PowerLite 5030UB User manual

PowerLite®Home Cinema
5030UB/5030UBe User's Guide

Contents
PowerLite Home Cinema 5030UB/5030UBe User's Guide ....................................................................... 7
Introduction to Your Projector ................................................................................................................... 8
Projector Features................................................................................................................................ 8
Product Box Contents...................................................................................................................... 9
Additional Components ................................................................................................................ 10
Optional Equipment and Replacement Parts................................................................................. 10
Warranty and Registration Information.......................................................................................... 11
Notations Used in the Documentation................................................................................................ 12
Where to Go for Additional Information .............................................................................................. 12
Projector Part Locations..................................................................................................................... 12
Projector Parts - Front/Top............................................................................................................ 13
Projector Parts - Rear.................................................................................................................... 14
Projector Parts - Base.................................................................................................................... 15
Projector Parts - Control Panel...................................................................................................... 16
Projector Parts - Remote Control................................................................................................... 18
Setting Up the Projector ........................................................................................................................... 20
Projector Placement........................................................................................................................... 20
Projector Setup and Installation Options ....................................................................................... 20
Projection Distance........................................................................................................................ 22
Projector Connections........................................................................................................................ 24
Connecting to Video Sources........................................................................................................ 25
Connecting to an HDMI Video Source ...................................................................................... 25
Connecting to an MHL-Compatible Device............................................................................... 26
Connecting to a Component Video Source............................................................................... 26
Connecting to a Composite Video Source ................................................................................ 27
Connecting to Computer Sources.................................................................................................. 28
Connecting to a Computer for VGA Video................................................................................. 28
Connecting to a Computer for HDMI Video............................................................................... 28
Connecting to External Speakers.................................................................................................. 29
Installing Batteries in the Remote Control .......................................................................................... 30
3

Using Basic Projector Features ............................................................................................................... 32
Turning On the Projector.................................................................................................................... 32
Turning Off the Projector.................................................................................................................... 33
Viewing 3D Images ............................................................................................................................ 35
Pairing the 3D Glasses with the Projector...................................................................................... 36
Charging the 3D Glasses............................................................................................................... 37
3D Viewing Range......................................................................................................................... 38
Selecting the Language for the Projector Menus................................................................................ 38
Adjusting the Image Height ................................................................................................................ 39
Image Shape...................................................................................................................................... 40
Correcting Image Shape with the Keystone Buttons...................................................................... 40
Adjusting the Image Position Using Lens Shift .............................................................................. 41
Resizing the Image With the Zoom Ring............................................................................................ 43
Focusing the Image Using the Focus Ring......................................................................................... 43
Remote Control Operation ................................................................................................................. 44
Selecting an Image Source ................................................................................................................ 46
Projection Modes ............................................................................................................................... 47
Changing the Projection Mode Using the Menus........................................................................... 48
Image Aspect Ratio............................................................................................................................ 49
Changing the Image Aspect Ratio................................................................................................. 49
Available Image Aspect Ratios...................................................................................................... 49
Color Mode......................................................................................................................................... 50
Changing the Color Mode.............................................................................................................. 51
Available Color Modes................................................................................................................... 51
Turning On Auto Iris....................................................................................................................... 52
Adjusting Projector Features................................................................................................................... 54
Shutting Off the Picture Temporarily .................................................................................................. 54
Projector Security Features................................................................................................................ 54
Locking the Projector's Buttons ..................................................................................................... 54
Unlocking the Projector's Buttons............................................................................................. 55
Installing a Security Cable............................................................................................................. 56
Using WirelessHD ..................................................................................................................................... 57
WirelessHD Transmitter Placement................................................................................................... 57
4

