18VOLT CORDLESS RIGHT ANGLE DRILL
ASSEMBLY AND OPERATING INSTRUCTIONS
Power Glide Limited Warranty
Consumer Power Tools for Home Use
World Factory, Inc. (Seller) warrants to the original Buyer only, that each POWER GLIDE™ portable power
tool will be free from defects in material and workmanship for a period of one (1) year from date of
purchase. SELLER’S SOLE OBLIGATION AND BUYER’S EXCLUSIVE REMEDY UNDER THIS LIMITED
WARRANTY SHALL BE THE REPAIR OR REPLACEMENT OF PARTS, WITHOUT CHARGE, WHICH
ARE DEFECTIVE IN MATERIAL OR WORKMANSHIP. ANY PARTS AS DETERMINED BY THE SELLER
WHICH HAVE BEEN MISUSED; ABUSED OR DAMAGED EITHER DIRECTLY OR INDIRECTLY FROM
REPAIRS OR ALTERATIONS ATTEMPTED BY UNAUTHORIZED PERSONS; IMPROPER
MAINTENANCE, NEGLECT OR ACCIDENT ARE NOT COVERED BY THIS LIMITED WARRANTY. To
make a claim under this Limited Warranty, you must return the complete power tool, transportation prepaid,
to any World Factory authorized service center. Call 1-888-422-7800 for the location of the nearest
authorized power tool service center.
Additional Limitations
THIS LIMITED WARRANTY DOES NOT APPLY TO ACCESSORY ITEMS SUCH AS CIRCULAR SAW
BLADES, DRILL BITS, ROUTER BITS, JIGSAW BLADES, SANDING BELTS OR PADS, GRINDING
WHEELS AND OTHER RELATED ITEMS. ALL IMPLIED WARRANTIES SHALL BE LIMITED IN
DURATION TO ONE (1) YEAR FROM DATE OF PURCHASE. IN NO EVENT SHALL SELLER BE LIABLE
FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING BUT NOT LIMITED TO
LIABILITY FOR LOSS OF PROFITS, ARISING FROM THE SALE OR USE OF THIS PRODUCT.
If any provision of this Limited Warranty is for any reason held to be invalid or unenforceable, such provision
shall not affect any other provision herein, this Limited Warranty shall be construed as if such invalid and/or
unenforceable provision had never been contained herein.
This Warranty contains the entire agreement between Seller and Buyer and supersedes any and all prior
agreements, arrangements, or understandings between the parties relating to product warranty.

Cautions: When using power tools, the following basic safety measures should be
followed to reduce and/or eliminate the risk of injury. Read and carefully observe these
instructions while using the device.
 1.MAINTAIN SAFE WORKING ENVIRONMENT.
  Never expose power tools to rain or moisture and do not use power tools in moist or wet
  environments. Ensure that there is good lighting. Do not use power tools in the vicinity
  of combustible liquids or gases. Disorder in the working area increases the risk of
  accidents.
 2.PREVENT ELECTRIC SHOCKS.
  Avoid bodily contact with grounded parts, e.g. pipes, radiators, stoves, or refrigerators.
 3. KEEP POWER TOOLS AWAY FROM CHILDREN.
  Do not let children or other people touch the tool or the power cable during operation
  and keep people out of your work area.
 4.STORE TOOLS IN A SAFE PLACE.
  Unused tools should be stored in a dry, secure area where children cannot reach them.
 5. SELECT THE PROPER TOOL FOR THE TASK.
  Do not use tools for any purpose other than those for which they were intended. The
  tool will operate more efficiently and safely in the specified performance range. Do not
  use any tools or attachments that are not suited for the work.
 6.Wear Appropriate Work Clothes.
  Do not wear any loose-fitting clothing or jewelry (they could get caught up in moving
  parts). If you have long hair, wear a hairnet. Make sure your hair, body and clothing
  remain clear of moving parts
 7. WEAR SAFETY EQUIPMENT.
  Always wear safety glasses and hearing protection. When performing any work that
  generates dust, use a breathing mask. For outdoor work, it is recommended that you
  wear gloves and non-slip footwear.
 8. DO NOT INCORRECTLY USE THE POWER CABLE.
  Do not carry the tool by the power cable and do not use the power cable to pull the plug
  out of the socket. Protect the power cable from heat, oil, and sharp edges.
 9. SECURE THE WORK-PIECE.
  Use clamping devices or a vice in order to hold the work-piece in a secure position that
  allows you to operate the tool with both hands.
10. DO NOT OVER REACH OR STRETCH BEYOND YOUR STANDING AREA.
  Avoid any abnormal postures. Ensure that you are standing securely and keep your
  balance at all times while operating a power tool.
11. PROPERLY MAINTAIN YOUR TOOLS.
  Keep your tools ready for use (e.g. sharp and clean) in order to assure proper operation.
  Follow the maintenance regulations and the instructions for tool changes. Check the
  plug and the cable regularly and if these are damaged, have them replaced by a
  recognized electrical specialist. Always keep handles dry and free from oil and grease.
12. DISCONNECT THE TOOL FROM THE POWER SUPPLY.
  When not in use, prior to maintenance and during the tool change, e.g. saw blade, drill
  bit and machine tools of all kinds disconnect from the power supply.
13. DO NOT LEAVE ANY TOOL KEYS INSERTED.
  Before switching on, check that keys, adjustment or setting tools have been removed
  from the power tool.
14. AVOID ANY UNINTENTIONAL OPERATION OR STARTING-UP OF THE DEVICE.
  Do not place your finger on the switch when carrying tools connected to the power
  supply. Make sure that the switch is off when connecting the device to the power supply.

