PureTM scale inhibitor,
or other scale inhibitor
system.
About the Combi Boiler

7
2.4 Specifications
• Specifications may be changed without prior notice.
• The capacity may differ slightly, depending on the water pressure, water supply, piping conditions, and water
temperature.
* Minimum flow rate may change by setting temperature and water temperature.
Item Specification
Model Name PV199DV (GHQ-C3201WX-FF PB US)
Type Installation Indoor / Outdoor Wall mounted
Air Supply / Exhaust Power Vented
Ignition Direct Ignition
Operating Pressure DHW 15-150 psi
(Recommended 30 psi for maximum performance)
Heating 12-30 psi
Minimum Activation Flow Rate*
Minimum Operating Flow Rate*
0.4 GPM (1.5 L/min)
0.29 GPM (1.1 L/min)
Dimensions (Height) × (Width) × (Depth) 27.0 in. (687 mm) × 18.5 in. (471 mm) × 12.8 in. (325 mm)
Weight 95 lbs. (43 kg)
Water Holding Capacity for DHW 0.37 Gallon (1.4 L)
Pressure Relief Valve
Setting Heating 30 psi
Connection
Sizes
DHW Cold Water Inlet NPT 3/4 in.
DHW Outlet NPT 3/4 in.
Heating Supply NPT 1 in.
Heating Return NPT 1 in.
Heating Pressure Relief Valve NPT 3/4 in.
Auto Feeder Inlet NPT 1/2 in.
Gas Inlet NPT 3/4 in.
Condensate Drain NPT 1/2 in.
Power
Supply
Supply 120 VAC (60 Hz)
Consumption NG: 210 W LP: 210 W
Freeze Prevention: 125 W
Maximum Current 4 Amps
Materials
Casing
•Front Cover, Side / Top Plate: Hot-dipped zinc-aluminum-
magnesiumalloy-coated steel w/ Polyester Coating
•Back Plate: Hot-dipped zinc-aluminum-magnesiumalloy-coated
steel w/o Coating
•Bottom Plate: Zincified Steel Plate / Polyester Coating
Flue Collar PP
Primary Heat Exchanger Stainless Steel 316L
Secondary Heat Exchanger Stainless Steel 316L
Safety Devices Flame Rod, High Limit Switch, Lightning Protection Device (ZNR),
Freezing Prevention Device, Fan Rotation Detector
Included Accessories
Anchoring Screws, Wall Mounting Bracket, Outdoor Temperature
Sensor, Anchoring Screws & Anchors for Outdoor Temperature
Sensor
About the Combi Boiler

8
Item Performance
Maximum Minimum
Gas Consumption
DHW NG 199,900 Btu/h 18,000 Btu/h
LP 199,900 Btu/h 18,000 Btu/h
Heating NG 120,000 Btu/h 18,000 Btu/h
LP 120,000 Btu/h 18,000 Btu/h
Maximum Hot Water Capacity
(45°F (25°C) Rise) 8.4 GPM (32 L/min)
Capacity Range 0.4-11.1 GPM (2-42 L/min)
Temperature
Settings
DHW* °F Mode 90-140°F (In 5°F intervals) (11 Options)
°C Mode 32°C, 35°C, 37°C-48°C (In 1°C intervals), 50°C, 55°C, 60°C (17 Options)
Heating °F Mode 100-180°F (In 1°F intervals) (81 Options)**
°C Mode 40-82°C (In 1°C intervals) (43 Options)**
Performances
* When you use Quick Connect Multi System, temperature setting range is changed below.
°F Mode: 100-140°F (In 5°F intervals)
°C Mode: 37-48°C (In 1°C intervals), 50°C, 55°C, 60°C
** Heating Temperature range depends on Installer Mode Setting.
Refer to the Installation Manual for details.
Pump Performance(with internal pressure drop)
00123
45
5
10
15
20
25
30
GPM
Head (ft)
Combination Boiler
Space Heating Ratings
Model Name Input, MBH Heating Capacity,
MBH*1
Net AHRI Rating
Water, MBH*2
AFUE, %
Maximum Minimum
PV199DV
(GHQ-C3201WX-FF PB US)
NG 120 18 111 97 95.0
LP 120 18 111 97 95.0
Space Heating Rating
* Based on standard test procedures prescribed by United States Department of Energy (DOE).
** The Net AHRI water ratings shown are based on a piping and pickup allowance of 1.15.
Consult Pavilion Customer Center before selecting a boiler for installations having unusual piping and pickup quirements,
such as intermittent system operation, extensive piping system, etc.
About the Combi Boiler

