Perfect Aire 1PACF34 User manual
CHEST FREEZER
3.5, 5.0, 7.0, AND 8.8 CU. FT.
FOR MODEL:
1PACF34
1PACF50
1PACF70
1PACF88
Before using your refrigerator, please
read this manual carefully and keep it for
future reference, along with your receipt.
USER MANUAL
1
7
8
9
1
3
5
6
IMPORTANT SAFETY INSTRUCTIONS
For your safety and to avoid any
unnecessary accidents, before
installing or using the appliance, we
recommend you read through these
instructions carefully, as they provide details
about its usage and functions:
Ensure that all people using this appliance are
familiar with its operation and safety features.
It is important that you install the appliance
correctly and pay attention to the safety
instructions carefully.
We recommend that you wait 4 hours with the
freezer upright before plugging the appliance
in, to allow the refrigerant to flow back into the
compressor.
Save this user's manual and keep it with the
appliance for future reference so that any
future users will be properly informed on its
usage.
If you think the freezing is not operating
correctly, please check the troubleshooting
page for assistance. If still in doubt, contact
customer service for assistance at
1-844-472-2473.
Safety for children and vulnerable persons
This freezer is not intended for use
by children or persons with reduced
physical, sensory, or mental capabilities, or
a lack of experience and knowledge, unless
they have been given instructions regarding
the use of the appliance by a person
responsible for their safety. Children should
be supervised to ensure that they do not play
with the appliance. The following precautions
are advised:
Keep all packaging away from children to
avoid risk of suffocation.
Protect children from being burned by
touching the hot compressor located at the
bottom rear of the appliance.
Don’t place items on top of the appliance as
this could cause injury should they fall off.
Never allow children to play with the appliance
by hanging or standing on top of the freezer or
inside the basket or chest compartment.
If you are discarding the freezer, pull the plug
from the outlet, cut the power cord as close to
the appliance as you can, and remove the door
to prevent playing children from suffering
electric shock or suffocation.
This appliance features a magnetic door seal; if
it is replacing an older appliance featuring a
spring lock (latch) on the lid, destroy the spring
lock before discarding the old appliance. This
will prevent playing children from suffocating.
General Safety
This appliance is intended to be used in
households and similar applications,
-staff kitchens in shops, offices and other
workplaces;
-farm houses and other residential dwellings;
-by clients in hotels, motels, or bed and
breakfast type establishments;
-catering and similar non-commercial uses.
WARNING- Do not use any means, other
than those stated in this manual, to accelerate
the defrosting process, including hair dryers.
WARNING-Do not damage the refrigerant
circuit.
WARNING- Check the power cord and plug
for damage. If either are damaged, leave the
appliance unplugged and call customer
service for replacement, which must be
installed by a qualified technician in order to
avoid a injury, damage to the appliance, or
voiding the warranty.
such as:
7
IMPORTANT SAFETY INSTRUCTIONS
PARTS DIAGRAM
INSTALLATION AND SET UP
TEMPERATURE ADJUSTMENT AND
OPERATION
MAINTENANCE
DEFROSTING
DISPOSAL
TROUBLESHOOTING
2
General Safety (continued)
WARNING- Ensure all vents have
sufficient airflow and are unobstructed.
WARNING- Do not store explosive or
substances such as aerosol cans with a
flammable propellant in this appliance. Do not
expose to flame.
WARNING- Do not use electrical appliances
inside the food storage compartments of the
appliance, unless they are of the type
recommended by the manufacturer.
WARNING- Do not store explosives or
substances with a flammable propellant, such
as aerosol cans, in this freezer. Do not expose
the appliance to flame.
WARNING- Do not use electrical appliances
inside the food storage compartment, unless
they are recommended by the manufacturer.
Refrigerant and the risk of fire:
This appliance contains a small
quantity of the refrigerant isobutene (R600a)
within the refrigerant circuit, a natural gas with
a high level of environmental compatibility,
which is nevertheless flammable. During
transportation and installation of the
appliance, ensure that none of the refrigerant
tubing becomes damaged to avoid the risk of
fire as R600a is flammable.
