VPC-HD22 Product Specification & Operational Manual
1
FULL HD
Color MOS
Assembly Unit
VPC-HD22
Product Specification
& Operational Manual
English

VPC-HD22
VPC-HD22 Product Specification & Operational Manual
2
Table of Contents
1. Scope of Application .3
2. Handling Precautions .3
3. Product Outline .4
4. Bundled Items .4
4-1. Standard Bundled Items
4-2. Packaging
5. Specifications .5
6. Part Names and Functions .7
6-1. Sensor board (BI-VC01PA)
6-2. Main board (MB-VC01)
6-3. Driver board (PD-VC01)
6-4. FPC (51 pins)
6-5. Electric power supply, USB I/F connector (10 pins)
6-6. G-SDI/HD-SDI output connector (BNC)
6-7. DC IRIS LENS connector (4 pins)
6-8. RS-232C I/F connector (3 pins)
7. External Connector Specifications .9
7-1. PD-VC01 CN1 (10 pins)
7-2. PD-VC01 CN2 (BNC)
7-3. PD-VC01 CN4 (4 pins)
7-4. PD-VC01 CN4 (4 pins)
8. Guideline for Thermal design .10
8-1. Operating temperature of main parts
8-2. Temperature measurement of the surface of the device
8-3. Reference> surface temperature of each device in a Pacific chassis(29mm×29mm×77mm)
9. Factory Settings .11
10. Dimension .13
11. Case for Indemnity (Limited Warranty) .14
12. MOS Pixel Defect .14
13. Product Support .14

VPC-HD22
VPC-HD22 Product Specification & Operational Manual
3
1. Scope of Application
This is to describe VPC-HD22, an assembly unit for camera modules. All specifications contained herein are
subject to change without prior notice. Reproduction in whole or in part is prohibited.
2. Handling Precautions
The assembly unit must not be used for any nuclear equipments or aerospace equipments
with which mechanical failure or malfunction could result in serious bodily injury or loss of
human life. Our warranty does not apply to damages or defects caused by irregular and/or
abnormal use of the product..
Please observe all warnings and cautions stated below.
Our warranty does not apply to damages or malfunctions caused by neglecting these
precautions.
Do not use or store the assembly unit in the dusty or humid places.
.
Do not apply excessive force or static electricity that could damage the assembly unit.
Do not shoot direct images that are extremely bright (e.g., light source, sun, etc).
Follow the instructions in Chapter 7, “External Connector Pin Assignment” for connecting
the camera module. Improper connection may cause damages not only to the camera
module but also to the connected devices. t
Confirm the mutual ground potential carefully and then connect the camera module to
monitors or computers. AC leaks from the connected devices may cause damages or
destroy the camera module.
Do not apply excessive voltage. (Use only the specified voltage.) Unstable or improper
power supply voltage may cause damages or malfunction of the camera assembly.
VPC-HD22 is an assembly unit for camera modules. It is designed based on the premise of
embedded in a camera. Therefore, the appropriate heat dissipation needs to be considered
when embedding the board unit. Operating the assembly unit without appropriate heat dissipation
considered may cause damages or malfunction.

VPC-HD22
VPC-HD22 Product Specification & Operational Manual
4
3. Product Outline
VPC-HD22 is provided as an assembly unit that is a full HD color camera module VPC-HD20 utilizing a 1/3 type
MOS image sensor.
1080 60p/59.94p/50p (3G-SDI), 1080 60i/59.94i/50i (HD-SDI), 720 60p/59.94p/50p (HD-SDI) is corresponded.
Key Features
□Features original ISP, state-of-the-art “ClairvuTM” engine for superb imaging quality.
□Sensor board 25.4mm×25.4mm, Main board 25.4mm×38mm, Driver board 25.4mm×38mm.
□Cameras are controllable with RS-232C and USB communications.
*This model uses μT-Kernel source code based on μT-License of T-Engine Forum
(www.t-engine.org ).
4. Bundled Items
4.1. Standard Bundled Items
□Sensor board (BI-VC01PA), Main board (MB-VC01), Driver board (PD-VC01)
*Boards are connected with FPC (51 pins) at the time of delivery.
□10 pins connector (power, USB, I/F)
□4 pins connector (DC IRIS)
□3 pins connector (RS-232C)
4.2. Packaging
□Individual carton
□Master carton (10pcs/carton)
*Master carton may change depends on the quantity to be shipped per delivery.