9
Memo
About the Combi Boiler

10
HEIGHT OF EACH FITTING FROM CASE
PRESSURE RELIEF VALVE FOR HEATING TOP 1.0” [26]
DOMESTIC WATER OUTLET BOTTOM 2.0” [51]
DOMESTIC WATER INLET BOTTOM 1.9” [49]
HEATING WATER OUTLET BOTTOM 2.2” [55]
HEATING WATER INLET BOTTOM 3.4” [86]
AUTO FEEDER WATER INLET BOTTOM 2.3” [58]
CONDENSATE DRAIN BOTTOM 1.7” [42]
GAS INLET BOTTOM 2.2” [55]
PRESSURE RELIEF VALVE
FOR HEATING (3/4”)
Outdoor Temperature Sensor
27.0” [687]
2.8” [71]
1.97” [50]
Ø2.4” [Ø61]
Ø2.4” [Ø61]
10.1” [256]
17.8” [451]
18.5” [471]
17.7” [450]
1.3” [34] 3.6” [92]
2.3” [58]
5.1” [130]
AIR INLET
FLUE COLLAR
HEATING WATER OUTLET (1”)
HEATING WATER INLET (1”)
AUTO FEEDER WATER INLET (1/2”)
WATER DRAIN VALVE
DOMESTIC WATER OUTLET (3/4”)
DOMESTIC WATER INLET (3/4”)
GAS INLET (3/4”)
(WATER FILTER)
WATER DRAIN VALVE
(WATER FILTER)
WATER DRAIN VALVE
WATER DRAIN VALVE
(WATER FILTER)
WATER DRAIN VALVE
WIRING THROUGHWAY
WIRING THROUGHWAY
(AC120V)
CONDENSATE DRAIN (1/2”)
4 x Ø0.5” [Ø13]
2 x 0.24” x 0.4” [6 x 10] OBLONG HOLE
4 x 0.24” x 0.6” [6 x 15] OBLONG HOLE
0.4” [10]
WALL MOUNTING BRACKET
(INCLUDED ACCESSORY)
1.8” [46]
28” [711]
1.2” [30]
0.5” [13]
26.0” [600] 2.3” [59]
12.8” [325]
0.2” [5.0]
10.2” [260]
16” [406]
5.1” [130]
3.5” [88]
1.3” [34]
1.1” [28]
2.6” [66]
3.9” [100]
5.5” [140]
6.7” [170]
(VIEW FROM BOTTOM)
2.5 Dimensions
About the Combi Boiler

11
PRESSURE RELIEF VALVE
FOR HEATING (3/4”)
Outdoor Temperature Sensor
27.0” [687]
2.8” [71]
1.97” [50]
Ø2.4” [Ø61]
Ø2.4” [Ø61]
10.1” [256]
17.8” [451]
18.5” [471]
17.7” [450]
1.3” [34] 3.6” [92]
2.3” [58]
5.1” [130]
AIR INLET
FLUE COLLAR
HEATING WATER OUTLET (1”)
HEATING WATER INLET (1”)
AUTO FEEDER WATER INLET (1/2”)
WATER DRAIN VALVE
DOMESTIC WATER OUTLET (3/4”)
DOMESTIC WATER INLET (3/4”)
GAS INLET (3/4”)
(WATER FILTER)
WATER DRAIN VALVE
(WATER FILTER)
WATER DRAIN VALVE
WATER DRAIN VALVE
(WATER FILTER)
WATER DRAIN VALVE
WIRING THROUGHWAY
WIRING THROUGHWAY
(AC120V)
CONDENSATE DRAIN (1/2”)
4 x Ø0.5” [Ø13]
2 x 0.24” x 0.4” [6 x 10] OBLONG HOLE
4 x 0.24” x 0.6” [6 x 15] OBLONG HOLE
0.4” [10]
WALL MOUNTING BRACKET
(INCLUDED ACCESSORY)
1.8” [46]
28” [711]
1.2” [30]
0.5” [13]
26.0” [600] 2.3” [59]
12.8” [325]
0.2” [5.0]
10.2” [260]
16” [406]
5.1” [130]
3.5” [88]
1.3” [34]
1.1” [28]
2.6” [66]
3.9” [100]
5.5” [140]
6.7” [170]
(VIEW FROM BOTTOM)
2.5 Dimensions
<inch [mm]>
About the Combi Boiler

