Prime Security 98 User manual

AMX98 (2) Rev. A - Owner's Manual

Table of Contents
AMX98...................................2
Lifetime Warranty............................2
Remote Controls ............................2
Electronic Scan Prevention (ESP).....................3
Instant Remote Control Code Deletion..................3
One-Step Remote Control Code Learning ................3
Valet Switch...............................3
Operating Instructions...........................4
To Arm The System ...........................4
To Disarm the System ..........................4
Remote-Controlled Silent Arm/Disarm .................4
User-Programmable Long-Term Silent Arm/Disarm ...........5
Two Stage Unlock Capability ......................5
Remote Panic with Safety Locks™....................5
Interior Light Illumination ........................5
User-Programmable Passive Door Lock .................5
User-Programmable Ignition-Controlled Door Lock/Unlock .......6
Protected Valet Mode ..........................6
Remote-Controlled Valet ........................6
Keyless Entry in Valet ..........................7
LED System Status Indicator .......................7
Remote-Controlled Accessory Outputs.................7
Zone
2
™ Impact Sensor .........................7
Remote-Controlled Sensor Bypass ....................8
Previous Intrusion Alert .........................8
Specific Zone Intrusion Identification ..................8
User-Programmable Door Ajar Indication ...............8
User-Programmable Siren Duration ...................9
Alarm State Memory ..........................9
Automatic Malfunction Override ....................9
User-Programmable Features .......................10
Programming Table for Alarm Features.................11
Programming Table for Remote Controls................12
1
AMX98 (2) Rev. A - Owner's Manual

AMX98
Congratulations! You have just purchased the AMX98 vehicle security system
manufactured by Prime Security.
To fully benefit from the capabilities of your AMX98, we encourage you to
read the Owner’s Manual thoroughly before using the system. If you have any
problems or questions regarding your system, consult the dealer from whom
you purchased this product. To locate an authorized Prime dealer, contact
Prime Security directly at 1-800-253-0334 (toll-free within the U.S.) or
1-847-215-2233.
Lifetime Warranty
Prime guarantees the operation of your control unit and remote controls for as
long as you own your car. (Please refer to your Lifetime Limited Warranty
Card for complete information.) Make sure that you receive your warranty
card from your dealer, complete the required information and mail the
registration portion to Prime Security. You should retain the top portion of the
warranty card for your records.
Remote Controls
Included with your system are two AviGlo™ 4-button/9-channel remote
controls. Once exposed to light, the AviGlo remote control buttons will glow,
making the buttons visible in the dark.
The remote control (remote) is a miniature transmitter powered by a small
+12 volt battery. Obstructions, electrical or radio interference, weather
conditions, window tint or a weak battery can reduce range. Your remote is
the key to your system and can be used to arm and disarm your alarm, lock
and unlock your doors, "pop" your trunk, and control optional accessories
such as a remote engine starter, window roll-up and garage door opener.
The system can accept up to four Prime remote controls. Additional remote
controls and remote control batteries can be purchased from any authorized
Prime dealer, or by calling Prime Security toll-free at 1-800-253-0334 (within
the U.S.) or 1-847-215-2233.
2
AMX98 (2) Rev. A - Owner's Manual

Electronic Scan Prevention (ESP)
Your system includes ESP, which blocks electronic scanner codes preventing
unauthorized operation of your system.
Instant Remote Control Code Deletion
In the event of a lost or stolen remote control, all remote controls can be
erased from the system’s memory preventing unauthorized system operation.
(See the "Programming Table for Remote Controls" on page 12).
One-Step Remote Control Code Learning
Your system allows you to add new remote controls in one step. (See the
"Programming Table for Remote Controls" on page 12).
Valet Switch
The valet switch is a small hidden toggle switch which allows you to control all
of the system’s programmable features. (See "User-Programmable Features" on
page10).Thisswitchcanonlybecontrolledwiththeuseofyourignitionkey.
NOTE:Besuretohaveyourdealershowyouwherethevaletswitch islocated.
3
AMX98 (2) Rev. A - Owner's Manual