Connecting the WirelessHD Transmitter............................................................................................ 57
Viewing WirelessHD Content............................................................................................................. 58
Switching WirelessHD Sources.......................................................................................................... 59
Using the WirelessHD Picture-in-Picture Feature .............................................................................. 60
Adjusting the Menu Settings.................................................................................................................... 62
Using the Projector's Menus............................................................................................................... 62
Image Quality Settings - Image Menu ................................................................................................ 63
Input Signal Settings - Signal Menu.................................................................................................... 66
Projector Feature Settings - Settings Menu........................................................................................ 70
Projector Setup Settings - Extended Menu......................................................................................... 73
Projector Information Display - Info Menu .......................................................................................... 76
Projector Reset Options - Reset Menu............................................................................................... 78
Maintaining and Transporting the Projector........................................................................................... 79
Projector Maintenance....................................................................................................................... 79
Cleaning the Lens.......................................................................................................................... 79
Cleaning the 3D Glasses............................................................................................................... 80
Cleaning the Projector Case.......................................................................................................... 80
Air Filter and Vent Maintenance .................................................................................................... 81
Cleaning the Air Filter................................................................................................................ 81
Replacing the Air Filter.............................................................................................................. 84
Projector Lamp Maintenance......................................................................................................... 85
Replacing the Lamp.................................................................................................................. 86
Resetting the Lamp Timer......................................................................................................... 90
Replacing the Remote Control Batteries ....................................................................................... 90
Transporting the Projector.................................................................................................................. 92
Solving Problems...................................................................................................................................... 93
Projection Problem Tips..................................................................................................................... 93
Projector Light Status......................................................................................................................... 93
Solving Image Problems .................................................................................................................... 96
Solutions When No Image Appears............................................................................................... 96
Solutions When "No Signal" Message Appears............................................................................. 97
Displaying From a PC Laptop................................................................................................... 97
Displaying From a Mac Laptop ................................................................................................. 98
5

Solutions When "Not Supported" Message Appears..................................................................... 98
Solutions When Only a Partial Image Appears.............................................................................. 98
Solutions When the Image is Not Rectangular .............................................................................. 99
Solutions When the Image Contains Noise or Static ..................................................................... 99
Solutions When the Image is Fuzzy or Blurry.............................................................................. 100
Solutions When the Image Brightness or Colors are Incorrect .................................................... 100
Solutions When a 3D Image Does Not Display Correctly ............................................................ 101
Solutions When a WirelessHD Source Does Not Display Correctly............................................. 102
Solving Projector or Remote Control Operation Problems............................................................... 102
Solutions to Projector Power or Shut-Off Problems..................................................................... 103
Solutions to Problems with the Remote Control........................................................................... 103
Where to Get Help............................................................................................................................ 104
Technical Specifications ........................................................................................................................ 106
General Projector Specifications...................................................................................................... 106
Projector Lamp Specifications.......................................................................................................... 107
Remote Control Specifications......................................................................................................... 108
Projector Dimension Specifications.................................................................................................. 108
Projector Electrical Specifications.................................................................................................... 108
Projector Environmental Specifications............................................................................................ 109
Projector Safety and Approvals Specifications................................................................................. 109
Supported Video Display Formats.................................................................................................... 109
Notices ..................................................................................................................................................... 113
Recycling.......................................................................................................................................... 113
Important Safety Information............................................................................................................ 113
Important Safety Instructions............................................................................................................ 114
3D Safety Instructions ................................................................................................................. 117
Restriction of Use........................................................................................................................ 118
FCC Compliance Statement............................................................................................................. 118
Trademarks...................................................................................................................................... 119
Open Source Software License........................................................................................................ 120
Copyright Notice............................................................................................................................... 164
A Note Concerning Responsible Use of Copyrighted Materials................................................... 165
Copyright Attribution.................................................................................................................... 165
6

PowerLite Home Cinema 5030UB/5030UBe User's Guide
Welcome to the PowerLite Home Cinema 5030UB/5030UBe User's Guide.
7

Introduction to Your Projector
Refer to these sections to learn more about your projector and this manual.
Projector Features
Notations Used in the Documentation
Where to Go for Additional Information
Projector Part Locations
Projector Features
The PowerLite Home Cinema 5030UB and 5030UBe projectors include these special features:
Bright, high-resolution projection system
• Up to 2400 lumens of brightness in 2D mode (white light output and color light output)
Note: Color brightness (color light output) and white brightness (white light output) will vary depending
on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output
measured in accordance with ISO 21118.
• 1080p native resolution
• Images up to 300 inches (7.62 m) for projection on any wall or screen
• Fujinon lens for uniformity
Full 3D projection
• Active 3D projection with RF active shutter glasses
• Supports side-by-side, top-and-bottom, and frame packing 3D formats
Flexible connectivity
• Two HDMI ports for video device or computer connection
• One MHL (Mobile High-definition Link)-compatible HDMI port for high-quality audio and video from
tablets and smartphones (PowerLite Home Cinema 5030UBe)
Easy-to-use setup and operation features
• Vertical keystone correction buttons for flexible projector placement
• Epson's Instant Off and Direct Power On features for quick setup and shut down
• 2.1× optical zoom ratio for improved zooming capability
8

