PROTRON PD-DVR100 User manual

OPEN/CLOSE
STANDBY/ON
R
E
C
S
O
U
R
C
E
P
L
A
Y
/
P
A
U
S
E
P
R
E
V
N
E
X
T
S
T
O
P
DVD+ReWritable
PD-DVR100
DVD Recorder
User’s Manual
OMPDDVR100.book Page i Monday, September 19, 2005 8:35 AM

Protron PD-DVR100 DVD Recorder User’s Manual.
© 2005 Protron Digital Corporation. All rights reserved.
Under copyright law, this manual may not be reproduced in any form, in whole or in part,
without the prior written consent of Protron Digital Corporation.
Disclaimer
Protron Digital Corporation has reviewed this manual and provides it only as a guide to
operation. All statements, technical information, and recommendations in this manual and in
any guides or related documents are believed reliable, but the accuracy and completeness
thereof are not guaranteed or warranted, and they are not intended to be, nor should they be
understood to be, representations or warranties concerning the products described.
Specifications are subject to change without notice.
Trademarks
Protron is a registered trademark of Prosonic Group Corporation.
Protron Digital Corporation
2133 S. Green Privado
Ontario, CA 91761
Printed in China
OMPDDVR100.book Page ii Monday, September 19, 2005 8:35 AM

i
Product Cautions
TO PREVENT POSSIBLE DANGER, ELECTRIC SHOCK, AND OTHER INJURIES WHEN
HANDLING YOUR DVD RECORDER, PLEASE BE AWARE OF OF ALL WARNINGS AND
SAFETY PRECAUTIONS LISTED BELOW.
Never spill any liquid of any kind on the device.
Never insert anything into the device, where objects can come into contact with
high voltage nodes or damage internal components.
Do not attempt to service the device yourself. Opening or removing covers
exposes high voltage nodes and other hazards. Refer all servicing to qualified
service personnel.
Do not touch the device or antenna during thunderstorms. Unplug the device
during thunderstorms or if it will not be used for extended periods. Failure to
do so may result in electric shock or fire.
Before cleaning the device, unplug it from the wall. Use a damp cloth for
cleaning. Never use liquid or aerosol cleaners.
To prevent overheating and ensure reliable operation, place the device only in a
well ventilated location. Avoid cramped or inadequately ventilated locations.
Note: Read all safety and operating instructions before operating your new DVD recorder.
R
E
C
S
O
U
R
C
E
P
L
A
Y
/
P
A
U
S
E
P
R
E
V
N
E
X
T
S
T
O
P
OPEN/CLOSE
STANDBY/ON
R
E
C
S
O
U
R
C
E
P
L
A
Y
/
P
A
U
S
E
P
R
E
V
N
E
X
T
S
T
O
P
OPEN/CLOSE
STANDBY/ON
R
E
C
S
O
U
R
C
E
P
L
A
Y
/
P
A
U
S
E
P
R
E
V
N
E
X
T
S
T
O
P
OPEN/CLOSE
STANDBY/ON
OMPDDVR100.book Page i Monday, September 19, 2005 8:35 AM

ii
Conformity and Compliance
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception (this can be
determined by turning the device off and on), the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution:
To comply with the limits for an FCC Class B computing device, the user should use the shielded
signal cable and power cord supplied with the unit. The FCC warns that changes or modifications
of the unit not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
Radio Frequency Interference Statement
Warning:
This is a Class B product. In a domestic environment this product may cause radio interference, in
which case the user may be required to take adequate measures.
Canadian DOC Notice for Class B Computing Devices
This digital apparatus does not exceed the Class B limits for radio noise emissions from a digital
apparatus as set out in the Radio Interference Regulations of the Canadian Department of
Communications.
CE Marking and Declaration of Conformity
This device complies with the requirements of related European standards, which
include the following:
• Emission: EN 55022, EN 61000-3-2, EN 61000-3-3
• Immunity: EN 50082-1
• Safety: EN 60950 Low-Voltage Directive (73/23/EEC)
OMPDDVR100.book Page ii Monday, September 19, 2005 8:35 AM

