Pyramid Ac receiver User manual

Please read this manual before installing your receiver
Pyramid AC Receiver
Installation Manual

Page 2
Pyramid AC Receiver Installation Manual
IMPORTANT
The first few pages of these instructions contain important information on safety and product
conformity. Please read, and ensure that you understand this information before continuing.

Page 3
Installation Manual Pyramid AC Receiver
CONTENTS
Product Safety ........................................................................................................................................................................................... 4
Electromagnetic Compatibility (EMC) .................................................................................................................................................. 4
Manufacturer s Declaration of Conformance .................................................................................................................................... 4
Unpacking ................................................................................................................................................................................................... 4
Barcoding ................................................................................................................................................................................................... 4
The AC Receiver .......................................................................................................................................................................................... 5
PCB Layout ................................................................................................................................................................................................... 6
PCB Power Connections .............................................................................................................................................................................. 7
Connecting the Preset Fee back Potentiometers ........................................................................................................................................ 7
Connecting the Lens Drive Outputs ............................................................................................................................................................. 8
Connecting the Pan/Tilt Hea an Auxiliaries .............................................................................................................................................. 8
Connecting the Pan/Tilt Hea an Auxiliaries Power Source ...................................................................................................................... 9
Anti-Tamper Connections ............................................................................................................................................................................. 9
Vi eo Connections ....................................................................................................................................................................................... 9
Fitting Network Car s ................................................................................................................................................................................. 10
PY-FTT, PY-485 an PY-422 Network Car s ............................................................................................................................................ 11
PY-COM Network Car s ............................................................................................................................................................................ 12
Fibre-Optic Network Car s ........................................................................................................................................................................ 12
Power Supply Connections ....................................................................................................................................................................... 13
A ressing a Receiver with the Pyrami 2 Keyboar .............................................................................................................................. 14
A ressing a Receiver with the Mk1 Keyboar ....................................................................................................................................... 15
Setting Receiver Configuration with the Pyrami 2 Keyboar .................................................................................................................. 16
Setting Receiver Configuration with the Mk1 Keyboar ........................................................................................................................... 17
Receiver Programming ............................................................................................................................................................................... 17
Testing ........................................................................................................................................................................................................ 18
Replacing the Li ........................................................................................................................................................................................ 18
Changing the Fuse ..................................................................................................................................................................................... 18
Specifications ............................................................................................................................................................................................. 19

Page 4
Pyramid AC Receiver Installation Manual
PRODUCT SAFETY
WARNING
 Please follow these instructions as you install the equipment and keep them for future use.
 Installation is only to be carried out by competent qualified and experienced personnel in accordance with the
country of installations National Wiring Regulations. Failure to do so can result in injury or death by electric shock.
 Use a class 2 isolated power supply for the 12V DC.
 The module is susceptible to damage from Electrostatic Discharge (ESD). Take normal ESD precautions when
handling your network card. ESD prevention kits are available from most electronics distributors.
 Do not exceed the voltage and temperature limits given in the specification.
 Switch off the power before fitting a network card.
 If you have any problems contact Baxall Limited.
ELECTROMAGNETIC COMPATIBILITY (EMC)
CAUTION
 This is a Class A product. In a domestic environment this product may cause radio interference in which case the
user may be required to take adequate measures.
 This product is intended for use in general purpose CCTV applications in a residential commercial or light
industrial EMC environment. Refer to Baxall Limited before using the product in medical and/or intrinsically safe
applications or in an industrial EMC environment.
 If you are using the PCB version of this product in a way other than correctly installed in the Pyramid system
weatherproof boxes then it is your responsibility to meet EMC requirements.
 The product must be installed in accordance with good installation practice for EMC to enable the product to
function as intended and to prevent EMC problems.
 Contact Baxall Technical Support to obtain a specification defining the acceptable levels of product degradation
with regard to EMC immunity.
MANUFACTURER S DECLARATION OF CONFORMANCE
CAUTION
The declaration of conformance applies only to the boxed version and PCBs which are correctly installed in our
Pyramid system weatherproof box.
The manufacturer declares that the equipment supplied with this manual is compliant with the essential protection
requirements of the EMC directive 89/336 and the Low Volta e Directive LVD 73/23 EEC. Conformin to the requirements
of standards EN55022 for emissions, IEC801 parts 2, 3 and 4 for immunity and BS415 superseded by EN60950 for
Electrical Equipment safety.
UNPACKING
Keep your packa in for use if your AC receiver is stored for an extended period or needs to be returned for any reason.
The packa in should contain:-
 An AC Receiver
 An A4 Module Description Sheet (for installation details)
 These instructions
 Two identical barcodes
Check the product code on the serial number label. If you have an incorrect item or it is dama ed then inform the
suppliers and carriers immediately. If this is the case, do not attempt to use the equipment.
BARCODING
The AC receiver is supplied with two identical barcodes. Remove one and affix it to the module description sheet, remove
the other and affix it to the module.
The barcode ives the unique 48-bit neuron ID to the module. This neuron ID is also stored inside the module and will
be transmitted onto the network whenever the PCB service pin is pressed. Before installation, make a careful note on
your module description sheet of all your installation details and the proposed location of the module. Then durin
subsequent installation usin the Windows installation tool the neuron ID can be entered.
We recommend that durin a system installation you store the module description sheets in a rin -bound file, and keep
them for reference after the installation is complete.

