Philips CSS5330G User manual

www.philips.com/support
User manual
Always there to help you
Register your product and get support at
CSS5330B
CSS5330G
Question?
Contact
Philips

1EN
Contents
1 Important 2
Help and support 2
Safety 2
Care for your product 3
Care of the environment 3
Compliance 4
2 Your product 4
Main unit 4
Remote control 5
Connectors 6
Wireless subwoofer 6
3 Connect and set up 7
Place speakers 7
Pair up with the subwoofer 7
Connect to TV 8
Connect digital devices through HDMI 8
Connect audio from TV and other devices 8
Set up speakers 9
4 Use your product 10
Adjust the volume 10
Choose your sound 10
MP3 player 11
Play music via Bluetooth 11
Play music via NFC 12
Auto standby 12
Apply factory settings 12
5 Update software 13
Check software version 13
Update software via USB 13
6 Wall mount 14
7 Productspecications 14
8 Troubleshooting 15

2EN
1 Important
Read and understand all instructions before you
use your product. If damage is caused by failure
to follow instructions, the warranty does not
apply.
Help and support
For extensive online support, visit
www.philips.com/support to:
• download the user manual and the quick
start guide
• watch video tutorials (available only for
selected models)
• nd answers to frequently answered
questions (FAQs)
• email us a question
• chat with our support representative.
Follow the instructions on the website to select
your language, and then enter your product
model number.
Alternatively, you can contact Consumer Care
in your country. Before you contact, note down
the model number and serial number of your
product. You can nd this information on the
back or bottom of your product.
Safety
Riskofelectricshockorre!
• Before you make or change any
connections, make sure that all devices are
disconnected from the power outlet.
• Never expose the product and accessories
to rain or water. Never place liquid
containers, such as vases, near the product.
If liquids are spilt on or into the product,
disconnect it from the power outlet
immediately. Contact Consumer Care to
have the product checked before use.
• Never place the product and accessories
near naked ames or other heat sources,
including direct sunlight.
• Never insert objects into the ventilation
slots or other openings on the product.
• Where the mains plug or an appliance
coupler is used as the disconnect device,
the disconnect device shall remain readily
operable.
• Batteries (battery pack or batteries
installed) shall not be exposed to excessive
heat such as sunshine, re or the like.
• Disconnect the product from the power
outlet before lightning storms.
• When you disconnect the power cord,
always pull the plug, never the cable.
Riskofshortcircuitorre!
• For identication and supply ratings, see
the type plate at the back or bottom of
the product.
• Before you connect the product to the
power outlet, ensure that the power
voltage matches the value printed on the
back or bottom of the product. Never
connect the product to the power outlet if
the voltage is different.
Riskofinjuryordamagetothisproduct!
• For wall-mountable products, use only the
supplied wall mount bracket. Secure the
wall mount to a wall that can support the
combined weight of the product and the
wall mount. Gibson Innovations bears no
responsibility for improper wall mounting
that results in accident, injury or damage.
• Never place the product or any objects
on power cords or on other electrical
equipment.
• If the product is transported in
temperatures below 5°C, unpack the
product and wait until its temperature
matches room temperature before
connecting it to the power outlet.
• Parts of this product can be made of
glass. Handle with care to avoid injury and
damage.

3EN
Riskofoverheating!
• Never install this product in a conned
space. Always leave a space of at least four
inches around the product for ventilation.
Ensure curtains or other objects never
cover the ventilation slots on the product.
Riskofcontamination!
• Do not mix batteries (old and new or
carbon and alkaine, etc.).
• Danger of explosion if batteries are
incorrectly replaced. Replace only with the
same or equivalent type.
• Remove batteries if they are exhausted or
if the remote control is not to be used for
a long time.
• Batteries contain chemical substances, they
should be disposed of properly.
Riskofswallowingbatteries!
• The product/remote control may contain
a coin/button type battery, which can be
swallowed. Keep the battery out of reach
of children at all times! If swallowed, the
battery can cause serious injury or death.
Severe internal burns can occur within two
hours of ingestion.
• If you suspect that a battery has been
swallowed or placed inside any part of the
body, seek immediate medical attention.
• When you change the batteries, always
keep all new and used batteries out of
reach of children. Ensure that the battery
compartment is completely secure after
you replace the battery.
• If the battery compartment cannot be
completely secured, discontinue use of the
product. Keep out of reach of children and
contact the manufacturer.
This is CLASS II apparatus with double
insulation, and no protective earth provided.
Care for your product
Use only microber cloth to clean the product.
Care of the environment
Disposal of your old product and battery
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
This symbol on a product means that the
product is covered by European Directive
2012/19/EU.
This symbol means that the product contains
batteries covered by European Directive
2013/56/EU which cannot be disposed of with
normal household waste.
Inform yourself about the local separate
collection system for electrical and electronic
products and batteries. Follow local rules and
never dispose of the product and batteries
with normal household waste. Correct disposal
of old products and batteries helps prevent
negative consequences for the environment and
human health.
Removing the disposable batteries
To remove the disposable batteries, see battery
installation section.