Product Box Contents
Additional Components
Optional Equipment and Replacement Parts
Warranty and Registration Information
Parent topic: Introduction to Your Projector
Product Box Contents
Save all the packaging in case you need to ship the projector. Always use the original packaging (or
equivalent) when shipping.
Make sure your projector box included all of these parts:
1 Projector
2 Remote control
3 Remote control batteries (two AA alkaline)
4 Power cord
5 Projector documentation CD
9

6 3D glasses (2 pairs)
7 WirelessHD Transmitter (PowerLite Home Cinema 5030UBe)
8 WirelessHD Transmitter AC adapter (PowerLite Home Cinema 5030UBe)
Parent topic: Projector Features
Additional Components
Depending on how you plan to use the projector, you may need to obtain the following additional
components:
• To receive a component video signal, you need a compatible component cable. You can purchase
one from Epson or an authorized Epson reseller.
• To receive an HDMI signal, you need a compatible HDMI cable. You can purchase one from Epson or
an authorized Epson reseller.
Note: To connect a Mac that includes only a Mini DisplayPort, Thunderbolt port, or Mini-DVI port for
video output, you need to obtain an adapter that allows you to connect to the projector's HDMI port.
Contact Apple for compatible adapter options.
• To receive an HDMI signal via MHL, you need an MHL-compatible device, an MHL cable or an HDMI
cable and an MHL adapter compatible with your device. Devices with an integrated MHL connector
may not require a cable (PowerLite Home Cinema 5030UBe).
• To receive and view a 3D signal, you need a compatible HDMI cable. You can purchase one from
Epson or an authorized Epson reseller. If your video source is a 3D Blu-ray disc, you also need a Blu-
ray player that supports 3D playback. See your local computer or electronics dealer for purchase
information.
Parent topic: Projector Features
Related references
Optional Equipment and Replacement Parts
Optional Equipment and Replacement Parts
You can purchase screens, other optional accessories, and replacement parts from an Epson authorized
reseller. To find the nearest reseller, call 800-GO-EPSON (800-463-7766). Or you can purchase online
at epsonstore.com (U.S. sales) or epson.ca (Canadian sales).
Epson offers the following optional accessories and replacement parts for your projector:
10

Option or part Part number
Genuine Epson replacement lamp (ELPLP69) V13H010L69
Replacement air filter V13H134A39
RF 3D glasses (ELPGS03) V12H548006
Projector ceiling mount CHF1000
Belkin Pro Series VGA/SVGA cable, 6 ft F3H982-06
Belkin Pro Series VGA/SVGA cable, 10 ft F3H982-10
Belkin Pro Series VGA/SVGA cable, 25 ft F3H982-25
Belkin PureAV HDMI audio video cable, 3 ft AV22300-03
Belkin PureAV HDMI audio video cable, 6 ft AV22300-06
Belkin PureAV HDMI audio video cable, 12 ft AV22300-12
Kensington security lock ELPSL01
Remote control 1598522
In addition to the accessories listed above, 1-year and 2-year extended service plans are available.
Parent topic: Projector Features
Warranty and Registration Information
Your projector comes with a basic warranty that lets you project with confidence. For details, see the
warranty brochure that came with your projector.
In addition, Epson offers free Extra Care Home Service. In the unlikely event of an equipment failure,
you won’t have to wait for your unit to be repaired. Instead, Epson will ship you a replacement unit
anywhere in the United States, Canada, or Puerto Rico. See the Extra Care Home Service brochure for
details.
Register your product online using the projector CD or at this site: epson.com/webreg
Registering also lets you receive special updates on new accessories, products, and services.
Parent topic: Projector Features
11

Notations Used in the Documentation
Follow the guidelines in these notations as you read your documentation:
•Warnings must be followed carefully to avoid bodily injury.
•Cautions must be observed to avoid damage to your equipment.
•Notes contain important information about your projector.
•Tips contain additional projection information.
Parent topic: Introduction to Your Projector
Where to Go for Additional Information
Need quick help on using your projector? Here's where to look for help:
•epson.com/support (U.S) or epson.ca/support (Canada)
View FAQs (frequently asked questions) and e-mail your questions to Epson technical support 24
hours a day.
• If you still need help after checking this manual and the sources listed above, you can use the Epson
PrivateLine Support service to get help fast. For details, see "Where to Get Help".
Parent topic: Introduction to Your Projector
Related references
Where to Get Help
Projector Part Locations
Check the projector part illustrations to learn about the parts on your projector.
Projector Parts - Front/Top
Projector Parts - Rear
Projector Parts - Base
Projector Parts - Control Panel
Projector Parts - Remote Control
Parent topic: Introduction to Your Projector
12

