PreCise Biometrics TACTIVO mini Product information sheet

TACTIVO™ mini
for iOS
User Reference Guide

Trademarks: Tactivo™ and PRECISE BIOMETRICS™
Patent: patents pending in EU and USA
©Precise Biometrics 2013-2014

INDEX
1. Introduction
2. General Information
3. System Requirements
4. Card Reader
5. Installation
6. Maintenance
7. Using Tactivo
7.1 Correct nger placement
7.2 Enhancing ngerprint image quality
8. Apps for Tactivo
9. Electromagnetic Compatibility
10. Environment

1. Introduction
Tactivo™ mini smart card and ngerprint reader makes strong
authentication easy and convenient using a smart card, ngerprint, or both.
For more information on Tactivo mini and available apps, visit
www.precisebiometrics.com.
2. General Information
Tactivo mini for iOS should only be used with iPhone or iPad devices with
Lightning connector, but the smart card reader functionality can also be
used on Windows (XP or later) and OS X (Mountain Lion or later) desktop
computers by using the micro USB connector. Devices running Android (4.0
or later) with USB ports are also supported. OS X support
may require additional conguration.
Do not allow Tactivo mini to get in contact with water or other uids. If this
happens, immediately remove the Tactivo mini from the iPhone/iPad and let
it dry thoroughly. Do not dry Tactivo mini using any external sources, such as
hair dryers or microwave ovens.
Tactivo mini is designed to work in the temperature range 32-95°F (0-35°C)
and can be stored in the range -4-113°F (-20-45°C )
Handling of Tactivo mini is the user’s responsibility and any action that can
damage the product is the user’s own responsibility. Do not paint, drop or
disassemble Tactivo mini, and do not put it in places or in devices where it
can be damaged such as in a clothes dryer.
Tactivo mini may contain small parts which may present a choking hazard
for small children. Keep such parts away from small children.

3. System Requirements
Usage of Tactivo mini requires an iPhone or iPad device with Lightning
connector. Find supported iOS versions at:
www.precisebiometrics.com/supported-ios-versions.
Using the smart card reader functionality of the Tactivo mini on a desktop
computer requires Windows XP or later or OS X Mountain Lion or later.
Using the Tactivo mini on Android requires an Android device with Android
version 4.0 or later, a USB port and USB On-The-Go (OTG) support as well as
a USB cable. It is compatible with all Android devices with a USB port and
USB On-The-Go (OTG) support.
4. Card Reader
The card reader in Tactivo supports ISO 7816-4 compatible smart cards
including U.S. credentials PIV, PIV-I, TWIC, and CAC. Embossed cards are
also supported. Do not use the card reader for other cards or for storage of
other things such as business cards.

A B C
5. Installation
Always make sure the Lightning connector of the Tactivo mini is properly
aligned with the corresponding connector of the iPhone/iPad before
connecting Tactivo mini. Bending while connecting or disconnecting might
damage Tactivo mini and the Lightning connector to the iPhone/iPad.
1. Plug in your Tactivo mini either directly into your iPhone (A) or
iPad (B) through the Lightning connector or into other devices
using a separate standard USB cable (C). The Tactivo mini can be
used as a standard smart card reader for Windows, OS X and An-
droid. Connect the Tactivo mini to the Windows, OS X or Android
device using a micro-USB to USB cable.
2. If you have a
smart card, slide
it in.
3. Scan the QR code to get the “My Tactivo”
app. Launch it and make sure you’ve got
the latest rmware.

6. Maintenance
Protect Tactivo mini from any kind of physical damage.
Ensure that you are electrostatically discharged before putting your
nger on the sensor. High electrostatic discharges might damage the
ngerprint sensor.
Keep the sensor surface clean or there is an increased risk that the
ngerprint can’t be successfully matched.
If necessary, clean the sensor surface with a clean cotton cloth. You can
dampen the cloth slightly with a cleaner.
Do not use paper tissues for cleaning purposes as they may scratch the
surface.
Do not spray cleaner directly onto the device.
Do not use chlorine-based cleaners, non-chlorine bleach, or chlorine-
based bathroom or mildew cleaners.
Do not use any solvents, such as acetone, paint thinners, turpentine, etc.

7.1 Correct Finger Placement
Correct and consistent nger placement is crucial for good performance.
1. Fingerprint sensor
2. Make sure to capture
this area on your nger
3. Swipe your nger
at on the sensor
in a rm downward
movement
4. Do not rotate your nger and
make sure it is not misaligned
5. Do not lift nger when swiping
and do not use only the ngertip

7.2 Enhance Fingerprint Image Quality
If your nger is very dry:
Try to press more rmly when swiping.
Breathe on your nger.
If your nger is very damp:
Try to press less rmly when swiping.
Wipe your nger dry.
More tips
See the “Maintenance” section to learn how to keep the sensor
surface clean.
If your ngerprint is still not recognized, please consider
re-enrollment to get a better reference image.

8. Apps for Tactivo mini
The use of apps for Tactivo mini is entirely at the user’s sole risk. Precise
Biometrics has no liability whatsoever and disclaims all responsibility for the
usage of apps for Tactivo.
9. Elecromagnetic Compatibility
Electromagnetic compatibility (EMC) is the ability of electronic equipment
to function properly together in the electronic environment.
CE Notice (Europe)
Tactivo meets the following technical standards:
• EN 301 489-1:2011
• EN 55022:2006 – A1:2007
• EN 61000-4-2:2008
• EN 61000-4-2:2008
FCC Information (USA)
Tactivo mini for iOS (P/N SAA 133 1002) complies with Part 15 (Class B) of
the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired
operation.

NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit dierent from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
CONTACT: Precise Biometrics Inc. 11951 Freedom Drive, 13th Floor,
Reston, VA 20190. +1 (800)) 609-0578
10. Environment
RoHS compliant
WEEE compliant
The Tactivo mini should be recycled as an electrical waste
ASP 140 1002 – 4160/5 RA
iPhone and iPad are trademarks of Apple Inc., registered in the U.S. and other countries. Lightning is
a trademarks of Apple Inc.