iii
Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Unpacking Your New DVD Recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Connecting the Recorder to Other Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Connecting to a Display Using Component Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Connecting to a Display Using S-Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Connecting to a Display Using Composite Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Connecting to a Television Signal Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Connecting to a 5.1 Channel Audio System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Connecting to a Stereo Audio System Using an Analog Connection . . . . . . . . . . . . . . . . . . . . 8
Connecting to a Stereo Audio System Using a Digital Connection . . . . . . . . . . . . . . . . . . . . . . 8
Connecting Other Audio/Video Sources to the Recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Using the Recorder for the First Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Operating the Recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Turning the Recorder On and Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Inserting a Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Understanding the LCD Readout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Bringing Up the On-Screen Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Accessing the Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Using the Remote Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Replacing the Remote Batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Recording DVDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Supported Media Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
About DVD Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
The LCD Readout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
The On-Screen Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Recording Video Manually . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Scheduling Recordings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Finalizing the Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Editing Recorded DVDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Using the Disc Edit Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Renaming the Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Erasing the Disc (DVD+RW Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Creating a New Title . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Overwriting the Disc (DVD+RW Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Making the Disc Compatible with Other DVD Players (DVD+RW Only) . . . . . . . . . . . . . . . . . 20
Locking and Unlocking the Disc (DVD+RW Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Finalizing the Disc (DVD+R Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Using the Title Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Editing a Title . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Renaming a Title . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Erasing a Title . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Overwriting a Title (DVD+RW Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Overwriting from a Title (DVD+RW Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Using Edit Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Creating/Deleting a Chapter Marker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Hiding a Chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Setting an Index Picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Splitting a Title (DVD+RW Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
OMPDDVR100.book Page iii Monday, September 19, 2005 8:35 AM

Table of Contents
iv
Playing DVDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
The LCD Readout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
The On-Screen Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Navigating Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Controlling Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Searching to a Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Programming Playback Sequence. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Playing Video CDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
The LCD Readout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
The On-Screen Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Navigating Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Controlling Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Searching to a Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Programming Playback Sequence. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Playing Audio CDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
The LCD Readout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
The On-Screen Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Controlling Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Programming Playback Sequence. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Playing Kodak Picture CDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
The LCD Readout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Controlling Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Navigating Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Transforming Images. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Enabling Slideshow Transition Effects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Repeating Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Playing Media on Data CDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
The LCD Readout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
The On-Screen Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Using the Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Controlling Audio File Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Controlling Image File Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Controlling Video File Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Searching to a Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Programming Playback Sequence. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Configuring the Recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Record. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Channel Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Support Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Television Tuner. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
OMPDDVR100.book Page iv Monday, September 19, 2005 8:35 AM

1
Introduction
Congratulations on purchasing your new Protron DVD Recorder!
With a television tuner and three audio/video inputs, you can record television broadcasts and
video signals from other devices on DVD, for up to 360 minutes of recorded video on each DVD.
Further, with a progressive scan component video output and 5.1 channel surround sound, your
DVD recorder can play back DVDs with the highest quality available. And it can even play music,
video, and photo CDs.
Features
• Records on DVD+R/RW media
• Up to 360 minutes of recorded video on a 4.7GB DVD (SLP mode)
• 3 S-Video/composite video inputs with corresponding stereo audio inputs
• 4-pin IEEE 1394 (i.LINK/FireWire) input
• TV tuner input/output
• Plays DVD, DVD±R/RW, CD-ROM, CD-R/RW, Audio CD (CD-DA), MP3 CD, Video CD (VCD),
Super Video CD (SVCD), and Kodak Picture CD media
• Displays media files (MP3, WMA, JPEG, MPEG, AVI, DAT/VCD) stored on data CDs
• Multi-angle video playback
• 10-bit, 525-line digital video converter
• 24-bit, 96kHz digital audio converters for high fidelity sound
• 5.1 channel surround sound
• Audio formats supported: Dolby Digital, DTS, MPEG-2, PCM
• Progressive scan component video output for crisp, flicker-free video
• S-Video output
• Composite video output
• Digital optical audio output
• Digital coaxial audio output
• Stereo audio output
OMPDDVR100.book Page 1 Monday, September 19, 2005 8:35 AM