Page 5
Installation Manual Pyramid AC Receiver
THE AC RECEIVER
The Pyramid AC Receiver is a fixed speed pan and tilt control receiver that can be connected to any camera within the
Pyramid system that has an AC Pan/Tilt head. The receiver is easy to install, and a service pin and test button are included
to aid the installation process. Once it has been fitted, the receiver will drive the pan, tilt, zoom and focus functions of a
Pan/Tilt head, and it can also drive auxiliary equipment (wipers, li hts etc.) throu h the four auxiliary relays on the receiver
PCB.
The AC receiver can be pro rammed remotely with privacy zones, limit stops, random patrols, and up to 128 presets. It
also contains a video amplifier, with ain and hi h-frequency lift. This can improve video transmission over lon er cable
runs.
MAIN PCB
FILTER
BOARD
EXTERNAL
TERMINAL
BLOCK
FACTORY
FITTED
12V DC PSU
(
UNDER PCB)
METAL
BASEPLATE
WEATHERPROOF
BOX
Figure 1 - AC Receiver Layout (Weatherproof Box Variants)
There are six variants of the AC receiver, which can be split into two roupsthe three variants that are supplied in a
weatherproof box (PY-ACW-) and the three variants that are supplied as a PCB only (PY-ACB-). In each of these two
roups, the difference between the three variants is based on the network speed and the type of network card fitted.
The -L variants (PY-ACW-L and PY-ACB-L) run on a low speed (9.8k b.p.s.) RS485 network while the -HR variants (PY-
ACW-HR and PY-ACB-HR) run on a hi h speed (78k b.p.s.) RS485 network. Both the -L and -HR variants are fitted with
a PY-COM network carda combined personality network card which can be confi ured by means of dip switches for use
in RS485 or RS422 networks. By default, the switches are set so that the card operates in RS485 protocol, but the card
protocol can be easily chan ed usin the switch settin s. For more details on the PY-COM network card, see pa e 12.
The -H variants (PY-ACW-H and PY-ACB-H) are fitted with a PY-FTT network card and run on a hi h speed (78k b.p.s.)
FTT10 network. For more details on the PY-FTT network card, see pa e 11.

Page 6
Pyramid AC Receiver Installation Manual
PCB LAYOUT
Shown below are the locations of the connectors, switches and LEDs on the AC receiver PCB.
CON4
CON1
CON6
CON3
CON2 TEST
BUTTON
10A
FUSE
SERVICE
PIN
SERVICE
PIN LED
LED1
ANTI-TAMPER
SWITCH
VIDEO
IN
VIDEO
OUT
CON5
LIVE
N
EUTRAL
IRIS -
FOCUS
-
5V + TILT FB PAN FB FOCUS F
B
ZOOM FB GND
ZOOM -
IRIS +
FOCUS
+
ZOOM +
3
1
8
7
6
5
4
3
2
1
DOWN
UP
LEFT
RIGHT
AUX 1
AUX 2
AUX 3
AUX 4
-
+
Figure 2 - AC Receiver PCB