4EN
Compliance
This product complies with the radio
interference requirements of the European
Community.
Hereby, Gibson Innovations declares that
this product is in compliance with the
essential requirements and other relevant
provisions of Directive 1999/5/EC.You
can nd the Declaration of Conformity on
www.p4c.philips.com.
2 Your product
Congratulations on your purchase, and
welcome to Philips! To fully benet from the
support that Philips offers, register your product
at www.philips.com/welcome.
Main unit
This section includes an overview of the main
unit.
a
Switch this product on or to standby.
b Display panel
c Standby indicator
When this product is in standby, the
standby indicator turns red.
d SOURCE
Select an input source for this product.
e Volume +/-
Increase or decrease volume.
f NFC tag
Tap the NFC-enabled device on the tag for
Bluetooth connection.
ba c e fd

5EN
Remote control
This section includes an overview of the
remote control.
a (Standby-On)
• Switch the main unit on or to standby.
b Source buttons
AUDIO IN: Switch your audio source to
the connection of an external device with
3.5mm jack (such as MP3).
AUX: Switch your audio source to the
connection of an external device with red/
white audio jacks.
OPTICAL: Switch your audio source to
the optical connection.
HDMI IN: Switch your source to the
HDMI IN connection.
b
a
c
d
f
g
i
j
e
h
l
k
: Switch to Bluetooth mode; Press and
hold three seconds to break the current
Bluetooth connection.
HDMI ARC: Switch your source to HDMI
ARC connection.
c /
Skip to the previous or next track in
Bluetooth mode (only for AVRCP-
supported Bluetooth devices).
d
Start, pause or resume play in Bluetooth
mode (only for AVRCP-supported
Bluetooth devices).
e BASS +/-
Increase or decrease bass.
f Volume control
• +/-: Increase or decrease volume.
• : Mute or restore volume.
g SOUND
Select a sound mode.
h AUDIO SYNC +/-
Increase or decrease audio delay.
i Speaker setup buttons
VOL: Enter volume setup mode for the
speakers.
DELAY: Enter distance setup mode for the
speakers.
j DIM / EXIT SETTINGS
• Set the brightness of the display panel
for this product.
• Exit speaker setup mode.
k NIGHT
Turn night mode on or off.
l TREBLE +/-
Increase or decrease treble.

6EN
Connectors
This section includes an overview of the
connectors available on this product.
a HDMI IN
Connect to the HDMI output on a digital
device.
b TO TV - HDMI OUT (ARC)
Connect to the HDMI (ARC) input on the
TV.
c FRONT SPEAKER L/R
Connect to the front speakers.
d SERVICE
Connect a USB ash drive to upgrade
software of this product (not for media
play).
e DC IN
Connect to the power supply.
f OPTICAL IN
Connect to an optical audio output on the
TV or a digital device.
g AUDIO IN
Audio input from an external device with
3.5 mm jack (such as MP3 player), or with
red/white audio jacks.
a b c d e g f
Wireless subwoofer
This product comes with a wireless subwoofer.
a PAIRING (pairing)
Press to enter the pairing mode for the
subwoofer.
b Subwoofer indicator
• When the power is turned on, the
indicator lights up.
• During wireless pairing between the
subwoofer and the main unit, the
indicator blinks white quickly.
• When the pairing succeeds, the
indicator lights up white.
• When the pairing fails, the indicator
blinks white slowly.
• When wireless connection is
disconnected for 1 minute, the
indicator turns off.
c AC MAINS~
Connect to the power supply.
b
a
c

