PICZO IRIS Plus User manual
Sida
1 1 Package Contents
1.1 1 Appearance
2 2 Remote
3 3 Basic Operations
3.1 3 Power ON/OFF
3.2 3 Adjusting Focus
3.3 3 ResizingProjectionScreen
3.4 4 Focus/Brightness/Keystone/Projection mode
4 5 Charging
4.1 5 Indicator Light Status
4.2 5 Battery Capacity
5 6 Interface Display
5.1 6 AptoideTV
5.2 6 Aptoide Store
5.3 6 Eshare
5.4 6 Files
5.5 6 Settings
5.6 6 APPS
5.7 6 HDMI
6 7 Eshare
7 8 Screen Mirroring IOS Iphone,Ipad
7.1 8 Screen Mirroring IOS Iphone Ipad
7.2 8 Screen Mirroring Mac
7.3 8 Screen Mirroring iMirror
7.4 8 HDMI Lightning Cable
7.5 9 Screen Mirroring Android
8 10 Eshare Remote app
8.1 10 Eshare App
9 11 Input Sources
9.1 11 Micro SD Card
9.2 11 Inserting microSD Card
9.3 11 Ejecting microSD Card
10 11 Product Maintenance
11 12 Technical Specifications
12 13 Frequently Asked Questions
13 14 Trademarks
14 14 Regulatory Information
15 14 Disposal and Recycling Information
15.1 14 Precautions
1
1 Package Contents
Projector
Mini tripod
Power Adapter Power Plug
HDMI® Cable
Wireless Mouse Remote
1.1 Appearance
SPEAKER
2
2 Remote
Please refer to the following
Please note:
•Handle the remote control carefully. Dropping or jarring the remote can damage internal
components.
•Exposure to direct sunlight, smoke or steam can also harm internal components.
Bluetooth Remote Pairing
1.Enter "Bluetooth ”.
2.Hold the "OK" and "VOLUME-" key 5
seconds to turn on the Bluetooth function of
remote. The red indicator of remote will
�lash quickly when bluetooth function is
opened.
3.urn on the Bluetooth , and scan ,
select"SONG-1" and connect.
Turn On and Turn Off
1.After "SONG-1" connected successfully,
click"
"in the remote to start Air Mouse function
2.Click" ” in the remote again, the Air
Mouse function will be closed,and the Arrow
mark will disappear after 15 seconds or
press"Return" key in the remote.
3
Screen Size Throw Distance
7" 0.18m
38" 1m
56" 1.5m
100" 2.5m
Please note:
•The measured values are estimated for reference only.
3.2 Adjusting Focus
P
Roll the focus wheel to adjust the clarity of the projetor image. Stop rolling the wheel once the
projected image becomes clear.
3.3 Resizing Projection Screen
The projection screen size is related to the distance from the projector to the surface on which the
display is being projected onto, also known as throw distance. Please refer to the following table for
the relationship between throw distance and screen size:
3 BASIC OPERATION OF THE PROJECTOR
3.1 Power on
In battery mode, holding power button 5 seconds
In charging mode, holding power button 5 seconds(P1), or holding power key
of remote 5s seconds(P2).
3.2 Power off
In battery mode, holding power button 5 seconds
In charging mode, holding power button 5
seconds(P1),or holding power key of remote 5s seconds(P2).
P1 P2
4
3.4 Focus/Brightness/Keystone/Projection mode
1. Adjust focus
Slide the focus wheel to
adjust the screen’s de�inition.
2. Adjust Brightness
adjust the screen’s definition.
3. Keystone Correction and Projection mode
Enter “Setting” on the home screen,and select.
1
3
5
4 Charging
The projector can be powered by AC adapter or internal rechargeable battery. To have maximum
battery life, it is highly suggested to charge the battery for at least 2 hours the first time.
1. Ensure the projector is turned off and connect it to the Power Adapter.
2. Connect the Power Adapter and the Power Plug
3. Insert the Power Plug into a wall outlet to charge the battery.
4.1 Indicator Light Status
Please refer to the following table for information about indicator light status:
Power OFF Power ON
Red Light Charging Charging
Blue Light Fully Charged Working
4.2 Battery Capacity
Please refer to the following table for information about the battery capacity and the battery level
indicator:
The battery capacity status will be shown in the upper right
corner of the screen.
Blinking low battery
The battery capacity status will be shown in the upper right
corner of the screen.
The main battery level indicator will be shown next to the
battery capacity status in the upper right corner of the screen.
Battery is running low. Please connect projector to
Power Adapter.