2
Unpacking Your New DVD Recorder
Before using your new DVD recorder, you should unpack the
contents of the box and check to make sure everything is present
and undamaged.
To unpack the player:
1. Open the box. Remove the recorder and styrofoam pads.
2. Remove the remote control from the recess in the left
styrofoam pad.
3. Remove the styrofoam pads and plastic bag enclosing the
player and set it aside.
4. Check to ensure the items indicated below are included in the
box. If any items are missing or damaged, contact the seller
immediately.
RCA Cables
Remote Control
2 AAA Batteries
MUTE
ZOOM
P-SCAN REPEAT TIMER
SETUP DISC EDIT EDIT
SLOW REC
A-B MODE
VOLUME
(LEVEL)
REV FWD
NEXTPREV
STOP PAUSE/STEP PLAY
DISPLAY TITLE MENU RETURN
SEARCH ADD/CLEAR PROGRAM
CHANNEL
ENTER
ANGLE AUDIO SUBTITLE
INPUT
OMPDDVR100.book Page 2 Monday, September 19, 2005 8:35 AM

Unpacking Your New DVD Recorder
3
5. Install the included AAA batteries in the remote.
6. Place the recorder in its intended position and
connect the power cable to a wall socket.
FR
C
SR
FL
SW
SL
Video
S Video
Y/G
Pr/R
Pb/B
Coaxial Optical
NT SC
!
AUDIO OUT VIDEO OUT DIGITAL AUDIO OUT
OMPDDVR100.book Page 3 Monday, September 19, 2005 8:35 AM

4
Connecting the Recorder to Other Devices
There are numerous connections on the rear of the recorder that may be used to connect to
other devices for video and audio playback and recording.
Connecting to a Display Using Component Video
Component video offers higher quality than all other video outputs on the recorder. In addition,
you can configure the component video output to transmit progressive scan video, which offers
crisp, flicker-free video.
The Y, Pb, and Pr outputs in the VIDEO OUT block on the rear of the recorder are the recorder’s
component video outputs.
To connect to a display using component video:
1. Using three RCA cables, connect the
Y, Pb, and Pr outputs in the VIDEO
OUT block on the rear of the
recorder to the corresponding
component video inputs on the
display.
2. If you would also like to connect the
audio output to the display, connect
the FR (right) and FL (left) outputs
in the AUDIO OUT block on the rear
of the recorder to the display’s
audio input.
3. If you have connected the audio
output to the display, go to the
Setup menu, select the Playback
sub-menu and set Analog Audio
Output to 2 CH (see “Playback” on
page 36).
4. In the Setup menu, select the
General sub-menu and set Video
Output Format as appropriate for
your display (see “General” on
page 35).
5. Also in the General sub-menu, set
Progressive/Interlace as desired.
Note: Progressive scan only works
with component video con-
nections to displays that sup-
port it. Check to ensure your
display supports progressive
scan before configuring the
recorder to use it.
FR
C
SR
FL
SW
SL
Video
S-Video
Y/G
Pr/R
Pb/B
Coaxial Optical
S-Video Video R --- Audio --- L
IN
1
IN
2
RF IN
RF OUT
UHF/VHF
SOURCE INPUT AUDIO OUT VIDEO OUT DIGITAL AUDIO OUT
Y
Pr
Pb
L
AUDIO
(OPTIONAL)
VIDEO
R
OMPDDVR100.book Page 4 Monday, September 19, 2005 8:35 AM

