Service Manual
ELITE AND REFLECTIONS
Ice Cream Freezers
ICF-51, ICF-65, ICE-60 and ICE-74 Models


For Service Information call 800-544-3057
Please have the following information available before calling. Information can be
found on the identification/certification tag:

Model Number
Serial Number
Date of Purchase
Part Description and number as shown in parts list


Piper Products, Inc.
300 South 84
th
Avenue
Wausau, WI 54401
Phone: [phone] / Fax [phone]
IMPORTANT INFORMATION
READ BEFORE USE

TABLE OF CONTENTS
INTRODUCTION ........................................................................................................................3
FREIGHT DAMAGE CLAIMS.....................................................................................................3
INSTALLATION .........................................................................................................................4
START-UP AND OPERATION ..................................................................................................5
THEORY OF OPERATION ........................................................................................................5
TH ERMOSTAT SETTINGS .......................................................................................................6
MAINTENANCE .........................................................................................................................8
STAINLESS STEEL AND GENERAL CLEANING ....................................................................9
TROUBLESHOOTING GUIDE ................................................................................................10
CM EXPLODED VIEW ............................................................................................................10
R-CM EXPLODED VIEW .........................................................................................................12
WIRING DIAGRAM ..................................................................................................................11
PIPER PRODUCTS, INC. LIMITED WARRANTY ................................................................14

WARNING
Installation of this equipment should be done only by persons qualified or
licensed to install electrical equipment.
Adjustments and service work should be performed only by a qualified service
technician. Service is available through Authorized Piper Products Parts and
Service Distributors throughout the United States. For a complete listing of these
call or write Piper Products, Inc. for the name of the nearest distributor.
This equipment is intended for commercial use only. Not for household use.
Use of other than genuine Piper Products replacement parts or service work
performed by other than an authorized Piper Products service agent will void the
warranty.
Do not use any corrosive cleaners. Piper only approves soap and water
for cleaning stainless steel.
INTRODUCTION
Congratulations! You have just purchased one of the finest pieces of equipment on the
market today. Before installing or operating your new Piper Products, Inc. equipment,
you should read through this manual. This manual should be retained for further refer-
ence as it contains installation and operating instructions, service tips, part lists and
warranty information.
For your safety, read and follow all cautions and warnings.
FREIGHT DAMAGE CLAIMS
Your Piper Products equipment was carefully inspected and packed before leaving our
factory. The transportation company assumes full responsibility for safe delivery of this
equipment. Piper Products cannot assume responsibilities for damage or loss incurred
in transit. Visible damage or loss should be noted on the freight bill and signed by the
person making the delivery.
A freight claim should be filed immediately with the transportation company. If damage is
unnoticed or concealed until equipment is unpacked, notify the transportation company
immediately and tell them you want to file a concealed damage claim. This must be
done within ten (10) days after delivery was made. Be sure to retain all packing material
and cartons.

INSTALLATION
ELECTRICAL CONNECTION

WARNING!!!! DO NOT USE EXTENSION CORDS (VOIDS WARRANTY)
Ground:
The electrical outlet must be provided with an efficient ground, and the voltage
and the frequency of the electrical line matches those indicated on the data plate.
If unsure about the efficiency of the ground, have your electrical circuit
checked by a qualified technician

Supply Voltage :
When the cooler is operating, check that the supply voltage is not dropping or
increasing under/over + 10% the rated voltage (98 Volts to 127 Volts) OR (198
Volts to 243 Volts)
The manufacturer is not responsible for damages or accidents
arising from the misuse or disregard of electrical connections.

Outside Storage:ATTENTION!
The cooler is not designed for outdoor use.
The cooler should not be stored outside in direct sun or rain.

 Ambient (Environmental) Conditions:
Only locate the cooler in a maximum condition of 80°F (27°C) and 60% Relative
Humidity
Positioning:
Keep away from heat sources, such as radiators or air conditioning pipes.
The ambient temperature must not be higher than 80°F (27°C).

Air Flow:
When installing unit, make sure there is a minimum of 2 inches air space at the
louvered panel located at the end of the unit.
12 inches air space at the louvered panel front and rear of the cabinet.
Cooler Leveling:
 To provide the best performance the cooler must remain level.