Page 7
Installation Manual Pyramid AC Receiver
PCB POWER CONNECTIONS
CON1 is used for PCB power connection. This power controls the switchin of the relays, the video ain and lift and the
lens functions. The AC power for the Pan/Tilt head and auxiliaries is connected separately to CON5.
The PCB requires a +12V DC, 1A class 2 power supply. The necessary connections have already been made on the
boxed variants, includin a roundin wire which is connected from the ne ative terminal of CON1 to the external terminal
block (Fi ure 3). On PCB versions, connect the 12V DC as shown in Fi ure 3.
G
R
O
U
N
D
I
N
G
W
I
R
E
NEUTRAL
LIVE
G
R
O
U
N
D
I
N
G
W
I
R
E
+
-
+
-
+
FUSED
SIDE NON-
FUSED
SIDE
-
Figure 3 - PCB Power Connections
CONNECTING THE PRESET FEEDBACK POTENTIOMETERS
If you are usin a preset Pan/Tilt head and lens, then CON2 provides the supplies and feedback connections for the
potentiometer wiper circuits. The direction of the feedback is automatically calculated when the test routine is invoked
(see Testing on pa e 18), this means it is not necessary to wire the pots in a specific direction.
Referrin to Fi ure 4, connect CON2 to the preset pots on the Pan/Tilt head and the lens. Connect any unused feedback
inputs to round. Make a note on your module description sheet of the preset connections and the type of lens.
CON2
TEST
BUTTON
10A
FUSE
5
V
+
T
I
L
T
F
B
P
A
N
F
B
F
O
C
U
S
F
B
Z
O
O
M
F
B
G
N
D
Figure 4 - CON2 Connections
CAUTION
The maximum power that can be drawn from the +5V supply on CON2 is 30mA. DO NOT use this supply for any
purpose other than for supplying feedback pots.

Page 8
Pyramid AC Receiver Installation Manual
CONNECTING THE LENS DRIVE OUTPUTS
CON3 provides the lens drive outputs for focus, iris and zoom. The drive volta e is +10V DC at up to 100 mA. Refer to your
lens instructions and connect up the lens accordin to Fi ure 5.
CON6
CON3
ANTI-TAMPER
SWITCH
IRIS -
FOCUS
-
ZOOM -
IRIS +
FOCUS
+
ZOOM +
Figure 5 - CON3 Connections
CONNECTING THE PAN/TILT HEAD AND AUXILIARIES
CON4 contains the power output connections for the Pan/Tilt head and auxiliaries (AUX 1, AUX 2, AUX 3 and AUX 4).
Referrin to Fi ure 6, connect LEFT, RIGHT, UP and DOWN to the Pan/Tilt head and AUX 1 to wash, AUX 2 to wipe, AUX
3 to lamps and AUX 4 to camera power. Do not connect any unused auxiliaries. Connect all the return (neutral) wires to
the spare terminals on the external terminal block. Make a note on your module description sheet of your auxiliary
connections.
CAUTION
Maximum current is 1A per relay. Connect lamps using a separate relay as they can draw a surge current when they
fail. This may cause damage to the AC receiver.
CON4
CON
5
8
7
6
5
4
3
2
1
D
OWN
UP
LEFT
R
IGHT
AUX 1
AUX 2
AUX 3
AUX 4
Figure 6 - CON4 Connections