Connecting the Recorder to Other Devices
5
Connecting to a Display Using S-Video
S-Video offers higher quality than composite video, but lower quality than component video.
The S-Video output is located in the VIDEO OUT block on the rear of the recorder.
To connect to a display using S-Video:
1. Using an S-Video cable (not
included), connect the S-Video
output in the VIDEO OUT block on
the rear of the recorder to the
display’s S-Video input.
2. If you would also like to connect the
audio output to the display, connect
the FR (right) and FL (left) outputs
in the AUDIO OUT block on the rear
of the recorder to the display’s
audio input.
3. If you have connected the audio
output to the display, go to the
Setup menu, select the Playback
sub-menu and set Analog Audio
Output to 2 CH (see “Playback” on
page 36).
4. In the Setup menu, select the
General sub-menu and set Video
Output Format as appropriate for
your display (see “General” on
page 35).
5. Also in the General sub-menu, set
Progressive/Interlace to Interlace.
FR
C
SR
FL
SW
SL
Video
S-Video
Y/G
Pr/R
Pb/B
Coaxial Optical
S-Video Video R --- Audio --- L
IN
1
IN
2
RF IN
RF OUT
UHF/VHF
SOURCE INPUT AUDIO OUT VIDEO OUT DIGITAL AUDIO OUT
L
AUDIO
(OPTIONAL)
VIDEO
R
OMPDDVR100.book Page 5 Monday, September 19, 2005 8:35 AM

Connecting the Recorder to Other Devices
6
Connecting to a Display Using Composite Video
Composite video is the most common video connection, but offers lower quality than either
S-Video or component video. The yellow Video output in the VIDEO OUT block on the rear of the
recorder is the recorder’s composite video output.
To connect to a display using composite video:
1. Using an RCA cable, connect the
Video output in the VIDEO OUT
block on the rear of the recorder to
the display’s composite video
input.
2. If you would also like to connect the
audio output to the display, connect
the FR (right) and FL (left) outputs
in the AUDIO OUT block on the rear
of the recorder to the display’s
audio input.
3. If you have connected the audio
output to the display, go to the
Setup menu, select the Playback
sub-menu and set Analog Audio
Output to 2 CH (see “Playback” on
page 36).
4. In the Setup menu, select the
General sub-menu and set Video
Output Format as appropriate for
your display (see “General” on
page 35).
5. Also in the General sub-menu, set
Progressive/Interlace to Interlace.
FR
C
SR
FL
SW
SL
Video
S-Video
Y/G
Pr/R
Pb/B
Coaxial Optical
S-Video Video R --- Audio --- L
IN
1
IN
2
RF IN
RF OUT
UHF/VHF
SOURCE INPUT AUDIO OUT VIDEO OUT DIGITAL AUDIO OUT
L
AUDIO
(OPTIONAL)
VIDEO
R
OMPDDVR100.book Page 6 Monday, September 19, 2005 8:35 AM

Connecting the Recorder to Other Devices
7
Connecting to a Television Signal Source
The RF IN jack on the rear of the recorder is the recorder’s television signal input. When a signal
is connected to RF IN, you can record it to DVD.
The RF OUT jack allows you to connect to another device the same television signal connected to
RF IN.
To connect a television signal to the
recorder:
1. Using a coaxial cable (not included),
connect the signal source to the RF IN
jack on the rear of the recorder.
2. If you would like to connect the same
signal source to another device as well,
use another coaxial cable to connect the
RF OUT jack to the other device.
3. In the Setup menu, select the Channel
Scan sub-menu and set Tuner Input
Source as appropriate (see “Channel
Scan” on page 39).
Connecting to a 5.1 Channel Audio System
The AUDIO OUT block on the rear of the recorder contains the recorder’s 5.1 channel surround
sound outputs.
To connect to an audio system using
5.1 channel surround sound:
1. Using six RCA cables, connect each of
the outputs in the AUDIO OUT block on
the rear of the recorder—FR (front
right), FL (front left), C (center), SW
(subwoofer), SR (surround right), and SL
(surround left)—to the corresponding
audio system inputs.
2. In the Setup menu, select the Playback
sub-menu and set Analog Audio Output
to 5.1 CH (see “Playback” on page 36).
3. Also in the Playback sub-menu, select Speaker Setting and select the desired 5.1 channel
output settings (see “Speaker Setting” on page 37).
TV SIGNAL
S-Video
IN
1
IN
2
RF IN
RF OUT
UHF/VHF
S
O
(OPTIONAL)
TV IN
FR
C
SR
FL
SW
SL
Video
S-Video
Y/G
Pr/R
Pb/B
Coaxial Optical
S-Video Video R --- Audio --- L
IN
1
IN
2
RF IN
RF OUT
UHF/VHF
SOURCE INPUT AUDIO OUT VIDEO OUT DIGITAL AUDIO OUT
SR
C
FR
SL
SW
FL
AUDIO SYSTEM
5.1 CHANNEL
AUDIO INPUT
OMPDDVR100.book Page 7 Monday, September 19, 2005 8:35 AM