12
2.6 External View
Indoor Installation
Pressure Relief Valve
(Heating)
Drain Pipe
Intake Pipe
Exhaust Pipe
Operation Display
Water Drain Valve
(with Water Filter)
Water Drain Valve
(with Water Filter)
Heating Supply
Auto Feeder Shutoff Valve
Water Drain Valve
Heating Return
Auto Feeder Inlet
Gas Supply Valve
Water Drain Valve
Water Supply Valve
Hot Water Outlet (DHW)
Pressure Relief Valve (DHW)
Drain Pipe
Cold Water Inlet (DHW)
Water Drain Valve
(with Water Filter)
About the Combi Boiler

13
3 Choosing an Installation Location
Locate the vent terminal and make sure there
are no obstacles around the termination for
exhaust to accumulate or be obstructed.
Do not enclose the termination with corrugated
metal or other materials.
Carbon monoxide poisoning or fire may occur
as a result.
DANGER
• Avoid places where fires are common,
such as those where gasoline, benzene and
adhesives are handled, or places in which
corrosive gases (ammonia, chlorine, sulfur,
ethylene compounds, acids) are present.
If you do not follow the above, a fire or
explosion may result causing property
damage, personal injury or death.
• Avoid installation in places where dust or
debris will accumulate.
Dust may accumulate and reduce the
performance of the fan of the appliance.
This can result in incomplete combustion.
• Avoid installation in places where special
chemical agents (e.g. hair spray or spray
detergent) are used.
Ignition failures and malfunctions may occur
as a result.
• Do not install this Combi Boiler in a
recreational vehicle or on a boat as this may
be a Carbon Monoxide Poisoning Hazard.
• The manufacturer does not recommend
installing the Combi Boiler in an attic due to
safety issues.
If you install the Combi Boiler in an attic:
- Make sure the appliance will have enough
combustion air and proper ventilation.
- Keep the area around the Combi Boiler
clean. Dust may accumulate and reduce the
performance of the fan of the appliance.
This can result in incomplete combustion.
- A drain pan, or other means of protection
against water damage, is required to be
installed under the Combi Boiler in case of
leaks.
WARNING
Outdoor installation
• The Combi Boiler is designed for either
indoor or outdoor installation. For
information about outdoor installation,
contact Pavilion Customer Center at https://
www.peerlessboilers.com/ or 1-855-443-
8468.
Never install it in a bathroom, it may be
damaged or a fire may be caused.
Do not install in the following places
• A location where it is not free from obstacles
and stagnant air.
• Near staircases or emergency exits.
• A place where it may be threatened by falling
objects, such as under shelves.
• On common walls as the appliance will make
some operational noises while it is running.
Consideration to the surroundings
• Do not install the Combi Boiler where the
exhaust will blow on outer walls, other
walls or material not resistant to heat. Also
consider the surrounding trees and animals.
The heat and moisture from the Combi
Boiler may cause discoloration of walls and
resinous materials, or corrosion of aluminum
materials.
• Do not locate the vent termination directed
towards a window or any other structure
which has glass or wired glass facing the
termination.
• Take care that noise and exhaust gas will not
affect neighbors.
• If the appliance is installed in a location with
very high humidity, condensate may form
inside the appliance and/or cause incomplete
combustion, damage to the electrical
components, or electric leakage.
Install according to regulations and manual
• Install the Combi Boiler in an area that allows
for the proper clearances to combustible
and non-combustible construction. Consult
the rating plate on the appliance for proper
clearances.
• The Combi Boiler must be installed according
to manual.
• Before installing, make sure that the exhaust
flue termination will have the proper
clearances according to the National Fuel
Gas Code (ANSI Z223.1- latest edition) or the
Natural Gas and Propane Installation Code
(CSA B149.1).
CAUTION
Choosing an Installation Location

