Powr-Kraft PK9715 User manual

FOR YOUR SAFETY
READ AND UNDERSTAND THE ENTIRE MANUAL BEFORE OPERATING
MACHINE
Save This Manual for Future Reference
All Terrain Mini Hauler
Operator’s Manual
MODEL NUMBER : P K 9 7 1 5
SERIAL NUMBER :
Both model number and serial number may be found on the main label.
You should record both of them in a safe place for future use.
Original Instruction

TABLE OF CONTENTS
Introduction
Specifications
Symbols
Safety
General Safety Rules
Specific Safety Rules
Contents supplied
Assembly
Know your mini hauler
Features & Controls
mini hauler Operation
Maintenance
Storage
Trouble Shooting
Parts Schedule
3
3
3
4
4
6
7
7
10
10
11
12
13
14
15
3
ENVIRONMENTAL
Recycle unwanted materials instead of
disposing of them as waste. All tools, hoses
and packaging should be resorted, taken
to the local recycling center and disposed
of in an environment-friendly safe way.
The rating plate on your machine may show
symbols. These represent important information
about the product or instructions on its use.
SYMBOLS
All terrain mini hauler
Wear eye protection.
Wear hearing protection.
Read these instructions for use carefully.
Wear safety footwear.
Wear safety gloves.
It is forbidden to remove or tamper with
the protection devices and safety devices.
keep away from hot parts on the machine.
INTRODUCTION
Your new all terrain mini hauler will more than
satisfy your expectations. It has been manufactured
under stringent quality standards to meet superior
performance criteria. You will find it easy and safe
to operate, and with proper care, it will give you
many years of dependable service.
Carefully read through this entire
operator’s manual before using this
unit. Take special care to heed the
cautions and warnings.
The four-speed gearbox, three forward and one
reverse, lies at the heart of the unit. It is oversized
so as to manage safely the huge torques generated
by the engine. Thanks to its efficient reduction
gearing, it is capable of moving around in every
situation and bearing any load.
The Engine manufacturer is responsible for all
engine-related issues with regards to performance,
power rating, specifications, warranty and service.
Please refer to the Engine Manufacturer’s
owner’s/operator’s manual, packed separately
with your unit, for more information.
Specifications
Item No.
Engine
Transmission
Load Capacity
Box Length
Box Width
Box Depth
Track Width
Sound power level ( LwA )
Sound pressure level ( LpA )
PK9715
196cc, 6.5HP
3F+1R
300 kg
860 mm
630 mm
290 mm
180 mm
103 dB(A) k=3 dB(A)
92 dB(A) k=3 dB(A)
10.1 m/s2k=1.5 m/s2
11.3 m/s2k=1.5 m/s2
179 kg
Vibrating level on
handlebar grips: (m/s2)
Left
Right
Weight

4
SAFETY
General Safety Rules
Understand your machine
Read and understand the operator’s manual and
labels affixed to the machine. Learn its application
and limitations as well as the specific potential
hazards peculiar to it.
Be thoroughly familiar with the controls and their
proper operation. Know how to stop the machine
and disengage the controls quickly.
Make sure to read and understand all the
instructions and safety precautions as outlined in
the Engine Manufacturer’s Manual, packed
separately with your unit. Do not attempt to
operate the machine until you fully understand
how to properly operate and maintain the Engine
and how to avoid accidental injuries and/or
property damage.
Work area
Never start or run the machine inside a closed
area. The exhaust fumes are dangerous, containing
carbon monoxide, an odorless and deadly gas.
Operate this unit only in a well ventilated outdoor
area.
Never operate the machine without good visibility
or light.
Personal safety
Do not operate the machine while under the
influence of drugs, alcohol, or any medication that
could affect your ability to use it properly.
Dress properly. Wear heavy long pants, boots and
gloves. Do not wear loose clothing, short pants,
and jewelry of any kind. Secure long hair so it is
above shoulder level. Keep your hair, clothing and
gloves away from moving parts. Loose clothes,
jewelry or long hair can be caught in moving parts.
Use safety equipment. Always wear eye protection.
Safety equipment such as a dust mask, hard hat,
or hearing protection used for appropriate
conditions will reduce personal injuries.
Check your machine before starting it. Keep guards
in place and in working order. Make sure all nuts,
bolts, etc. are securely tightened.
Never operate the machine when it is in need of
repair or is in poor mechanical condition. Replace
damaged, missing or failed parts before using it.
Check for fuel leaks. Keep the machine in safe
working condition.
Never remove or tamper with safety device. Check
their proper operation regularly.
Do not use the machine if the engine’s switch does
not turn it on or off. Any gasoline powered machine
that can not be controlled with the engine switch
is dangerous and must be replaced.
Form a habit of checking to see that keys and
adjusting wrenches are removed from machine
area before starting it. A wrench or a key that is
left attached to a rotating part of the machine may
result in personal injury.
Stay alert, watch what you are doing and use
common sense when operating the machine.
Do not overreach. Do not operate the machine
while barefoot or when wearing sandals or similar
lightweight footwear. Wear protective footwear
that will protect your feet and improve your footing
on slippery surfaces. Keep proper footing and
balance at all times. This enables better control of
the machine in unexpected situations.
Avoid accidental starting. Be sure the engine is off
before transporting the machine or performing
any maintenance or service on the unit.
Transporting or performing maintenance or service
on a machine with engine on invites accidents.
Fuel safety
Fuel is highly flammable, and its vapors can explode
if ignited. Take precautions when using to reduce
the chance of serious personal injury.
All terrain mini hauler
Keep your hands or feet away from track
and rotating parts.
Do not smoke or have open flames.
Thrown objects.
Keep bystanders away.