WARNING- Freezers contain refrigerant and
gases in the insulation. Refrigerant and gases
must be disposed of professionally as they
are flammable may cause eye injuries or
ignition. Ensure that tubing of the refrigerant
circuit is not damage prior to proper disposal
at an authorized waste facility.
lamps, naked flames, or any ignition sources
away from the appliance.
If the refrigerant circuit becomes
damaged
: Thoroughly ventilate the room to
avoid the risk of fire and eye injury should
any leakage of refrigerant (R600a) exist.
Warning: Risk of fire/flammable
materials!
Keep burning candles, lamps,
Electrical safety
IMPORTANT SAFETY INSTRUCTIONS
To avoid the risks that are always
present when using an electric
appliance, we recommend that you read and
follow the electrical safety instructions below:
Replacing the LED light:
WARNING — The LED light must not be
replaced by the user! If the light is damaged,
contact customer service for assistance.
•
Unpack and check the appliance over. If any
damage is evident, don’t plug in the appliance,
keep all packing materials, and immediately
contact customer service.
•
The cord must not be altered in any way as
it may overheat and cause a fire.
•
Make sure the cord is not trapped or
damaged when positioning the freezer.
•
The plug for the appliance must be
accessible after installation.
•
Do not pull the cord to unplug the freezer.
Pull by the plug.
•
Do not plug in or use the appliance if the
outlet or socket is broken. There is a risk of
electric shock or fire.
•
You must not operate the appliance without
the interior lighting lamp cover.
•
Do not place power strips or extension cords
immediately behind the appliance due to heat
from the compressor.
•
This appliance is fitted with a 3-prong
grounding plug with a rated current of
220~240 V/50Hz. The grounding plug should
be in accordance with current specifications
for use in all houses fitted with 230V
sockets. If the outlet doesn't support 3-
prong plugs, do not cut off the ground
prong. Instead, please contact a qualified,
registered electrician to install the correct
outlet.
•
Do not use extension cords or plug adapters,
which could overload the circuits and could
cause a fire. Always plug the freezer into its
own dedicated outlet which has a voltage rating
that matches the rating plate.
•
Turn the freezer off and unplug it from the
outlet before cleaning or moving it.
Model NO:
1PACF34, 1PACF50, 1PACF70, 1PACF88
0
0
DO NOT touch the frozen foods inside the freezer or the freezer compartment itself
with wet hands as this could result in frostbite.
Pictures are for reference only, and may be slightly different from the actual appliance.
-
Door Handle
Power Cord
PARTS DIAGRAM
BEFORE USE
•
Remove the freezer from the shipping box, along with all plastic, etc.; leave the door open to ventilate
the appliance.
•
The appliance is cleaned prior to shipment. However, we recommend cleaning the interior again after
delivery.
•
This appliance has a 3-prong grounding plug which requires a 220~240V wall outlet.
•
Leave the freezer unplugged and upright for 4 hours to allow the refrigerant to flow back into the
compressor.
•
Run the appliance for about 1 hour before placing items into the freezer, to allow enough time for the
compartment to cool .
3
State of California Proposition 65 Warnings:
WARNING:This product contains one or more chernicals known to the State of California to
cause cancer.
WARNING:This product contains one or more chernicals known to the State of California to
cause birth defects or other reproductive harm.
V
en
t
Co
v
er
To prevent moisture loss, odor transfer, or leaking: prior to freezing, food should be
placed into
separate non-toxic, tasteless, impermeable, waterproof, sealed bags or containers.
Hot food should be cooled to room temperature before being put into the freezer to prevent both
heat transfer to other stored foods and increased power consumption.
Review the Table below prior to freezing food, to ensure items are suitable for storage in your chosen
appliance:
One, two, and three-star compartments are not suitable for freezing fresh food.
Two-star compartments are not suitable for storing pre-frozen food, storing or making ice cream, or
making ice cubes.
Order Appropriate food
Compartment
TYPE
Target
storage temp.
(°F/°C)
1
2
(***)*-Freezer <-.4/-18
Seafood (fish, shrimp, shellfish), freshwater
aquatic products and meat products
(recommended for 3 months, the longer the
storage time, the worse the taste and nutrition),
suitable for frozen fresh food.