START-UP AND OPERATION
OPERATING THE COOLER
Before Operating the Cooler
Ensure that the electrical outlet is connected effectively to earth (ground),
suitable to provide the voltage indicated on the data plate.
Ensure proper air flow to the front rear and sides.
Ensure the cooler is level.
Electrical Service Switch: Turn the control panel switch to the “ON” position.
The pilot light will light and the condensing unit will start.
Allow unit to pre-cool for 45 minutes with the lids on
Energy Savings / Product Performance Location Tips:
When possible, DO NOT place the cooler near air conditioning vents or returns.
When possible, place the cooler the maximum distance from the exit or entrance
door.

THEORY OF OPERATION
The mechanical refrigeration system uses a 1/2 horsepower low temperature
compressor and capillary tube system controlled by a temperature control to
provide cooling to copper coils mounted around the stainless steel cavity.
Operate freezer by turning it “ON” or “OFF” with the master switch, not with
the thermostat.
IMPORTANT: When loading freezer, DO NOT load above product load
line for proper operation and product temperature. This equipment is
intended for use with pre-packaged foods only.
Product should be in a frozen state when placed in the freezer. If product is
soft, place lids on unit to aid in temperature pull-down.
IMPORTANT: Once the serving period is completed, place lids back onto
freezer. Leave lids on until the next serving period. DO NOT leave lids
off longer than 2 hours at one time.


TH ERMOSTAT SETTINGS
The thermostat has a preset temperature of 0° Fahrenheit with a 4° differential
from the factory.
 

KEY COMBINATIONS


LED MODE SIGNIFICATION

On Compressor enabled
Flashing Anti-short cycle delay enabled (AC parameter)

On Defrost in progress
Flashing Dripping in progress

On Fans output enabled
Flashing Fans delay after defrost

On Measurement unit
Flashing Programming mode

On Measurement unit
Flashing Programming mode

To display target set point. In
programming mode it selects a
parameter or confirms an operation.
To start manual defrost.
In programming mode it browses the
parameter codes or increases the
displayed value.
In programming mode it browses the
parameter codes or decreases the
displayed value.
To lock or unlock the keyboard
To enter in programming mode
To return to room temperature display

HOW TO SEE THE SET POINT
1. Push and immediately release the SET key. The set point will be shown.
2. Push and immediately release the
SET key or wait about 5 seconds to return to normal
visualization.
HOW TO CHANGE THE SETPOINT
1. Push the SET key for more than 2 seconds to change the Set Point Value.
2. The value of the set point will be displayed and the “°C” or “°F” LED starts blinking
3. To change the set value push the
 or  arrows.
4. To memorize the new set point value push the
SET key again or wait 10 seconds.
HOW TO START A MANUAL DEFROST
Push the DEF key for more than 2 seconds and a manual defrost will start.
Message Cause Outputs
“P1” Room probe failure Compressor output according to “Cy” and “Cn”
“P2” Evaporator probe failure Defrost end is timed
“HA” Maximum temperature alarm Outputs unchanged
“LA” Minimum temperature alarm Outputs unchanged
“EA” External alarm Outputs unchanged
“CA” Serious external alarm All outputs OFF
“dA” Door open Compressor and fans restart
ALARM RECOVERY
Probe alarms “ P1 ” and “ P2 ” start some seconds after the fault in the related probe; they
automatically stop some seconds after the probe restarts normal operation. Check
connections before replacing the probe. Temperature alarms “
HA ” and “ LA ” automatically stop
as soon as the temperature returns to normal values.
Alarms “EA” and “CA” (with iF=bL) recover as soon as the digital input is disabled.










MAINTENANCE
To obtain the best performance from your equipment, it should be cleaned daily and
maintained in good condition.
SAFETY / ENVIRONMENTAL CAUTION
PERSONAL PROTECTION:
Check your company safety and environmental policy before cleaning or servicing.
Safety Tip! : Utilize protective gloves and safety glasses
ELECTRICAL POWER:
Before performing EXTENDED CLEANING where electrical components can
become wetted, the power switch must be turned to OFF and the unit
disconnected from the power source.
WARNING:
Do not use any chlorinated or highly caustic cleaners, acids, ammonia
or other corrosive cleaners. These may cause corrosion and/or damage to the
stainless steel. Piper only approves soap and water for cleaning stainless steel. Do
not allow water to stand in wells for long periods of time. Well must be emptied and
cleaned after every serving period.
REQUIRED MONTHLY MAINTENANCE:
Check that the condenser fan works properly
Check thermostat settings
Check operating temperature of unit
Clean entire refrigerated case
Clean condenser coils
Check and clean drainage lines
Check electrical connection