Projector Parts - Front/Top
1 Lamp cover
2 Horizontal and vertical lens shift dials
3 Exhaust vent
4 Remote receiver
5 Lens shutter
6 Lens
7 Air intake/air filter cover
8 Front adjustable foot
9 Control panel
10 Focus ring
11 Zoom ring
Parent topic: Projector Part Locations
13

Projector Parts - Rear
1 Cable clip holes
2HDMI1 port
3HDMI2 port
4Component port
5Video port
6PC port (VGA)
7RS-232C port
8Trigger out port
9Service port
10 Remote receiver
11 AC input port
Parent topic: Projector Part Locations
Related tasks
Installing a Security Cable
14

Projector Parts - Base
1 Front adjustable feet
2 Mounting bracket holes
3 Cable cover attachment point
4 Air exhaust vent
Caution: The air exhaust vent cools the WirelessHD receiver. If you mount the projector on the ceiling,
make sure dust does not block the vent or the WirelessHD receiver can overheat.
Parent topic: Projector Part Locations
15

Projector Parts - Control Panel
1 Status light
2Lamp light
3Temp light
4Menu button (accesses projector menu system)
5 Control panel cover
16

6 Vertical keystone adjustment buttons (adjust screen shape) and arrow buttons
7 Arrow buttons
8Esc button (cancels/exits functions)
9Enter button (selects options)
10 Source button (cycles through the list of sources)
11 Power button/light
Parent topic: Projector Part Locations
Related references
Projector Light Status
17

Projector Parts - Remote Control
1On button (turns on projector)
2P-in-P button (controls the Picture-in-Picture function)
3 Source buttons (selects specific video input sources)
18

4HDMI Link button (displays the settings menu for HDMI Link)
Link Menu button (displays the main menu of the connected device)
Control buttons (control playback and other features of connected devices that support the HDMI
CEC standard)
52D/3D button (cycles between 2D and 3D modes)
6 Arrow buttons (move though on-screen options)
7Default button (returns selected setting to default value)
8Menu button (accesses projector menu system)
9Auto Iris button (optimizes the image based on brightness of content)
10 User button (customizable for different functions)
11 Memory button (accesses the Memory menu)
12 WirelessHD Transmitter control buttons (PowerLite Home Cinema 5030UBe)
13 Pattern button (displays a test pattern)
14 3D Format button (changes the 3D format)
15 Frame Int button (adjusts the Frame Interpolation setting)
16 Aspect button (selects the image aspect ratio)
17 RGBCMY button (adjusts hue, saturation, and brightness for each RGBCMY color)
18 Esc button (cancels/exits functions)
19 Enter button (selects options)
20 Super Res button (reduces blurring around the edges of images when viewing 3D content)
21 Color Mode button (selects display modes)
22 Volume up/down buttons (adjusts volume for devices connected via HDMI Link)
23 Blank button (turns off video projection)
24 Illumination button (lights the remote control)
25 Standby button (turns off the projector)
Parent topic: Projector Part Locations
Related references
Remote Control Operation
19

Setting Up the Projector
Follow the instructions in these sections to set up your projector for use.
Projector Placement
Projector Connections
Installing Batteries in the Remote Control
Projector Placement
You can place the projector on almost any flat surface to project an image.
You can also install the projector in a ceiling mount if you want to use it in a fixed location.
Keep these considerations in mind as you select a projector location:
• Place the projector on a sturdy, level surface or install it using a compatible mount.
• Leave plenty of space around and under the projector for ventilation, and do not place it on top of or
next to anything that could block the vents.
• Position the projector within reach of a grounded electrical outlet or extension cord.
Projector Setup and Installation Options
Projection Distance
Parent topic: Setting Up the Projector
Related tasks
Changing the Projection Mode Using the Menus
Projector Setup and Installation Options
You can set up or install your projector in the following ways:
Front
20