Page 9
Installation Manual Pyramid AC Receiver
CONNECTING THE PAN/TILT HEAD AND AUXILIARIES POWER SOURCE
CON5 accepts the AC power input which is then switched to CON4. It powers the Pan/Tilt head and auxiliaries. CON5 can
be connected to either a 24V AC or Mains power supply.
For Mains Connections
Referrin to Fi ure 7, connect CON5 to the LIVE and NEUTRAL connections on the external terminal block. The connections
should be made to the non-fused side of the terminal block. The centre connection on CON5 is not connected.
FUSED
SIDE NON-
FUSED
SIDE
LIVE
NEUTRAL
LIVE
NEUTRAL
Figure 7 - Connecting CON5 to a Mains Power Supply
For 24V AC Connections
Connect the 24V AC power supply to the LIVE and NEUTRAL terminals on CON5 (see Fi ure 7 above). The centre
terminal on CON5 is Not Connected (NC).
WARNING
Never use both 24V AC and Mains on the same receiver PCB.
ANTI-TAMPER CONNECTIONS
CON6 is used as an input for an external anti-tamper switch. It is connected in parallel with the built in anti-tamper switch
that is marked in Fi ure 2.
On the boxed variants, the built in anti-tamper switch is connected in a normally open (N/O) confi uration. However, it is
fitted with a sprin which is compressed when the module lid is closed, and thus closin the contact. When the lid is
removed, the input is opened and the alarm will be activated.
If the built in anti-tamper switch is not used, CON6 can be connected to an external anti-tamper switch. To do this, the
sprin must be removed from the built in anti-tamper switch. CON6 should then be connected to the external anti-tamper
switch in a normally closed (N/C) confi uration.
VIDEO CONNECTIONS
All video must be connected to the receiver PCB via 75 ohm BNC connectors and video coaxial cable. Referrin to Fi ure
2, connect the video from your camera to VIDEO IN and connect VIDEO OUT to the matrix.
Your AC receiver has an on-board video amplifier with ain and lift. Adjustment of ain and lift is done remotely, usin a
Pyramid keyboard. For more details on adjustin ain and lift levels, consult the Pyramid 2 Keyboard Operating Manual.

Page 10
Pyramid AC Receiver Installation Manual
FITTING NETWORK CARDS
To connect the AC receiver to the network, it is first necessary to ensure that the correct Pyramid network card is fitted to
the PCB. The cards that can be used are as follows:
PY-COM Combined network card. Can be confi ured for use in RS485 and RS422 networks. Automatic
baud-rate selection between low and hi h speeds (9.8k b.p.s. or 78k b.p.s.).
PY-FTT Compatible with FTT10 (Flexible Topolo y) 2-wire bus-connected, half duplex. Hi h speed only.
PY-422 Compatible with RS422, 4-wire point-to-point, full duplex. Available in low and hi h speed variants.
PY-485 Compatible with RS485, 2-wire bus-connected, half duplex. Available in low and hi h speed variants.
PY-FI7 and PY-FI9 Compatible with dual, multi-mode fibre optic point-to-point connections. PY-FI7 operates at 78k
b.p.s., PY-FI9 operates at 9.8k b.p.s.
If the correct network card is not already fitted, chan e it usin Fi ure 8 as a uide.
CAUTION
To avoid damaging the module switch off the power before fitting the network card.
Figure 8 - Fitting a Network Card
Once a network card has been fitted, it must be connected to the network. The way in which this is done depends on the
type of network card in use. See the followin sections for more details.

Page 11
Installation Manual Pyramid AC Receiver
PY-FTT, PY-485 AND PY-422 NETWORK CARDS
To connect PY-485, PY-FTT and PY-422 network cards to the network, it is necessary to make two connections. Firstly, the
network card is connected to the filter board usin the four-core screen cable provided. Secondly, the filter board is
connected to the network.
Use Fi ure 9 below to connect PY-485 or PY-FTT network cards to the network.
RED
BLACK
SCREEN
FILTER BOARD
PY-485 and PY-FTT
SCREEN
PAIR
1
SCREEN
PAIR 2
Figure 9 - PY-485 and PY-FTT Connections
Use Fi ure 10 to connect PY-422 network cards to the network.
WHITE
GREEN
RED
BLACK
SCREEN
FILTER BOARD
PY-422
SCREEN
INPUT
OUTPUT
+
+
-
-
Figure 10 - PY-422 Connections