STAINLESS STEEL AND GENERAL CLEANING
Stainless Steel and Aluminum:
 Piper only approves soap and water for cleaning stainless steel.
NOTICE: Do NOT use chlorinated cleaners.
General Surfaces, Fiberglass:
 Clean surfaces with a soft cloth or sponge utilizing a mild detergent. Rinse completely
with warm water and then dry.
 NOTICE: Do NOT use steel wool
Hardened Foods or Scale Deposits :
Clean hardened foods or scale deposits by utilizing a plastic scouring pad and a mild
detergent. Rinse completely with warm water and dry.
NOTICE: Do NOT use steel wool
CLEANING CONDENSING UNIT (CM)
NOTICE FAILURE TO PROPERLY CLEAN THE CONDENSER WILL VOID THE WARRANTY
Monthly cleaning of the condensing unit is essential for product temperature and
refrigeration system performance.
Cleaning Method:
WARNING: Disconnect electrical power to the cooler by turning master switch to the
“OFF” position and unplugging cooler from electrical receptacle
Remove the louvered panels from the condensing unit compartment.
Clean condenser by using a brush and vacuum cleaner to remove all dust and dirt.
CAUTION: The fins on the condensing unit coils are sharp!
Safety Tip! : Utilize protective gloves and safety glasses
WARNING: Refrigerant is under high pressure. Do NOT bend, kink or damage any
tubing or condensing unit coil.




TROUBLESHOOTING GUIDE
If problems are not found by the following checks, then you should contact
your Authorized Parts and Service Dealer for service. They have the
necessary parts and training to repair your unit quickly and efficiently.
DANGER: Disconnect all power to unit before servicing.
Call Piper Products directly at 800-544-3057 if you need further assistance.
Symptoms Possible Cause Remedies
Pilot light is off and condensing
unit does not run No electrical supply
Is the unit plugged in?
Check circuit breaker and fuse.
Check switch on control panel is in "on" position.
Pilot light is on but condensing
unit does not run Thermostat Control Is the thermostat control set properly?
Unit does not cool to proper
temperature
Ducting Are there heating or A/C ducts, make-up air ducts or
fans causing cool drafts?
Not pre-cooled Has the unit been allowed to pre-cool for at least 30
minutes?
Thermostat Control Is the thermostat control set properly?
Voltage Call a service technician.
Does not maintain food
temperature
Air flow Check condenser coils for proper air flow.
Ducting Are there heating are A/C ducts, make-up air ducts
or fans causing cool drafts?
Not pre-cooled Has the unit been allowed to pre-cool for at least 30
minutes?
Food Temperature Were pans of food placed into the unit at or below
0˚F?
Thermostat Control Is the thermostat control set properly?
Voltage Call a service technician.

ICFEXPLODEDVIEW

ITEM PART NO. DESCRIPTION
1 0111877 SJTOW 14/3 WIRE AC POWER CORD
2 0331350 SWITCH: TA201-TB-B ON/OFF TAB
3 0189500 INDICATOR LIGHT
4 0112234 MOTOR – 1/70HP 1500RPM 120V CW
5 0114523 BLOWER – WHEEL 6.06ODX1.03W ALUM
6 0114515 CONDENSER: ½ HP LO TEMP R507
7 706420 PROBE – 18NB-NTC-2.5M
8 0115055 DIGITAL CONTROL – ICF-BMD
9 0112764 DRIER – REFRIG C032S 1-4 ODF 120V
10 0114525 VALVE – SOLENOID ¼ ODF 120V
11 0114616 ACCUMLUATOR: #118009-31-3/16OD
12 13-104385 INDICATOR – MOISTURE ¼” ODF
13 0111492 EVAPORATOR: ELECT CONDENSATE – 120V 160W
14A CSTR-5PP 5” CASTER NO BRAKE
14B CSTR-5PPB 5” CASTER W/ BRAKE
15 0114526 COIL – ICF
16 0114595 HEATER-STRIP FRAME ICF65
1501109 6” S/S LEG IN LIEU OF CASTER (NOT SHOWN)