Operating Instructions
To Arm The System
The alarm can be programmed for active or passive arming. Active arming
means the alarm can only be armed by the remote control. Passive arming
means the alarm will automatically arm itself. (See the "Programming Table
for System Features" on page 11.)
Active Arming
Press the remote ARM/DISARM button for 1-2 seconds. The siren will chirp
twice, the parking lights will flash twice, the doors will lock, the LED will flash
slowly and the starter will be disabled.
Passive Arming
Turn the ignition key "OFF," exit the vehicle and close the doors. When the
interior lights turn off, the LED will begin flashing rapidly to indicate the alarm
is passive arming. After 30 seconds, the siren will chirp twice, the parking
lights will flash twice, the LED will flash slowly and the starter will be disabled
(at any time during passive arming, the alarm can be actively armed).
To Disarm the System
Press the remote ARM/DISARM button for 1-2 seconds. The siren will chirp
once, the parking lights will flash once, the doors will unlock, the interior
lights will turn on, the LED will turn off and the starter will be enabled.
Remote-Controlled Silent Arm/Disarm
Press the remote SILENT button for 1-2 seconds to arm or disarm your system
without the usual siren chirps.
Silent Arm Indications
The parking lights will flash twice, the doors will lock, the starter will be
disabled and the LED will flash slowly.
Silent Disarm Indications
The parking lights will flash once, the doors will unlock, the starter will be
enabled and the LED will turn off.
4
AMX98 (2) Rev. A - Owner's Manual

User-Programmable Long-Term Silent Arm/Disarm
This feature allows you to completely disable the arm/disarm siren chirps until
you decide to restore them. (See the "Programming Table for System Features"
on page 11.)
Two-Stage Unlock Capability
If the optional Two-Stage Unlock feature was installed, press the remote
ARM/DISARM button for 1-2 seconds and only the driver door will unlock.
Within 3 seconds, press the remote ARM/DISARM button again and the
passenger door(s) will unlock (may require an optional relay).
Remote Panic with Safety Locks™
In a threatening situation, you can activate Remote Panic with Safety Locks.
When activated, the siren will sound and the parking lights will flash. If you
are inside your vehicle and the ignition key is "ON," the doors will lock. If you
are outside the vehicle with the ignition key "OFF," the doors will unlock.
To Activate
1.Press the remote ARM/DISARM button for 3-4 seconds.
2. The siren will sound and the parking lights will flash.
3.If the ignition key is "OFF," the doors will unlock. If the ignition key is
"ON," the doors will lock.
To Deactivate
1.Press the remote ARM/DISARM button for 1-2 seconds.
2. The siren will shut off and the parking lights will stop flashing.
Interior Light Illumination
When the alarm system is remotely disarmed, the vehicle interior light(s) will
turn on for 30 seconds or until the ignition key is turned on.
User-Programmable Passive Door Lock
The system will not automatically lock the doors when the alarm passively
arms to prevent the keys and remote from being locked in the vehicle. If you
prefer, you can easily program the alarm to automatically lock the doors every
time the alarm passively arms. (See the "Programming Table for System
Features" on page 11.)
5
AMX98 (2) Rev. A - Owner's Manual

User-Programmable Ignition-Controlled Door Lock/Unlock
For the ultimate in security and convenience, the system is programmed to
automatically lock your doors when the ignition key is turned "ON" or the
engine is started, and will unlock when the ignition key is turned "OFF." This
feature can be programmed ON or OFF. (See the "Programming Table for
System Features" on page 11.)
Protected Valet Mode
You should place your system in Protected Valet Mode whenever your vehicle
is being serviced by mechanics, car wash personnel or driven by valet parking
attendants. While in the Protected Valet Mode, all alarm functions are
bypassed to prevent unauthorized or accidental operation. Remote-controlled
door lock/unlock , trunk release and all optional accessories will still operate.
To Turn On Protected Valet Mode
1.Turn your ignition key to the "ON" position or start the engine.
2.Flick the valet switch to the "ON" position.
3. The LED will turn on solid red to indicate the system is in Protected Valet
Mode.
4.Turn your ignition key to the "OFF" position.
To Turn Off Protected Valet Mode
1.Turn your ignition key to the "ON" position or start the engine.
2.Flick the valet switch to the "OFF" position.
3. The LED will turn off to indicate the system is no longer in Protected Valet
Mode.
4.Turn your ignition key to the "OFF" position
Remote-Controlled Valet
For your convenience, the system can be put into Valet mode via the remote
control. While in Remote-Controlled Valet, all alarm functions are bypassed.
To Activate Remote-Controlled Valet
1.Press the remote ARM/DISARM and SILENT buttons at the same time.
2. The parking lights will flash 4 times.
3.The LED will turn on solid red to indicate the alarm is now in
Remote-Controlled Valet.
6
AMX98 (2) Rev. A - Owner's Manual