Page 12
Pyramid AC Receiver Installation Manual
PY-COM NETWORK CARDS
If a PY-COM network card is fitted to the AC receiver, it can be confi ured by means of dip switches for use in both RS485
and RS422 networks. The dip switches for the different network types are shown below:
RS485 Mode
RS485 networks are 2-wire, bus-connected (also referred to as daisy-chain). In RS485 mode, the dip-switches on the
PY-COM will be set differently dependin on where the unit is placed on the network. If the unit is the first or last in the
network, one network card in the unit will need to be set to provide biasin and termination as required. If the unit is central
to the network, all network cards will be set for use in a intermediate module.
Set the switches as required and wire the card to the network as shown in Fi ure 11. It is not necessary to make any
connections to the filter board.
ON
87654321
ON
87654321
ON
87654321
First Module
Intermediate Module
Last Module
White represen
ts
switch position
Not usedNetwork Not usedNetwork Not used
Network
Figure 11 - RS485 Switch Settings
RS422 Mode
RS422 networks use a 4-wire, point-to-point connection methodolo y. Set the switches as required and wire the card to
the network as shown in Fi ure 12. It is not necessary to make any connections to the filter board.
876543
Input
ON
21
Output
White represen
ts
switch position
Figure 12 - RS422 Switch Settings
FIBRE-OPTIC NETWORK CARDS
If a PY-FI7 or PY-FI9 network card is bein used, there is no need to make any connections throu h the filter board, as
these network cards are connected to the network directly. For details on to do this, see the installation uide that is
provided with the network card.

Page 13
Installation Manual Pyramid AC Receiver
POWER SUPPLY CONNECTIONS
The boxed variants of the AC receiver include a terminal block mounted on the metal base plate. This external terminal
block is used to earth the metal base plate and to connect the factory fitted 12V DC PSU to the mains power supply.
NEUTRAL
EARTH
LIVE
NEUTRAL
LIVE
GROUND
FUSED
SIDE
NON-FUSED
SIDE
Figure 13 - External Terminal Block
WARNING
 Ensure that the power is switched off before connecting the mains wires.
 The module must be earthed.
 Do not connect additional mains devices to the fused side of the external terminal block.
Connect the Live, Earth and Neutral wires from the mains to Live, Earth and Neutral on the non-fused side of the external
terminal block. Switch on the mains power and any other power supplies that are bein usedthe module now contains
live voltages.
When the power is switched on, LED1 li hts to indicate the polarity of the 12V DC. If the polarity is correct it will li ht reen,
and if it is incorrect, it will li ht red.

Page 14
Pyramid AC Receiver Installation Manual
ADDRESSING A RECEIVER WITH THE PYRAMID 2 KEYBOARD
Each receiver that is connected to the Pyramid system must have a unique address called a network address, and an
operator with installer privile es can do this usin the Pyramid 2 Keyboard.
Confi uration of the receiver requires the service button to be pressed on the receiver PCB, and this may be a two man
operation if the receiver is located remotely from the keyboard. For this reason, it is easier to address a receiver before it
is added to the network, and this can be done usin a special mode of the Pyramid keyboard called Self-Bind (also known
as Fn 100). Self-bindin mode is commonly used when confi urin telemetry receivers, or when cameras need to be
controlled in a system without a CCTV matrix.
Durin the self-bindin process, the installer can setup the network address, which includes the node IDthe number
that is entered to indicate which device is to be controlled (e. ., Camera receiver number 4). Once the network address
has been confi ured, the receiver can be attached to the network and controlled throu h the Pyramid matrix.
To address a receiver in self-bindin mode, follow the steps below:
1. Connect up a Pyramid 2 Keyboard to the telemetry receiver. This can either be connected directly to the receive
communications card at the receiver site, or remotely throu h the Pyramid network in the normal way.
2. Lo onto the Pyramid 2 Keyboard usin the installer password. The Installer Logon screen is displayed.
3. Press the Function 100 soft-key. The Direct Access screen is displayed.
4. Press the Receiver soft-key.
5. Press the Rx Utilities screen key.
6. Press the Unit Address Type soft-key.
The Addressing screen is displayed.
7. Press the Receiver Address soft-key. The keyboard LCD displays a messa e askin the operator to press the
service pin.
Operator Rx Utilities
12...12...
Operator Rx Utilities
12...12...12...12...
3
5
6
7
3
Figure 14 - Addressing a Receiver
8. So that the keyboard can identify the receiver, press its service pin. On the AC receiver, the service pin is located on the
PCB as two pins to be shorted (see Fi ure 2).
When the service pin is pressed, the receivers neuron ID is transmitted to all other devices on the Pyramid network.
The neuron ID is a unique identifier which is used to establish communication between the receiver and all other
devices. Once the receiver has been identified by the network, it can be assi ned a node ID.
9. The keyboard LCD displays a messa e askin the operator to enter the new node ID. The node ID is the visible part
of a network address, as it is the number that an operator enters on a keyboard to indicate the device that is to be
controlled (e. ., Camera receiver number 3).
Use the number keys to enter the node ID.
10. Press the Receiver Address soft-key a ain to confirm the node ID.
The keyboard LCD displays a messa e confirmin the address.

