Protective Enclosures Company TV Shield Pro 2015 User manual
1
PRO
Centerpointe Circle, Suite 1319,
Altamonte Springs, Florida. 32701
1-800-331-2628
Save this assembly manual for future reference in the event that you need to order replacement parts.
•Owner’sManual
•AssemblyInstrucons
•WarrantyInformaon
INS-A-TVSHIELDPRO-ENG 10/13/15
Made in the USA
Copyright (©) Protecve Enclosures Company, LLC
2
3
PRO®
MEDIUM: FITS MOST 40” TO 50” TVS
MAX INTERIOR DIMENSIONS: 45.95"W X 27.95"H X 3.94"D
EXTERIOR DIMENSIONS: 49.01"W X 31.01"H X 7.75"D
WEIGHT: 88 LBS
PRO®
LARGE: FITS MOST 51” TO 60” TVS
MAX INTERIOR DIMENSIONS: 55.95"W X 33.95"H X 3.94”D
EXTERIOR DIMENSIONS: 59.01"W X 37.01"H X 7.75”D
WEIGHT: 108 LBS
PRO®
MAX INTERIOR DIMENSIONS: 63.95"W X 38.95"H X 3.94”D
EXTERIOR DIMENSIONS: 67.01"W X 42.01"H X 7.75”D
WEIGHT: 128 LBS
PRO®
MAX INTERIOR DIMENSIONS: 74.95"W X 44.95"H X 3.94”D
EXTERIOR DIMENSIONS: 78.01"W X 48.01"H X 7.75”D
WEIGHT: 152 LBS
PROTECTIVE ENCLOSURES COMPANY LLC (PEC) DOES NOT WARRANT AGAINST DAMAGE CAUSED BY THE USE OF ANY PEC PRODUCT FOR
PURPOSES OTHER THAN THOSE FOR WHICH IT WAS DESIGNED OR DAMAGE CAUSED BY UNAUTHORIZED ATTACHMENTS OR MODIFICA-
TIONS, AND IS NOT RESPONSIBLE FOR ANY DAMAGES, CLAIMS, DEMANDS, SUITS, ACTIONS OR CAUSES OF ACTION OF WHATEVER KIND
RESULTING FROM, ARISING OUT OF OR IN ANY MANNER RELATING TO ANY SUCH USE, ATTACHMENTS OR MODIFICATIONS.
reinforced.
mishandling the enclosure.
BE SURE TO COMPARE YOUR TV DIMENSIONS TO THE MAXIMUM INTERIOR DIMENSIONS OF THE TV SHIELD PRO. IF YOUR TV OR DISPLAY
IS TOO LARGE IT WILL NOT ALLOW FOR PROPER INSTALLATION OR USE.
4
TOOLSREQUIREDFORINSTALLATION
These are the tools that are generally required for assembly of our products. These tools are not included with the
product purchase, nor included in the box. You will need to use the hardware from a separately sold TV wall or
ceiling mount.
CordlessDrillorElectricDrill
PhillipsScrewDriver
5/16”SocketandSocketWrench
AnAdultw/anAdultHelper
ElectronicStudFinderforDrywallApplicaons
(forinstallaonofyourseparatelysoldwallmountor
ushmounng)
BubbleLevel
NeedleNosePliers
TapeMeasure SeparatelySoldWall/CeilingMount
andMountHardware
5
PARTSIDENTIFICATION
IncludedinBox
A.(1)FrontFrame B.(1)BasePlate C.(2)InternalMountBrackets
D.(2)Keys F.(2)1/4”E-ClipsE.(2)GasShocks
G.(3)3/16”E-Clips(or(4)3/16”
E-Clipswithallunitsabove42-50”)
H.(4)1”x0.90”NylonSpacers
(usedforushmounng)
See Remaining Parts Idencaon Items on the Next Page
