Pyle PLDANDHR1053 User manual

AndroidTouchscreenTablet
EntertainmentDisplay
PLDANDHR1053
Vehicle Headrest Mount Multimedia System with
Bluetooth, Wi-Fi &App Download (10.5’’-inch)

2 3
8
9
7
6
5
4
1
www.PyleUSA.com
2
FRONT PANEL
MULTIMEDIA PLAYER
1. LCD Panel
2. POWER
3. IR WINDOW
4. DC 12V
5. A Earphone jack
6 Reset
7. Power button
8. TF read port
9. USB read port
SIDE PANEL
1. DC 12v Jacket
2. Earphone
3. Reset
4. Micro SD Memory Card Slot
5. USB port

3
www.PyleUSA.com
1. Main Menu
You can choose Video, Music player, picture, Browser, AV in, le, Audio.
You can check all other information from APP
2. The APPs icon shows all installed smart APP. You can use Car launcher to
load and edit all les or other app.

www.PyleUSA.com
4
3. Setting
Connect to Wi-Fi by following image below

5
www.PyleUSA.com
4. Sound Setting from this side
5. File

www.PyleUSA.com
6
6. Bluetooth Setup
7. Video player

7
www.PyleUSA.com
8. Albums
9. USB/SD Card Read

www.PyleUSA.com
8
10. IR /FM Setup
11. FM Setup

9
www.PyleUSA.com
INSTALLATION
1. Take out the machine, remove the bracket.
2. Remove the screws from bracket.
3. Put the plastic bracket parts in between two metal poles ,at the same
time, push 2 screws to x up bracket.
4. Hold up unit, insert the metal plate in black of the unit into plastic bracket
parts, then adjust it to the right angle and x it tightly, at last lower the
orignal car headrest to the appropriate position.

www.PyleUSA.com
10
WIRING
Attention
1. Do not put the machine in the rain or damp environment lest outbreak of
re or any damage to machine.
2. Do not repair the machine by youself. Please turn o the machine and
inform us if any problem found, the factory or the agent will arrange
specialized personnel to disassemble and repair the machine for you .
3. Please keep the machine away from dampness, dust, oil and straight
sunlight.
4. Do not use diluents or other chemical cleaner when cleaning the machine.
Please clean the machine by soft cloth with special cleaner.
5. Please keep the machine in a good environment. The storage temperature
for this machine is from 68 °F to 70T and the operating temperature for
this machine is from -10T to 140 °F.
6. This machine supports 1080P and most video le like DIVX/MPEG4 /
MP3/WMAR/JPEG
7. Please prevent the machine from the inuence of other equipment.
8. For your safty,please do not turn or operate this machine when driving as
it may be ileagal in some countries and regions.
9. Safe power supply: DC12V (voltage range:10V-14V)
10. There may be some small and bright spots on the screen. This is a
common technical matter and does not indicate any quality problem of
this machine.
Audio Out Right (Red)
Audio Output Left (White)
Video Output (Yellow)
VIdeo Input (Yellow)
Audio Input Right (Red)
Audio Input Left (White)
DC + 12V (Red)
GND (Black)

11
www.PyleUSA.com
TROUBLESHOOTING
CLEANING
• Do not leave this product submerged in water
• When cleaning the device, use a clean dry cloth to wipe the device clean.
(Do not use solvents).
• Clean only with a clean and dry cloth.
TROUBLES
No sound
and image
No image
No sound
Color cast
No power
SOLUTIONS
Power is disconnected;
the machine is not turned ON
signal wire is disconnected
Volume too low or the volume setup is not workable
function menu setup is incorrect; weak signal
Voltage is not accurate: check interconnect circuit;
Fuse is disconnected: change fuse specication

www.PyleUSA.com
12
PLDANDHR1053
Android Touchscreen Tablet Entertainment Display
Vehicle Headrest Mount Multimedia System with Bluetooth,
Wi-Fi & App Download (10.5’’ -inch)
Features:
• Universal Vehicle Headrest Mount Display
• Audio & Video Car Entertainment System
• Built-in Android OS Computer
• Touchscreen 'Tablet-Style' Functionality
• Hi-Res LCD Digital Wide-Screen Video
• User-Friendly Control Interface
• Full HD 1080 Support
• Built-in Stereo Speakers
• FM Radio Transmitter
• Front Panel Button Controls
• Connect & Stream External Devices
• USB Flash & Micro SD Memory Card Readers
• Digital File Playback: Audio, Image & Video Files
• Headphone Jack, 3.5mm
• RCA (Audio/Video) Wiring Harness
• Convenient Removable Leather Screen Cover
• Built-in IR Transmitter Support for Wireless IR Headphones
• Easily Attaches to Front-Seat / Back-Seat Headrests
• Includes All Necessary Hardware & Cables for Installation
• *Can be Hard-Wired or Powered via Included Plug-in Cigarette Lighter
Power Cable
Bluetooth Connectivity:
• Built-in Bluetooth for Wireless Music Streaming
• Works with All of Today’s Latest Bluetooth Devices
• Smartphones, Tablets, Laptops, etc.
• Simple & Hassle-Free Pairing
• Bluetooth Version: 4.0

13
www.PyleUSA.com
Android Interface:
• Built-in Android Computer Operating System
• Multi-Touch Capacitive Display Screen
• Wi-Fi Wireless Streaming Connectivity
• Access to the Google Play Store
• Download Apps, Surf the Web, Play Games
• Wireless Smartphone Mirror Link Support
• 8 GB Built-in Flash Memory
• Processor: Quad Core 1.6 GHz Cortex A7
• Works with Android & Apple Phones
What’s in the Box:
• Android Touchscreen Display
• Headrest Mounting Bracket
• Power Wiring Harness Cable
• Cigarette Lighter Power Cable
Technical Specications:
• Display Type: LCD, 10.5’’ -inches
• Video System: PAL / NTSC Compatible Auto Switching
• Aspect Ratio: 16:9
• Screen Resolution: 1024 x 600 Pixels
• Contrast Ratio: 300:1
• Brightness: 350 cd/m2
• English OSD Menu
• Maximum USB/SD Card Size: 32GB
• Digital File Compatibility: MP3, MP4, MP5, JPG, MPEG4, WMA, AVI
• Power Supply: DC 12V
• Dimensions (L x W x H): 10.2'' x 6.7'' x 1.2’’ -inches
• Sold as: 1