SPECIAL INSTRUCTIONS NOTES
IF YOU HAVE ANY PROBLEMS OR QUESTIONS CONCERNING THIS PRODUCT,
DO NOT RETURN IT TO YOUR RETAILER. CONTACT CUSTOMER SERVICE AT
1-888-422-7800.

1
4
15. POWER EXTENSION CABLES.
  Use only those extension cables that have been manufactured for this purpose and are
  marked as appropriately tested and approved.
16. BE ALERT.
  Observe your work. Proceed sensibly. Do not use the tool if you are physically or
  mentally impaired in any manner. Do not operate tools under the influence of drugs,
  alcohol or medication.
17. Check Your Tool for Damage.
  Before using the tool, carefully check the protective devices for problem-free operation
  and intended function. Verify there are no damaged parts. Check whether the function
  of moving parts is in order, whether they stick and whether parts are damaged.
  DAMAGED PROTECTIVE DEVICES AND PARTS MUST BE PROPERLY REPAIRED
  OR REPLACED BY A CUSTOMER-SERVICE WORKSHOP PRIOR TO "TOOL USE".
  NEVER USE TOOLS AND SWITCHES THAT CANNOT BE SWITCHED ON AND OFF.
18. REPAIRS ONLY BY AN ELECTRICAL SPECIALIST.
  This power tool complies with all known safety regulations. Only an electrical specialist
  may carry out repairs.
19. USE ONLY ACCESSORIES AND ADDITIONAL DEVICES RECOMMENDED BY THE
  TOOL MANUFACTURER.
  The use of any insert tools or accessories other than those recommended in the
  operating instructions increase risk of injury.
 1. If under extreme conditions, any electrolyte should escape from the battery, it is
  essential to avoid contact with skin. If electrolyte does come into contact with your
  skin, rinse it off with water immediately. In the event of electrolyte contact with your
  eyes, consult a physician immediately. Before use of the charger and the Battery
  Packet, read the Instruction Manual carefully.
 2. Verify the available current corresponds to the current required by the battery charger.
 3. Never let moisture, rain, or splashed water reach the charging location.
 4. Do not charge your Battery Packet when the temperature is below 10˙C (+ 40˙F) or
  above 40˙C(+ 105˙F).
 5. Battery packets that are damaged or can no longer be recharged must be disposed of
  as hazardous waste. Do not throw the Battery Packet into the trash, into fire, or into
  water. Consult your local telephone listing for a battery recycling center in your area.
 6. If the electrical cable is damaged, the wire should be replaced by the supplier or by its
  authorized repair shop. Repairs should only be made by an authorized specialist.
 7. Use only Battery Packets and chargers that have been produced by the original
  manufacturer. DO NOT OTHER BATTERY PACKETS, OR CHARGERS WITH THIS
  TOOL
 8. Always keep the charger free from dust and dirt.
 9. Insert the Battery Packet into the charger. Verify correct polarity before charging.
10. Always remove Battery Packet before working on the tool. Cover the Battery Packet
  contacts to avoid short-circuiting the Battery Packet.
11. Avoid the risk of explosion! Do not throw Ni-Cd batteries into water or fire.
12. Protect the Battery Packet from impacts. Do not open packet.
13. Never completely discharge the Battery Packet. Recharge occasionally if Battery
  Packet is not in use for a prolonged period.
SPECIAL SAFETY INSTRUCTIONS FOR BATTERY PACKET AND CHARGER
MECHANICAL SPEED REGULATE
MAINTENANCE AND CLEANING:
SPECIFICATIONS
Before doing any work on the tool, always remove the battery pack. Clean the tool with a
moist cloth and a little lubricating soap. Do not use any cleaning agents or solvents these
could attack the plastic parts of the tool. Always keep the surface of the device free from
dust and dirt.
This cordless tool has been manufactured in accordance with the applicable standards and
equipment safety legislation. When using electrical appliances, it is important to take some
safety precautions in order to avoid possible injury and damage. For that reason, you
should carefully read and store these instructions such that this information is available to
you at all times
Technical data
1 2
(SEE FIGURE 6)
You can increase the rotate speed by
pushing the regulate button forward.
Position 2: 0-1300 RPM
You can decrease the rotate speed by
pushing the regulate button backwards.
Position 1: 0-425 RPM High Speed Low Speed
(FIGURE 6)
18V DC
0~425, 0~1300
3/8 inch, Jacob's Keyless
18V DC; 1.3 Ni-Cd # 60108004
4.55 lbs
60101212
All Metal
Forward, Reverse, Lock
Motor Voltage
No Load Speed
Chuck Size
Battery
Weight
Type
Gears
Controls
Battery Charger 1 - 1.5 Hour, 110/120V ~ 60Hz.