VPC-HD22
VPC-HD22 Product Specification & Operational Manual
5
5. Specification
5.1. General Specifications
(1)
Pick up device
Device Type
1/3 type MOS sensor (color)
Effective Pixel Numbers
1944(H) × 1092(V)
Unit Cell Size
2.75μm(H) ×2.75μm(V)
Chip Size
5.346mm(H) × 3.003mm(V) (Effective Pixels)
(2)
Resolution
1080p,1080i :
1920(H) × 1080(V)
720p :
1280(H) × 720(V)
(3)
Aspect Ratio
16 : 9
(4)
Video Output Format
1920 x 1080p @60fps(Level A)
3G-SDI
1920 x 1080p @60fps(Level B)
3G-SDI
1920 x 1080p @59.94fps(Level A)
3G-SDI
1920 x 1080p @59.94fps(Level B)
3G-SDI
1920 x 1080p @50fps(Level A)
3G-SDI
1920 x 1080p @50fps(Level B)
3G-SDI
1920 x 1080i @60fps
HD-SDI
1920 x 1080i @59.94fps
HD-SDI
1920 x 1080i @50fps
HD-SDI
1280 x 720p @60fps
HD-SDI
1280 x 720p @59.94fps
HD-SDI
1280 x 720p @50fps
HD-SDI
(5)
Sync. System
Internal Sync.
(6)
Video Output Standard
3G-SDI/HD-SDI : Y/Pb/Pr(4:2:2 10bit) BNC 75Ωterminal
(7)
Sensitivity
F5.6 2000lx
(8)
Minimum illumination
F1.4 1.2lx
Conditions : VIDEO 50%, AGC 30dB, Electric Shutter OFF
(9)
Dust or stains in optical
systems
No dust or stain shall be detected on the testing screen with setting the camera aperture at
F16.
(10)
Power Requirements(*1)
DC+9～+15V
(11)
Power Consumption(*1)
4.0W at DC+12V IN
(12)
Dimensions
Refer to overall dimension drawing
(13)
Weight
Approx. 12g (Sensor board, Main board)
(14)
Lens Mount
OLPF and a filter on a sensor board at the time of delivery
(15)
Gain Setting
AGC (Max. Gain : 0dB～30dB)
MANUAL : 0dB～30dB
(16)
Shutter Speed Variable
Range
OFF : 1/60(60fps, 59.94fps), 1/50(50fps)
MANUAL : 1/8k, 1/4k, 1/2k, 1/1k, 1/500, 1/250, 1/120, 1/100, 1/60, Open
AUTO : 1/8k s～Open (Upper limit and lower limit can be set.)
(17)
White Balance Adjustment
Range
AUTO, AUTO(Outdoor), Preset 7 different kinds, User Preset 1～5, One Push
Preset:
Daylight(5500K), Cloudy(6500K), Shade(8000K), Tungsten(3200K), Fluorescent(White),
Fluorescent(Neutral White), Fluorescent(Daylight) 6500K
(18)
DC IRIS output(*1)
Auto/Open Selectable. Can be used with electric shutter (With priority to electric shutter).
(19)
Auto Exposure Detection
Average/Center-Weight/Spot(1/256)/Backlight Compensation
(20)
Flicker Cancelling
OFF/ON
(21)
Edge Enhancement
OFF, 1, 2, 3, 4, 5 (typ.3)

VPC-HD22
VPC-HD22 Product Specification & Operational Manual
6
(22)
Color Saturation Adjustment
0%(B/W)～100%(typ.)～200%
(23)
Gamma Compensation
Auto Gamma Compensation OFF(γ≒0.45) , ON, ON[Strong]
(24)
Contrast Adjustment
-2, -1, 0, 1, 2 Selectable (typ.0)
(25)
Color Balance
Blue/Red：-100～0～100(typ.0) , Green/Magenta：-100～0～100(typ.0)
(26)
Black Level Adjustment
Level:0～127(typ.0)
(27)
Pixel Defect (White spot)
Correction
Corrected at factory setting.
(28)
Remote Control Operation
Cameras can be controlled via RS-232C communications or USB 2.0 Full Speed (12Mbps).
Camera settings can be controlled by control software via PC.
(29)
Safety/Quality standards
UL: Conform to UL Standard including materials and others
RoHS: Conform to RoHS
CE and FCC are acquired as VPC-HD20 (chassis typed camera).
(30)
Durability (*1)
Vibration
Acceleration
: 98m/s2 (10G)
Frequency
: 20～200 Hz
Direction
: X,Y, and Z, 3 directions
Testing time
: 120min for each direction
Shock
No malfunction shall be occurred with 980m/s2(100G) for ±X,±Y, and ±Z, 6
directions.
(31)
Operation environment
(*1)
Performance guaranteed
0 ～+40℃Humidity
20 ～80%RH
with no condensation
Operation guaranteed
-5 ～+45℃Humidity
20 ～80%RH
with no condensation
※Performance guaranteed: All the specifications specified in this manual is guaranteed
under performance guaranteed temperature.
※Operation guaranteed : All the camera functions operate normally under operation
guaranteed temperature.
(31)
Storage Environment (*1)
Storage Temperature:
-25 ～+60℃Humidity
20 ～80%RH
with no condensation
(*1) Applied when embedded in VPC-HD20, chassis typed camera.
<3G-SDI output Level A and Level B>
A difference between Level A and Level B is a way of mapping Y signal and Cb/Cr signal onto 3G-SDI standard signal. The
difference does not affect the resolution of the video signal. Some 3G-SDI receivers correspond to either Level A or B, whereas
other receivers correspond to both Levels, so please set the camera mode to match your 3G-SDI receiver.