Connecting the Recorder to Other Devices
8
Connecting to a Stereo Audio System Using an Analog Connection
The FR (right) and FL (left) outputs in the AUDIO OUT block on the rear of the recorder are the
recorder’s analog stereo audio outputs.
To connect to an audio system using
analog stereo sound:
1. Using two RCA cables, connect the FR
(right) and FL (left) outputs in the
AUDIO OUT block on the rear of the
recorder to the audio system’s analog
stereo audio input.
2. In the Setup menu, select the Playback
sub-menu and set Analog Audio Output
to 2 CH (see “Playback” on page 36).
Connecting to a Stereo Audio System Using a Digital Connection
There are two digital audio outputs in the DIGITAL AUDIO OUT block on the rear of the player:
Coaxial and Optical.
To connect to an audio system using
coaxial digital audio:
1. Using a coaxial digital cable (not
included), connect the Coaxial
connector in the DIGITAL AUDIO OUT
block on the rear of the recorder to the
audio system’s coaxial digital audio
input.
2. In the Setup menu, select the Playback
sub-menu and set Digital Audio Output
as appropriate (see “Playback” on
page 36).
To connect to an audio system using
optical digital audio:
1. Remove the plastic lens protectors from
the Optical connector in the DIGITAL
AUDIO OUT block on the rear of the
recorder and from the audio system’s
optical digital audio input.
2. Using a optical digital cable (not
included), connect the Optical
connector on the recorder to the audio
system’s optical input.
3. In the Setup menu, select the Playback
sub-menu and set Digital Audio Output
as appropriate (see “Playback” on page 36).
FR
C
SR
FL
SW
SL
Video
S-Video
Y/G
Pr/R
Pb/B
Coaxial Optical
S-Video Video R --- Audio --- L
IN
1
IN
2
RF IN
RF OUT
UHF/VHF
SOURCE INPUT AUDIO OUT VIDEO OUT DIGITAL AUDIO OUT
L
R
AUDIO SYSTEM
STEREO
AUDIO INPUT
FR
C
SR
FL
SW
SL
Video
S-Video
Y/G
Pr/R
Pb/B
Coaxial Optical
S-Video Video R --- Audio --- L
IN
1
IN
2
RF IN
RF OUT
UHF/VHF
SOURCE INPUT AUDIO OUT VIDEO OUT DIGITAL AUDIO OUT
AUDIO SYSTEM
COAXIAL DIGITAL
AUDIO INPUT
FR
C
SR
FL
SW
SL
Video
S-Video
Y/G
Pr/R
Pb/B
Coaxial Optical
S-Video Video R --- Audio --- L
IN
1
IN
2
RF IN
RF OUT
UHF/VHF
SOURCE INPUT AUDIO OUT VIDEO OUT DIGITAL AUDIO OUT
AUDIO SYSTEM
OPTICAL DIGITAL
AUDIO INPUT
OMPDDVR100.book Page 8 Monday, September 19, 2005 8:35 AM