23
1. (SEE FIGURE 1)To install the battery insert the
 charged battery (2) in the tool handle (1) until the
 release buttons (3) snap into place.
2. To remove the battery (2) from the tool depress the
 release buttons (3) on the side of the battery pack
 and pull straight down, away from the tool handle.
Caution: Use only Power Glide supplied battery
 and charger with this tool. Do not use other
 manufacturers batteries or chargers.
1. Cordless drill
2. Speed regulate button
3. Keyless drill chuck
4. Reverse Switch
12
3
5. On-Off switch with speed control
6. Battery packet
7. Charger base
8. Indicator lights
ON
O
F
F
S
E
T
OPERATING INSTRUCTIONS AND CONTENTS
BATTERY PACK INSTALLATION & REMOVAL
BATTERY CHARGING
1.(SEE FIGURE 2) Insert the chargers power cord (1)
 into a standard 110/120v ~ 60Hz power outlet.
2.Carefully insert the battery pack (2) into the charging
 base. (3) The battery pack fill fit properly in only one
 direction, take care not to force the battery pack in
 the wrong direction. The green light over the word
 "off" (5) will come on. If it does not, check the power
 supply to the charger.
3. To begin charging, press the "Set" button (4) on the
 charger base. The red light over the word "On" (5)
 will come on indicating charging in process.
4. When the red light goes off, the battery has been recharged. For normal charging this
 process takes 1-1.5 hours. Unplug the charger and remove the battery from the charger
 base.
Caution: The battery packet must be charged before you first use your machine. The
 battery packet only reaches its full capacity after several charges. Avoid repeated
 consecutive rapid charges of the battery. Do not recharge after using only briefly.
 (15 min. or less) The battery packet and the power supply unit warm up during the
 charge process. This is not a malfunction.
(FIGURE 1)
(FIGURE 2)
1
2
3
4
5
Do not dispose of Ni-Cd batteries in household waste! Consult your local telephone listing
for a battery recycling center in your area.


RECYCLING
O
N
O
F
F
S
E
T
1
2
34
5
6
7
8
WARNING: Do not change drill rotation direction while running, damage to the tool
may result
INSERTING DRILL BITS AND SCREWDRIVER BITS
1
2
1. In order to insert a drill bit/screwdriver bit, grasp
 the back section of the chuck (2) and rotate the
 front section of the chuck (1) to open or close
 the chuck.
2. Insert the tool as far as it will go into the drill
 chuck opening.
3. Firmly tighten the chuck by hand. Check whether
 the tool is firmly seated in the drill chuck
(FIGURE 4)
VARIABLE SPEED ON AND OFF SWITCH
Set rotation direction switch (1) to desired position.
To switch on: Press ON/OFF switch. (2) Rotation
speed will increase as the trigger is pressed.
To switch off: Release ON/OFF switch. (2)
Varying the Speed
Simply apply pressure onto the On-Off/Switch (2)
by squeezing it in, this will increase the speed and
release the pressure on the On-Off/Switch (2) will
decrease the speed.
Forward & Reversing Switch
Set rotation direction switch (1) either to the right for
counter clockwise rotation or to the left for clockwise rotation, When ON/OFF switch (2) is
activated, rotation direction switch (1) is locked.
Drilling with the lowest rotation speed for a extended period of time, increases the danger
of the overheating of the motor. Allow cooling time of approx. 15 Minutes.
1
2
(FIGURE 5)
Do not dispose of Ni-Cd batteries
in household waste
Recycling
Do not throw Ni-Cd batteries
into water
Ambient temperature maximum
40˙C (105˙F)
Protect Ni-Cd batteries against
heat and fire risk of explosion