3
***-Freezer <-.4/-18
Seafood (fish, shrimp, shellfish), freshwater aquatic
products and meat products
(recommended for 3 months, the longer the storage
time, the worse the taste and nutrition), are not suitable
for frozen fresh food.
4
**-Freezer <10.4/-12
Seafood (fish, shrimp, shellfish), freshwater aquatic
products and meat products
(recommended for 2 months, the longer the storage
time, the worse the taste and nutrition), are not suitable
for frozen fresh food.
*-Freezer <-21.2/-6
Seafood (fish, shrimp, shellfish), freshwater aquatic
products and meat products
(recommended for 1 months, the longer the storage
time, the worse the taste and nutrition), are not suitable
for frozen fresh food.
3
Climate class
SN
N
ST
T
This appliance performs best according
to the operational temperature chart on
the right. It may not work properly if left to
operate for a long period of time outside
the indicated range.
4
Ambient temperature
50° to 90°F (+10° to 32°C)
60° to 90°F (+16° to 32°C)
60° to 100°F (+16° to 38°C)
60° to 109°F (+16° to 43°C)
INSTALLATION AND SET UP
•The supply voltage should be 220~240V AC. If
the sockets in your home can not sustain a
constant 13 amp draw, and do not accept the 3-
prong grounding plug supplied with the freezer,
contact a qualified electrician for replacement.
•The use of adapters or extension cables is not
recommended.
•The plug has a removable fuse cover that
must be reattached after the fuse is replaced. If
the fuse cover is lost or damaged, the plug must
not be used until the cover or the plug is
replaced.
•Only 13 amp fuse approved to BS1363/A
standards must be used as replacements.
•A damaged plug should be cut off as close to
the plug body as possible, the fuse should be
removed and the plug disposed of safely .
•Plug the freezer into a dedicated 220~240 V
AC wall outlet. Do not tamper with the plug in
any way.
5
Important!
To prevent the risk of overheating or fire,
the compressor located at the back of the
appliance must not be against a wall. Good
ventilation is required to allow heat to dissipate
around the freezer, increase efficiency, and
lower power consumption. Sufficient clear space
should be maintained around the freezer. There
must be 3 in. (75mm) between the back of the
freezer and the wall; at least 4 in. (100 mm) of
space on either side, a height of over 19 in
(500 mm) above its top.
100m
75mm
Cleaning before use
•
Unpack the appliance and check it over. If
any damage is evident, don’t plug in the freezer
and immediately contact customer service,
keeping all packing materials.
•
Before using the appliance for the first time,
wash the interior and any interior accessories
with lukewarm water and neutral soap, then dry
thoroughly. This removes the typical smell of a
brand new product.
Important! Do not use detergents or abrasive
powders, as these will damage the finish.
Appliances must not be exposed to rain.
Sufficient air must be allowed to circulate
around the lower rear section of the appliance,
as poor air circulation can affect performance.
The freezer should be positioned away from
heat sources such as stoves and direct
sunlight.
Installation Position requirements
Warning! Before installing this appliance,
read the Safety instructions carefully, for
the correct operation of the appliance and to
avoid personal injury.
Any electrical work that is required to install this
appliance MUST be carried out by a qualified
electrician.
Warning:
THIS APPLIANCE MUST BE GROUNDED
•Make sure the plug remains accessible after
installation.
•This appliance is intended for freezing food
and/or beverages only in the environments
described on page 1. The freezer is heavy. Be
careful when moving it.
•Never stand, climb, or sit on the freezer.
•Frozen food must not be refrozen once it has
been thawed out.
•Keep burning candles, lamps, and all naked
flames away from the freezer so they do not
set the appliance on fire.
Leveling
•The appliance must be level in order to
eliminate vibration. To level the freezer, it
should be upright with both adjusters in
stable contact with the floor.
•You can adjust the level by unscrewing the
feet in the front to the appropriate level using
your fingers or adjustable wrench.
4 in.
19 in.
3 in.
6
TEMPERATURE ADJUSTMENT AND OPERATION
ADJUSTMENT
MID
TEMPERATURE
.{Q)_
OFF
•Turn the knob to the right towards MAX to
make food colder.
•If it is too cold, turn the knob to the left
towards MIN.