7EN
3 Connect and set
up
This section helps you connect this product to a
TV and other devices, and then set it up.
For information about the basic connections of
this product and accessories, see the quick start
guide.
Note
• For identication and supply ratings, see the type plate
at the back or bottom of the product.
• Before you make or change any connections, make sure
that all devices are disconnected from the power outlet.
Place speakers
Speaker position plays a critical role in setting
up a surround sound effect. For best effect,
position all the speakers towards the seating
position and place them close to your ear level
(seated).
SUB
WOOFER
L
SPEAKER
R
SPEAKER
Note
• Surround sound depends on factors such as room
shape and size, type of wall and ceiling, windows and
reective surfaces, and speaker acoustics. Experiment
with the speaker positions to nd the optimum setting
for you.
Follow these general guidelines for speakers
placement.
1 Seating position:
This is the center of your listening area.
2 Main unit (function as center speaker):
Place the main unit directly in front of the
seating position, either above or below
your TV.
3 FRONT SPEAKER L (front left) and
FRONT SPEAKER R (front right) speakers:
Place the left and right speakers in the
front, and at equal distance from the main
unit. Make sure that the left, right, and the
main unit are at equal distance from your
seating position.
4 SUBWOOFER (subwoofer):
Place the subwoofer at least one meter
to the left or right of the TV. Leave about
10-centimeter clearance from the wall.
Pair up with the subwoofer
The wireless subwoofer automatically pair up
with the main unit for wireless connection
when you turn on the main unit, and the
subwoofer.
If no audio from the wireless subwoofer can be
heard, do the following for pairing.
1 Turn on the main unit, and the subwoofer.
» If the connection to the main unit is
lost, the white LED on the subwoofer
blinks slowly.
2 Press the PAIRING (PAIRING) button on
the subwoofer to enter the pairing mode.
» The white LED on the subwoofer
blinks quickly.

8EN
3 In OPTICAL mode (press OPTICAL) ,
within six seconds, on the remote control,
press twice then Volume + once, and
then hold down BASS +.
» If the pairing succeeds, the white LED
on the subwoofer lights up.
» If the pairing fails, the white LED on
the subwoofer blinks slowly.
4 If the pairing fails, repeat the steps above.
Connect to TV
Connect this product to a TV.You can listen to
audio from TV programs through the speakers
of this product.
Connect to TV through HDMI (ARC)
Best quality audio
This product supports HDMI with Audio
Return Channel (ARC). If your TV is HDMI
ARC compliant, you can hear the TV audio
through the speakers of this product by using a
single HDMI cable.
1 Using a High Speed HDMI cable, connect
the HDMI OUT (ARC) connector on this
product to the HDMI ARC connector on
the TV.
• The HDMI ARC connector on the TV
might be labeled differently. For details,
see the TV user manual.
2 On yourTV, turn on HDMI-CEC
operations. For details, see the TV user
manual.
TV
Note
• If yourTV is not HDMI ARC compliant, connect an
audio cable to hear theTV audio through this product.
• If yourTV has a DVI connector, you can use an HDMI/
DVI adapter to connect to TV. However, some of the
features may not be available.
Connect digital devices
through HDMI
Connect a digital device such as a set-top box,
DVD/Blu-ray player, or games console to this
product through a single HDMI connection.
When you connect the devices in this way and
play a le or game, the
• video is automatically displayed on your
TV, and
• audio is automatically played on this
product.
1 Using a High Speed HDMI cable, connect
the HDMI OUT connector on your digital
device to the HDMI IN on this product.
2 Connect this product to TV through HDMI
OUT (ARC).
• If the TV is not HDMI CEC compliant,
select the correct video input on your
TV.
3 On the connected device, turn on HDMI-
CEC operations. For details, see the user
manual of the device.
Connect audio from TV and
other devices
Play audio fromTV or other devices through
the speakers of this product.
Use the best quality connection available on this
product,TV, and other devices.