Connecting the Recorder to Other Devices
9
Connecting Other Audio/Video Sources to the Recorder
There are three audio/video inputs on the recorder, one on the front and two on the rear. Each
has an S-Video input, a composite video input, and a stereo audio input.
In addition, there is a 4-pin IEEE 1394 (i.LINK/FireWire) input on
the front of the recorder.
You can record the video signal from any one of these sources to
DVD.
To connect a digital audio/video (IEEE 1394) source to the
recorder, use an IEEE 1394 cable to connect the device to the
DV IN input on the front of the recorder.
To connect analog audio/video sources to the recorder:
1. Select an audio/video input from the three available on the recorder.
Note: You should use the input on the front of the recorder for non-permanent connections,
such as to a camcorder when transferring its recorded video to DVD.
2. If you would like to use S-Video, which
offers higher quality video than
composite, connect an S-Video cable
(not included) between the video
source and the S-Video input in the
input block selected in step 1 above.
If you would like to use composite
video, connect an RCA cable between
the video source and the Video input in
the input block selected in step 1 above.
3. Using two RCA cables, connect the
audio source to the L (left—white) and
R (right—red) inputs in the input block
selected in step 1 above.
R
E
C
S
O
U
R
C
E
P
L
A
Y
/
P
A
U
S
E
P
R
E
V
N
E
X
T
S
T
O
P
FR
C
SR
FL
SW
SL
Video
S-Video
Y/G
Pr/R
Pb/B
Coaxial Optical
S-Video Video R --- Audio --- L
IN
1
IN
2
RF IN
RF OUT
UHF/VHF SOURCE INPUT AUDIO OUT VIDEO OUT DIGITAL AUDIO OUT
R
L
VIDEO
S-VIDEO
AUDIO
AUDIO/VIDEO SOURCE
OR
OUTPUT
OMPDDVR100.book Page 9 Monday, September 19, 2005 8:35 AM

10
Using the Recorder for the First Time
Before using your new DVD recorder, you will need to set the clock and, if you have connected a
television signal, scan the signal spectrum to disable weak channels.
To set the clock:
1. Turn the recorder on.
2. Press SETUP to enter the Setup menu.
3. Use and to select the Clock sub-menu
and press ENTER.
4. Use and to select Date and press
ENTER.
5. Enter the current date using the keypad.
Alternatively, you can select each digit
individually by pressing and , then
adjust it by pressing and .
6. Press ENTER to set the date.
7. Use and to select Time and press ENTER.
8. Enter the current time using the keypad.
Alternatively, you can select each digit individually by pressing and , then adjust it by
pressing and .
9. Press ENTER to set the time.
To scan the television signal spectrum:
1. Ensure the recorder is on and enter the Setup menu with the SETUP button.
2. Use and to select the Channel Scan
sub-menu and press ENTER.
3. Ensure the Tuner Input Source is set
correctly (see “Channel Scan” on page 39
for a full description of the choices).
Note: If you are connecting directly to a
cable television wall outlet, con-
tact your cable company to find
out which system is in use in your
area. IRC will work with most systems.
4. Use and to select Scan Channels and press ENTER.
The recorder will scan the signal spectrum and display its progress as it does so.
SYSTEM SETUP - CLOCK
Date (mm/dd/yy)
Time (hh:mm:ss)
1 2 / 0 1 / 0 3
1 2 : 0 0 : 0 0
SYSTEM SETUP - CHANNEL SCAN
Tuner input source
Scan channels
Modify channel information
Air
EDIT
SCAN
OMPDDVR100.book Page 10 Monday, September 19, 2005 8:35 AM

11
Operating the Recorder
Turning the Recorder On and Off
Once the recorder is attached to a power outlet, you can turn it on and off by pressing the
button on the front of the recorder or on the remote.
Inserting a Disc
The receptacle for DVDs and CDs is located on the front of the player.
To insert a disc:
1. Press the button on the front of the player or on the remote to open the receptacle.
2. Place the disc on the tray.
3. Press the button again to close the receptacle.
Understanding the LCD Readout
The LCD readout on the front of the recorder displays information about the current disc,
playback, and recording. When the recorder is off, the readout shows the current time.
The following is a brief description of each of the indicators on the LCD readout. Consult the
sections in this manual on disc playback and recording for more detailed information.
Indicator Indication
REPEAT ALL/A-B The recorder is in a repeat mode:
• REPEAT—Repeating a chapter/track/file
• REPEAT ALL—Repeating all chapters/tracks/files on the disc
• REPEAT A-B—Repeating an arbitrary section of the audio/video
MP3/SVCD/DVD The current disc type:
• MP3—MP3 CD
• SVCD—Super Video CD
• VCD—Video CD
• CD—Audio CD or CD-ROM
• DVD—DVD or DVD-R/RW or DVD+R/RW
The current video output format:
•—PAL
•—NTSC
The recorder is playing the current disc.
The current disc is paused.
REPEAT
MP3 P N
DVD
S
ANGLE
D
REC
AM
PROGRAM
RANDOM
PM Su MoTu WeVCD
ALL
PBC L RThFrSa
A- B CHANNEL
OMPDDVR100.book Page 11 Monday, September 19, 2005 8:35 AM