VPC-HD22
VPC-HD22 Product Specification & Operational Manual
7
6Part Names and Functions
BI-VC01 Board
MB-VC01 Board
PD-VC01 Board
OLPF
Filter Case
BNC (3G,HD-SDI OUT)
1
2
3
4
6
587
CN1
CN1 CN2
CN3 CN4 CN5 CN1 CN2
1. Sensor board (BI-VC01PA)
OLPF and filter case are attached to the sensor board.
Protect the OLPF from dusts.
Has the same serial number as the one on a main board
2. Main board (MB-VC01)
Mainly provided with on-board FPGA and CPU.
Has the same serial number as the one on a sensor board.
3. Driver board (PD-VC01)
Mainly provided with on-board 3G-SDI, HD-SDI drive, and power circuit.
Has the same serial number as the one on a sensor board.
4. FPC (51 pins)
FPCs which connect each board
Boards are connected at the time of delivery.
Sensor board and main board are paired up as the correction data of the sensor is saved in the main
board.
5. Electric power supply, USB I/F connector (10 pins)
Power input (DC+12V) and USB I/F signal.
Connect to the power input and USB using the attached 10 pins cable.
6. 3G-SDI/HD-SDI output connector (BNC)
3G-SDI/HD-SDI video-out signal
Connect to the 3G-SDI/HD-SDI monitor using BNC cable.
7. DC IRIS LENS connector (4 pins)
Signal for the DC IRIS lens.LENS

VPC-HD22
VPC-HD22 Product Specification & Operational Manual
8
Connector for Power input and Connnect to the DC IRIS LENS using the attached 4 pins cable.
No connection is needed when DC IRIS is not in use.
8. RS-232C I/F connector (3 pins)
Signal for RS-232C
Connect to the RS-232C using the attached 3 pins cable.
No connection is needed when RS-232C is not in use.

VPC-HD22
VPC-HD22 Product Specification & Operational Manual
9
7. External Connector
7.1 PD-VC01 CN1 (10 pins)
7.2 PD-VC01 CN2 (BNC)
7.3 PD-VC01 CN4 (4 pins)
1 4
7.4 PD-VC01 CN5 (3 pins)
1 3
Pin No.
1
Power IN DC+12V
2
GND
3
N.C.
4
N.C.
5
N.C.
6
N.C.
7
USB_VBUS
8
USB_D-
9
USB_D+
10
GND
Pin No.
1
3G-SDI/HD-SDI output
2
GND
Pin No.
1
IRIS_DUMP+
2
IRIS_DUMP-
3
IRIS_DRIVE-
4
IRIS_DRIVE+
Pin No.
1
RS-232C-TXD
2
RS-232C-RXD
3
GND
1
10
Model Name BM10B-SRSS-TB (JST)
Model Name BCJ-BPLHA (CANARE)Model Name BCJ-BPLHA (CANARE)
Model Name BM4B-SRSS-TB (JST)
Model Name BM3B-SRSS-TB (JST)

VPC-HD22
VPC-HD22 Product Specification & Operational Manual
10
8. Guideline for Thermal design
This camera is designed for embedding into a chassis, therefore, operating the board itself without heat
release will exceed the tolerance of the operation temperature. The operation temperature will reach 130℃
when operating FPGA without casing. Do not leave it on without casing as it may cause burns and damages
to the camera. Please refer to the guideline below for designing heat dissipation.
8.1. Operating temperature of main parts
Board(ref)
Data sheet value
Upper limit temperature of
IC package surface
Image sensor
BI-VC01PA(IC1)
ta=75℃
85℃
FPGA
MB-VC01(IC1)
ta=85℃
80℃
CPU
MB-VC01(IC4)
ta=85℃
95℃
SDI IC
PD-VC01(IC3)
ta=85℃
95℃
Upper limit temperature of the package is ta+10℃for parts defined “ta” on a data sheet.
As the data sheet value of FPGA says “tj,” upper limit temperature of FPGA shall be 80℃based on the thermal
conductivity of the package and power consumption.
Please release heat so that surface temperature of the IC package on a board in a chassis does not exceed the
upper limit temperature. Please measure the temperature in the usage environment.
Give first priority to the heat dissipation of the FPGA because it is the main heat source.
8.2. Temperature measurement of the surface of the device.
Measure temperature by fixing a thermocouple to the device surface with tape, making a slit in the heat
conduction sheet, and adhering a heat-sink tightly onto it.
(E.g.：Temperature measurement of the surface of FPGA)
8.3. Reference> surface temperature of each device in a Pacific chassis(29mm×29mm×77mm)
Ambient
Temperature
25℃
40℃
45℃
Image sensor
58
73
78
FPGA
55.7
70.7
75.7
CPU
51.7
66.7
71.7
SDI IC
55.1
70.1
75.1

