Philips

LED Display

107cm (42")

BDL4250EL

Deliver your marketing messages in style

with this sleek LED display

Maximising your content delivery whilst lowering your TCO has never been so easy or

stunning. This 42" display offers gorgeous full HD picture quality with lower power

consumption thanks to the edge LED backlight.

Operational flexibility

• Edge LED Backlight

•DVIOut

• Display Port for faster graphics support

•ManyFunctions.OneWire

• Network Controllability: RJ45

• Smart insert in the backcover to place a small pc

• Smart Control Software Suite

• IR Passthrough

• Enhanced zoom feature supports tiled matrix applications

• Portrait mode operability

• Remote Management and Configuration via RS232

Optimized for public viewing

• Full HD LCD display, 1920x1080p

BDL4250EL/00

Highlights

LED Display

107cm (42")

Edge LED Backlight

Experience an even dispersion of light with

cutting edge LED technology. White LED's

(light emitting diodes) are positioned around

the rim of the panel to give a more even spread

of light. This results in even lower power

consumption, less heat to dissipate, and a true,

uniform color range.

DVI Out

Create a digital video wall of up to 25 displays

in a 5 x 5 configuration with a DVI daisy chain.

Simply connect the DVI Out port to a DVI in

of another display to create the most stunning

video wall experience around.

Display Port

Enjoy crystal clear images with the high-

bandwidth graphics support of the Display

Port. As well as transmitting full high-definition

video the Display Port will also transmit audio,

thus eliminating the need for extra cables.

One Wire

Take full control of your display by running all

operational commands as well as your video

signal through just one single HDMI cable. This

unique feature makes it so much easier and

more convenient to ensure the smooth

running and maintenance of your display.

Consumer Electronics Control (CEC)

commands make finding out vital information

about your display absolute childsplay.

Smart Control

Control and manage all of the signage displays

on your network with this powerful software

tool which allows you to change the settings of

your display centrally via an RJ45 or RS232

connection. Smart Control allows you to set

the video input, modify the color settings, set

the display's ID when creating video walls and

even diagnose each display's status, giving you

all the power you need to manage your

displays from one central location.

Smart insert

Professional PC's are part of most public

signage installations. Quite often they increase

the overall depth to the display and cause a lot

of cable clutter. So we have designed this

display with Smart insert in the

backcoverwhich is ideal for the integration of a

professional small form factor PC. On top of

that, the cable management system offers a

great solution to keep your cables neat and

professional looking.

SmartPower

The backlight intensity can be controlled and

pre-set by the system to reduce the power

consumption by up to 50%, which saves

substantially on energy costs.

RJ45

Simple management of your display is available

thanks to the introduction of a LAN (RJ45)

port. You can configure each display or find

out the status of each device quickly and

conveniently via an RJ45 connection.

Zoom function for tiled matrix

The internal zoom function enables easy

implementation of a video wall matrix, without

the need for expensive external equipment.

Capable of many different configurations,

creating a stunning video wall has become

simplicity itself.

IR Passthrough

Control all displays in your signage network

through one single remote control, via the

primary display. Simple and convenient, this

means you don't have to worry about other

displays changing configuration settings when

using your remote control unit.

Slim Bezel

Issue date 2014-10-29

Version: 3.3.1

12 NC: 8670 000 90643

EAN: 87 12581 64631 8

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips N.V.

or their respective owners.

www.philips.com

BDL4250EL/00

Specifications

LED Display

107cm (42")

Picture/Display

• Panel resolution: 1920x1080p

• Brightness: 500 cd/m²

• Response time (typical): 8 ms

• Contrast ratio (typical): 4000:1

• Aspect ratio: 16:9

• Pixel pitch: 0.4845 x 0.4845 mm

• Display colors: 1.07 billion

• Picture enhancement: 3/2 - 2/2 motion pull down,

3D Combfilter, Motion compens. deinterlacing, 3D

MA deinterlacing, Dynamic contrast enhancement

• Viewing angle (H / V): 178 / 178 degree

• Diagonal screen size: 42 inch / 107 cm

• Optimum resolution: 1920 x 1080 @ 60Hz

Connectivity

• PC: RJ45, VGA-in D-Sub 15HD, RS232 D-Sub9,

RS232 D-sub9 output, 3.5 mm PC audio input x1

• AV input: DVI-D x1, Component (BNC) x1,

Composite (BNC) x1

• Other connections: Display Port, DVI Out, HDMI,

USB, AC-out

• AV output: Audio (L/R) x1

Supported Display Resolution

•Computer formats

Resolution Refresh rate

1920 x 1200 60Hz

1920 x 1080 60Hz

1600 x 1200 60Hz

1440 x 900 60Hz

1366 x 768 60Hz

1360 x 768 60Hz

1280 x 1024 60Hz

1280 x 800 60Hz

1280 x 768 60Hz

1024 x 768 60Hz

800 x 600 60, 72, 75Hz

640 x 480 60, 67, 72, 75Hz

•Video formats

Resolution Refresh rate

480i 60Hz

480p 60Hz

576p 50Hz

576i 50Hz

720p 50, 60Hz

1080i 50, 60Hz

1080p 50, 60Hz

Dimensions

• Set dimensions (W x H x D):

965.8 x 558.8 x 69 mm

• Bezel thickness: 15.8 mm

• VESA Mount: 400 x 200 mm, 200 x 200 mm

• MTBF: 60,000 hrs

• Product weight: 18.3 kg

• Product weight (lb): 40.4

Convenience

• Signal Loop Through:: DVI, RS232, IR Loopthrough

• Network controllable: RJ45, RS232, HDMI (One

Wire)

• Placement: Landscape, Portrait

• Picture in picture:: PBP, PIP, POP

• Energy saving functions:: Smart Power

• Ease of installation: AC Out, Carrying Handles,

Smart Insert

• Keyboard control:: Hidden, Lockable

• Other convenience: Carrying handles

• Packaging:: Reusable box

• Tiled Matrix: Up to 5 x 5

Power

•Consumption(On mode): TBD

• Power supply: 90-264 VAC, 50/60 Hz

• Standby power consumption: <0.5W

Sound

• Built-in speakers: 2 x 10W RMS

Operating conditions

• Temperature range (operation): 5 - 40 °C

• Relative humidity: 20 - 80 %

Accessories

• Included accessories: Remote Control, Batteries

for remote control, AC Power Cord, VGA cable,

User manual on CD-ROM, Quick start guide

• Stand: BM05462 Optional

Miscellaneous

• On-Screen Display Languages: English, French,

German, Spanish, Polish, Turkish, Russian,

Simplified Chinese, Italian

• Regulatory approvals: CE, FCC, Class B, UL/cUL,

CCC, C-Tick, RoHS, GOST

• Warranty: 3 year warranty

Packaging dimensions

• EAN: 87 12581 64631 8

• Number of products included: 1

• Packaging type: Carton

•