14
Installation in the vicinity of gas ranges,
stoves, fans, and range hoods
• Avoid installation above gas ranges or stoves.
• Avoid installation between the kitchen fan
and stove. If oily fumes or a large amount of
steam are present in the installation location,
take measures to prevent the fumes and
steam from entering in the appliance.
• Install in a location where the exhaust gas
flow will not be affected by fans or range
hoods.
CAUTION
NOT
CORRECT
CORRECT
NOT
CORRECT
• Place the appliance for easy access for
maintenance and repair.
• Do not install the Combi Boiler in a location
where the appliance will be exposed to
excessive winds.
• Locate the appliance in an area where
leakage from the appliance or connections
will not result in damage to the area adjacent
to the appliance or to the lower floors of the
structure. When such installation locations
cannot be avoided, a suitable drain pan,
adequately drained, must be installed under
the appliance. The pan must not restrict
combustion air flow.
• As with any water heating appliance, the
potential for leakage at some time in the life
of the product does exist. The manufacturer
will not be responsible for any water damage
that may occur.
• Water quality:
If this Combi Boiler will be installed in a
location where the hardness of the supply
water is high, scale Build-up may cause
damage to the Plate Heat Exchanger.
Perform suggested treatment and
maintenance measures in reference to “8.2
Water Treatment”.
Damage to the Combi Boiler as a result of the
below is not covered by the Pavilion Limited
Warranty.
- Water in excess of 12 gpg (200 mg/L) of
hardness
- Poor water quality (see the following table)
NOTICE
NOTE Consult with the customer concerning
the location of installation.
Contaminant Maximum Allowable Level
Total Hardness* 200 mg/L (12 gpg) or less
Aluminum 0.05 to 0.2 mg/L or less
Chloride 250 mg/L or less
Copper 1.0 mg/L or less
Iron 0.3 mg/L or less
Manganese 0.05 mg/L or less
pH 6.5-8.5
Total Dissolved Solids 500 mg/L or less
Zinc 5 mg/L or less
Sulfate 250 mg/L or less
Residual chlorine* 4 mg/L or less
Source: EPA National Secondary Drinking Water
Regulations (40 CFR Part 143.3)
* Maximum limit suggested/approved by the
manufacturer.
Choosing an Installation Location

15
State of California: The Combi Boiler must be
braced, anchored or strapped to avoid moving
during an earthquake. Contact local utilities for code
requirements in your area or call 1-855-443-8468
and request instructions.
For Venting Manufacturers Requirements, see the
Pavilion website (https://www.peerlessboilers.
com/).
Choosing an Installation Location

16
Cooking Equipment
When utilizing an indoor air supply, if the Combi
Boiler will be installed in the vicinity of a permanent
kitchen range or stove that has the possibility of
generating steam that contains fats or oils, use a
dividing plate or other measure to ensure that the
Combi Boiler is not exposed to air containing such
impurities.
Exhaust hood
Range
The dividing pla
te should
be of non-combus
tible
material of a width
gr
eater than the Combi
Boiler
.
4.2 For Quick Connect Multi-System
The Quick Connect Cord is 6 ft (1.8 m) long.
Install the units 3-18 in. (76-457 mm) apart from
each other to ensure the cord will be able to reach
between the units .
3-18 in.
(76-457 mm)
4 Installation Clearances
4.1 Indoor Installation
Before installing, check for the following:
Install in accordance with relevant building and
mechanical codes, as well as any local, state or
national regulations, or in the absence of local
and state codes, refer to National Fuel Gas Code
ANSI Z223.1 / NFPA 54- latest edition. In Canada,
see the Natural Gas and Propane Installation
Code CSA B149.1- latest edition for detailed
requirements.
WARNING
Required Clearances From the Combi Boiler
Maintain the clearances from both combustible and
non-combustible materials.
12 in. (300 mm)
or mor
e
3 in. (76 mm)
or more
4 in. (100 mm)
or more
Securing of space for inspection/repair
In order to facilitate inspection and repair, the
minimum clearances should be met.
* 3 in. (76 mm) or more
** 8 in. (203 mm) or more
24 in.
(610 mm)
or more
*
*
** **
Exhaust
Installation Clearances

