PROAIM CT-SLBD-01 User manual

1
What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
Proaim Smart Lock Drawer for Proaim Victor V1,
Victor Lite, Atlas Cart (CT-SLBD-01)
Assembly Manua l
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
Smart-Lock Drawer
Lock
1 x T-Type Allen Key
(Size: 2.5mm)

2
• When the drawer is properly aligned, using a
drilling machine (Not Included) drill six holes
exactly where the markings are, as shown in
the gure.
NOTE: The drawer is axed to your cart by
drilling holes into the cart, ensuring a solid and
secure aachment .
• Remove the mat of Victor V1-42 cart
(Not Included), as shown in the image.
NOTE: Mat can be removed for drilling because
mat is already axed to the cart. The drawer
needs to be drilled.
Smart-Lock Drawer Setup
• Matching the drawer and cart holes, insert a
screw and properly ghten using a 2.5mm
Allen Key.
• Follow the same process for inserng all
screws.
NOTE: The so-closing sliding mechanism
prevents the gear inside the drawer from
smashing & hing together.
• Align the drawer under the top shelf of the
cart and mark where the holes are.
NOTE: Smart-Lock Drawer is a deep & fully
enclosed one that takes in all suitable video
producon accessories carries your hard drives,
camera accessories, cleaning supplies & other
quick-access tools & facilitates convenient
access to them .

3
• Then, insert the nuts into the lock bolts and
ghten them with an Allen key.
NOTE: Hold the nut using a Plass (Not
Included) and ghten it using an 2.5mm Allen
Key.
• The lock is properly aached to the cart.
• Aach the lock to the boom of the top shelf
of the cart and mark the lock holes.
• Insert the bolts by properly matching the
holes of the lock and cart.
• Now make holes in the marking points with
the help of a drilling machine.
• Remove both the nut bolts of the lock with
the help of an 2.5mm Allen Key, as shown in
the image.

4
NOTE: It features a 3-digit personalized
combinaon lock that ensures your valuable
gear is fully protected & makes you work with
full freedom without worrying about the
drawer’s stu.
NOTE: Follow the same procedure to insert the
drawers on the other side and boom of the
cart.
1. You can mount 3 drawers in Victor V1-42
cart ,at top –2 & boom –1 drawer as
shown in the image.
2. you can set drawer's posion anywhere
according to your requirement.
• Set the drawer’s number lock according to
your preference and lock it.
Capability of Carts & Drawer Mounng

5
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon
and evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our utmost
support and care unl you use our product.
YOUR PROAIM SMART-LOCK DRAWER
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