•To stop running the appliance temporarily,
turn the knob all the way to the left to OFF.
•This appliance is intended for freezing food
and/or beverages only in the environments
described on page 1. The freezer is heavy. Be
careful when moving it.
•Never stand, climb, or sit on the freezer.
•Frozen food must not be refrozen once it has
been thawed out.
•Keep burning candles, lamps, and all naked
flames away from the freezer so they do not
set the appliance on fire.
•To avoid causing damage to the appliance,
do not overload the appliance with too much
food in the chest compartment.
EFFICIENT OPERATION
Adhere to the following instructions in order to
reduce energy consumption.
•To change the
temperature
inside the freezer, turn the
temperature control knob on
the front of the appliance
near the bottom. We
recommend selecting
•To prevent cold air from escaping the chest
freezer, open and close the door quickly;
keeping the door opened for as short a time
period as possible.
•Install the appliance in a dry, well-ventilated
location to avoid high moisture.
•Never use the freezer to store water or food
that requires water as a storage medium.
Never place fresh seafood containing water
directly into the appliance.
DAILY OPERATION
•
•
Do not store flammable gas or liquids in the
appliance. There is a risk of an explosion.
Do not operate any electrical appliances in
the freezer (ie. ice cream makers, mixers
etc.).
•When unplugging the freezer, always pull the
plug from the socket, do not pull on the cord.
•Do not place hot items near the plastic
components of the freezer.
•Do not place anything directly against the air
outlet on the rear wall.
•Store pre-packaged frozen food according to
the manufacturer's instructions.
•Food
manufacturer's storage
recommendations
should always be strictly adhered to. Refer to
package instructions for storage.
• Do not place carbonated or fizzy drinks in the
freezer as this puts pressure on the container,
which may cause it to explode and damage
the appliance.
•Do not touch items or remove them from the
freezer if your hands are wet, as this could
cause frostbite.
•Do not consume popsicles, ice cubes, or any
other frozen food straight from the freezer as
this can cause frostbite or freezer burn to the
mouth and lips.
•Opening the door for long periods can cause a
significant increase of the temperature in the
freezer compartment.
•Clean accessible drains, as well as surfaces
that regularly come in contact with food.
•Store raw meat and fish in sealed, airtight
containers so it does not contaminate other
food.
•If the freezer will be empty for extended time
periods, turn it off then defrost, clean, and dry
it, leaving the door propped open to prevent
mold growth inside the appliance.
MID for most applications.
Insert the plug into a dedicated, grounded
230V wall outlet.
·Position the freezer away from direct sunlight,
rain, or frost; avoid standing the freezer near
heat sources, stoves, fires, or heaters.
•staff kitchens in shops, offices and other
workplaces;
•farm houses and other residential dwellings;
•by clients in hotels, motels, or bed and
breakfast type establishments;
•catering and similar non-commercial uses.
This appliance is intended to be used
in households and similar applications,
such as:
To prevent the risk of fire or shock, after
cleaning the freezer check the following:
•Is the cord plugged firmly into a dedicated wall
outlet? Confirm that the plug is not abnormally
hot.
•Check the power cord for cracks and damage.
Should any damage be evident, do not plug it
back in; contact customer service.
WAIT 5 MINUTES OR MORE BEFORE RE-STARTING
•
Restarting the freezer immediately after it has
been turned off may cause: fuses to blow, the
circuit-breaker to trip, the compressor to be
overloaded, and/or other damage to the
appliance.
Never use polishing powder, soap powder,
benzine, oil or
hot water as
these will @�
damage the
painting and
plastic components.
CLEANING AND DEFROSTING Caution!
Cleaning
To prevent electrical shock or personal injury by,
turn off and unplug the freezer before cleaning.
•
•
Do not clean the appliance with metal objects,
steam cleaners, essential oils, solvents, or
abrasive cleansers.
Do not use sharp objects to remove frost from
the freezer. Use a plastic scraper.
EXTERIOR
Wipe down with a soft, dry cloth. A cloth that has
been moistened with detergent may be used if
needed for highly soiled surfaces; wipe with a
damp cloth dipped in clean water before drying.