To Deactivate Remote-Controlled Valet
1.Press the remote ARM/DISARM and SILENT buttons at the same time.
2. The parking lights will flash 3 times.
3.The LED will turn off to indicate the alarm is no longer in
Remote-Controlled Valet.
Keyless Entry in Valet Mode
While the system is in the Valet mode, you can still use your remote control to
lock and unlock the doors as well as activate any optional accessory such as
trunk release or remote engine starter.
LED System Status Indicator
The LED on your vehicle’s dashboard or center console will inform you of the
system status.
LEDStatus
OffSystem is disarmed
On solidIn a valet mode
Slow flashSystem is armed
Flashing in cyclesSee "Specific Zone Intrusion Identification"
on page 8
Rapid flashPassive arming
Remote-Controlled Accessory Outputs
These outputs allow you to add optional remote-controlled accessories to your
system such as a remote engine starter, trunk release, window roll-up, garage
door opener or fuel door release. To activate your optional accessories, see
the "Programming Table for Remote Controls" on page 12.
Zone2 ™ Impact Sensor
The Zone2 Impact Sensor has two individual vibration/impact sensing zones.
Zone #1
If a less threatening vibration or impact is detected, the siren will issue 2
warn-away chirps. A second violation will also issue 2 warn-away chirps. If
within 45 seconds a third violation is detected, the sensor will automatically
trigger the alarm. The siren will sound and the lights will flash.
Zone #2
If a more threatening vibration or impact is detected at any time, the siren and
lights will activate instantly.7
AMX98 (2) Rev. A - Owner's Manual

Remote-Controlled Sensor Bypass
You can bypass the system sensor(s) at any time. The alarm system will still
provide full perimeter protection.
To Bypass the Sensor(s):
1.Press the remote TRUNK and OPTION buttons at the same time.
2. The siren will chirp twice. . . pause. . . chirp twice. . . pause . . . chirp
twice.
3.The sensor(s) is now bypassed until you remotely disarm and then re-arm
your system.
Previous Intrusion Alert
If the vehicle had been tampered with and the alarm has been triggered, the
siren will chirp 3 times upon remote disarm instead of the usual 1 chirp.
Specific Zone Intrusion Identification
If the alarm had been triggered in your absence, the siren will chirp 3 times
upon remote disarm (Previous Intrusion Alert). When you enter the vehicle
and turn the ignition "ON," the LED will flash in cycles to specifically identify
which zone has triggered the alarm.
LEDZone
One Flash...One Flash...Impact sensor
Two Flash...Two Flash...Hood/trunk trigger
Three Flash...Three Flash...Door trigger
User-Programmable Door Ajar Indication
When you remotely arm the alarm system and a door is ajar (not closed), the
siren will chirp 2 times, then chirp 3 times and the parking lights will flash 3
times. This feature provides audible and visual indication to prevent battery
drain. (See "Programming Table for System Features" on page 11.)
NOTE: If your vehicle has factory delayed lighting, this feature will be
turned off.
8
AMX98 (2) Rev. A - Owner's Manual

User-Programmable Siren Duration
Upon activation, the siren can be programmed to run for 30 or 60 seconds
before it will shut off and instantly rearm. (See the “Programming Table for
System Features” on page 11.)
Alarm State Memory
If your vehicle battery is disconnected and later reconnected, the system will
automatically return to its last state before power was removed, whether it was
armed, disarmed or in Valet Mode. For example, if a mechanic disconnects
the battery while the alarm is disarmed or in Valet Mode, he won’t trigger the
alarm when he reconnects the battery. If a thief removes power while the
alarm is armed, and reconnects it, the alarm will instantly sound, the parking
lights will flash and the starter will be disabled.
Automatic Malfunction Override
In the event of a faulty sensor or alarm input trigger zone, the alarm, when
remotely armed, will alert you by a series of chirps and parking light flashes.
How to Interpret the Chirps and Parking Light Flashes
When you press the remote control buttons, the system will respond with
chirps and flashes of the parking lights to indicate the system status. An
explanation of these chirp/flash acknowledgments follows:
Number of chirps and flashes Explanation
1 chirp, 1 flash Disarming of the alarm.
2 chirps, 2 flashes Arming of the alarm.
2 chirps and flashes, then 3 more chirps
and flashesArmed and a door is ajar.
2 chirps and flashes, then 4 more chirps
and flashesArmed and there is a sensor malfunction (automatically bypassed).
3 chirps, 3 flashes Disarmed and there was an intrusion attempt.
4 chirps, 4 flashes Armed and there is a trigger malfunction
(automatically bypassed).
9
AMX98 (2) Rev. A - Owner's Manual