17
5 Installation of the Combi Boiler
5.1 Mounting the Combi Boiler to the
wall
• Protect your hands with gloves and take
caution to not inflict injury.
• Be careful not to hit electrical wiring, gas, or
water piping while drilling holes.
CAUTION
• The weight of the appliance will be applied
to the wall. If the strength of the wall is not
sufficient, reinforcement must be done to
prevent the transfer of vibration.
• Install the appliance on a vertical wall and
ensure that it is level.
NOTICE
Do not drop or apply unnecessary force to the
appliance when installing. Internal parts may be
damaged and may become highly dangerous.
WARNING
2. Hang the Combi Boiler on the Wall Mounting
Bracket.
3. Affix the Mounting Bracket (Lower) to the wall
by 2 screws.
1. Ensure that the Wall Mounting Bracket is
leveled.
Drill holes for the Wall Mounting Bracket and
affix the Wall Mounting Bracket securely to the
wall by 5 screws.
Finally, make sure the bracket can support the
weight of the Combi Boiler.
Mounting Bracket
(Upper)
Hang
Anchoring Scr
ew
Wall Mounting
Bracket
Mounting Bracket
(Upper)
Hang
Anchoring Screw
Wall Mounting
Bracket
Mounting Bracket
(Upper)
Hang
Anchoring Screw
Wall Mounting
Bracket
Anchoring Scr
ew
Mounting Br
acket
(Lower)
Installation of the Combi Boiler

18
5.3 Filling the condensate container
with water
5.2 Elevation Adjustment Above 2,000 ft
• Adjust the DIP switches as illustrated in the
table below, if this Combi Boiler is installed at an
altitude of 2,000 ft (610 m) or higher.
• Disconnect the electrical power and then adjust
the DIP switches.
Refer to page 68 for the location of the DIP switch
bank and how to change the DIP switches.
Failure to perform this step will result a “73” code
displayed on the Operation Display and a cease in
operation.
If this occurs, disconnect, then reconnect the
electrical power to the Combi Boiler to reset the
system. Follow the procedure described below to ensure
that the condensate container is filled with water.
Fill the condensate container by pouring approx. 10
oz. (280 mL) of water into the exhaust flue on the
top of the Combi Boiler as illustrated below.
If the vent pipe has already been installed:
After installing the condensate drain pipe, make
sure that the area around the Combi Boiler is well
ventilated; open a window or a door if necessary.
Then, operate the Combi Boiler and verify that
condensate is coming out of the condensate drain
pipe.
(During normal use of the Combi Boiler, condensate
will begin to discharge from the condensate drain
pipe within 15 minutes of use. However, depending
on the season and/or installation site conditions, it
may take longer.)
NOTE Do not change any other DIP switches.
Prior to initial start up, make sure that you fill
the condensate container with water.
This is to prevent dangerous exhaust gases from
entering the building.
Failure to fill the condensate container could
result in severe personal injury or death.
DANGER
Here
High elevation adjustment
DIP switches
#5 #6
0-2,000 ft (0-610 m)  
2,001-4,000 ft (611-1,219 m)  
4,001-7,000 ft (1,220-2,134 m)  
7,001-10,000 ft (2,135-3,048 m)  
ON = / OFF = 
10 oz.
280 mL
In
take
Exhaus
t
Installation of the Combi Boiler