5
When refilling or draining the fuel tank, use an
approved fuel storage container while in a clean,
well-ventilated outdoor. Do not smoke, or allow
sparks, open flames or other sources of ignition
near the area while adding fuel or operating the
unit. Never fill fuel tank indoors.
Keep grounded conductive objects, such as tools,
away from exposed, live electrical parts and
connections to avoid sparking or arcing. These
events could ignite fumes or vapors.
Always stop the engine and allow it to cool before
filling the fuel tank. Never remove the cap of the
fuel tank or add fuel while the engine is running
or when the engine is hot. Do not operate the
machine with known leaks in the fuel system.
Loose the fuel tank cap slowly to relieve any
pressure in the tank.
Never over fill fuel tank. Fill tank to no more than
12.5mm (1/2”) below the bottom of the filler neck
to provide space for expansion as the heat of the
engine can cause fuel to expand.
Replace all fuel tank and container caps securely
and wipe up spilled fuel. Never operate the unit
without the fuel cap securely in place.
Avoid creating a source of ignition for spilled fuel.
If fuel is spilled, do not attempt to start the engine
but move the machine away from the area of
spillage and avoid creating any source of ignition
until fuel vapors have dissipated.
Store fuel in containers specifically designed and
approved for this purpose.
Store fuel in a cool, well-ventilated area, safely
away from sparks, open flames or other sources
of ignition.
Never store fuel or machine with fuel in the tank
inside a building where fumes may reach a spark,
open flame, or other sources of ignition, such as a
water heater, furnace, clothes dryer and the like.
Allow the engine to cool before storing in any
enclosure.
Machine use and care
Position the machine in such a way that it can not
move during maintenance, cleaning, adjustment,
assembly of accessories or spare parts, as well as
under storage.
Do not force the machine. Use the correct machine
for your application. The correct machine will do
the job better and safer at the rate for which it
was designed.
Do not change the engine governor settings or
over-speed the engine. The governor controls the
maximum safe operating speed of the engine.
Do not run the engine at a high speed when you
are not working.
Do not put hands or feet near rotating parts.
Avoid contact with hot fuel, oil, exhaust fumes and
hot surfaces. Do not touch the engine or muffler.
These parts get extremely hot from operation.
They remain hot for a short time after you turn off
the unit. Allow the engine to cool before doing
maintenance or making adjustments.
If the machine should start to make an unusual
noise or vibration, immediately shut off the engine,
disconnect the spark plug wire, and check for the
cause. Unusual noise or vibration is generally
warning of trouble.
Use only attachments and accessories approved
by the manufacturer. Failure to do so can result
in personal injury.
Maintain the machine. Check for misalignment or
binding of moving parts, breakage of parts and
any other condition that may affect the machine’s
operation. If damaged, have the machine repaired
before use. Many accidents are caused by poorly
maintained equipment.
Keep the engine and muffler free of grass, leaves,
excessive grease or carbon build up to reduce the
chance of a fire hazard.
Never douse or squirt the unit with water or any
other liquid. Keep handles dry, clean and free from
debris. Clean after each use.
Observe proper disposal laws and regulations for
gas, oil, etc. to protect the environment.
Store idle machine out of the reach of children
and do not allow persons unfamiliar with the
machine or these instructions to operate it. Machine
is dangerous in the hands of untrained users.
Service
Before cleaning, repair, inspecting, or adjusting,
shut off the engine and make certain all moving
parts have stopped. Disconnect the spark plug
wire, and keep the wire away from the plug to
prevent accidental starting.
All terrain mini hauler