Page 15
Installation Manual Pyramid AC Receiver
ADDRESSING A RECEIVER WITH THE MK1 KEYBOARD
A receiver can also be addressed usin the Pyramid Mk1 Keyboard. Follow the steps below:
1. Connect up a Pyramid Mk 1 Keyboard to the telemetry receiver. This can either be connected directly to the receive
communications card at the receiver site, or remotely throu h the Pyramid network in the normal way.
2. Usin the keyboard, insert the Installers Card and lo on with the PIN number 1892.
3. Press the key sequence 100 and then the Function key.
The left hand side of the keyboard display will show Fn 0100 to indicate that self bindin mode has been invoked.
4. Repeatedly press the List Down key, until the LCD display shows the option Replace RX.
5. Once this option is displayed, select soft key number 1 marked Yes.
At this point, the keyboard is now waitin for the receiver to identify itself usin the service PIN.
6. Momentarily short out the service PIN jumper on the receiver PCB (see fi ure 2).
The receiver neuron ID is transmitted onto the network, and the keyboard display will show the text Receiver Identified.
7. Type in the node ID you require this receiver to be confi ured to, and then press the Camera Select key.
After a short delay, the keyboard will then display the messa e Subnet Node Calculated.
8. After 10 seconds, the keyboard will then lo itself out automatically.
9. Repeat steps 1-3 to lo back on to the keyboard and o into self-bind mode.
10. Select a camera in the normal way by typin in the node ID and then pressin the Camera Select key.
11. Move the joystick. The PTZ will move, and the standard receiver screen will be displayed on the keyboard.
Troubleshooting
QI pressed the service PIN on the receiver, but the keyboard did not show the Receiver Identified messa e.
ANo data is comin throu h, check out the data cablin between the receiver and the keyboard.
QI ot to sta e 7, but the Subnet Node Calculated messa e remained on the keyboard screen and the keyboard did not
lo off.
AData is only bein transmitted in one direction. Check to see if the data cable has been connected to the correct side
of the communications card, or that one side of the twisted pair has become disconnected.
Note
The AC receiver can also be addressed and installed usin the Pyramid Installation Tool. See the Pyramid Installation
Tool Operating Manual for more details.