19
6 Venting the Combi Boiler
CARBON MONOXIDE POISONING
Follow all vent system requirements in
accordance with relevant local or state
regulation, or, in the absence of local or state
code, if in the U.S., refer to the National Fuel
Gas Code ANSI Z223.1 / NFPA 54- latest edition,
and if in Canada, in accordance with the Natural
Gas and Propane Installation Code CSA B149.1
- latest edition.
WARNING
For PVC/CPVC/PP material
• Schedule 40 PVC pipe may be used as the vent
material. If required by local code, use schedule
40/80 CPVC or PP.
• If the Combi Boiler set temperature is 160°F
(70°C) or higher, use schedule 40/80 CPVC or PP.
Refer to the following.
• This Combi Boiler must be vented with plastic
pipe materials as specified in the table below.
Vent installations in Canada which utilize plastic
vent systems must comply with ULC S636.
6.2 General Requirements
• This is a Category IV appliance.
Only vent materials approved for use with
Category IV appliances shall be used.
6.2.1 Vent Piping Material
6.1 Venting Installation Sequence
4. Install termination assembly as described in
this manual or in the vent manufacturer’s
installation instructions.
If necessary, install Bird Screen (not supplied
with Combi Boiler).
5. Install combustion air and exhaust vent piping
from Combi Boiler to termination.
6. Slope the horizontal vent 1/4 in. upwards for
every 12 in. (305 mm) toward the termination.
7. Install supports and hanger straps allowing
for movement from expansion, or as per vent
pipe manufacturer’s instructions or local code
requirements.
1. Install the Combi Boiler.
2. Determine the termination method—horizontal
or vertical, etc.
3. Determine proper location for wall or roof
penetration for each termination.
NOTE Do not exceed maximum allowed vent
lengths as described in this manual.
[Exhaust Vent / Air Intake]
Material United States Canada
Exhaust Air Intake Exhaust Air Intake
Schedule 40
PVC ANSI/ASTM D1785 ULC S636
Certified
Materials
Only
CSA
B137.3
PVC-DWV ANSI/ASTM D2665 CSA
B181.2
Schedule 40
CPVC ANSI/ASTM F441 CSA B137.3
Polypropylene
(PP)*
Centrotherm- lnnoFlue®
(certified ULC S636),
DuraVent PolyPro® (certified ULC S636)
System 1738TM
PVC Fuel Gas
Venting
IPEX Management Inc.
(certified UL 1738)
* Only listed manufacture specified vent parts
may be used for this Combi Boiler.
Refer to the manufacture’s literature for
detailed information.
- Approved Vent Manufacture:
- Centrotherm- lnnoFlue® PP
- DuraVent PolyPro®
** Applicable vent termination are “90°
elbow” or “Tee type”. Concentric vent
termination of polypropylene are
prohibited.
Parts #
Single Wall Pipe
(2 in. / 3 in.)
ISVL02xx(UV)/03xx(UV),
ISEP02xx/03xx, ISIA0203
Elbow ISELL0287(UV)/0387(UV),
ISELL0245/0345
Termination** ISELL0287UV/0387UV,
ISTT0220/0320
Bird Screen IASPP02/03
Parts #
Single Wall Pipe
(2 in. / 3 in.)
2PPS-xxBL/3PPS-xxBL,
2PPS-xxL/3PPS-xxL
Elbow 2PPS-E90(B)L/3PPS-E90(B)L,
2PPS-E45(B)L/3PPS-E45(B)L
Termination** 2PPS-E90(B)L/3PPS-E90(B)L,
2PPS-T(B)L/3PPS-T(B)L
Bird Screen 2PPS-BG/3PPS-BG
• Under normal conditions, this Combi Boiler will
not produce an exhaust flue temperature in
excess of 149°F (65°C).
Outdoor installation
• The Combi Boiler is designed for either indoor
or outdoor installation. For information about
outdoor installation, contact Pavilion Customer
Center at https://www.peerlessboilers.com/ or
1-855-443-8468.
Never install it in a bathroom, it may be
damaged or a fire may be caused.
CAUTION
Venting the Combi Boiler