WARNING
: To prevent a short-circuit and/or
electrical shock, do not splash water directly onto
the chest freezer; do not submerge or wash it
with water.
INTERIOR
Clean the freezer regularly to keep it sanitary
at all times.
IMPORTANT!
•Turn the temperature control knob to MIN at
least 12 hours before defrosting.
•After the 12 hours has elapse, switch to OFF
and unplug the freezer from the outlet.
•Remove all food from the freezer; wrap them
in
paper before storing in a cold place. Leave the
freezer door open.
•After defrosting, the freezer compartment
must be cleaned and wiped dry.
•Plug the appliance back in and turn it on by
rotating the temperature control knob to MIN;
wait one hour before replacing the food.
•After a few hours, turn the knob back to its
original position.
WARNING:
Do not use steam cleaners, heat guns, or any
other appliances to speed up defrosting, unless
directed by the manufacturer. WARNING:
Do not use electrical appliances inside the
freezer, unless directed by the manufacturer.
•Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of
obstruction.
•Open the door and wipe clean with a dry cloth.
DEFROSTING
Defrost the freezer compartment two
or three times a year, when the ice is
about 3/20th in. (4 mm) thick. To defrost, follow
these steps:
Service
•Any electrical work required to service the
appliance must be carried out by a licensed
electrician. This product must be serviced
using only genuine spare parts provided by
the manufacturer.
7
DEFROSTING AND MAINTENANCE
DISPOSAL OF THE APPLIANCE
1. Pull the electrical plug out of the outlet.
2. Cut off the power cord and discard along with the electrical plug.
Warning! Freezers contain refrigerant and gases in the insulation which must be
disposed of professionally as they may cause eye injuries or ignition. Ensure the
tubing of the refrigerant circuit is not damaged prior to proper disposal.
Correct Disposal of this appliance
This symbol on the product or in its packing indicates that this
product may not be treated as household waste. Instead, it should
be taken to the appropriate waste collection point for the recycling of
electrical and electronic equipment. By ensuring this product is
disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could
otherwise be caused by the inappropriate waste handling of this
product. For more detailed information about the recycling of this
product, please contact your local government, your household
waste disposal service, or the shop where you purchased the product.
It is prohibited to dispose of this appliance as household waste.
Dispose of this appliance in accordance with Federal and Local regulations. Refrigerants
must be evacuated before disposal. Packaging materials with the recycle symbol should
be disposed of in a suitable waste collection container for recycling.
Before disposal of the appliance
8
9
TROUBLESHOOTING
WHEN NOT USED
FOR A LONG PERIOD
TRANSPORION
TEMPORARY
STORAGE
A
1
844
472
2473
(1
844
4
A
A
E)
U
If you experience a problem with your
appliance or are concerned that the appliance
is not functioning correctly, you can carry out
some easy steps below.
Warning! Do not try to repair this
appliance yourself. If the problem
persists after you have tried the steps
mentioned below, contact customer service.
IMPORTANT!
This appliance contains no user serviceable
parts. Repairs may only be performed by
licensed electricians. If your freezer is
malfunctioning, contact customer service at
1-844-472-2473 (1-844-4PA-AIRE) for further
instructions.
Issue Solution
10
No refrigeration at all
Inadequate
refrigeration
Excessive noise
Condensation
on t
h
e
f
ree
z
er
exterior
M
D
M
X
;
j
�
Pipe
If you experience a problem with your appliance or are concerned that the appliance is not functioning correctly,
you can carry out some easy steps below. If the problem continues, disconnect the power cord plug from the wall
outlet before calling customer service. To prevent electric shock, do not disconnect the plug from the outlet with wet
hands.
Warning! Don't try to repair the appliance yourself. If the problem persists after you have tried the steps mentioned
below, contact customer service at 1-844-472-2473 (1-844-4PA-AIRE).
TROUBLESHOOTING
Distributed by:
Perfect Aire, LLC
5401 Dansher Rd.
Countryside, IL 60525
844-4PA-AIRE | 844-472-2473
www.perfectaire.us
Specification and performance data is subject to change without notice.
PA/User_1PACF34_1PACF50_1PACF70_1PACF88/04282019
This manual suits for next models
3
Table of contents
