CORRECTLY INCORRECTLY
Note: the enclosed template can be used for general positioning only
(fig. 1).
Mounting to sheetrock wall
Note: Bracket can only be used with standard 16" spaced wood wall
studs.
Bracket must be positioned so that the bracket is fastened firmly to
studs at each end.
All required hardware is included.
Note: Because the Receiver Unit’s power cord is 6’, when determining the
Display Unit mounting location, the distance to the nearest AC power
outlet must be considered.
&Determine desired location to mount Display Unit.
Within this area, locate the two 16.54" spaced wall studs that must
be used as the Wall Bracket mounting location. (fig. 1 and 2)
éWith the Wall Bracket held in place, ensure it is properly leveled.
Then, mark where the four holes must be drilled. (fig. 2)
Note: Use only the holes in Bracket.
“Remove the Wall Bracket, and using a 13/64" wood drill bit, drill the
four holes. (fig. 3)
‘Reposition the Wall Bracket, and with four lag bolts (fig. 4), secure
into place.Tighten with 13mm or 1/2" socket wrench. (fig. 5)
Note: Do not use plastic wall anchors with these lag bolts.
Note: Lag bolts must be fastened and centered securely into the stud.
Mounting Wall Bracket
fig. 1
fig. 2
420mm /16,54"
60,5mm /2.38"
fig. 3
fig. 4
fig. 5
English

2
Mounting to concrete wall
&Determine desired location to mount Display Unit. Use the enclosed
template for alignment purposes. (fig. 1)
éWith the Wall Bracket held in place, ensure it is properly leveled.
Then, mark where the four holes must be drilled. (fig. 4)
“Remove the Wall Bracket, and using a 5/8" masonry drill bit, drill the
four holes. (fig. 2)
‘Insert a concrete anchor (with bolt) into each hole.
(Firmly tighten each bolt.Then, remove the bolts.
§Reposition the Wall Bracket, and with the four bolts (and washers),
secure into place.
Mounting to concrete block wall
&Determine desired location to mount the Display Unit.
Within this area, position the Wall Bracket so that the four end
mounting holes are located over the cavities of the concrete blocks
(refer to Figure 1)
éWith the Wall Bracket held in place, ensure it is properly leveled.
Then, mark where the four holes are to be drilled.
Note: Use only the four outside or end holes in the Bracket.
“Remove the Wall Bracket and reconfirm that the marks made in the
previous step are located in the cavities of the concrete blocks. Re-
locate the marks as required to ensure that they are in the cavities
of the concrete blocks.
‘With a 1/2” masonry drill bit, drill the four holes.
(Hinge the plastic legs of the toggle bolt into the channel of the metal
end of the toggle bolt so it can fit into the 1/2” hole drilled in the
wall (refer to Figure 2).
§Insert the toggle bolt into the hole in the wall and push it in until it
is in the cavity of the block.
èWith the plastic pull ring of the toggle bolt, pull the metal end of the
toggle bolt firmly against the back of the cavity of the concrete block
(refer to Figure 3).
WASHER
Cavities In Block
Fig. 1
Fig. 2
Fig. 3

3
!While holding the plastic pull ring, slide the plastic retaining sleeve
towards the wall until it fits into the hole in the wall. This will hold
the toggle bolt in the wall while the Wall Bracket is mounted (refer
to Figure 4).
Push down on the lower plastic leg of the toggle bolt and break it off
flush with the wall (refer to Figure 5).
Push up on the upper plastic leg of the toggle bolt and break it off
flush with the wall (refer to Figure 6).
Install the remaining 3 toggle bolts in the remaining holes the same
way that the first one was installed.
Position the Wall Bracket in place and install the four 1/4-20 bolts,
including washers, in each of the outside corner holes. Do not
tighten completely (refer to Figure 7).
Confirm that the Wall Plate is level, then tighten the bolts securely
(refer to Figure 8).
Mounting to metal stud wall
&Determine desired location to mount the Display Unit.
Within this area, locate the two 16.54” spaced metal wall studs that
must be used as the Wall Bracket mounting location.
éLocate the center of both wall studs at the height that the Wall
Bracket is to be mounted.
“With the Wall Bracket held in place, ensure it is properly leveled.
Then, mark where the four holes are to be drilled.
Note: Use only the four outside or end holes in the Bracket
(refer to Figure 1).
‘Remove the Wall Bracket and reconfirm that the marks made in the
previous step are located in the center of the metal wall studs. Re-
locate the marks as required to ensure that they are in the center of
the metal wall studs (refer to Figure 2).
9
10
11
12
13
Metal Wall
Studs
Fig. 1
Holes Centered In
Metal Wall Studs
Fig. 2
Fig. 4
Fig. 5
Fig. 6
Fig. 7
Fig. 8

4
(With a 1/2” drill bit, drill the four holes. A smaller pilot hole may be
required if the 1/2” drill bit bends the metal stud instead of piercing
it.
§Hinge the plastic legs of the toggle bolt into the channel of the metal
end of the toggle bolt so it can fit into the 1/2” hole drilled in the
wall (refer to Figure 3).
èInsert the toggle bolt into the hole in the wall and push it in past the
metal stud (refer to Figure 3).
!With the plastic pull ring of the toggle bolt, pull the metal end of the
toggle bolt firmly against the back of the metal stud (refer to Figure
4).
While holding the plastic pull ring, slide the plastic retaining sleeve
towards the wall until it fits into the hole in the wall. This will hold
the toggle bolt in the wall while the Wall Bracket is mounted (refer
to Figure 5).
Push down on the lower plastic leg of the toggle bolt and break it
off flush with the wall (refer to Figure 6).
Push up on the upper plastic leg of the toggle bolt and break it off
flush with the wall (refer to Figure 7).
Install the remaining 3 toggle bolts in the remaining holes the same
way that the first one was installed.
Position the Wall Bracket in place and install the four 1/4-20 bolts,
including washers, in each of the outside corner holes. Do not
tighten completely (refer to Figure 8).
Confirm that the Wall Plate is level, then tighten the bolts securely
(refer to Figure 9).
9
10
11
12
13
14
Fig. 3
Fig. 4
Fig. 5
Fig. 6
Fig. 7
Fig. 8
Fig. 9

~ MAINS
RS232 DVI-D Y/C S-VHS
L
R
L
R
AUDIO IN AUDIO IN
G/Y/Y
CVBS B/Pb/Cb
R/Pr/Cr V
H
AUDIO IN
R
VGA 1 VGA 2 RC-OUT
AV2 AV 1 AV3
L
AUDIO IN
VGA 1VGA 2DVI-D
2
1

1