VPC-HD22
VPC-HD22 Product Specification & Operational Manual
11
9. Factory Setting
Factory Settings
Video Format Settings
1920 x 1080p @60fps(Level A)
1920 x 1080i @60fps
1920 x 1080p @60fps(Level B)
1920 x 1080p @59.94fps(Level A)
1920 x 1080p @59.94fps(Level B)
1920 x 1080p @50fps(Level A)
1920 x 1080p @50fps(Level B)
1920 x 1080i @60fps
1920 x 1080i @59.94fps
1920 x 1080i @50fps
1280 x 720p @60fps
1280 x 720p @59.94fps
1280 x 720p @50fps
Gain Mode
Auto, Manual
Auto
Manual Gain
0dB～30dB
0dB
Max Gain
0dB～30dB
30dB
Shutter Mode
Auto, Manual
Auto
Shutter Limit Max
Open ～< Shutter Limit Min
Open
Shutter Limit Min
Shutter Limit Max < ～1/8000
1/8000
Manual Shutter
Open～1/8000
Open
Iris
Open, Auto
Open
Flicker Cancel
OFF/ON
OFF
AE Mode
Average
Center-Weight
Center-Weight
Spot
Backlight Compensation
Spot Block
X=0～15 , Y=0～15
X=8, Y=8
AE Level
0(%)～100(%)
50(%)
AE Speed
0 ~ 100
2
White Balance Settings
Auto
Auto
Auto(Outdoor)
Daylight(5500K)
Cloudy(6500K)
Shade(8000K)
Tungsten(3200K)
Fluorescent(White)
Fluorescent(Neutral White)
Fluorescent(Daylight)
OnePush
Manual
Preset 1～5
Manual R Gain
0(%)～800(%)
100(%)
Manual B Gain
0(%)～800(%)
100(%)
Noise Reduction
OFF, ON
OFF
Edge Enhancement
OFF, 1, 2, 3, 4, 5
3
Color Saturation
0(%)～200(%)
100(%)

VPC-HD22
VPC-HD22 Product Specification & Operational Manual
12
Color Balance Blue/Red
-100～100
0
Color Balance Green/Magenta
-100～100
0
Pedestal
OFF/ON
OFF
Pedestal Level
0～127
44
Contrast
-2, -1, 0, 1, 2
0
Auto Gamma
OFF, ON, ON[Strong]
OFF

VPC-HD22
VPC-HD22 Product Specification & Operational Manual
13
10. Dimensions

VPC-HD22
VPC-HD22 Product Specification & Operational Manual
14
11. Case for Indemnity (Limited Warranty)
We shall be exempted from taking responsibility and held harmless for damage or losses incurred by
the user in the following cases.
In case damage or losses are caused by fire, earthquake, or other acts of God, acts by third party,
deliberate or accidental misuse by the user, or use under extreme operating conditions.
In case indirect, additional, consequential damages (loss of business interests, suspension of
business activities) are incurred as result of malfunction or non-function of the equipment,
we shall be exempted from responsibility for such damages.
In case damage or losses are caused by failure to observe the information contained in the
instructions in this product specification & operation manual.
In case damage or losses are caused by use contrary to the instructions in this product
specification & operation manual.
In case damage or losses are caused by malfunction or other problems resulting from use of
equipment or software that is not specified.
In case damage or losses are caused by repair or modification conducted by the customer or any
unauthorized third party (such as an unauthorized service representative).
Expenses we bear on this product shall be limited to the individual price of the product.
12. MOS Pixel Defect
MOS pixel defects might be noted with time of usage of the products.
The cause of the MOS pixel defects is the characteristic phenomenon of MOS itself and Pacific Corp is
exempted from taking any responsibilities for them.
13. Product Support
When defects or malfunction of our products occur, and if you would like us to investigate on the cause
and repair, please contact your distributors you purchased from to consult and coordinate.