Page 16
Pyramid AC Receiver Installation Manual
SETTING RECEIVER CONFIGURATION WITH THE PYRAMID 2 KEYBOARD
After a receiver has been addressed, the Pyramid 2 Keyboard can be used to specify the confi uration of the receiver
remotely via the Pyramid network.
To set the confi uration of a receiver, follow the steps below:
1. Enter the keyboard menu system. See the Pyramid 2 Keyboard Operating Manual for more details.
2. Select a monitor by enterin a number and pressin the Monitor key.
3. Enter the number of the receiver that is to be confi ured and press the Camera key.
4. Press the Utility Menu screen key.
5. Press the Receiver Utilities soft-key.
6. Press the Rx Config soft-key. The Receiver Configuration screen is displayed.
7. Some Pan/Tilt units are capable of continuous rotation (360O). A small ap can exist in the feedback potentiometer,
and this ap is known as the dead band. If a continuous rotation Pan/Tilt head is bein used, press the Non-Cont soft-
key, so that the receiver is confi ured for a continuous rotation Pan/Tilt unit. The text on the soft-key chan es to Cont.
The default settin is to leave the soft-key displayin the text Non-Cont (i.e., non-continuous Pan/Tilt head operation).
8. Receivers are supplied with feedback potentiometers enabled. If there are no feedback inputs to the receiver, the
manual operation of the Pan/Tilt unit will be affected (e. ., the pan and tilt controls will only operate in one direction),
since the feedback inputs are used as a constant check for end stops. If this is the case, disable the feedback
potentiometers to correct the problem and enable manual operation. To do this, press the F/B soft-key, so that the text
chan es to No F/B.
The default settin is to leave the soft-key displayin the text F/B (i.e., feedback potentiometers enabled).
9. In some cases, zoom lenses have three wire control of zoom and focus functions (i.e., Ground, Zoom +/-, Focus +/-)
rather than the usual four wire control. If this is the case, the receiver needs to be confi ured for the use of a 3-wire
lens, so that it carries out the zoom operation first followed by the focus operation on preset recall. To do this, press
the 3 Wire Lens soft-key.
The default settin is to leave the 3 Wire Lens soft-key off (i.e., in four wire control).
VCR / MUX
Operator Utility Menu
7
8
9
1
0
11
Figure 15 - Receiver Configuration
10. Press the Enter soft-key to confirm the selection and to send the information to the receiver.
11. Press the Utility Menu screen key to leave the Receiver Configuration screen.
CAUTION
If the Pan/Tilt head connected to the receiver is not fitted with potentiometers the F/B function must be disabled at
step 8. If this is not done the pan and tilt operations will only work in one direction. If a Pan/Tilt head is fitted with
potentiometers ensure that mechanical limit stops are set and then press the test button on the receiver PCB. This
will ensure that the potentiometer directions are learnt correctly.

Page 17
Installation Manual Pyramid AC Receiver
SETTING RECEIVER CONFIGURATION WITH THE MK1 KEYBOARD
The Pyramid Mk1 Keyboard can also be used to specify the receiver confi uration. Follow the steps below:
1. Lo on usin an installers card (Use Fn 100 if the receiver is not connected to a matrix).
2. Select a valid monitor, and then enter the number of the receiver that is to be confi ured.
3. Press the List Up key twice to select Chan e Rx Confi .
4. Select the Yes soft key.
5. The LCD displays the messa e Rx has feedback pots. Press the Yes or No soft key to indicate whether the receiver
is connected to feedback potentiometers.
6. To determine whether the receiver is connected to a continuous rotation head, the LCD displays the messa e Rx is
cont rotate head. Press the Yes or No soft key.
7. The LCD displays the messa e Rx has 3 wire lens Press the Yes or No soft key to indicate whether the receiver is
usin a 3-wire lens.
The receiver has now been confi ured, and the keyboard will return to the initial display.
CAUTION
If the Pan/Tilt head connected to the receiver is not fitted with potentiometers the feedback pots function must be
disabled at step 5. If this is not done the pan and tilt operations will only work in one direction. If a Pan/Tilt head is
fitted with potentiometers ensure that mechanical limit stops are set and then press the test button on the receiver
PCB. This will ensure that the potentiometer directions are learnt correctly.
RECEIVER PROGRAMMING
The Pyramid 2 Keyboard can also be used to carry out more advanced receiver pro rammin (e. ., presets, privacy
zones, limit stops, random patrols). For more details on how to do this, see the Pyramid 2 Keyboard Operating Manual.
A copy of the manual is supplied with the Pyramid 2 Keyboard, and can also obtained from the Baxall website at
www.baxall.com, or from Baxall Technical Support.
Basic receiver pro rammin can also be achieved usin the Mk1 Keyboard. Instructions on how to do this can be
obtained from Baxall.

