PGS X-Warrior User manual

PGS Introduction
"Value Series" : Best VALUE gaming cases with the
highest C/P Ratio (Cost to Performance ratio).
"Professional Series –Red label" : Super tower or Super
mid-tower cases with elegant, clean line designs.
"Aluminum –Silver label" : Unique “Full aluminum” cases
targeting at power users, professionals and gamers.
"Ultimate Gaming Series –Black label" : Ultimate gaming
cases targeting at the extreme gamers. This Series offers
gamers with most functions, expandability and Extreme
cooling.
"Compact –Blue Label" : Small form factor case series
including cube cases, mini-ITX and Mini-Tower
(Micro-ATX).
Yellow

Design Concept
Like a warrior in an armored suit on the battle field, the fierce looking X-
Warrior is one of the coolest gaming case which is affordable and yet
charismatic in its own design and certainly a great show-off to your
friends. This case is one of the BEST VALUE case in the market today if not
the BEST VALUE case.
The Chassis is solidly constructed with 0.5mm SECC. It is also beautifully
finished with ALL BLACK interior with "blue" PCI plate and screw-less knobs
(Black Edition) or ALL RED interior with “BLACK” PCI plate and “RED”
screw-less knobs (Red Edition) and it includes many advanced features
even for the most demanding gamers and enthusiasts. The
chassis supports 3 x 5 1/4" devices, 1x 3.5" FDD (with adaptor) and 4 x 3.5"
HDD + 1 x 2.5" SSD.
X-Warrior also supports long high end VGA cards up to 400 mm which is
more than sufficient for those heavy PC users and gaming enthusiasts.
X-Warrior also provides un-rival air flow and cooling. Users can install
2x12cm fan at side panel (optional) / 1x12cm fan at rear (included) and
2x12cm fans in front (one fan included). Bottom PSU position will also
suck in cold air and help cool your system.
The cable management holes are pre-drilled on the MB plate to reduce the
cable mess inside your chassis.A CPU hole is also pre-drilled on the MB
plate for easy mounting or assembly of your CPU cooler. Water-cooling
holes are also available at the case rear to support water cooling systems.
The X-Warrior is the best Gaming case your money can buy !!

Gallery
Front Back
Side
Top45
o
Open

Features
- High performance "Mid-Tower" for gamers and enthusiast.
- Solidly constructed chassis –0.5mm SECC Japanese Steel.
- ALL BLACK interior with "blue" PCI plate and screw-less knobs (Black Edition) or
ALL RED interior with “BLACK”PCI plate and “RED”screw-less knobs (Red
Edition) for an unique touch!
- Supports longer high-end VGA cards up to 400mm
- Supports 3 x 5 1/4" , 1 x 3.5"(with adaptor), 1 x 2.5" HDD and maximum 4 x 3.5"
HDDs (internal)
- "Easy-install" screw-less kits for the 5 1/4" devices
- Cable management holes are pre-drilled to reduce cable mess
- CPU hole is pre-drilled on the MB plate for ease of CPU cooler assembly
- Can install 2x12cm fan at side panel (optional) / 1x12cm fan at rear (included) and
2x12cm fans in front (one fan included)
- Bottom PSU position enables PSUs to suck in cold air for better cooling with
washable dust filter.
- Water-cooling holes are pre-drilled to support water-cooling systems
- 2 x USB/ Audio + Mic (AC’97 + HD audio) are easily accessible from the top
panel.

Specifications
Spec
Cooling System
Case Type
Material
Motherboards
Chassis Dimensions
Drive Bays
Expansion Slots
Max length space available for PCI slots
I / O Ports
Fan
Rated voltage
Voltage range
Starting voltage
Power consumption
Rated current
Speed
Air Flow (CFM)
Air pressure
Noise (dBA)
Bearing
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
Middle Tower
SECC 0.5mm
ATX & Micro ATX
488(H) x 187(W) x 520(D)
3 x 5.25" (External)/4 x 3.5" (Internal)/1 x 2.5" HDD
7 Slots
400mm
2 x USB2.0 / Mic & headphone (AC97 & HD audio)
120 x 120 x 25mm
12V
DC6V~13.8V
9V
2.4W
0.20A
1500 RPM +- 10%
58.35 CFM (Max)
2.1mm H2O
26.67 dBA
Sleeve
Front
12cm Blue LED Fan
120 x 120 x 25mm
12V
DC6V~13.8V
9V
2.4W
0.20A
1500 RPM +- 10%
58.35 CFM (Max)
2.1mm H2O
26.67 dBA
Sleeve
Rear
12cm Fan

Air Flow
Superb airflow - install up to 5 fans !! 1. Front - 1 x 12cm (included) Blue LED
Front - 1 x 12cm (optional)
2. Back - 1 x 12cm fan (included)
3. Side - 2 x 12 fan (optional)

Inside

Close Up