20
Exhaust Chimney Kit (3 in.): IFCK03xx,
Flexible Pipe PP (3 in.): IFVL03xxx
Intake Termination**: ISELL0387UV, ISTT0320,
Bird Screen: IASPP03
Exhaust
&
Intake*
Single Wall Pipe (3 in.): ISVL03xx(UV),
ISEP03xx
Elbow (3 in.): ISELL0387UV, ISELL0345UV,
ISEL0387, ISEL0345,
Increaser: ISIA0203
- Centrotherm- lnnoFlue® PP
* Recommended items.
** Applicable vent termination are “87° elbow” or
“Tee type”.
Concentric vent termination of polypropylene
are prohibited.
Exhaust Flex Chimney Lining Kit (3 in.): 3PPS-FKL,
Flex Length (3 in.): 3PPS-FLEXxx
Intake Aluminum Flex Length (3 in.): 3DFA-xx,
Coupler (3 in.): 3DFA-FCP
Exhaust
&
Intake*
Elbow (3 in.): 3PPS-E45L, 3PPS-E90L,
Single-Wall Pipe (3 in.): 3PPS-xxL
Appliance Adapter for PVC Coupler (2 in.):
2PPS-ADL,
Increaser: 2PPS-X3L
- DuraVent®- Flex Through Chimney w/ Air Intake
For flexible pipe for chimney
• During the installation, ambient temperatures
must be greater than 40 °F (5 °C). Afterwards,
installation site ambient temperature must
be greater than -4 °F (-20 °C). Flexible vent
pipe breakage may occur if these temperature
requirements are not observed.
• Only listed manufacture specified vent parts
may be used for this appliance. Refer to the
manufacture’s literature for detailed information.
NOTE Covering non-metallic vent pipe and
fittings with thermal insulation is
prohibited.
• Use only solid PVC / CPVC (schedule 40) or PP
pipe.
• 2 in. or 3 in. schedule 80 pipe may also be used
on this Combi Boiler, however the Btu/h input of
the Combi Boiler will be reduced by up to 9%.
• Maintain the same vent pipe diameter from the
Combi Boiler flue to the termination.
• In Canada, plastic vent systems must be certified
to ULC S636. The components of the certified
vent system must not be interchanged with other
vent systems or unlisted pipe/fittings.
• In Canada, specified primers and glues of the ULC
S636 certified vent system must be from a single
system manufacturer and not intermixed with
other system manufacturer’s vent system parts.
6.2.2 Installation Instructions
• Follow all general venting guidelines as outlined in
this manual.
• Clearance described in this document is the
minimum recommendation/required distance.
Take appropriate clearance according to the
situations of the site.
• Make sure the vent system is gas tight and will
not leak.
• Support the vent pipe with hangers at regular
intervals as specified by these instructions or the
instructions of the vent manufacturer.
• All piping must be fully supported. Use pipe
hangers at a minimum of 3 ft (0.9 m) intervals.
CARBON MONOXIDE POISONING
• Failure to properly seal the vent system could
cause flue products to enter the living space.
• (For flexible pipe for chimney)
Handle the flexible vent carefully.
Dropping, Crushing and Stacking may cause
damage, and may result in fires, property
damage or exposure to Carbon Monoxide.
WARNING
NOTE • Do not use the Combi Boiler to
support the vent piping.
• Do not common vent or connect
more than one appliance to this
venting system.
• Ensure at least 3 ft (0.9 m) or
more distance between the
near edge of the air intake
pipe or exhaust pipe to the
inside corner of a wall.
Inside corner
3 ft (0.9 m)
or more
[Pipe Cement / Primer]
Material United States Canada
PVC ANSI/ASTM D2564 ULC S636
Certified Materials
Only
CPVC ANSI/ASTM F493
Use of cellular core PVC (ASTM F891), cellular
core CPVC, or Radel® (polyphenylsulfone) in
non-metallic venting system is prohibited.
WARNING
Venting the Combi Boiler