Page 18
Pyramid AC Receiver Installation Manual
TESTING
Once the receiver has been addressed and confi ured, an on board test procedure can be activated which steps throu h
outputs in the sequence shown in the table below. The test procedure also allows the receiver to detect the feedback
polarity for the Pan/Tilt head and lens.
The test procedure runs when the test button is pressed with an appropriate tool (Fi ure 2). The test takes 57 seconds.
WARNING
 The AC receiver PCB now contains live voltages.
 Before running the test procedure fit the Pan/Tilt head in its intended position and ensure that it cannot collide
with anything or stretch any cables. Electrical and mechanical limit stops should be set to prevent such events.
Electrical limit stops can be set using the Pyramid 2 Keyboardconsult the Pyramid 2 Keyboard Operating
Manual for more details.
Step Action Time Step Action Time
1 Ri ht and Down 5s 13 Pause 2s
2 Pause 2s 14 Zoom Out 3s
3 Pan Left 3s 15 Zoom In 3s
4 Pause 1s 16 Pause 2s
5 Pan Ri ht 3s 17 Iris Close 3s
6 Pause 2s 18 Iris Open 3s
7 Tilt Up 3s 19 Pause 2s
8 Pause 1s 20 AUX 1 2s
9 Tilt Down 3s 21 AUX 2 2s
10 Pause 2s 22 AUX 3 2s
11 Focus Near 3s 23 AUX 4 2 s
12 Focus Far 3s 24 Exit
REPLACING THE LID
Once the necessary connections have been made and the receiver has been tested and addressed, refit the lid securely
to prevent unauthorised access. To do this, ti hten the four securin screws with an appropriate tool until they cannot be
undone by hand. Do not exceed a torque of 4 Nm.
CHANGING THE FUSE
The fuse holder (see Fi ure 2) contains a 10A A/S fuse for protectin the relay outputs.
To replace the fuse, switch off all power to the module, turn the top anti-clockwise usin an appropriate tool, chan e the
fuse and replace the top.

Page 19
Installation Manual Pyramid AC Receiver
SPECIFICATIONS
Usage
 Fixed speed pan and tilt control receiver that can be connected to a PTZ camera within the Pyramid system that has an
AC Pan/Tilt head. Once fitted, the unit will drive a PTZ head and up to four auxiliary functions (e. ., wipers, li hts). The
receiver can also be pro rammed remotely with privacy zones, limit stops, random patrols, and 128 presets.
Features
 Fixed speed outputs for 240V AC pan and tilt units
 All connections (except CON6, LIVE and NEUTRAL) via removable screw terminal blocks
 Built in or external anti-tamper switch
 Service pin, barcode and test button included for ease of installation
 Can be installed usin Pyramid Installation Tool
 Pan, tilt, zoom, focus and iris control, 10V DC (max 100mA)
 Up to 128 pro rammable presets
 Random patrol, privacy zones and electronic end stop functions
 Video ain and lift to compensate for lon cable runs
 Four auxiliary functions
Network
 One network port, to which PY-FTT, PY-COM, PY-485, PY-422, PY-FI7 or PY-FI9 network cards can be fitted. Supports
FTT10, RS422, RS485 and Fibre networks
Relays
 Pan/Tilt head relays
 4 auxiliary relays for wash, wipe, lamps and camera power
 Relay outputs Max 240 V at 1A
 Fuse 10A Anti-Sur e
Video
 Via BNC connectors
 Video 1V pk-pk PAL/NTSC
 Max Gain >5dB remotely pro rammable from the keyboard
 Max Lift >4dB at 4MHz remotely pro rammable from the keyboard
Power
 Board Power 12V DC ± 10%, 1A class 2
 Relay Power max 240V AC, 10A
 Nominal Consumption 8.5 Watts (12V DC)
 CON2, +5V max 30mA (feedback pots)
Physical
 Unit available enclosed in a IP65 weatherproof box or as a PCB only
 Wei ht of PCB only variants 0.5 k
 Wei ht of weatherproof box variants 5 k
 PCB size 130 x 160 x 40 mm (excludin mountin pillars)
 Weatherproof box size 280 x 280 x 130 mm
Te perature Specification
 Operational temperature limits of -10ºC to +50ºC at 10% to 80% relative humidity (non-condensin )
 Stora e temperature limits of -20ºC to +60ºC at 10% to 95% relative humidity (non-condensin )

HB-PYAC-2 Issue 2 12/01
Baxall Limited, Stockport, En land. Visit our Web site: http://www.baxall.com
Baxall Limite reserve the right to make changes to the pro uct an
specification of the pro uct without prior notice to the customer.