Operating the Recorder
12
Bringing Up the On-Screen Display
The On-Screen Display (OSD) displays and allows you to to change information about the current
disc and playback. To bring up the OSD, press the DISPLAY button on the remote.
Accessing the Setup Menu
The Setup menu allows you to configure the operation of the recorder. You can change video,
audio, television, and language settings, and control access to mature programming. See
“Configuring the Recorder” on page 35 for more information. To access the Setup menu, press
the SETUP button on the remote.
PBC Playback control is on (Video CDs). When playback control is on, the
Video CD’s menu will be available.
CHANNEL The input source is set to Tuner. The two digits immediately below
CHANNEL will indicate the current channel number.
DTS multi-channel sound is enabled.
Dolby Digital multi-channel sound is enabled.
Recording(s) have been scheduled (see “Scheduling Recordings” on
page 17).
The recorder is recording.
ANGLE There are multiple camera angles available for the DVD video currently
playing.
AM/PM When the time is showing on the readout, these indicate AM or PM.
L/R The audio channel used for Audio CD and Video CD playback:
• L/R—stereo sound
• L—left channel mono
• R—right channel mono
PROGRAM The recorder is playing back a programmed sequence.
RANDOM The recorder is playing back chapters/tracks/files in a random sequence.
Su/Mo/Tu/We/Th/Fr/Sa The current day of the week
Indicator Indication
OMPDDVR100.book Page 12 Monday, September 19, 2005 8:35 AM

13
Using the Remote Control
The remote control can be used to control every aspect of the recorder’s operation and includes
more functionality than the controls on the recorder itself.
The following is a list of all buttons on the remote and their functions:
Button Function
Turns the player on and off (standby)
Cycles through the signal sources: Tuner, AV1, AV2, AV3, DV (IEEE 1394) and
the current disc (if a disc is inserted)
Ejects the disc
Cycles through the camera angles available on the disc
Cycles through the audio channels available on the disc
Cycles through the subtitle channels available on the disc
Used to enter numbers and navigate directly to a specified track (CDs),
chapter (DVDs), or photo (photo CDs)
Changes the television channel
Brings up the search display, which you can use to jump to a location on the
current disc
MUTE
ZOOM
P-SCAN REPEAT TIMER
SETUP DISC EDIT EDIT
SLOW REC
A-B MODE
VOLUME
(LEVEL)
REV FWD
NEXTPREV
STOP PAUSE/STEP PLAY
DISPLAY TITLE MENU RETURN
SEARCH ADD/CLEAR PROGRAM
CHANNEL
ENTER
ANGLE AUDIO SUBTITLE
INPUT
OMPDDVR100.book Page 13 Monday, September 19, 2005 8:35 AM

Using the Remote Control
14
Adds a selection to the program playlist or removes a selection from the
playlist
Brings up the Program menu, which allows you to program playback sequence
Used to navigate menus
Confirms the current selection or entry
Brings up the On-Screen Display (OSD), which displays and allows you to
change current playback information
Returns to the Title menu
Returns to the previous menu viewed on the disc
When playing a Video CD, this button turns playback control on and off. When
playback control is on, any menu on the disc will be available.
Returns to the menu
When navigating directories on a data CD, this button navigates up one level.
Stops playback
Pauses playback. When playback is paused, pressing this button steps forward
one frame at a time.
Begins or resumes normal playback
Adjusts the audio volume
Returns to the previous chapter, track, photo, or media file
Skips to the next chapter, track, photo, or media file
Fast reverses the audio/video. Pressing this button cycles through the fast
reverse speeds.
Fast forwards the audio/video. Pressing this button cycles through the fast
forward speeds.
Mutes the audio
Slows down playback. Pressing this button repeatedly cycles through the slow
play speeds.
Begins recording. See “Recording Video Manually” on page 17 for more
information.
Button Function
OMPDDVR100.book Page 14 Monday, September 19, 2005 8:35 AM