User-Programmable Features
All system and remote control programmable features are accomplished by
turning the ignition key "ON" (or starting the engine) and flicking the valet
switch on and off a preset number of times.
The system also allows you to add new remote controls in one step, delete lost
or stolen remote controls or rearrange the factory preset remote control
functions.
1.Remove the system from Protected or Remote-Controlled Valet mode.
Programming cannot be accessed while the system is in Valet mode
indicated by the LED on solid red.
2.Select the feature you wish to program from the "Programming Table for
System Features" or the "Programming Table for Remote Controls" on pages
11 & 12. Note the number of chirps associated with that feature.
3.Turn the ignition key to the "ON" position.
4.Within 10 seconds, begin flicking the valet switch on and off. The siren
will chirp once each time you flick the switch on then off.
5. Continue flicking the switch on and off, counting the number of chirps.
NOTE: Stop when you reach the number of chirps associated with
your chosen feature.
6.Follow the "Secondary Action." You will hear a number of chirps to
confirm that you have changed the setting of that feature.
7.Turn the ignition key to the "OFF" position.
8.Repeat steps 1-7 for any other feature you wish to program.
10
AMX98 (2) Rev. A - Owner's Manual

Programming Table for System Features
FeatureFactory
SettingNo. of Chirps Secondary Action
Active / Passive ArmingPassive4Wait 3 seconds, the siren will chirp
once for Active, twice Passive.
Passive Door LockOFF5Wait 3 seconds, the siren will chirp
once for OFF, twice for ON.
Passive Armed ConfirmationON6Wait 3 seconds, the siren will chirp
once for OFF, twice for ON.
Ignition-Controlled Door
Lock / UnlockON9Wait 3 seconds, the siren will chirp once for OFF, twice for ON.
Door Ajar IndicationON12 Wait 3 seconds, the siren will chirp
once for OFF, twice for ON.
Siren Duration
(30 or 60 seconds)30 Seconds 13 Wait 3 seconds, the siren will chirp
once for 60 seconds, twice for 30.
Long-Term Silent Arm / DisarmON14 Wait 3 seconds, the siren will chirp
once for OFF, twice for ON.
11
AMX98 (2) Rev. A - Owner's Manual

Programming Table for Remote Controls
FeatureFactory SettingNo. of
Chirps Secondary Action
Arm/DisarmARM/DISARM
Button15 Press the ARM/DISARM button, the siren will chirp 1 time.
Remote-Controlled
Trunk Release Output TRUNK Button16 Press the TRUNK button, the siren will chirp 2 times.
Remote-Controlled
Silent Arm/DisarmSILENT Button17Press the SILENT button, the siren will chirp 3 times.
Remote-Controlled
Accessory Output OPTION Button18 Press the OPTION button, the siren will chirp 4 times.
Remote-Controlled ValetARM/DISARM +
SILENT Buttsons 19Press the ARM/DISARM + SILENT buttons, the siren will chirp 5 times.
Remote-Controlled
Accessory Output ARM/DISARM + OPTION Buttons20 Press the ARM/DISARM + OPTION buttons, the siren will chirp 6 times.
Remote-Controlled
Sensor BypassTRUNK + OPTION Buttons 21 Press the TRUNK + OPTION buttons, the siren will chirp 7 times.
One Step Remote
Control Code LearningARM/DISARM Button22 Press ARM/DISARM button, the siren will chirp 1 time.
Instant Remote Control
CodeDeletion —23Wait 3 seconds, the siren will chirp
twice, allcodes are erased out of
memory.
12
AMX98 (2) Rev. A - Owner's Manual

AMX98 (2) Rev. A - Owner's Manual

AMX98 (2) Rev. A - Owner's Manual