ICEEXPLODEDVIEW 
ITEM PART NO. DESCRIPTION
1 0111877 SJTOW 14/3 WIRE AC POWER CORD
2 0331350 SWITCH: TA201-TB-B ON/OFF TAB
3 0189500 INDICATOR LIGHT
4 0112234 MOTOR – 1/70HP 1500RPM 120V CW
5 0114523 BLOWER – WHEEL 6.06ODX1.03W ALUM
6 0114515 CONDENSER: ½ HP LO TEMP R507
7 706420 PROBE – 18NB-NTC-2.5M
8 0115055 DIGITAL CONTROL – ICF-BMD
9 0112764 DRIER – REFRIG C032S 1-4 ODF 120V
10 0114525 VALVE – SOLENOID ¼ ODF 120V
11 0114616 ACCUMLUATOR: #118009-31-3/16OD
12 13-104385 INDICATOR, MOISTURE ¼” ODF*
13 0111492 EVAPORATOR: ELECT CONDENSATE – 120V 160W
14A CSTR-5PP 5” CASTER NO BRAKE
14B CSTR-4POPB 4” CASTER WITH BRAKE
15 0114526 COIL – ICF
16 0114595 HEATER-STRIP FRAME ICF65
1501109 6” S/S LEG IN LIEU OF CASTER (NOT SHOWN)

WIRINGDIAGRAM






120 VOLT AC
5.0 AMPS
600 WATTS

PIPERPRODUCTS,INC.LIMITEDWARRANTY 

Piper Products, Inc. warrants totheoriginalpurchaserthatits equipment will be free from defects in the
materialsand/orpartsforaperiodof12monthsfromdateofshipmentandreportedtothefactory.
Thepurchaserisresponsibleforhavingequipmentproperlyinstalled,operatedundernormalconditionswith
proper supervision and to perform periodic preventative maintenance. Equipment failures caused by
inadequatewaterquality,impropercleaning,harshchemicals,oracidsarenotcoveredunderwarranty.
Themanufacturer’sobligationunderthiswarrantyshallbethereplacementorrepairofdefectivepartswithin
thewarrantyperiod.Excessivelabor(morethan1/2hour)requiredtoaccessPiperequipmentbuiltintocabi‐
nets,tablesorstructuresbyothers,isNOTcoveredunderlaborwarranty.Example:Pipermultiple‐orsingle‐
wellfoodwells.Alllaborshallbeperformedduringregularworkinghours.Overtimepremiumwillbecharged
tobuyer.Afterthoroughexamination,thedecisionofthePiperProductsServiceDepartmentshallbefinal.
AnydefectivepartstoberepairedorreplacedmustbereturnedtoPiperProducts,Inc.,300South84thAvenue,
Wausau,WI54401,transportationchargesprepaid,andtheymustbeproperlypackedandtagged.Theserial
and model number of the equipment and date of original installationofsuchequipmentmustbegiven.
However,afteroneyearwewillnotassumeanyresponsibilityforanyexpenses(includinglabor)incurredin
the field incidental to the repair or replacement of equipment covered by this warranty. Our obligation
hereundertorepairorreplaceadefectivepartistheexclusiveremedyforbreachofthiswarranty;andwewill
notbeliableforanyotherdamagesorclaims,includingconsequentialdamages.
If,uponinspectionbyPiperProducts,Inc.oritsAuthorizedServiceAgency,itisdeterminedthatthisequipment
hasnotbeenproperlyinstalledorhasnotbeenusedinanappropriatemanner,hasbeenmodified,hasnotbeen
properlymaintained,thewarrantywillbevoid.Also,ifthenameplate or other identifying marks have been
removed,defacedorchangedortheunithasbeenrepairedoraltered by persons other than expressly
approvedbyPiperProducts,Inc.,thewarrantywillbevoid.Iftheequipmenthasbeensubjectedtomisuseor
misapplication,neglect,abuse,accident,damageduring transitordelivery,fire,flood,riotoractsofGod,then
thiswarrantyshallalsobevoid.Whenanysituationoccurswhichvoidsthewarrantythemanufacturershall
notbeliableforanydamagetoanypersonoranypropertywhichmayresultfromtheuseoftheequipment
thereafter.
WarrantyislimitedtoPipermanufacturedproductsonlyanddoesnotapplytootherequipmentwhichmaybe
connectedtoorinstalledwithin.
No representative, dealer, distributor or any other person is authorized or permitted to make any other
warrantyorobligatePiperProducts,Inc.toanyliabilitynotstrictlyinaccordancewiththispolicy.
Thiswarrantyisinlieuofallotherwarrantiesexpressedorimplied,includinganywarrantyofmerchantability,  and
fitness for a particular purpose. Piper Products does hereby exclude and shall not be liable to purchaser for
 any
consequentialorincidentaldamagesincludingbutnotlimitedtodamagestoproperty,damagesforlossof
 use,lossof
time,lossofprofitsorincome,resultingfromanybreachofwarranty.


NOTES

300 South 84
th
Avenue
Wausau, WI 54401
Phone: [phone] / Fax [phone]