Battery depleted. Projector will power off unless connected
to Power Adapter.
5 Interface Display
5.1 Aptoide TV
Aptoide TV brings you an app store that offers content with a rich user
experience, optimized for the larger screen devices, Yep, it means that you can
use Aptoide not only in your mobile devices but also from the comfort of your
couch.
5.2 Aptoide
The Independent Android App StoreDiscover and distribute top apps in the safest
Android app store. No geo-restrictions so that you can find all the content you
want, wherever you want.
5.3 Eshare
Compatible iOS,Android and Windows device EShare is a multiscreen interaction
application which makes the user experience natural and enjoyable for home
entertainment, business presentation, and educational training. To use this app on
your Android phone or tablet, you need a Projector/IFPD with EShareServer pre-
installed.Where various adjustments can be done to fully enjoy the features of the
projector.
5.4 Files
Access you memory and SD-Card and USB stick
5.5 Settings
Access your setttings for the projector.
5.6 Apps
Access your downloaded apps.
5.7 HDMI
Projecting the display screen from computers, DVs DSC or other HDMI source
devices like PS4, Xbox 360 game consoles via HDMI cable connection.
6
1.Allows user to share/mirror smartphone/Computer to the projector with the use of the app.
2.Allows user to control the projector with the use of EShare app.Please make sure your
device is connected to the same network with projector.
3.Visit "http://XXX.XXX.X.XXX:8000" as display in the project screen from your mobile
device brower or Scran the -QR code to download app.
4.Launch EShare and click "EShare-XXXX" to connect. Enter
“APPs”on the homescreen and open EShare Server app.
EShare Download link and QR
code: Link: http://
d.eshare.tech/#once
6 Eshare
Compatible iOS,Android and Windows device.
7
7.2 Mac
EShare-XXXX
1.Projector Networked: Click connect it to projector
through the same network.
2.Click choose ID “EShare-XXXX”and be done.
7 Screen Mirroing IOS Iphone,Ipad
1.In Wi-Fi environment:Go to iPhone's
"Setting"---"Wi-Fi", then connect your phone and
projector to the same network.
2.Back to the phone homepage, slide upward of
iOS equipment to display the hidden menu and
click "Airplay".
3.Choose ID "EShare-XXXX", then open
"Mirroring" and done.
8
7.3 iMirror
7.1 Iphone Ipad
1.Please connect iphone to the projector as shown.
2.Use Hdmi lightning adapter
3.Click the "Trust" option, then start mirroring.
7.4 HDMI Lightning Cable
7.5 Android
Connect To Interactive Touchscreen/projector
Firstly ensure that your Android device and Interactive Touchscreen/projector are connected at the
same network.
Then launch the EShare App on the phone, and EShare will automatically find the Interactive
Projector(s) connected on the same network with the EShare Server App.
Next, click the device name you plan to connect to, and the client device will be connected to
Touchscreen/TV. Or you can click “Scan QR” and scan the QR shown on the Touchscreen/TV.
Launch the “Mirroring”
function, and then you
can enable/disable
the mirroring from the
Notice Bar.
EShare Download link and QR
code: Link: http://
d.eshare.tech/#once
9
Mouse Touch Control Key Control Apps Keyboard
8 Eshare Remote
Click “Remote” to act your phone as wireless mouse, remote controller, keyboard, air mouse, etc.
10
8.1 Eshare App
Scan for download Iphone and Ipad.
"Press tv mirror" You can use your screen
as a touch panel on your Iphone or Ipad"
10 Product Maintenance
10.1 Projector
•Charge the battery for at least 2 hours the first time.
•If the projector gets dirty: wipe clean with a dry cloth.
•Do not wipe the projector with a damp cloth.
10.2 Remote Control
The remote control comes with an included AAA battery in the original package. Please use the sam
type of battery when replacement is needed.
9.1 microSD Card
Make sure to insert the microSD card the correct way to playback and view content. The microSD card
should gently be inserted all the way inside the card slot, leaving the microSD card flush with the
surface of the projector.
The microSD card read status will be shown in the upper right corner of screen:
No microSD card or incompatible card.
microSD card successfully connected.
Please note:
•The projector supports microSD cards up to 64GB.
9.2 Inserting microSD Card
Use the tip of a fingernail to gently push the microSD card in place with a forwards and down motion.
This side up Correct Wrong
9.3 Ejecting microSD Card
Use the tip of a fingernail to gently push the microSD card inwards to release and eject. Now it is safe
to remove the microSD card.
11
9 Input Sources
12
11 Technical Specifications
Please note:
•The specifications are subject to change without notice.
Product Name Mini Projector
Display Technology 0.2" DMD DLP
Native Resolution FWVGA(854*480)
Compatible Resolution Up to 1080P
Light source RGB 3LED OSRAM
LED working life Above 30000 hrs
Focus Manual Zoom
Offset Support
Operation System Android
CPU
Memory
Cortex A7 Quad-Core, 1.2GHz
RAM:DDR3 1G + ROM Flash memory 16 GB(EMMC 5.1)
Wi-Fi 802.11 a/b/g/n/ac (2.4/5.0 GHz dual band)
Wireless mirror IOS,
Bluetooth 5.0
Keystone Correction
Support
Projection Methods
Front/Rear/Ceiling
Operation Methods Remote, Mouse, Physical Buttons
Application Compatible with thousands of Apps.
Projection Screen Size
Interface
7"~200"
HDMI X1 HDMI input (1.4 line)
USB X 2 Multimedia Play
Micro SD X1 Multimedia Play
DC X1
3.5mm stereo audio output *1
Physical Buttons Power
Built-in Speaker 5
W( X1)
Built-in Battery Li-Polymer,
Working time 2hrs(Approx.)
Projector Size (mm)
Net Weight
Power supply
136(D) x65(W) x 60(H)
510g
DC 12V/2A
3500*2 mAH
Android
13
12 Frequently Asked Questions
Question: Why is the indicator light status showing blue, but the projection screen is not showing?
Answer: Make sure not to press and hold the Power key too long. Release the Power key as soon
as the indicator turns blue. Please be patient and do not push the Power key repeatedly during the
system boot process, which may cause the projector to crash.
Question: Why can I not view the files on my microSD card?
Answer: If the capacity of the microSD card is higher than 64GB, the projector will not be able to
read the content on the card. The maximum capacity supported by the projector is up to 64GB.
Also, ensure that the microSD card is formatted to NTFS (up to 64GB) or FAT32 (up to 32GB).
Question: Why can some video files not be played?
Answer: Make sure that the file format is supported by the projector and that the video resolution
is 1080p or lower. The maximum supported video resolution is full 1080p at 60Hz. Please refer to
Supported Video File Formats in chapter 10 Technical Specifications for more information.
Question: Why does some videos not have sound?
Answer: Due to a copyright issue with Dolby®, this projector does not support Dolby Audio
Decoding. You might not get sound from some videos if they are using Dolby Audio Decoding.
Question: Why does the system crash or get stuck?
Answer: This usually occurs when the computing power of the projector cannot perform on the
same level as the connected device. It is also common when trying to display a device running a
higher resolution than the projector can support.
Please note:
•Most issues can be solved by restarting the projector. Press and hold the Power key on the
projector for 3 seconds to power off the projector. Then press and hold the Power key on the
projector for 3 seconds to power on the projector again, completing the process.
Question: No Display from HDMI.
Answer:Re-check the connections of the projector from the source. Loose connection or
faulty cable(s) can cause this issue. Adjusting the source's resolution may also sort it out.
Question: The remote is not working in Netflix?
Answer: Please use mouse to operate Netflix.
14
13 Trademarks
Piczo is a registered trademark of Swede Invent AB, registered in Sweden. Distributed by Swede
Invent AB, Säterivägen 16, 65341 Karlstad, Sweden. © 2019 All Rights Reserved. Made in China.
SD and related marks and logos are trademarks of SD-3C LLC in the United States, other countries or
both. HDMI, the HDMI logo, and High-Definition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing, LLC in the United States and/or other countries. DLP and the DLP
logo are registered trademarks of Texas Instruments. Dolby is a registered trademark of Dolby
Laboratories.
14 Regulatory Information
15 Disposal and Recycling Information
Damaged batteries should be treated as hazardous materials. Do not return the device if the battery is
swelling, leaking, or if you in any other way suspect that the battery is damaged. In this case, please
make sure you dispose of or recycle the item and its accessories according to local laws and
regulations. Do not puncture, drop or incinerate the battery.
15.1 Precautions
•To prevent electric shock, do not open the case. If needed, please ask your local retailer for
repair or replacement services.
•When operating the projector: do not look into the lens, as this may cause injury to the eyes.
•To prevent fire or electric shock, do not operate this product in wet or moist environments.
•When using the projector: avoid dropping and impact, as this may damage internal
components.
•Always use the included Power Adapter when charging the projector.
•Avoid keeping the Power Adapter plugged in to the projector when it is not in use, unless
charging is needed.
Table of contents
Other PICZO Projector manuals
